Audio Technica ATR4750 User manual

ATR4750
Omnidirectional Condenser
Computer Desk Microphone
Select Audio-Technica ATR series microphones purchased in the U.S.A. from an authorized Audio-
Technica (A.T.U.S.) dealer are warranted for the lifetime of the original purchaser by A.T.U.S. to be free
of defects in materials and workmanship. In event of a defect, End-User’s exclusive remedy is at A.T.U.S.’
election, the cost of repair, refund of the purchase price in the form of credit or cash, or replacement of
the product. A.T.U.S. reserves the right to replace any product with one of equal value. The product must
be delivered to A.T.U.S., prepaid to the address below, together with the sales slip or other proof
of original purchase and $8.00 for handling and return to a U.S. address. Check or money order required;
no cash or stamps.
This warranty excludes defects due to normal wear, abuse, shipping damage, or failure to use product
in accordance with instructions. This warranty is void in the event of unauthorized repair or modification,
or removal or defacing of the product labeling.
A.T.U.S.’ warranty is to the End User only. Except for A.T.U.S.’ said express warranty, A.T.U.S.
MAKES NO WARRANTIES, EXPRESS OR IMPLIED, WITH RESPECT TO THE PRODUCTS.
A.T.U.S. SPECIFICALLY MAKES NO WARRANTY OF MERCHANTABILITY OR FITNESS
FOR A PARTICULAR PURPOSE.
Except to the extent precluded by applicable state law, A.T.U.S. IS NOT LIABLE FOR CONSEQUENTIAL,
INCIDENTAL, DIRECT OR SPECIAL DAMAGES ARISING, DIRECTLY OR INDIRECTLY, IN RESPECT OF
SUCH PRODUCTS OR USE OR FAILURE THEREOF, WHETHER BASED ON BREACH OF WARRANTY,
NEGLIGENCE, STRICT LIABILITY, TORT OR OTHERWISE.
This warranty gives you specific legal rights, and you may have other rights which vary from state to state.
Outside the U.S.A., please contact your local dealer for warranty details.
U.S. ATR SERIES
LIFETIME LIMITED END-USER WARRANTY
ATR4750
Features
• Flexible gooseneck mic plugs into your computer’s
microphone input
• Perfect for podcasting and video conferencing
• Omnidirectional pickup pattern offers full area coverage
User Instructions
Connecting Microphone
• Plug the cable’s mini-plug into your computer’s standard mic
input. (Most computers will supply the required plug-in power
through the mic input.)
Using Desk Stand
• Insert the base of gooseneck (where it joins with the cable)
into the slot on the desk stand. The two flanges on the base
should slide into the notches of the otherwise circular slot.
Using Monitor Mount
• Slide the base of gooseneck (where it joins with the cable)
into the mount. The two flanges on the base should fit into the
notches scored in the mount.
• Remove backing on the mount’s adhesive pad.
• Adhere mount to the computer monitor’s frame or stand (do
not mount on the screen) or to some other suitable surface.
Specifications
Element: Condenser; Polar Pattern: Omnidirectional;
Frequency Response: 50 – 13,000 Hz; Sensitivity: -48 dB;
Power Requirements: 1-10V DC; Cable: 1.8 m (6') terminated
with 3.5 mm (1
/8") stereo mini-plug; Accessories Included:
Desk stand; monitor mount
Specifications and product details are subject to change without notice.
English
Thank you for purchasing this Audio-Technica omnidirectional
condenser computer desk microphone. Please read the
instructions in this manual before using.
Audio-Technica U.S., Inc., 1221 Commerce Drive, Stow, Ohio 44224
www.audio-technica.com P52497

Caractéristiques :
• Microphone à col de cygne flexible, à brancher sur l’entrée micro de votre
ordinateur
• Idéal pour les podcasts et les visioconférences
• Directivité omnidirectionnelle assurant une couverture complète
Instructions d’utilisation
Branchement du microphone :
• Branchez le mini-jack du câble dans l’entrée micro standard de votre
ordinateur (la plupart des ordinateurs fournissent l’alimentation « plug-in
power » requise via l’entrée micro).
Utilisation du pied :
• Insérez la base du col de cygne (au niveau du raccordement avec le
câble) dans la fente du pied du microphone. Les deux brides sur la base
doivent être glissées dans les encoches de la fente circulaire.
Utilisation de la fixation pour moniteur :
• Glissez la base du col de cygne (au niveau du raccordement avec le
câble) dans la fixation. Les deux brides sur la base doivent être glissées
dans les encoches de la fixation.
• Retirez l’arrière du patin adhésif de la fixation.
• Collez la fixation sur le cadre ou le pied du moniteur de l’ordinateur (pas
sur l’écran) ou sur toute autre surface adaptée.
Características:
• Tubo tipo flexo que se conecta a la entrada para micrófono de la
computadora
• Perfecto para podcasting y videoconferencias
• Patrón de captación omnidireccional que ofrece una cobertura de área
completa
Instrucciones de usuario
Conexión del micrófono:
• Enchufe el miniconector del cable en la entrada para micro estándar
de su computadora. (La mayoría de las computadoras proporcionan la
alimentación necesaria a través de la entrada para micro).
Uso del soporte de sobremesa:
• Inserte la base del flexo (donde se une al cable) en la ranura del soporte
de sobremesa. Las dos pestañas de la base deben encajar en las
muescas de la ranura circular.
Uso del soporte para monitor:
• Inserte la base del flexo (donde se une al cable) en el soporte. Las dos
pestañas deben encajar en las muestras marcadas del soporte.
• Retire la cinta adhesiva del soporte.
• Pegue el soporte al marco o al pie del monitor de la computadora (no a la
pantalla) o a otra superficie apropiada.
Caractéristiques :
Élément : condensateur ; Directivité : omnidirectionnelle ; Réponse
en fréquence : 50 à 13 000 Hz ; Sensibilité : -48 dB ; Spécifications
alimentation : 1 à 10 V CC ; Câble : 1,8 m (6 pi) muni d’un mini-jack stéréo
de 3,5 mm (1
/8po) ; Accessoires inclus : pied ; fixation pour moniteur
Les caractéristiques des produits sont susceptibles d’être modifiées sans préavis.
Especificaciones:
Elemento: condensador; Patrón polar: omnidireccional; Respuesta
de frecuencia: 50-13 000 Hz; Sensibilidad: -48 dB; Requisitos de
alimentación: 1-10 V CC; Cable: 1,8 m (6') terminado con miniconector
estéreo de 3,5 mm (1 /8"); Accesorios incluidos: soporte de sobremesa;
soporte para monitor
Las especificaciones y los detalles del producto están sujetos a cambios sin previo aviso.
Français
Merci d’avoir acheté ce microphone à condensateur
omnidirectionnel pour ordinateur de bureau Audio-Technica. Lisez
les instructions du présent manuel avant de l’utiliser.
Español
Gracias por adquirir este micrófono para computadora de sobremesa
de condensador omnidireccional de Audio-Technica. Lea las
instrucciones de este manual antes de utilizar el micrófono.
