Audio Visual Furniture T525EX User manual

Table T525EX
Assembly Instructions
www.video-furn.com 288 Don Hillock Drive |Aurora |Ontario|L4G 0G9 |
1.877.834.3876

Parts
Included
Hardware
Included
Tools Required
Not Included
Furniture
Bolt
x26
M8
Nut
x4
Fender
Washer
x4
Dowel
PIN
x8
CAM
Nut
x8
Zip
Bolt
x2
Mending
Plate
x2
TV32-50
HW Bag
x2
M8x25mm
SHCS Bolt
x6
OR
Basic
Wrench or
Socket set
¼-20
1” Bolt
x8

Step 1
Attach Bases
together.
Furniture Bolt
x4
CAM
x8
Furniture Bolt
x4
Step 2
Attach Fasteners
Step 3
Attach Tabletop Base
PIN
x8
Remove Panel Hex key found in
TV 32-50
HW Bag

Step 4
Attach Table tops.
Furniture Bolt
x14
Step 5
Attach ZIP-bolts+plates
Assembly Instructions
www.video-furn.com 288 Don Hillock Drive |Aurora |Ontario|L4G 0G9 |
1.877.834.3876

Step 6
Attach TV mount
x4
Assembly Instructions
www.video-furn.com 288 Don Hillock Drive |Aurora |Ontario|L4G 0G9 |
1.877.834.3876
TV32-50
HW Bag

Step 7
Run cables/wiring
then
Attach TV Shroud
Assembly Instructions
www.video-furn.com 288 Don Hillock Drive |Aurora |Ontario|L4G 0G9 |
1.877.834.3876
Step 8
Install Island
Step 9
Reinstall Side Panel
Furniture Bolt
x4
Furniture Bolt
x4
Shroud slides onto
TV TUBE
Finished.
