Audio SC-222T User manual

Please follow the instructions in this manual to obtain the optimum results from this unit.
We also recommend that you keep this manual handy for future reference.
AM/FM TUNER
SC-222T
OPERATION MANUAL
PUBLIC ADDRESS SYSTEM
ON
OFF
POWER
TUNING AUTO BAND
SC-222T
AM/FM TUNER

TABLE OF CONTENTS
1. SAFETY PRECAUTIONS .......................................................................................3
2. GENERAL DESCRIPTION ....................................................................................5
3. FEATURES ...............................................................................................................5
4. NOMENCLATURE AND FUNCTIONS
4.1 Front Panel ............................................................................................................6
4.2 Rear Panel.............................................................................................................7
5. TUNER .............................................................................................. 8
6. APPLICATIONS ......................................................................................................9
7. SPECIFICATIONS ................................................................................................10
8. DIMENSIONAL DIAGRAM ..................................................................................11
OPERATION
2

Be sure to read the instructions in this section carefully before use.
Make sure to observe the instructions in this manual as the conventions of safety symbols and messages
regarded as very important precautions are included.
We also recommend you keep this instruction manual handy for future reference.
Safety Symbol and Message Conventions
Safety symbols and messages described below are used in this manual to prevent bodily injury and property
damage which could result from mishandling. Before operating your product, read this manual first and
understand the safety symbols and messages so you are thoroughly aware of the potential safety
Indicates a potentially hazardous situation which, if mishandled, could
result in death or serious personal injury.
Indicates a potentially hazardous situation which, if mishandled, could
result in moderate or minor personal injury, and/or property damage.
When Installing the Unit
Do not expose the unit to rain or an environment
where it may be splashed by water or other liquids,
as doing so may result in fire or electric shock.
Use the unit only with the voltage specified on the
unit. Using a voltage higher than that which is
specified may result in fire or electric shock.
Do not cut, kink, otherwise damage nor modify the
power supply cord. In addition, avoid using the
power cord in close proximity to heaters, and never
place heavy objects -- including the unit itself -- on
the power cord, as doing so may result in fire or
electric shock.
Be sure to replace the unit's terminal cover after
connection completion. Because high voltage is
applied to the speaker terminals, never touch these
terminals to avoid electric shock.
Be sure to ground to the safety ground (earth)
terminal to avoid electric shock. Never ground to a
gas pipe as a catastrophic disaster may result.
Avoid installing or mounting the unit in unstable
locations, such as on a rickety table or a slanted
surface. Doing so may result in the unit falling
down, causing personal injury and/or property
damage.
When the Unit is in Use
Should the following irregularity be found during
use, immediately switch off the power, disconnect
the power supply plug from the AC outlet and
contact your nearest dealer. Make no further
attempt to operate the unit in this condition as this
may cause fire or electric shock.
If you detect smoke or a strange smell coming
from the unit.
If water or any metallic object gets into the unit
If the unit falls, or the unit case breaks
If the power supply cord is damaged (exposure of
the core, disconnection, etc.)
If it is malfunctioning (no tone sounds.)
To prevent a fire or electric shock, never open nor
remove the unit case as there are high voltage
components inside the unit. Refer all servicing to
your nearest dealer.
AUDIO
AUDIO
Do not place cups, bowls, or other containers of
liquid or metallic objects on top of the unit. If they
accidentally spill into the unit, this may cause a fire
or electric shock.
Do not insert nor drop metallic objects or
flammable materials in the ventilation slots of the
unit's cover, as this may result in fire or electric
shock.
1. SAFETY PRECAUTIONS
3

An all-pole mains switch with a contact separation of at least 3 mm in each pole shall be incorporated in
the electrical installation of the building.
When Installing the Unit
Never plug in nor remove the power supply plug
with wet hands, as doing so may cause electric
shock.
When unplugging the power supply cord, be sure
to grasp the power supply plug; never pull on the
cord itself. Operating the unit with a damaged
power supply cord may cause a fire or electric
shock.
When moving the unit, be sure to remove its power
supply cord from the wall outlet. Moving the unit
with the power cord connected to the outlet may
cause damage to the power cord, resulting in fire or
electric shock. When removing the power cord, be
sure to hold its plug to pull.
Do not block the ventilation slots in the unit's cover.
Doing so may cause heat to build up inside the unit
and result in fire.
Avoid installing the unit in humid or dusty locations,
in locations exposed to the direct sunlight, near the
heaters, or in locations generating sooty smoke or
steam as doing otherwise may result in fire or
electric shock.
When the Unit is in Use
Do not place heavy objects on the unit as this may
cause it to fall or break which may result in
personal injury and/or property damage. In
addition, the object itself may fall off and cause
injury and/or damage.
Make sure that the volume control is set to
minimum position before power is switched on.
Loud noise produced at high volume when power is
switched on can impair hearing.
Do not operate the unit for an extended period of
time with the sound distorting. This is an indication
of a malfunction, which in turn can cause heat to
generate and result in a fire.
Contact your dealer as to the cleaning. If
dust is allowed to accumulate in the unit over a
long period of time, a fire or damage to the unit
may result.
AUDIO
If dust accumulates on the power supply plug or in
the wall AC outlet, a fire may result. Clean it
periodically. In addition, insert the plug in the wall
outlet securely.
Switch off the power, and unplug the power supply
plug from the AC outlet for safety purposes when
cleaning or leaving the unit unused for 10 days or
more. Doing otherwise may cause a fire or electric
shock.
SAFETY PRECAUTIONS
4

3. FEATURES
The SC-222T is a public address amplifier switch with can provide an ideal public address solution from
small to big places such us mosques, schools, hotels and factories to train stadium and air stations.
2. GENERAL DESCRIPTION
1.Stores up to 100 stations.
2.Remote control included.
3.Automatic tune and memory functions.
5

4. NOMENCLATURE AND FUNCTIONS
4.1 FRONT PANEL
1. TUNER SCREEN
Display the working state of TUNER
2. UP
UP search channel (Tuner)
3. DOWN
Down search channel (Tuner)
4. AUTO
Auto band search button (Tuner)
5. BAND
AM/FM Band select button (Tuner)
6. POWER SWITCH
On top of the opening Power
Press the end, power shut down
7. POWER
Power indicator
6
2345
167
ON
OFF
POWER
TUNING AUTO BAND
SC-222T
AM/FM TUNER

NOMENCLATURE AND FUNCTIONS
4.2 REAR PANEL
910 11
8
8.~220V 50Hz AC POWER INPUT
9. FM BAND 75 OHM ANTENNA
10.AM-BAND ANTENNA
11.
AUDIO OUTPUT
7
~220V 50Hz
20W
T1AL 250V
AUDIO
OUTPUT
RR
LL
LOOP ANTENNA
Fm75
ANTENNA
AMGND

5. TUNER OPERATION
FM 104.70
AM
FM
STEREO MUTE AM/FM MEMORY AUTO
MHz
KHZ 02 mSEC
MIN
cHdB
CINEMA DSP
FM 104.70
AM
FM
STEREO MUTE AM/FM MEMORY AUTO
MHz
KHZ 02 mSEC
MIN
cHdB
CINEMA DSP
FM 104.70
AM
FM
STEREO MUTE AM/FM MEMORY AUTO
MHz
KHZ 02 mSEC
MIN
cHdB
CINEMA DSP
FLUORESCENCE DISPLAY
TUNER OPERATING
1. Open power supply switch on, fluorescence
show last time close employment state.
Stereo show Auto tune show
Wave band show
Frequency show
Frequency unit show
Wave band show Frequency show
2. Select broadcast wave band
As if show an't want to wave band, invite
press Wave band key stoke accept of wave
band, per Press once, give switch fm/am.
3. Select broadcasting station means
Auto tune show occasionally auto illumine
Per press once auto /
Manual tune select key
(auto/ma)give switch
4. Select broadcast broadcasting station
Press key up direction high end frequ-
ency search, press key down direction
low end frequency search.
Auto tune occasionally: Auto take over one
Broadcasting station
Manual tune occasionally: Repeat press(or
Persist press)up to select broadcasting station
FM 104.70
AM
FM
STEREO MUTE AM/FM MEMORY AUTO
MHz
KHZ 02 mSEC
MIN
cHdB
CINEMA DSP
Auto tune show occasionally auto illumine
8

6. APPLICATIONS
REAR PANEL CONNECTIONS
MIXER AMPLIFIER
AUX2 OUT
AUX1
MIC2 MIC3
MUTE EMC INPUT
MIC2 MIC3
LINE INPUT
OUTPUT
COM 4-16 70V 100V
AM ANTENNA
FM ANTENNA
9
~220V 50Hz
20W
T1AL 250V
AUDIO
OUTPUT
RR
LL
LOOP ANTENNA
Fm75
ANTENNA
AMGND

7.SPECIFICATIONS
MODEL
AM/FM TUNERAM/FM TUNER
SC-222T
TUNERTUNER
87-108MHz 522-1611kHz
=20uV =6.0mV/m
=40dB =36dB
FREQUENCY RESPONSE
SENSITIVITY
SIGNAL / NOISE RATIO
FM
FM
FM
AM
AM
AM
DIMENSION(mm)
NET WEIGHT
GROSS WEIGHT
484X209X44
POWER CONSUMPTION
POWER REQUIREMENTS
~220V 50Hz
5Kg
3.8Kg
8W
10

100
Over
100
Over
Over
100
8. DIMENSIONAL DIAGRAM
UNIT :mm
6
44
41
209
44
50
436
484
UNIT :mm
11
ON
OFF
POWER
TUNING AUTO BAND
SC-222T
AM/FM TUNER
~220V 50Hz
20W
T1AL 250V
AUDIO
OUTPUT
RR
LL
LOOP ANTENNA
Fm75
ANTENNA
AMGND
ON
OFF
POWER
TUNING AUTO BAND
SC-222T
AM/FM TUNER

PUBLIC ADDRESS SYSTEM
VersionV0.1
