Audiovox Rampage ACC-52 Programming manual

MODEL ACC-52
REMOTE-CONTROL
10-DISC CD CHANGER
OWNER'S MANUAL
AND
INSTALLATION GUIDE
OPEN

INTRODUCTION
Congratulations on your purchase of this remote mount 10 Disc CD Changer. It allows you to easily upgrade
yourexistingcarstereosystemtothequalityofCompactDiscentertainment. Theentiresystemplaysthrough
your FM Stereo car radio and stereo speaker system - there’s nothing else to add or replace. Best of all, the
CDChangeriseasytoinstall. Thereareonlythreewirestoconnectandfour simple plug-in cables.Justfollow
the simple step-by-step instructions that follow.
FEATURES
nRemote mount changer holds up to 10 compact discs
nRemote control with back-lit LCD panel, displays disc, track and function
nRemote controls include forward and reverse track and disc search, track and disc scan, shuffle and
repeat play plus high speed audible cue and review search
nAdvanced technology includes 8x oversampling digital filter and twin 1-bit digital/analog converters
nThe special design allows horizontal, vertical or 45-degree mounting.
TOLL-FREE ASSISTANCE
The installation and connections are so simple we doubt you’ll need our help, but if you do, we’re here to help
you. Just call our toll-free assistance line at 1-800-645-4994 during the days/hours shown.
EASTERN
8:30AM - 7PM
9AM - 5PM
7:30AM - 6PM
8AM - 4PM
CENTRAL
6:30AM - 5PM
7AM - 3PM
MOUNTAIN
PACIFIC
5:30AM - 4PM
6AM - 2PM
MON. - FRI.
SATURDAY
DAY TIME ZONE
2
INDEX
Introduction and Contents Page 2 Mounting the Remote Control Page 12
Packing List Page 3 Remote Control Operating Instructions Page 13
Before Installing the Unit Page 4 Hints for Correct and Safe Operation Page 15
Where to Install the Changer Page 5 Handling the Discs Page 15
Installation Page 6 Use of the CD Magazine Page 16
Overall Wiring View Page 9 CD Changer Operating Instructions Page 17
Wiring the CD Changer Page 10 Specifications Page 17
Troubleshooting Page 18

CD Magazine (P/N ACC-52MAZ)
1 pc.
Index label sheet
1 pc.
Owner's Manual
and Installation Guide
1 pc.
Self-tapping screw
(M5 x 12)
4 pcs.
Seals (A)
1 pc.
5 Meter Din Cable
1 pc.
Hexagonal bolt with washer
(M5 x 10)
7 pcs.
INSTALLATION PARTS
OTHER ACCESSORIES
MAIN UNIT
PACKING LIST
Changer
Bracket (L)
1 pc.
Bracket (R)
1 pc.
Seals (B)
1 pc.
3
FM Module
Remote Control
Screw (C)
Phillips Head Self-Tapping
Screw
(M3x12)
2 pcs.
OPEN

Note
Ifthechangeristobeinstalledinacarthatisequippedwithanon-boarddriveornavigationcomputer,donotdisconnect
the battery cable. If the cable is disconnected, the computer memory may be lost. Under these conditions, use extra
caution during installation not to cause a short circuit.
Do not install the unit in the following locations.
lLocations exposed to direct sunlight.
lWhere hot air is discharged from the car heater.
lIn areas subject to extreme temperatures.
Incorrect installation can cause the sound to "skip" when playing a disc.
Mount the unit firmly in place, using the supplied brackets and screws.
Be careful not to damage the car wiring.
lBe sure to use the supplied screws.
lBe careful not to snag any wires when tightening screws.
lDo not use any of the screws that are part of the brake or steering system, to install the unit.
lThisunitcannotbeinstalledonitsside,end,orupsidedown. Installationinsuchpositionswillcausemalfunctioning
of the mechanism.
Installation and Wiring Precautions
4
To prevent a short-circuit,
lBe sure to turn off the ignition and remove the negative (-) battery cable, prior to installation.
lConnect power wires last.
1
BEFORE INSTALLING THE UNIT
Transport Lock Screws
The mechanism in the CD changer is "locked" into place during shipment by the
transport screws. Be sure to remove the screws prior to installation.
lCaution l
After removing the transport lock screws, place the supplied seals (A) over the screw
holes. These seals are used to keep dust out of the unit, which could cause a malfunction.
6
5
4
3
2
TRANSPORT LOCK SCREWS
(2 RIGHT SIDE, 1 LEFT SIDE)
ADDITIONAL 10-DISC MAGAZINES
Additional CD magazines are available as an accessory item (Part No. ACC-52MAZ) from the store where your ACC-52
was purchased. If they are out of stock, you can order them direct from Audiovox. Send a check or money order (do not
send cash) made payable to Audiovox Corp in the amount of $49.95 (U.S. Currency) to:
Audiovox Corp.
150 Marcus Blvd.
Hauppauge, N.Y. 11788
Attn: Parts Department
NOTE: New York residents, please include applicable sales tax.
H
V
45

5
MOUNT ON FLOOR OF TRUNK
(HORIZONTAL OR 45 DEGREES)
MOUNT ON
SIDEWALL OF
CARGOAREA
MOUNT ON BULKHEAD BEHIND
SEAT OF PICKUP TRUCKS
MOUNT ON BACKWALL
OF HATCH AREA
MOUNT ON SIDE OF
TRUNK SIDEWALL
TRUNK MOUNTING (SEDANS)
This is usually the easiest location to use as there is ample
space available. Check that you do not interfere with the
removal of your spare tire, etc. Observe caution on fuel tank
statedabove.Theonlynegativeaspectistheneedtoroutethe
wiring from the trunk to your car dashboard.
HATCHBACKS, WAGONS & VANS
A simple investigation of the areas shown will often provide
several possibilities. Observe caution on fuel tank stated
above and make sure the unit is protected from cargo,
passenger entry and exit, etc.
UNDER PASSENGER’S FRONT
SEAT/BEHIND SEAT
If sufficient space and easy access exist, the area under the
passenger's front seat is ideal, and will also allow easy wiring
access. However, you may need to temporarily remove the
seat for ease of installation. The area behind either the
passenger’s or driver’s seat on pickup trucks is another ideal
location.
MOUNT UNDER LIP OF TRUNK
MOUNT UNDER
SEAT
The ACC-52changer is designedfor horizontal(flat),vertical(upright)or 45-degreemounting.Itmustneverbemounted
upside-downoroneitheroneofit'ssidesasexplainedpreviously. Afewofthemanymountingpossibilities are shownbelow.
The following precautions must be considered when selecting the mounting location:
1. FuelTank-Neverinstallaboveyourfueltankastheholesyoumustdrillmaypiercethetankorthefuellines. Alsocheck
for other obstructions such as wires, etc.
2. ExcessiveHeat-Avoidareasexposedtodirectsunlight(ontopofrearpackageshelf)ornexttoyourcarheater’soutput
ducts.
3. Ease of Use - Make certain the changer is easily accessible for loading and unloading the CD magazine.
4. Distance - The data cable that joins the changer to the FM module is 15 feet long. Do not exceed this length.
5. If mounting to a plastic surface, do not use the self-tapping screws provided. Use the bolts and hex nuts provided for
a more secure installation.
IMPORTANT: Failure to properly secure the CD changer is the most common cause of all “skipping” and related
CD play problems. Changer must be mounted as explained on the following pages.
WHERE TO INSTALL THE CHANGER

PROCEDURE FOR HORIZONTAL INSTALLATION
INSTALLATION
Theunitcanbeinstalledhorizontally,verticallyorata45°angle. Thepositionofthebuilt-inanti-vibrationsprings(leftandright
side), must correspond to the mounting position chosen. If the springs are not set correctly for the type of installation chosen,
the anti-vibration compensation will not be effective and vibration may cause the disc to skip.
CAUTION: Aftersettingthebuilt-in anti-vibration springs, place the supplied Seals (B) over the holes. These seals are used
to keep dust, which could cause a malfunction, out of the unit.
position "H"
position "V"
HORIZONTAL INSTALLATION
Set the left and right anti-vibration
springs to position "H".
VERTICAL INSTALLAITON
Set the left and right anti-vibration
springs to position "V".
45° ANGLE INSTALLATION
Set the left and right anti-vibration
springs to position "45°".
H
V
45
H
V
45
Drill holes 4mm in diameter.
1
2
3
Attachbracket(L)andbracket(R)toeachsideoftheunit,
using the hexagonal bolts with washer base (M5 x 10)
Determinethe mounting location, and drill four mount-
ing holes.
Securetheunitinplace,usingfourself-tappingscrews
(M5 x 12).
Use RTV (silicone sealer) on screw threads or around
the holes to prevent moisture intrusion.
Never mount the unit near the fuel tank.
Bracket (R)
Bracket (L)
Hexagonal bolt (4)
with washer base (M5 x 10)
Anti-vibration
springs position
NOTE: Use seals (A) to cover unused
mountingholesonsidesof unit.
H
V
45
V45
H
position "45°"
45°
H
V
45
6
Bracket (R)
Self-tapping screw (M5 x 12)
Bracket (L)

Hexagonal bolt
with washer base (M5 x 10)
Bracket (R)
Bracket (L)
4
2Attachbracket(L)andbracket(R)toeachsideofthe
unit, using the hexagonal bolts with washer base
(M5 x 10).
Mount the unit in place, using four self-tapping screws
(M5 x 12).
Use RTV (silicone sealer) on screw threads or around
the holes to prevent moisture intrusion.
Set the left and right anti-vibration springs to position
"V".
Determinethemountinglocation,anddrillfourmount-
ing holes.
3
7
PROCEDURE FOR VERTICAL INSTALLATION
NOTE: If the anti-vibration spring position has been changed and verified for vertical mounting
(as shown on page 3), start with step 2.
1
Never mount the unit near the fuel tank.
Drill holes 4 mm in diameter.
position "V"
Self-tapping screw
(M5 x 12)
Bracket (R)
Bracket (L)
NOTE:Useseals(A)tocoverunused
mountingholesonsidesofunit.
H
V
45

4
2Attachbracket(L)andbracket(R)toeachsideofthe
unit, using the hexagonal bolts with washer base
(M5 x 10).
Mount the unit in place, using four self-tapping screws
(M5 x 12).
Use RTV (silicone sealer) on screw threads or around
the holes to prevent moisture intrusion.
Set the left and right anti-vibration springs to position
"45°".
Determinethemountinglocation,anddrillfourmount-
ing holes.
PROCEDURE FOR 45° ANGLE INSTALLATION
NOTE: If the anti-vibration spring position has been changed and verified for 45° angle
1
Never mount the unit near the fuel tank.
8
Bracket (L)
Bracket (R)
Hexagonal bolt
withwasherbase(M5 x10)
Drill holes 4mm in diameter. Bracket (R)
Self-tapping screw (M5 x 12)
NOTE:Useseals(A)tocoverunused
mountingholesonsidesofunit.
Bracket (L)
position "45°"
45°
H
V
45
3

9
NOTE: When routing wires and cables
from the rear of the car to the dash-
board, it is best to conceal the wires
under carpeting. If you do not know
how to do this, your local auto me-
chanicorcarstereoinstallershouldbe
consulted.
REMOTE CONTROL
CABLE (4-1/2 FEET)
CHANGER
BLACK GROUND WIRE
OVERALL WIRING VIEW
This page is provided to give you a quick look at the entire wiring of the ACC-52. Use it to plan your wire routing
paths and possible connection points. Detailed wiring is explained in the following pages.
DATACABLE
(15 FEET)
ORANGE/WHITE
WIRE CONNECT TO THE CAR'S
FUSEBLOCK AT THE
"RADIO" OR "ACCESSORY"
IDENTIFIED TERMINALS
GREEN/WHITE POWER WIRE
ANTENNA INPUT
ANTENNA OUTPUT
EXISTING CAR RADIO
ANTENNA SOCKET
EXISTING CAR
STEREO
EXISTING CAR
RADIOANTENNA
CABLE
CONNECT TO
SOURCE OF CON-
STANT +12 VOLTS
REMOTE CONTROL
FM MODULE

10
WIRING THE FM MODULE
The FM module should be positioned near your existing car
stereo and the 15 foot data cable should be connected to it.
Make the following connections to the FM module:
15 FOOT DATA CABLE
"TO CD CHANGER"
LABEL
CAR FUSEBLOCK
ORANGE w/WHITE
STRIPE WIRE
15 FOOT EXTENSION LEAD
(MAY NOT BE REQUIRED)
SPLICE INTO "LIVE" WIRE
AND TAPE SPLICE
EXISTING +12 VOLT
"LIVE" WIRE
"RADIO" OR "ACCESSORY"
TERMINAL
FM MODULE
12 VOLT
CARBATTERY
DATA CABLE
The15footdatacableconnectsthechangertotheFMmodule.
First connect the end of the data cable labelled "TO CD
CHANGER"tothesocketontheleftsideofthechanger.Route
theother endof the cableup tothecar’s dashboardarea near
yourexistingcarradioandplugthedatacable into the mating
socket on the end of the FM module.
WIRING THE CD CHANGER
ORANGE WITH WHITE STRIPE WIRE
Attached to the FM module is a 3 foot orange with white
stripe wire. This is to be connected to a + 12 volt circuit that
is only live when the ignition is on. The best connection
point is at the car’s fuse block at the “RADIO” or “ACCES-
SORY” identified terminals.
GREEN WITH WHITE STRIPE
POWER WIRE
The 3 foot green with white stripe wire must be connected
toa “live” 12 volt wire in the vehicle. You will have to check
the wire you connect it to and make certain it is always “live”’
even when the car’s ignition is turned off. If none is found,
route the wire to the car’s fuseblock and connect it to a “live”
circuit there.
FM MODULE
FM MODULE
GREEN w/WHITE
STRIPE WIRE

CAR ANTENNA INPUT
Locate your existing car radio antenna cable. This is
normally a black cable about as thick as a pencil and
will be plugged into a socket on the rear of your car
radio. Unplug this antenna lead and plug it into the
mating female socket on the FM module.
IMPORTANT -Some Import cars have a special dual
antenna called “DIVERSITY ANTENNA”. If your car
has this type of antenna system, you will find the
antennacablewillnotfitthesocketontheFMmodule.
Use of the ACC-52 with “DIVERSITY ANTENNA" is
notrecommended.Youmayalsofindsomelate model
GM carshaveanantennaplugthatistoosmalltomate
with the FM module. If this is found, call Audiovox’s
Toll-FreeAssistanceforaspecialadaptor.Thisadap-
torcanalsobepurchasedatanycarstereoinstallation
center.
RADIO ANTENNA OUTPUT
Attached to the FM module is a male antenna plug.
Simply plug this into the socket on the car radio from
which you just removed the car antenna cable.
REMOTE CONTROL CABLE
Attached to your remote control is a cable that plugs
intotheremainingsocketontheendoftheFMmodule.
Position the remote control near the area you will
permanently mount it and route the cable to the FM
module. Plug the cable into the FM module.
WIRING THE FM MODULE (con't.)
BLACK GROUND WIRE
The 3 foot black wire attached to the FM module
must be secured to a grounded metal part of the
car’s chassis. If you cannot find an existing bolt or
screwtofastenitto,youmustdrillaholeinthemetal
andsecureitwithascrew.Toinsureagoodground,
remove any paint or grease where the wire will
connect. BLACK GROUND WIRE
EXISTING
SCREW
OR BOLT
GROUNDED METAL PART
OF CHASSIS
FM MODULE
FM MODULE
CARRADIO
FEMALE CONNECTOR
FM MODULE
EXISTING CAR ANTENNA
EXISTING CAR RADIO
(UNPLUGANTENNA CABLE)
REMOTE CONTROL
CARANTENNA CABLE
REMOTE CONTROL CABLE
MALE ANTENNA PLUG
FM MODULE
MALE ANTENNA PLUG
11

12
MOUNTING THE REMOTE
CONTROL
On the back of the remote control you will find an adhesive
backed “Velcro” pad. Select the desired mounting area on
your car dashboard that will allow ease of use and full
visibilityoftheLCDdisplay. Peelofftheprotectivepaperon
theadhesivepad. Makecertainthedashareaiscleanofall
wax, grease, etc., and press the remote control in place.
Allowa1/2hourfortheadhesivetosecure,thenyouwillfind
theVelcro pads will allow youto remove the remote control
for hand-held use if desired and replace it as often as
needed.
MOUNTING THE FM MODULE
There are two mounting tabs on the FM module. It can be
secured by two methods. Use two screws “C” and drill
two 3/32" holes or use electricians tape or twist ties (not
provided).
ADJUSTMENT OF FM MODULE TUN-
ING
Tooperate your ACC-52, your car radio must be first tuned
to the FM band at 89.1MHz. If you find interference on this
frequency, you can change the output frequency from the
FMmoduleto88.7MHz., bymovingtheslideswitchonthe
FMmoduleto the88.7MHz. position. Youwillthen haveto
tune your radio to 88.7 MHz. instead of 89.1 MHz. when
using your CD changer.
CHANGER RESET BUTTON
IMPORTANT: After all wiring of the ACC-52 is
completed, press the “RESET” button on the
changer BEFORE inserting the CD magazine. If
wired correctly, the changer will mechanically
cycle within 5 seconds of pressing the button.
If you do not hear the unit cycle, re-check all
wiring until the reset function operates as
described. DO NOT attempt to insert the CD
magazine until correct reset function is
obtained. (See page 13 for further information).
CLEAN MOUNTING AREA
REMOTE
CONTROL
REMOVE PAPER LINER AND
PRESS IN PLACE DRILL TWO
3/32" DIA. HOLES
FM CONVERTER
DOOR OPENED
CAUTION LABEL
CD CHANGER
SCREW
"C"
(2 PCS.)
SLIDE
SWITCH
FM
MODULE
RESET BUTTON
RESET BUTTON
TOOL
MOUNTING
SURFACE
CAR DASHBOARD

CONTROLS
LCD Display
Play/Pause ( / II)
Power Off Switch (OFF)
Disc Select ( + - )
Track Select ( )
Track Search ( )
Track/Disc Shuffle (SHFL)
Track/Disc Repeat (RPT)
Track/Disc Scan (SCN)
Reset Button
PREPARING FOR OPERATION
1. Load CD magazine bm and insert into changer as
described on page 16.
2. Turnon yourcar ignitionandyourcar stereobn and
select “FM” band bo.
3. Tuneto 89.1 on the FM band bp unless you set the
selection switchonthe FMmodule to88.7; then
tune to 88.7 on the FM band.
Note: You may find that it will be easier to use
one of your presets specifically for CD
operation.
4. Depress the “RESET” button bq on the remote
control.
Note: This is only required the First Time you use
the Changer.
5. Turn on the CD player by pressing the Play/Pause
button br. The CD panel bs will illuminate and disc
number 1 will begin play.
6. Adjust your car radio’s volume, balance and tone
controls for desired sound.
7. When the last track on disc 1 has played, the unit
will automatically advance to the next disc in
sequence and begin playing. This will continue
until all discs have been played at which time the
unit will begin playing disc number 1 again.
13
OPERATING INSTRUCTIONS
UponinsertingaloadedCDmagazineintothechanger,theunit willbeginautomaticallycheckingthemagazineforthenumber
ofdiscsloadedandtheirlocations.Thiswilloccurevenifthevehicle’signitionisturnedoff.Thisprocesswilltakeapproximately
45 seconds. During this time, the remote control function will be inoperative.
10
2
1
3
5
4
6
7
8
9
DISC SELECT
POWER
INTRO SCAN
SHUFFLE
9
10
7
1
4
2
8
3
5 6
INTRO SCAN
SHUFFLE
SHFL
REPEAT
OFF
12
13 14
11
16
15
FM 89.1
17

USE OF CONTROLS pressing the Shuffle again, or by activating the Scan 9 or
Repeat 8 functions.
When the Shuffle button is pressed and held longer than 2
seconds,theSHFL and DISC indications will appear onthe
LCD panel and the discs in the magazine will be played in a
random shuffled order, as well as the tracks on each disc.
When all the tracks on the selected disc have been played,
the next disc will be selected in shuffled order and its tracks
will be played in shuffled order. The Disc Shuffle mode can
be cancelled by pressing the Shuffle button again, or by
activating the Scan 9 or Repeat 8 functions.
8TRACK / DISC REPEAT (RPT)
Whenthe Repeat button is pressed, the indication RPT will
appear on the LCD panel and play of the selected track will
becontinuouslyrepeateduntiltheRepeatmodeiscancelled
bypressingtheRepeatbuttonagainorbyactivatingtheScan
9 or Shuffle 7 functions.
When the Repeat button is pressed and held longer than 2
seconds, the RPT and DISC indications will appear on the
LCD panel and play of the selected disc will be continually
repeateduntiltheDiscRepeatmodeiscancelledbypressing
theRepeatbuttonagainorbyactivatingtheScan 9orShuffle
7 functions.
9TRACK / DISC SCAN (SCN)
When the Scan button is pressed, the indication "SCN" will
appear on the LCD panel and the first 10 seconds of each
trackonthediscwillbeplayedinorder. Whenadesiredtrack
isreached,presstheScanbuttonagainandplayofthattrack
will continue (SCN will disappear from the display). Scan
mode will be cancelled by activating any other function
(Repeat,Shuffle,DiscSelect,TrackSelect,orTrackSearch).
Whenthe Scan button is pressed and held for longer than 2
seconds, the SCN and DISC indications will appear on the
LCD panel and the first 10 seconds of the first track of each
disc in the magazine will be played. When a desired disc is
reached, press the Scan button again and play of that disc
will continue (SCAN and DISC will disappear from the
display). DiscScanmodewillalsobecancelledbyactivating
any other function (Repeat, Shuffle, Disc Select, Track
Select, or Track Search).
bl RESET BUTTON
A reset button is located on the front panel of the remote
controlwhichmustbeactivatedwithapenorotherthinobject
as it is recessed to prevent accidental engagement. The
resetcircuitryisprovidedtoprotecttheunit'smicroprocessor
andlaserpick-upsystemandshouldonlybeactivatedunder
the following circumstances:
1. Initialinstallationafterallwiringiscompleted(thismustbe
done).
2. Ifabnormaldiscoperationisencountered,theresetbutton
maybe pressedto clearthe systemandreturn tonormal
operation.
IMPORTANT: Use of the Reset button on the CD Changer
will cause the CD magazine to be automatically ejected.
Make certain changer door is fully opened prior to using
Reset.
14
1 LCD DISPLAY
TheLCD Display Panel will illuminate when the CD changer is
operating. Different symbols will appear depending on the
function andoperation in use. Eachdisplay is explained inthe
applicable function explanation below.
2 PLAY / PAUSE ( / )
Pressing this button turns on the CD changer, illuminates the
LCD panel and begins play of disc #1 if a new CD magazine
has been loaded into the changer. If a magazine was already
in the changer, play will resume from the track on the disc
previously in play. Play of the disc is shown by the indication
and the rotating disc symbol on the LCD panel. Pressing
thebuttonagainwilltemporarilystopplayofthedisc. Thepause
indication willappearontheLCDpanelandthedisc symbol
will stop rotating and flash instead. Press the button again to
resume play of the disc.
NOTE: If left in the PAUSE mode for 5 minutes, the unit will
automatically shut off.
3 POWER OFF SWITCH (OFF)
PressthisswitchtoturntheCDchangeroffandreturntonormal
FM reception.
4DISC SELECT ( - +)
Press the disc select button to select the desired disc for play
asshownontheLCDpanel. Theunit willautomaticallyloadthe
selected disc and begin play. To advance to a higher number
disc,pressthe +sideofthebutton. Toreturntoalowernumber,
press the - side.
5TRACK SELECT ( )
The Track Select function is used to quickly access the begin-
ning of a particular track. Press Forward Track Select ( )
or BackwardTrack Select ( )to locate the desiredtrackas
shown by the track number indication on the LCD panel.
6TRACK SEARCH ( )
High-speed audible search to any section of the disc can be
madeby the searchfunctions. Press and holdthe button
toadvancequicklyintheforwarddirectionor pressandholdthe
buttontoadvancerapidly inthebackward direction. Dur-
ingsearchoperation,therotationdiscsymbolwillturnfasterand
theappropriatesymbol or willflashontheLCDpanel.
When the forward search button is held down and end of
the last track is reached, or the backward search is held
downandtheunitreachesthebeginningofthefirsttrackonthe
disc, the unit will enter the Pause mode until the button is
released.
7 TRACK / DISC SHUFFLE (SHFL)
When the Shuffle button is pressed, the indication SHFL will
appear on the LCD panel and the tracks on the disc will be
played in a random, shuffled order. The Track Skip 5 function
willalsoselecttracksintheshuffledorderinsteadofthenormal
progression. The Track Shuffle mode can be cancelled by

ThisCDChanger isdesigned tobe operatedonly on12 voltDCnegative groundsystems. The unitcan notbe usedon 24volt
or positive ground systems.
TEMPERATURE
Theunitmaynotoperatecorrectlyinextremelyhotorcoldtemperatures. Itisequippedwithabuilt-inthermalprotectioncircuit
which will stop operation of the unit when the temperature reaches the pre-set level. If this should happen, the unit will
resume operation when the vehicle returns to a normal temperature range.
Remove the magazine from the unit when it is not being used during hot weather. If the discs are left in an extremely hot car
they may warp. If the CD changer is not used for long periods of time, remove the compact discs from the magazine, and
store them in their cases.
CONDENSATION
Moisture can condense on the laser lens of the CD changer during rainy and humid days, or right after the heater is turned on
in the car (if the changer is mounted in the passenger compartment). If this should happen the unit will not operate correctly.
To remedy the situation, remove the discs from the unit and wait approximately one hour. During this time the moisture will
evaporate and the unit will operate normally.
INTERRUPTIONS IN SOUND (Skipping)
Thesoundfromtheunitmay"skip"andbeinterruptediftheanti-vibrationspringsarenotsetcorrectly,ifthechangerismounted
on-end or upside-down, or when travelling on very rough road surfaces. If this should occur, check for errors made during
installation or wait for the road surface to improve.
3" (8cm) CD-SINGLES
Thisunitis notdesignedto play3"(8cm) CD-Singlediscs. Insertinga 3"discinto themagazine,eitherwithor withouta3"disc
adaptor, can damage the changer and the disc. Such damage will not be covered by the Warranty on this product.
HANDLING THE DISCS
Dirt,dust,scratchesandwarpagecausesoundskipsduringplaybackandadeteriorationofsoundquality. Totakepropercare
of your discs:
1. Use compact discs that have the logo.
2. Fingerprints and dust should be carefully wiped off the disc's signal surface (glossy side) with a soft cloth. Unlike
conventional records, the compact disc has no grooves to collect dust and microscopic debris, so gently wiping with
a soft cloth should remove most particles. Wipe in a straight motion from the inside to the outside of the disc. Small
dust particles or light stains will have absolutely no effect on reproduction quality.
3. Neverusesuch chemicals as record sprays, antistatic sprays or fluids,benzine or thinner to clean compact discs. Such
chemicals could irreparably damage the disc's plastic surface.
4. Discs should be put back in their cases after use to avoid serious scratches that could cause the sound to skip.
5. Donotexpose discs to direct sunlight, high humidity, or high temperaturesforextended periods of time. Long exposure
to high temperatures can warp the disc.
6. Do not stick paper, labels, or tape on the disc surface.
7. Do not write with any type of pen, pencil, or marker on the disc surface.
8. Tominimizefingerprintsandsmudgesonthesignalsurface,alwaystrytoholdthediscsbytheirouteredgeandcenterhole.
HINTS FOR CORRECT AND SAFE OPERATION
15
CAUTION: When the CD magazine is ejected by the use of the Reset button, whichever disc was in play prior to depressing
Resetwillbeleftintheplaypositioninthechanger. Itiscriticalthatbeforere-insertingtheCDmagazine,youmust
REMOVEALLDISCSfrom it. Afteryouhave insertedtheempty CDmagazine,depress "EJECT"onthechanger
andthe"in play"discwill beloaded intotheempty magazine. Youmaythen removethe magazineandre-load as
many discs as desired.
WARNING: Avoid use of Reset buttons after initial use unless you have a definite abnormal disc operation. Use the EJECT
button on the changer to remove the CD magazine for normal operation.

LOADING DISCS INTO THE MAGAZINE
ThisCDChangerusesaspecially-designedmagazinetohold
upto 10 compact discs. To load discs into the magazine, grip
the tab on the magazine tray into which you will be loading a
discandpullitoutgentlyasshowninFigure1. Pulloutonlyone
tray at a time. Insert a disc into the tray with the label side up
(playsurfacefacingdown)asshowninFigure2. Pushthetray
back into the magazine as shown in Figure 3. Load discs into
the remaining 9 trays in a similar manner.
REMOVING DISCS FROM THE MAGAZINE
Toremoveadiscfromthemagazine,pulloutthetrayofthedisc
toberemoved, liftout thedisc,andpushthe trayback intothe
magazine.
USE OF THE CD MAGAZINE
NOTES:
Fig. 3
Fig. 2
Fig. 1
Label side up
Avoid touching the playing side of the disc.
Only one disc can be inserted into each tray of the maga-
zine. Do not try to insert more than one disc into each tray
as damage to the discs and magazine may occur.
This changer is not designed to play 3" CD-Single discs
(8cm). Inserting a 3" disc into the magazine, either with
orwithout a 3" discadaptor,candamagethechangerand
thedisc.Suchdamage willnotbecovered bytheWarranty
on this product.
Additional CD magazines are available as accessory item
part number ACC-52MAZ from your Audiovox dealer, or
you may contact us directly at:
l
l
l
l
LOADING THE MAGAZINE INTO THE CHANGER
Completely slide the door on the changer to the right as shown in
Figure 4. Making sure the top of the magazine is facing upward,
gentlyinsertitintotheunituntilitclicksintoplace,asshowninFigure
5. Slidethedoorofthechangerfullyclosedandtheunitisreadyfor
operation.
REMOVING THE MAGAZINE FROM THE CHANGER
The magazine can be removed from the changer using one of two
methods as outlined below in steps 1 and 2.
NOTE: Besuretokeepthedooronthechangerclosedatalltimes
whennotloadingorremovingthemagazine. Leavingthedooropen
couldallowdust,dirtandmoisturetoenterthechangerwhichcould
cause the unit to malfunction.
1. Duringnormaloperationwithpowerapplied,slideopenthe
door on the changer and press the eject button as shown
in Figure 6. The magazine will eject and can be removed.
2. If the magazine will not eject in a normal manner, remove
power by disconnecting the DIN cable from the changer.
a. Slideopenthe magazinedoor. Atthelowerleftrearofthe
changer, as shown in Figure 6, insert a thin-bladed screw
driverstraightintotheaccessholeabout1-1/2inchesuntil
it contacts the release tab.
b. Lightlyleveragethebladetotherightandthemagazinewill
disengage and be ejected.
Fig. 6
Fig. 5
Fig. 4
Eject Button
16
Mechanical Release
Access Hole (Left
Rear)

CD CHANGER OPERATING INSTRUCTIONS
This CD Changer is designed to operate through a compatible Audiovox car stereo which incorporates the
controls and display functions or through the FM section of any car stereo. Please check with your Audiovox
stereo specialist for recommendations of the models that will work with this changer. The specific operating
instructions for the changer will be contained within the Owner's Manual of the compatible unit.
SPECIFICATIONS:
Changer:
Frequency Response: 5 - 20,000 Hz ±1dB
Distortion: 0.008% @ 1kHz
Dynamic Range: 95 dB
Signal-to-Noise Ratio: 95 dB
Channel Separation: 70 dB @ 1kHz
Wow & Flutter: below measurable limits
Dimensions: 9-5/8" W x 3-3/8" H x 6-7/8" D
245 mm x 85 mm x 174 mm
Operating Voltage: 12 Volts DC, negative ground
Current Drain: 800mA (Playback/loading/ejecting)
FM Modulator:
Output Frequency: 88.7/89.1 MHz (Switchable)
Accessories Supplied: 10-disc magazine, P/N ACC-52MAZ
Mounting hardware (1set)
Connecting cable (1ea.)
17

TROUBLESHOOTING
An error made in operation or during installation of this product may be mistaken for a system malfunction. Please perform
the checks described below before contacting your dealer or service facility.
No power
Magazine cannot be
installed
CD is not played
Noise, skipping, or
intermittent sound
duringplayback.
Possible Cause Remedy
Symptom
Check fuses in vehicle fuse box and changer system.
Replace as necessary with fuse of same type and
rating as original. If fuse blows again, consult with
service facility.
Check all wiring and correct as necessary.
Insert magazine in proper direction.
Load disc correctly in the magazine.
Check sound on another disc. If sound from second
disc is OK, first disc is defective.
Clean disc
Remove the transit screws from sides of the unit.
Set the mounting angle adjustment to the correct
position as per the installation instructions.
Blown fuse
Incorrect connection
Magazine is inserted in wrong
direction.
Discisloadedincorrectlyinmagazine.
Scratches on disc or warped disc
Extremely dirty disc
Transit screws still in place
Mounting angle adjustment is not
correct.
18

AUDIOVOXCORPORATION(theCompany)warrantstotheoriginalretailpurchaserofthisproduct
that should this product or any part thereof, under normal use and conditions, be proven defective
in material or workmanship within 12 months from the date of original purchase, such defect(s) will
berepairedorreplacedwithneworreconditionedproduct(attheCompany'soption)withoutcharge
for parts and repair labor.
Toobtainrepairorreplacement withinthe termsof thisWarranty, theproduct isto bedelivered with
proofofwarrantycoverage(e.g.dated billofsale),specificationofdefect(s),transportationprepaid,
to the warranty center at the address shown below.
ThisWarrantydoesnotextendtotheeliminationofcarstaticormotornoise,tocorrectionofantenna
problems, to costs incurred for installation, removal, or reinstallation of the product, or damage to
tapes, compact discs, speakers, accessories, or vehicle electrical systems.
This Warranty does not apply to any product or part thereof which, in the opinion of the Company,
has suffered or been damaged through alteration, improper installation, mishandling, misuse,
neglect,accident, orby removal ordefacement of thefactory serial number/barcode label(s). THE
EXTENT OF THE COMPANY'S LIABILITY UNDER THIS WARRANTY IS LIMITED TO THE
REPAIRORREPLACEMENTPROVIDEDABOVEAND,INNOEVENT,SHALLTHECOMPANY'S
LIABILITY EXCEED THE PURCHASE PRICE PAID BY PURCHASER FOR THE PRODUCT.
This Warranty is in lieu of all other express warranties or liabilities. ANY IMPLIED WARRANTIES,
INCLUDING ANY IMPLIED WARRANTY OF MERCHANTABILITY, SHALL BE LIMITED TO THE
DURATIONOFTHISWRITTENWARRANTY. ANYACTIONFORBREACHOFANYWARRANTY
HEREUNDER INCLUDING ANY IMPLIED WARRANTY OF MERCHANTABILITY MUST BE
BROUGHTWITHINAPERIODOF30MONTHSFROMDATEOFORIGINALPURCHASE. INNO
CASE SHALL THE COMPANY BE LIABLE FOR ANY CONSEQUENTIAL OR INCIDENTAL
DAMAGES FOR BREACH OF THIS OR ANY OTHER WARRANTY, EXPRESS OR IMPLIED,
WHATSOEVER. NopersonorrepresentativeisauthorizedtoassumefortheCompanyanyliability
other than expressed herein in connection with the sale of this product.
Some states do not allow limitations on how long an implied warranty lasts or the exclusion or
limitationofincidentalorconsequentialdamagesotheabovelimitationsorexclusionsmaynotapply
toyou. This Warranty gives you specific legal rights and you may also have otherrightswhich vary
from state to state.
12 MONTH LIMITED WARRANTY
U.S.A. : AUDIOVOX CORPORATION, 150 MARCUS BLVD., HAUPPAUGE, NEW YORK 11788 l 1-800-645-4994
CANADA: CALL 1-800-645-4994 FOR LOCATION OF WARRANTY STATION SERVING YOUR AREA 128-4270E

© 2001 Audiovox Electronics Corp., Hauppauge, NY 11788 Printed in China
128-6002
