AUTEC AIRBM3V7L User manual

Original instructions
AIR SERIES
Part E:
Battery AIRBM3V7L
Docking station AIRDOCK01
INDEX
1 Battery AIRBM3V7L .............................................................................................. 2
1.1 Technical data ................................................................................................. 2
1.2 Plate ................................................................................................................ 2
1.3 Warnings for battery usage .............................................................................. 3
1.4 First aid ........................................................................................................... 3
1.5 Instructions for use .......................................................................................... 3
1.6 Storage ............................................................................................................ 4
1.7 Battery disposal ............................................................................................... 5
2 Docking station AIRDOCK01 ................................................................................ 6
2.1 Connecting the docking station and the power supply unit ............................... 6
2.2 Positioning ....................................................................................................... 7
2.3 Warnings for docking station usage ................................................................. 7
2.4 Disposal ........................................................................................................... 8
3 Malfunctions .......................................................................................................... 9
AUTEC
LIAIREA0-01

2
LIAIREA0-01
Battery AIRBM3V7L
AUTEC - Air series
1 Battery AIRBM3V7L
The A8 transmitting unit can only be powered through the battery AIRBM3V7L.
Always close the battery inside the transmitting unit and fasten it with
its cover and a screw: never use the transmitting unit if the battery is not
fastened under the cover with a screw.
A
B
C
DABattery housing
BBattery
CCover
DTechnical data plate
1.1 Technical data
Battery AIRBM3V7L: type/voltage/capacity ................................... Li-ion/3.7V /1300mAh
Max. recharge time ........................................................................................................ 4h
Recharge temperature ................................................... +5°C to +45°C (+41°F to +113°F)
Usage temperature .......................................................... -20°C to +55°C (-4°F to +131°F)
Storage temperature ...................................................... -20°C to +60°C (-4°F to +140°F)a
a. Valid for a storage time of 6h, in conformity with the requirements of section 38.3 of the "UN
Manual of Tests and Criteria" (UN/DOT Transportation Testing). do not use or recharge the battery
at temperatures exceeding the limits provided in paragraph 1.6.
1.2 Plate
The battery has a plate showing battery's identi󰘰cation, main technical data, and marks (if any).
This plate must not be:
-removed from its position (removal will invalidate the guarantee)
-altered or damaged (contact Autec for replacement).

AUTEC - Air series
Battery AIRBM3V7L 3
LIAIREA0-01
1.3 Warnings for battery usage
Only use original Autec batteries and only recharge batteries with battery
rechargers power supply units provided by Autec for this unit.
Never use damaged batteries.
Never use batteries if they have been dropped even just once.
Improper use of batteries may pose the hazard of 󰄈re, explosion, overheating
or other hazards. These are some examples of improper use:
-short circuit the battery poles
-disassemble, cut, open, press, deform, drill, modify, tamper with batteries
or attempt to repair them in any way
-try to insert objects in the batteries
-dive or expose batteries in/to water or other liquids.
1.4 First aid
If a person comes into contact with material leaking from a damaged battery,
immediately wash thoroughly the involved part with soap and water for at
least 15 minutes and consult a doctor.
1.5 Instructions for use
Do not attempt to repair damaged or faulty batteries.
It is recommended to recharge the battery before you use it for the 󰘰rst time.

4
LIAIREA0-01
Battery AIRBM3V7L
AUTEC - Air series
In order to ensure the maximum battery life over time, please follow these instructions:
-do not use or recharge the battery at temperatures exceeding the limits provided in
paragraph 1.1
-follow storage prescriptions provided in paragraph 1.6
-do not expose the battery to heat sources.
Partial recharge/discharge does not cause damages to the battery, on the contrary, it can
prolong battery life.
Batteries may be recharged and discharged hundred of times, but progressive reduction of
the maximum capacity occurs with use.
Use of altered batteries or batteries that are not the original ones will void any warranty.
Autec accepts no responsibility for any use that does not comply with the limitations
and indications provided, and for any damage that may result from improper, incorrect
or irrational use of the battery.
1.6 Storage
Please note that if a battery is not used, it will self-discharge over time;long-lasting storage
may also lead to permanent capacity loss.
If you expect not to use the battery for a long time, it is recommended to store it in a cool
and dry place, in order to ensure its maximum lifetime.
The following table shows the residual battery capacity in comparison to its nominal value,
depending on the storage temperature and period.
Temperature range Period Residual capacity
45 to 60°C (113 to 140°F) 1 month 75%
25 to 45°C (77 to 113°F) 3 months 70%
-20 to 25°C (-4 to 77°F) 1 year 80%
This table refers to a battery stored at half charge (voltage between 3.75V and 3.85V), which
is the ideal condition for storage. Batteries stored at half charge will last at least three times
more than batteries stored at full charge.
For example, if storing at a temperature from -20 to 25°C (from -4 to 77°F), it is recommended
to run a charge-discharge cycle for the battery every 90 days. After each charge-discharge
cycle, bring the battery back to the ideal half charge condition before storing it again.
In addition, pay attention not to store batteries at low charge levels. In this case, self-discharge
may drop the battery to such a low charge level that it will no more be possible to recharge it.
Do not store fully charged or completely 󰄉at batteries for a long time.

AUTEC - Air series
Battery AIRBM3V7L 5
LIAIREA0-01
1.7 Battery disposal
Do not throw the batteries away with domestic trash and do not burn them
as they may explode.
Batteries may contaminate the environment due to toxic or harmful substances that can be
dangerous for humans, animals and the vegetation. For this reason, they must not be disposed
of as unsorted household waste. They must be brought to the appropriate collection point for
the collection, recycling and treatment of batteries.
Users participation in the collection and recycling of batteries is important to reduce to the
minimum any potential impacts of substances used in these components on the environment
and on human health.
1.7.1 Directive 2006/66/EC and amendments
Di󰘯erent collection and recycling schemes for batteries are established
across the European Union. For any information on the schemes
valid in your area, please contact the relevant local authorities in
your territory.
The crossed-out wheeled bin marked on batteries indicates that they
must be disposed of separately from household waste, in conformity
with the EU Directive 2006/66/EC and its amendments, and with
local regulations.

6
LIAIREA0-01
Docking station AIRDOCK01
AUTEC - Air series
2 Docking station AIRDOCK01
The docking station AIRDOCK01 can only be used to recharge the AIR series A8 unit through
an adapter; this is provided together with the radio remote control and can either be wall-
mounted (FRA012-S05) or car mounted (CLA05D-050A).
Docking station Power supply FRA012-S05-I* Power supply unit CLA05D-050A
*: E: European plug
U: US plug
C: Chinese plug
A: Australian plug
B: UK plug
A8 transmitting units must only be charged through the docking station
AIRDOCK01 and its adapter, (wall mounted FRA012-S05 or car mounted
CLA05D-050A) provided by Autec together with the radio remote control.
Use of a docking station and a power supply unit other than those provided
will void the warranty.
Use the docking station only to recharge the A8 and not as a stand for the unit.
2.1 Connecting the docking station and the power supply unit
Insert the jack plug of the power supply unit in the corresponding socket on the docking
station, in order to connect them.
Never use the docking station and the power supply unit if they are damaged.
The power supply unit must be connected to a socket that can be easily
reached and disconnected.

AUTEC - Air series
Docking station AIRDOCK01 7
LIAIREA0-01
2.2 Positioning
Put the docking station in a indoor and dry place, far from liquids, dust and
heat sources.
Do not put any objects over the docking station when it is powered.
Do not in any case perforate, modify or tamper with the docking station.
2.3 Warnings for docking station usage
Users of the docking station must respect the following behaviour rules and provisions.
This equipment is not suitable for people (including children) with reduced
physical, sensory or mental capabilities.
This equipment is for professional use only, and cannot be used by unskilled
people, unless they are supervised and have received instructions on the
use of this device by a person in charge for their safety.
Do not handle the docking station and/or the mains adapter with soaked or
wet hands or feet or using objects, tools and/or instruments that conduct
electricity, are not insulated or are not protected from the risk of electrical
shock; do not in any case use damaged or wet objects and/or tools.
Disconnect power supply, disconnect the jack plug and remove the unit (if
present) before any cleaning or maintenance operation.
Before you put the unit in the docking station's cradle, check that the contacts
of both are intact and clean. If necessary, clean them with a non-abrasive
cloth or brush and a generic electrical contact cleaner.
Improper use of docking stations and power supply units may pose the
hazard of 󰄈re, explosion, overheating or other hazards.
To recharge the battery, make sure that the machine is in a safe state, so
that it cannot generate hazards (i.e. never leave the load suspended). When
the A8 unit is being recharged in the docking station, the unit must not be
used to control the machine, and the stop function is not available.

8
LIAIREA0-01
Docking station AIRDOCK01
AUTEC - Air series
Pay attention not to let elements (such as concrete, sand, lime, etc.) deposit
on the battery charger, because they can compromise its use and safety.
Recharge in an enclosed space.
Autec accepts no responsibility for any use that does not comply with the limitations
and indications provided, and for any damage that may result from improper, incorrect
or irrational use of the docking station and of the power supply unit.
2.3.1 Charged
First power on the docking station with its power supply unit
and then:
1. insert the A8 unit into the docking station: red LED on
indicates that charging has started (max. 4 h)
2. remove the A8 unit from the docking station when necessary
Note: when the green LED switches on, the A8 unit is completely
charged.
2.4 Disposal
When disposing of the battery charger, give it to the waste separate collecting services in
the user's country.

AUTEC - Air series
Malfunctions 9
LIAIREA0-01
3 Malfunctions
Use the light signals shown by the A8 unit during recharging to identify possible malfunctions.
If the problem persists after the suggested solution has been carried out, contact the support
service of the machine manufacturer.
LED Signals Possible reason Solutions
Green
ON at the end of
charge, but the
battery endurance is
signi󰄈cantly shorter
than normal
Exhausted battery. Replace the battery with a
charged and working one.
Red
ON after recharging
for approximately 4h Faulty battery Replace the battery with a
charged and working one.
ON with weak
luminous intensityb
Dirty contacts on the
transmitting unit and/or on the
docking station.
Clean the contacts on the
transmitting unit and on the
docking station with a non-
abrasive cloth or brush and
a generic electrical contact
cleaner.
Switched o󰓐
AC/DC power supply unit
is damaged or not correctly
powered.
Check that the AC/DC power
supply unit is intact, well
connected to the plug and
correctly powered (see power
supply unit's technical data
plate).
Faulty docking station. Replace the docking station
with a working one.
Faulty transmitting
unit
Replace the transmitting unit
with a working one.
Faulty battery Replace the battery with a
working one.
b. This signal appears if the A8 unit is in the docking station with the STOP pushbutton activated,
and when you press the START pushbutton the luminous intensity signi󰘰cantly increases.
