Auto Ingress AI-SLG-800 User manual

Installation Manual
Sliding Gate Operator
Automatic Entrence Solution Provider
24 x 7 Service Support +91 755 00 22 007 | +91 733 88 52 901 – 905
DESIGN |MANUFACTURE |SALES |SERVICE

2
Australian
Technology
• Wrongoperationmayresultininjuryorevendeathtotheuser.
• Wrongoperationmayresultininjuryorphysicaldamagetotheoperator.
• Thisoperatorneedstobeconnectedwithstabilisedanduninterruptedpowersupplyforsafety
ofmicro-controllerunitandtheoperator.
• Installation and adjustment must be carried out according to the Installation Manual.
Carelessnessininstallationandadjustmentmayresultinaccidentssuchasfire,electricshocks
orfalloff.
• Duringtheinstallationdonotallowthepedestrianstopassthroughtheautomaticgateor
approachtheworksite.Becauseanytoolsorpartsfalloffduringtheinstallationmayresultin
injurytothepedestrians.
• Don’tremodeltheparts,otherwisefire,electricshocksorfallmayoccur.
• Don’tusethepowerbeyondthestipulatedvoltageorfrequency,otherwise fire or electric
shocksmayoccur.
• Dofixupauxiliarysafetybeamsensortoensurethedetectingrangeforthewalkingareaof
thegateleaf,otherwisethepassers-bymaybecollidedorsqueezedbythegateleaf,causing
injury.
Thankyouforyourpurchaseofourautomaticgateequipment.
Yourautomaticgateoperatorhasbeendesignedandmanufacturedtocomplywithstringent
safetyrequirementsforcompliancetotheAustralianstandard.
Itisessentialthatyoumakeyourselffamiliarwithandatleastonceaweekormoreregularlycheck
thesafetyfeaturesofthegatetoensuresafetyoftheusers.Ifyoufindthatthegateoperatoris
unsafethenitmustberenderedtoasafeconditionbyeitherleavingitfullyopenorfullyshut.
Always engage Auto Ingress authorized service technician for periodic inspections and
maintenanceofthisequipment.
We recommend services every quarter of the year to ensure safety of users and longevity of
operatorlifecycle.
Inaccordance withthesafety andmaintenancerequirementsofthisequipment,AutoIngress
has developed a set of procedures to ensure optimum safety and long term reliability of this
installation.
Safety Precautions
IMPORTANT SAFETY MESSAGE

3
Australian
Technology
• Don’tuseagateleafthatexceedsthespecifiedweight,otherwiseitwillcausefailure.
• If you chose the electromagnetic lock, don‘t use it in an environment beyond an
ambienttemperature,otherwiseitwillcausemalfunction.
• The graphic drawings and specifications in this manul are for reference only. You
shouldrelyuponrealobjects.Productdesignesaresubjecttochangewithoutnotice.
• CAUTION!For personalsafety, itis importantto followall theinstructions carefully.
Incorrectinstallationormisuseoftheproductmaycauseseriousharmtopeople.
• Don’tusethegateinaplacesubjecttodampness,vibrationorcorrosivegas,otherwise
itmaycauseaccidentssuchasfire,electricshocksorfall.
• Makesurethatsuitablespacebeavailableafterthegateisopened,otherwiseuser’s
fingersmaybesqueezedbythegateleaf.
• Don‘tcutoffpowerwhenthegateisinoperation,otherwiseitmayresultinaccident
topassers-by.
• Pleasesticktheadhesivestickeronthegateleaffirmly.Ifnot,itmaycauseinjurytothe
passer-bywhodidn’tpayattentiontothegateleaf.
• Don’tconnectanexternalelectricdevicetothemicrocontrolerasitmaycausefire.
• Keeptheinstructionsinasafeplaceforfuturereference.
• This product was designed and manufactured strictly for the use indicated in this
document.AnyotherusagenotexpresslyindicatedinthisDocument,maydamage
theproductand/orbeasourceofdanger.
• Donotinstallthemachineinanareasubjecttoexplosionhazard.InflammabIegasses
orfumesareaserioussafetyhazard.
• Beforecarryingoutanyworkonthesystem,turnofftheelectricitysupply.
• Donotmakeanyalterationstothecomponentsoftheautomaticoperator.
• Donotallowchildrenorotherpeopletostandnearanymovingpartofthegatewhile
inoperation.
• Keeptransmitters awayfrom childrento preventthe machinefrom beingactivated
accidentally.
• Disconnectthesupplywhencleaningorothermaintenanceisbeingcarriedout,ifthe
applianceisautomaticallycontrolled.
• Theelectricalcordplugmustpluginingateoutletorwaterproofcoveroutlet.
Caution
Other Precautions

4
Australian
Technology
AI-SLG-800
Installation
•Beforeusingthemachine,checkpowersupply,grounding,voltage,etc.
•Checkwhetheritisconnectedaccordingtothedemandofwiring
diagram.
•Thegateshouldbepulledeasilyandsmoothlymanuallywhentheworm
gearsarereleased.
•Thewormgearswillbecoupledbeforepoweron.
•TheproductmustbeinstalledbyAutoIngressauthorisedtechnician.

5
Australian
Technology
Motor
Limit stopper
Nylon Rack
Photocell (Optional)
Alarm lamp (Optional)
Example of an installed automatic sliding gate
Installation and adjustment
Installbaseplateontheground,then,fastentheslidingmotoronthebaseplate.
Key: Ensure baseplate on level position.

6
Australian
Technology
Limit stopper magnet stopper
Install the limit stopper or limit magnet at proper position on the rack
Note:Waitofthegateshouldbeinthewheelsandnotinthepinion.
Racktobeinstalledcorrectlytoavoidweightinpinion.
Thespacebetweenrackandpiniongearisabout0.5mm.
Before place the limit stoper or magnet on the rack, the gear box of the
operatormustbereleased.AsperFig,Usethekeytumclockwisetorelease
thegear.
Movethegatemanuallytotheopenlimitandcloselimit,markthepointsonthe
Rack,then,fixthelimitStoppersorMagnetsatthelimitpointsontheRack.

7
Australian
Technology
/magnet /magnet
/magnet /magnet
Standard installation layout

8
Australian
Technology
AC control board

9
Australian
Technology
AI-SLG-500
Installation
•Beforeusingthemachine,checkpowersupply,grounding,voltage,etc.
•Checkwhetheritisconnectedaccordingtothedemandofwiring
diagram.
•Thegateshouldbepulledeasilyandsmoothlymanuallywhentheworm
gearsarereleased.
•Thewormgearswillbecoupledbeforepoweron.
•TheproductmustbeinstalledbyAutoIngressauthorisedtechnician.

10
Australian
Technology
Motor
Limit stopper
Nylon Rack
Photocell (Optional)
Alarm lamp (Optional)
Example of an installed automatic sliding gate
Installation and adjustment
Operater base
Aftertheconcretehashardened,mountthe gateoperatorbasetotheconcrete
pad.Verifythatthebaseisproperlyleveled.
Usingboltsandwashers,mountthegateoperatortothebaseandinsertthecover.
Checktheoperatorandmakesureitislinedupwiththegate.

11
Australian
Technology
Spring limit switch
Toensuresafety,itisrecommendedtoinstalllimitswitchesatbothendsofthegatetoprevent
thegatefromslidingoutoftherails.Therailsmustbeinstalledhorizontally.
InstallthelimitblockasshowninFigureabove.Thespringlimitswitchandblocksareusedto
controlthepositionofthegate.
Releasethegearwiththekeyandpushtheslidinggatemanuallytopre-determinetheposition,
fixtheblocktotherackandlockthegearbypushupthereleasebar.Movingthegateelectrically,
adjusttheblocktotheproperpositionuntilthepositionoftheopeningandclosingmeetthe
requirement.

12
Australian
Technology
AISLG500.PCB
GND
24VDC
Out I.R
COM
24VDC
Terminal X2
Infrared Control board
Infrared with DC input
Signal
Wiring notes of control board
a. PowerInput(X1):E(Earth),L(Live),N(Neutral).
b. Cautionlight:connectcautionlightwiretoD1andD2(terminalX3)
c. Outputpowersupply:24VDC,COM(COM),I.R.(N.CInfrared)Iftheinfraredbeamisinterrupted
duringclosing,thegatewillreverseandopenimmediately.Theproductisnotfactoryequipped
withaninfrareddevice,theinfraredoutputsignalmustbeN.C.
Verify open direction :Ifthegatedoesnotmoveinthedesireddirection,thenyouwillneed
toreversethemotoroperatingdirection,opentheplasticcover,youcandothisbyexchanging
wires‘U’and‘W’,‘OPLM’and‘CLLM’.
Remote control : The remote control works in a single channel mode. It has four buttons.
Thefunctionofbutton1,button2,button3andbutton4arethesame.Witheachpressofthe
remotecontrolbuttonwhichhasbeenprogrammed,thegatewillclose,stop,open.

Important Notes :
1.AnyunauthorisedconnectiontotheMicroControllerwillmaketheWarrantyinvalid
2.IftheinstallationisnotcarriedoutasperAutoIngressrecommendedguideline,Warrantyis
void
3.Foractivationoftheoperatorbyanyothermodeorconnectiontootherexternaldevicenot
providedinthemanual,pleasecontactourtechnicanteam
4.Westronglyrecommendregularmaintenanceoftheoperatorforitsoptimumperformance
5.AutoIngressreservestherighttochangethedesignandspecificationwithoutpriornotification
Description ACMOTOR
Powersupply 220V±10%50HZ
PowerofMotor AC280W
Current 3A
Maxweightofgate ≤800kg
Thermalprotectionon
motorwinding 120°C
Workingenvironment -20°C~55°C
IPRating IP44
AI-SLG-800 Specifications
Description ACMOTOR
Powersupply 220V±10%50HZ
PowerofMotor AC200W
Current 2.5A
Maxweightofgate ≤500kg
Thermalprotectionon
motorwinding 120°C
Workingenvironment -20°C~50°C
IPRating IP44
AI-SLG-500 Specifications
Head Office - Australia
Indian Office
Auto Ingress India Pvt Ltd
B-4/32, SIDCO Industrial Estate, Maraimalai Nagar, Chennai - 603209 Tamil Nadu, India
Phone: +91 44 2745 2151, Mobile: +91 755 00 22 007 | +91 733 88 52 901 – 905
