Autojack PH15KW Assembly instructions

Owner’s Manual & Safety Instructions
Read this manual before using this product.
Failure to do so can result in serious injury.
SAVE THIS MANUAL.
PH15KW
15KW
Propane Gas Heater

INDEX
15KW Propane Gas Heater
PH15KW
1. Work Area Safety
2. Electrical Safety
3. Personal Safety
4. Symbols & Technical
5. Information
6. Installation
7. Application
8. Warnings
9. Maintenance & Troubleshoot
10. Declaration
01
01
02
03
04
05
06
08
09
07

.01.
15KW Propane Gas Heater
PH15KW
General Safety Warnings: Read all safety warnings, instructions,
illustrations and specifications provided with this appliance. Failure to
follow all instructions listed below may result in electric shock, fire and/or
serious injury.
Save all warnings and instructions for future reference.
The term “appliance” in the warnings refers to your mains-operated
(corded) appliance or battery-operated (cordless) appliance.
1) Work area safety
a) Keep work area clean and well lit. Cluttered or dark areas invite
accidents.
b) Do not operate appliances in explosive atmospheres, such as in the
presence of flammable liquids, gases or dust.
2) Electrical safety
a) Appliance plugs must match the outlet. Never modify the plug in any
way. Do not use any adapter plugs with earthed (grounded)
appliances. Unmodified plugs and matching outlets will reduce risk of
electric shock.
b) Avoid bodily contact with earthed or grounded surfaces, such as
pipes, radiators, ranges and refrigerators. There is an increased risk
of electric shock if your body is earthed or grounded.
F Do not expose appliances to rain or wet conditions. Water entering
an appliance will increase the risk of electric shock.
G Do not abuse the cord. Never use the cord for carrying, pulling or
unplugging the appliance. Keep WKHcord away from heat, oil, sharp
edges or moving parts. Damaged or entangled cords increase the
risk of electric shock.
e) If operating an appliance in a damp location is unavoidable, use a
residual current device (RCD) protected supply. Use of an RCD
reduces the risk of electric shock.

.02.
15KW Propane Gas Heater
PH15KW
3) Personal safety
a) Stay alert, watch what you are doing and use common sense
when operating the appliance.
b) Ensure the switch is in the OFF-position before disconnecting
and picking up or carrying the appliance.
4) Appliance use and care
a) Do not use the appliance if the switch does not turn it ON and OFF.
Any appliance that cannot be controlled with the switch is dangerous and
must be repaired.
b) Disconnect the plug from the source before making any adjustments,
changing accessories, or storing appliances. Such preventive safety
measures reduce the risk of starting the appliance accidentally.
c) Store idle appliances out of the reach of children and do not allow
persons unfamiliar with the appliance or these instructions to operate the
appliance.
d) Maintain appliances and accessories. Check for misalignment or
binding of moving parts, breakage of parts and any other condition that
may affect the appliance’s operation. If damaged, have the appliance
repaired before use. Many accidents are caused by poorly maintained
appliances.

.03.
Technical Data:
Use only in a well ventilated area and away from combustible materials
●NOT to be used for the heating of habitable areas of domestic premises,
for use in Public buildings, refer to national regulations.
●After use turn off the gas supply at the cylinder valve.
●Ensure that the fan is operating correctly before lighting the burners.
15KW Propane Gas Heater
PH15KW
Read the manual before set-up and/or use.
Do not dispose with household waste.
SYMBOL DESCRIPTION
Conforms to relevant safety standards.

.04.
General Information:
15KW Propane Gas Heater
PH15KW
1.1. The heaters mentioned in this manual must only be used outdoors
or in well ventilated surroundings.
1.2. For every KW it is necessary to have permanent ventilation of
25cm³, equally distributed between the floor and high level, with a minimum
outlet of 250cm³.
1.3. Gas cylinders must be used and kept in accordance with current
regulations.
1.4. Never direct the hot air flow towards the cylinder.
1.5. Use only the supplied pressure regulator.
1.6. Never use the heater without its cover.
1.7. Do not exceed 100W/m³ of free room. The minimum volume of the
room must be larger than 100m³.
1.8. Do not obstruct the inlet or outlet sections of the heater.
1.9. If the heater has to work for a long period at its maximum capacity,
it’s possible that ice will form on the cylinder. This is due to excessive vapor
withdrawal. Not for this reason, or for any other, should the cylinder be
heated. To avoid this effect, or at least to reduce it, use a large cylinder or
two cylinders linked together (Figure1).

.05.
15KW Propane Gas Heater
1.10. Do not use the heater in cellars, basements or in any room below
the ground level.
1.11. In case of malfunction, please contact the technical assistance
service.
1.12. After use, turn the gas cylinder tap off.
1.13. The gas bottle must always be replaced following safety rules away
from any possible source of ignition.
1.14. The gas hose must not be twisted or bent.
1.15. The heater must be placed where there is no risk of fire, the hot air
outlet must be at least 3m from any flammable wall or ceiling and must
never be directed towards the gas bottle.
1.16. Only use original gas hose and spare parts.
1.17. Heaters described in this leaflet are not intended for domestic use.
1.18. In the case that a gas leak is found or suspected, immediately close
the gas cylinder, switch the heater off and do not use it again until it has
been checked by a qualified service centre. If the heater is installed
indoors, provide good ventilation by opening door and windows completely.
1.19. If in any doubt contact your supplier.
Installation:
2.1 Connect the heater to a suitable electric socket /230V~50Hz
2.2 Make sure that the machine is properly earthed.
2.3 Connect the gas supply hose to the pressure regulator and connect the
regulator to a suitable LPG cylinder.
2.4 Open the tap of the cylinder and check the supply hose and fittings for
a gas leak. For this operation it is recommended to use an approved leak
detector.
2.5 NEVER USE NAKED FLAMES.
2.6 For automatic appliances, connect the room thermostat to the socket
on the appliance and adjust it to the required temperature.
PH15KW

.06.
15KW Propane Gas Heater
PH15KW
Application use:
1. Check the heater for possible shipping damage.
2. Connect the hose and regulator assembly to the LPG cylinder by
rotating the nut counterclockwise into the LPG cylinder’s valve outlet and
securely tighten.
3. Open the cylinder’s gas valve and check all gas connections with
a soap and water solution.
4. Connect power cord to well-grounded 220-240V~, 50Hz source
of power.
3.1 IGNITION / Manual ignition
a. Turn the power switch to position I and check that the fan starts
running correctly. (Fig 2.)
b. Push the gas valve button and push repeatedly the piezoelectric
lighter until the flame lights up. (Figure. 3-4)
c. As the flame lights up, keep the valve button pushed for 10 seconds
approx. Should the heater stop when the valve button has been released,
wait one minute and repeat the starting operation keeping the valve button
pushed for a longer time.
d. Regulate the gas flow pressure according to the thermal power
desired, by turning the wheel of the pressure reducer anticlockwise to
increase the pressure or clockwise to decrease.
e. Contact your supplier should any problems continue.

.07.
15KW Propane Gas Heater
PH15KW
！！！WARNING
Asphyxiation Hazard
1. Do not use in unventilated areas.
2. The flow of combustion and ventilation air must not be obstructed.
3. Proper ventilation air must be provided to support the combustion
air requirements of the heater being used.
4. Lack of proper ventilation air will lead to improper combustion.
5. Improper combustion can lead to carbon monoxide poisoning
leading to serious injury or death. Symptom of carbon monoxide
poisoning can include headaches, dizziness and difficulty in breathing.
FUEL GAS ODOUR
LP gas and natural gas have man made odorants added specifically for
detection of fuel gas leaks.
If a gas leak occurs you should be able to smell the gas. Since Propane
(LP) is heavier than air you should smell for the gas odour low to the floor.
ANY GAS SMELL THIS MOTH BE ACTED ON IMMEDIATELY!
1. Do not take any action that could ignite the gas. Do not operate
any electrical switches. Do not pull any power supply or extension cords.
Do not light matches or any other source of flame. Do not use your
telephone.
2. Get everyone out of the building and away from the area
immediately.
3. Close all propane (LP) gas tank or cylinder fuel supply valves, or
the main fuel supply valve located at the meter if you use natural gas.
4. Propane (LP) gas is heavier than air and may settle in low areas.
5. Use your neighbor’s phone and call your fuel gas supplier and
your fire department. Do not re-enter the building or area.
6. Stay out of the building and away from the area from the area
until declared safe by the firefighters and your fuel gas supplier.
7. FINALLY, let the fuel gas service person and the firefighters
check for escaped gas. Have them air out the building and area before
you return. Properly trained service people must repair any leaks, check
for further leakages, and then relight the appliance for you.

15KW Propane Gas Heater
PH15KW
Maintenance:
4.1. The repairs or maintenance operations must only be carried out by
qualified personnel.
4.2. The unit must be checked by a qualified technician at least once a year.
4.3. Regularly check the conditions of gas hose, and gas regulator if it must
be replaced only use original spare parts.
4.4. Before starting any maintenance operation on the heater disconnect
from both gas and electrical supply's.
4.5. If the unit has not been used for a long period we advise that a
technician carries out a general check up before using. It is important to
control the following:
4.5.1. Check the starting electrode position (see Figure.5).
.08.

15KW Propane Gas Heater
PH15KW
Seller Details:
.09.

TOOLSAVE
UNIT C MANDERS INDUSTRIAL ESTATE
WOLVERHAMPTON WV1 2RP
