Energy GH 0618 Installation and user guide

www.energy-ind.com Please read this handbook carefully, before use
Gas Heater GH0618
Installation, Operation, Service and Maintenance Guide
GH 0618
The guarantee is considered in case of installation
by a permissible agency of Energy company services.

Contents
Product Standards 4
General conditions and specification 4
Installation Preparation 7
Vent pipe Installation Condition 8
Different types of heater installation and operation 9
Connection to Natural Gas Piping 15
Pre purge/post purge 16
Heater ventilator 16
Electrical connections 16
Thermostat Installation Regulations 18

Contents
Application of Keys and Signs on Thermostat Frame and Monitor 19
Turning on theThermostat 20
review eyelet 21
Limit control 22
Wiring diagram 23
Maintenance 24
Error codes 25
Technical Specifications 26
Maximum horizontal vent lengths 27

4Instructions Gas Heater GH0618
This gas heater is equipped with high efficiency heating system.The heating system of this heater includes in-shot burner and heat exchanger which as
result into transferring of the combustion heat to the air.
The control system of the heater is fully automated and is guaranteeing the security and safety operation of the system, based on the latest international
standards.
1-The product specifications is based on EN1266 Standard.
2-All design, production, purchase,quality guarantee and after-the-sale services stages are based on ISO9001:2008 Standard from TUV NORD Credit source.
3-All production stages are under supervision of the quality unit of Energy Company.
1-The heater shall not be installed in the places with flammable air, with dust and corrosion gas pollution or in the moisture.
2-The distance of flammable materials and the system should be at least 50 cm and it should be placed in the distance of 20 cm with the nearest wall.
3-For true and correct operation of the heater, the distance between the fan and the wall shall be at least 30 cm.
4-Please prohibit from installing the heater on flammable materials.
5-This system is equipped with the vent pipe and its combustion products should be kept outside the environment.
Product Standards
General conditions and specification
Dear client

5
Instructions Gas Heater GH0618
6- The heater should be installed on a pillar with suitable height from the land and the installation of the heater on wall pillar is permissible provided that
the services and maintenance facilities are available.
7- The front of the heater should be open for 1 meter. No garment shall be installed against the heater.
8- The system is designed to work in the environments with the temperature of 0 to 35 degrees of centigrade. For higher temperatures, please contact
sale engineering department of Energy Company in 61444.
-The system shall not be installed in bedroom, bath, washroom or storage and/or to supply the combustion air from these places.
-The distance between the heater and curtains and flammable materials shall not be less than 50 cm.
-The system shall not be placed where it can be in the danger of mechanical or physical shocks,unless,there are some protecting pillars available.In the mean-
time, if the place is installed in villa area, to protect children some necessary arrangements, such as pillar, etc. should be observed so that the children cannot
reach the fan.(If it was impossible to install the pillar with the height of 1.5 meters,necessary arrangements shall be observed to protect children from fan).
- The vent on the wall for combustion air, shall be at least one meter far from each horizontal and vertical balances of the vent pipe.
NOTICE!
The heater is able to operate on hermetic style (to supply combustion air from
outdoor) with a coaxial vent pipe and or separate type (with two separate vent
pipes) which is installed based on the environmental conditions and there is
the availability to supply combustion air from inside or outside environment

6Instructions Gas Heater GH0618
- To supply combustion air from outdoors: ( only B type)
A) At least two permanent and non-blocking vents should be installed in upper and lower part, one with the maximum distance of 300 mm from the floor and
another one with maximum distance of 300 mm from ceiling of the place of installation of the heater.
B) Size of each side of the entrance, should not be less than 80 mm.
C) If the air entrance is opened to the outdoors directly and without any channels, the area of the vents should be at least 121 square centimeters, which is
equal a vent with the dimensions of 110×110 mm and the status of the vents should be based on paragraph A.Air entrances should supply an area; the free
surface should be determined for 75% and for the wooden vents, the free surface should be 25%.
- No combustion air shall be supplied from illegal resources (the combustion air shall not be supplied from some places such as engine house, dangerous areas, and dust).
NOTICE!
If you are smelling the gas:
1-Please fasten the gas main valve.
2-Open the doors and windows.
3-Do no touch electricity switches and do not turn on the electrical appliances.
4-Do not use the interior telephone lines.
5-Call the gas company relief post or fire fighting organization.

7
Instructions Gas Heater GH0618
1- Place of installation of the heater should be completely balanced.
2- If the system is installed on hermetic type, a special coaxial vent pipe for this heater or two seprated vent pipes should be used. If the coaxial vent pipe is
used, the air entrance pipe shall not be opened and it should be closed by air inlet cap and sealed.
3- Combustion products shall be transferred to the vent pipe with a true method with a minimum length of horizontal pipe and then should be transferred
outside via the vent pipe.
4- vent pipe path should not be lower than vent pipe outdoor in any point.
5- Please, make sure that the vent pipe is not closed before installing the vent pipe.
6- Please make sure that the vent pipe is connected to the heater correctly and the vent pipe gases will not permeate to the environment.
7- Based on the amount of gas consumed by the system,based on the technical particulars table, it is necessary to predict a gas pipe, equipped with a valve,
at the place of installation, based on the natural gas piping standards.
8- The required electricity is 220 V, 2 A, equipped with the suitable fuse.
Warning!
The heater should be installed and operated with an authorized Energy service
representative, observing full safety regulations
Preparation for installation

8Instructions Gas Heater GH0618
9- The thermostat should be located at the height of 1.5m of the floor in a place which is not open to the sunshine or cold weather.
The fantasy cement and metal caps on the roof with small side holes, are producing accidents and type H or standard round terminal should be used.
Never use aluminum pipe (flexible) for the heater and other gas burner systems; because,these kinds of pipes will be exited simply.
End of vent pipe should be equipped with the terminal and it should be at least 60 cm higher than the highest part of the building.
Before installation of the heater, please analyze the construction vent pipes from the viewpoint of open path, sealing,no seam and similar length in total path.
NOTICE!
The system is equipped with a thermostat to control the environmental temperature
which is attached with the heater equipments.
To operate and control the heater,please connect the thermostat to the heater by
means of a cable prepared at the back of the heater
Vent pipe installation conditions

9
Instructions Gas Heater GH0618
Different kinds of installation, operation and piping of heater vent pipe
Type 1:B22
In this status, the air required for the combustion, is supplied from place of installation of the heater.vent pipe is used (size:10 cm) for exit of the combustion
products on system’s vent pipe exit par, air entrance cap is lifted from the heater; so the entrance air filter net is being recognized.
To connect heater vent pipe to the vent output, the coaxial converter should be used.This part is directly connected to the heater vent output,and it should be
fixed by screw after the assurance of its complete connection.
The vent pipe distance should be the smallest path to the output of place of installation and if it is possible,minimum horizontal length should be used at piping
system.(according to the table3)
NOTICE!
At the end of vent pipe,standard terminal should be used and the vent pipe shall
not be left without a terminal.
NOTICE!
In this type combustion air entrance shall not be blocked.

10 Instructions Gas Heater GH0618
Two kinds of type B22 piping in the horizontal and vertical vent pipes status (figure1,figure2)
NOTICE!
Air supply vent at the place of installation of the heater, should be in the dimen-
sions mentioned at general conditions.
vent pipe
combustion air entrance
coaxial converter
(figure1)
standard terminal

11
Instructions Gas Heater GH0618
vent pipe
standard terminal
(figure2)
coaxial converter
combustion air entrance

12 Instructions Gas Heater GH0618
In this types of installation of the heater, the air required for combustion is supplied from the environment,outside place of installation of the heater.
Coaxial vent pipe will establish the combustion air input and combustion products output.Length of the coaxial pipe is 1 meter at maximum and if the heater is
installed in this condition,the coaxial vent pipe will be transferred by after-the-sale services department.(figure3)
To connect coaxial vent pipe to the heater, suitable screw should be used.
Coaxial vent pipe (c12)
combustion air entrance should be closed
Type 2: Hermetic (c12/c32/c52)
NOTICE!
In c12 type, combustion air entrance shoulde be closed.
(figure3)

13
Instructions Gas Heater GH0618
In this types of installation of the heater, the air required for combustion is supplied from the environment,outside place of installation of the heater.
Coaxial vent pipe will establish the combustion air input and combustion products output.Length of the coaxial pipe is 1 meter at maximum and if the heater is
installed in this condition,the coaxial vent pipe will be transferred by after-the-sale services department.(figure3)
To connect coaxial vent pipe to the heater, suitable screw should be used.
Coaxial vent pipe (c12)
combustion product vent pipe:
Single wall vent pipe ( size: 10 cm) shoud be used for output of combustion products. To connect vent pipe to the heater, coaxial converter should be used. It
should be screwed after the certainty about its complete connection. (figure4)
vent pipe path should be the shortest path up to the place of installation output and if possible,the minimum length in the piping system should be used.
(according to the table3)
Combustion air entrance:
Connect single wall vent pipe ( size:10 cm) at entrance air pipe and screw it after you have made sure that it is completely installed and sealed.
entrance air pipe path should be the shortest path up to the place of installation input. (according to the table3)
Warning!
Make sure that you have used standard terminal at the end of the vent pipe and
entrance air pipes and never leave the pipes without the terminal.
separate pipes(c32/c52)

14 Instructions Gas Heater GH0618
NOTICE!
If the vent pipe and air entrance pipe are arparallel,please make sure to install
the vent pipe in the distance of 30 cm outer than air entrance pipe (as shown
above).
some kind of c32,c52 types piping
(figure4)

15
Instructions Gas Heater GH0618
1- To connect heater to the gas piping system, a 3/8 inch hose which is prepared in the factory should be used.
2- One part of the hose and special fastening is attached with heater which should be used at the gas valve output.
3- Please input the hose to the head and fasten it.
4- Open the gas valve and control the gas leakage with soap foam.
Warning!
The consuming fuel of this heater is natural gas.
It is prohibited to use liquid gas for operating the heater.
Connection to natural gas piping
Warning!
Length of the hose to be connected to gas piping is 2 meters at maximum.

16 Instructions Gas Heater GH0618
Pre purge:
Before turning on the burner; pre purge operation is used for 37 seconds to clean the combustion case and heat exchanger.
Post purge:
After turning the burner off,the post purge operation is carried out for cleaning the combustion case and the heat exchanger of any gas resulted for 17 seconds.
The heater fan has an automatic operation.
Inbothmanualandautomaticstatus(thermostatic),isgoingtobeturnedon47secondsafterturningontheburnerandturnedoff 80secondsafterturningofftheburner.
This heater is equipped with an electronic board which is installed inside the heater,one thermostat (remote control) which is attached to cable 2x0.5.By means
of this thermostat (remote control) you can control the heater totally.
Pre purge/post purge
Heater ventilator
Electrical connections

17
Instructions Gas Heater GH0618
Pre purge:
Before turning on the burner; pre purge operation is used for 37 seconds to clean the combustion case and heat exchanger.
Post purge:
After turning the burner off,the post purge operation is carried out for cleaning the combustion case and the heat exchanger of any gas resulted for 17 seconds.
The heater fan has an automatic operation.
Inbothmanualandautomaticstatus(thermostatic),isgoingtobeturnedon47secondsafterturningontheburnerandturnedoff 80secondsafterturningofftheburner.
This heater is equipped with an electronic board which is installed inside the heater,one thermostat (remote control) which is attached to cable 2x0.5.By means
of this thermostat (remote control) you can control the heater totally.
Pre purge/post purge
Heater ventilator
Electrical connections
A three-line cable equipped with plug, with the connection to land is considered for connection of the system to the outlet.
Warning!
This heater shall not be operated or used without thermostat (remote control).
This heater is only capable to be installed to the attached thermostat.
Any connection of similar or different thermostat is prohibited.
Warning!
In order to protect from probable injuries to the system, it is necessary to wire
the system based on the regulations of this instruction to control the wiring,
before connection of the electricity

18 Instructions Gas Heater GH0618
.
Thermostat Installation Regulations
1- This thermostat, in addition to the ability to measure the environmental temperature, is able to control the heater completely.
2- The thermostat should be placed on a flat wall in the same place with the heater.
3- A cable 2 x 0.5 is considered for connection of thermostat (remote control).
4- By means of a small screwdriver, push the thermostat door to the upside and open it.
5- Pull the terminal out of its place, fasten two cables in the terminal by a small screwdriver and locate the terminal at its own place carefully.
6- Based on the type of the wall on which the thermostat is located, you may extract the place of installation of two thermostat cable on plastic frame.
7- Install the thermostat back door by means of a screw and fastening available at thermostat package.
8- Push the thermostat on the back door to fix it.

19
Instructions Gas Heater GH0618
Application of Keys and Signs on Thermostat Frame and Monitor
Increase set point
decrease set point
Determining the operation mode
(Summer / manual / thermostatic)
ON/OFF
Week /days
Environmental temperature/ set point
Hour burner
Summer mode
Manual mode
OFF
Flame
Thermostat monitor and frame

20 Instructions Gas Heater GH0618
The first time you are turning on the thermostat,you may set the hour, minutes and weekly days.
If you do not want to set the above-mentioned items, press the (OK) key several times and enter the main page of thermostat.
After you have turned the thermostat on, press the (Auto) key to determine the heater operation mode.
Description monitor symbol Heater operation status
Turn the heater on/off without considering the environmental temperature Manual
Based on the temperature of the environment and set point heater will be
turned on/off Thermostatic
Only as the fan,you may turn the fan on/off.The burner is really turned off. Summer
Turning on the Thermostat
