Autojack IG950i Installation manual

IG950i/IG1200i/IG2000i
Inverter Generator
IG950i/IG1200i/IG2000i
ORIGINAL INSTRUCTIONS
SAFETY AND OPERATING MANUAL

IG950i/IG1200i/IG2000i
TABLE OF CONTENTS
Welcome to Autojack!
Dear Customer, Congratulations on your purchase. Before using the
Product for the first time please be sure to read these instructions for use.
They provide you with all information necessary for using the product safely and to
ensure its long service life.
Closely observe allsafety information in these instructions!
General Power Tool Safety Warnings………………………………….…......01
Symbols & Cable Rating Chart ……….…………………………………….………04
Machine Details and Product features……….…………………………….….05
Assembly……………………………………………………………………………………..11
Operation…………………………………………………………………………………..13
Maintenance and Service…………………………………….……………………..17
Troubleshooting……………………………………………………..………………..19
Autojack Guarantee…………………………………………………………………….20
Declaration of Conformity…………………………..………………………………22
Parts list/Parts Diagram……………………….……………………………………...23

IG950i/IG1200i/IG2000i 01
WARNING Read all safety warnings and
all instructions. Failure to follow the warnings
and instructions may result in electric shock, fire
and/or serious injury.
Save all warnings and instructions for
future reference. The term "power tool" in
the warnings refers to your electric (corded)
power tool or battery-operated (cordless) power
tool.
1. Work area safety
a) Keep work area clean and well lit. Cluttered
or dark areas invite accidents.
b) Do not operate power tools in explosive
atmospheres, such as in the presence of
flammable liquids, gases or dust. Power tools
create sparks which may ignite the dust or
fumes.
c) Keep children and bystanders away while
operating a power tool. Distractions can cause
you to lose control.
2. Electrical safety
a) Power tool plugs must match the outlet.
Never modify the plug in any way. Do not use
any adapter plugs with grounded power tools.
Unmodified plugs and matching outlets will
reduce risk of electric shock.
b) Avoid body contact with grounded surfaces,
such as pipes, radiators, ranges and
refrigerators. There is an increased risk of
electric shock if your body is grounded.
c) Do not expose power tools to rain or wet
conditions. Water entering a power tool will
increase the risk of electric shock.
d) Do not abuse the cord. Never use the cord for
carrying, pulling or unplugging the power tool.
Keep cord away from heat, oil, sharp edges or
moving parts. Damaged or entangled cords
increase the risk of electric shock.
e) When operating a power tool outdoors, use an
extension cord suitable for outdoor use. Use of a
cord suitable for outdoor use reduces the risk of
electric shock.
f) If operating a power tool in a damp location is
unavoidable, use a residual current device (RCD)
protected supply. Use of an RCD reduces the risk
of electric shock.
3. Personal safety
a) Stay alert, watch what you are doing and use
common sense when operating a power tool. Do
not use a power tool while you are tired or under
the influence of drugs, alcohol or medication. A
moment of inattention while operating power
tools may result in serious personal injury.
b) Use personal protective equipment. Always
wear eye protection. Protective equipment such
as dust mask, non-skid safety shoes, hard hat, or
hearing protection used for appropriate conditions
will reduce personal injuries.
c) Prevent unintentional starting. Ensure the
switch is in the off position before connecting to
power source and/or battery pack, picking up or
carrying the tool. Carrying power tools with your
finger on the switch or energising power tools that
have the switch on invites accidents.
d) Remove any adjusting key or wrench before
turning the power tool on. A wrench or a key left
attached to a rotating part of the power tool may
result in personal injury.
GENERAL POWER TOOL SAFETY WARNINGS

IG950i/IG1200i/IG2000i 02
e) Do not overreach. Keep proper footing and
balance at all times. This enables better control
of the power tool in unexpected situations.
f) Dress properly. Do not wear loose clothing or
jewellery. Keep your hair, clothing and gloves
away from moving parts. Loose clothes,
jewellery or long hair can be caught in moving
parts.
g) If devices are provided for the connection of
dust extraction and collection facilities, ensure
these are connected and properly used. Use of
dust collection can reduce dust-related hazards.
4. Power tool use and care
a) Do not force the power tool. Use the correct
power tool for your application. The correct
power tool will do the job better and safer at the
rate for which it was designed.
b) Do not use the power tool if the switch does
not turn it on and off. Any power tool that
cannot be controlled with the switch is
dangerous and must be repaired.
c) Disconnect the plug from the power source
and/or the battery pack from the power tool
before making any adjustments, changing
accessories, or storing power tools. Such
preventive safety measures reduce the risk of
starting the power tool accidentally.
d) Store idle power tools out of the reach of
children and do not allow persons unfamiliar
with the power tool or these instructions to
operate the power tool. Power tools are
dangerous in the hands of untrained users.
e) Maintain power tools. Check for misalignment
or binding of moving parts, breakage ofparts and
any other condition thatmay affect the power
tool’s operation. If damaged, have the power tool
repaired before use. Many accidents are caused by
poorly maintained power tools.
5. Service
a) Have your power tool serviced by a qualified
repair person using only identical replacement
parts. This will ensure that the safety of the power
tool is maintained.
b) If the replacement of the supply cord is
necessary, this has to be done by the
manufacturer or its agent in order to avoid a
safety hazard.
GENERAL POWER TOOL SAFETY WARNINGS

IG950i/IG1200i/IG2000i 03
6. Additional Safety Instructions for
Generators
a).Keep the generator at least 1 m (3 ft.) from
buildings orother equipment, or the engine may
overheat.
b).Place the generator ona solid, flat surface.
c).Make sure the surrounding area is free from
any material that could burn or be damaged by
heat.
d).Never move ortilt the generator whilst itis
switched on.
e).Alwaysswitch the engine OFF when refuelling.
f).Always refuel in a well ventilated area.
g).Never overfill the tank, fill to the level
specified .
h).Never smoke whilst refuelling and avoid
smoking or using a naked flame near the
generator.
i).Never start the engine ifthere is spiltfuel. Any
spillage must be wiped clean and the generator
allowed to drybefore attempting tostart the
engine.
j).Never usethe generator inwet conditions
unless it iswell protected/covered. Under these
conditions, adequate ventilation MUST be
provided.
k).Never operate the generator with wet hands
l).Never usewater orany other liquids toclean
the generator.
m).Make sure you ground (earth) the generator.
n).Always makesure the applied load does not
exceed the generator rating. Overloading the
generator isdangerous and could cause serious
damage.
o).Always disconnect the generator when carrying
out any maintenance.
p).Always allowthe generator toreach operating
speed before connecting a load.
q).Never allow thegenerator to run out offuel
when a load isconnected.
r).Never transport the generator with fuel inthe
tank.
s).Never connect the generator toa commercial or
residential power supply; e.g. ringmain.
t).Never allow the generator air vents to become
blocked.
GENERAL POWER TOOL SAFETY WARNINGS

IG950i/IG1200i/IG2000i 04
SYMBOLS AND POWER RATING CHART
Danger! – Read the operating
instructions to reduce the risk of
injury.
Caution! Wear safety goggles.
Caution! Wear ear defenders. The
impact of noise can cause damage
to hearing.

IG950i/IG1200i/IG2000i 05
MACHINE DETAILS AND PRODUCT FEATURES
Machine Details
Specifications:
IG950i
Engine
Engine model – XY139F-6
Type – petrol
Displacement – 40m3
Ignition type – C.D.I
Fuel tank capacity – 2.1L
Maximum run time at 3/4 load – 5.3h
Engine oil capacity – 0.25L
Generator
Rated Frequency – 50Hz
Rated AC voltage – 230V
Max output power – 800W
Continuous output power – 700W
Output type – modified sine wave
Rated DC voltage – 12V
Rated DC current – 4A
Rated output current – 3.04A
Rated power factor – 1
Performance Class – G1
Quality Class – A
Noise Level(LWA) -58dB(A)
(taken at 7 m)
IP Rating – IP23M
Package Contents:
InverterGenerator
12Volt Connecting Lead Assembly
Spark Plug Box Spanner
Cross-Head Screwdriver
Intended Use
Designed to generate electric energy
Using equipment in ways other than its
intended use the user and not the
manufacture will be liable for any damage or
injuries caused.
Also note that this equipment is not designed
for commercial or industrial use. Warranty will
be voided if used for these purposes.
1.Air vent knob
2.Fuel cap
3.Fuel valve knob
4.Starting handle
5.Side maintenance cover
6.Top maintenance cover
7.Muffler
8.Choke
9.Engine ON/OFF switch
10.Earthing point
11.Economy control switch
12.AC socket
13.DC socket
14.DC circuit breaker
15.Output indicator
16.Overload indicator
17.Oil alarm indicator
18.Primer bulb

IG950i/IG1200i/IG2000i 06
MACHINE DETAILS AND PRODUCT FEATURES

IG950i/IG1200i/IG2000i 07
MACHINE DETAILS AND PRODUCT FEATURES
Machine Details
Specifications:
IG1200i
Engine
Engine model – XY144F-1
Type – petrol
Displacement – 60m3
Ignition type – C.D.I
Fuel tank capacity – 3L
Maximum run time at 3/4 load – 5.5h
Engine oil capacity – 0.27L
Generator
Rated Frequency – 50Hz
Rated AC voltage – 230V
Max output power – 1100W
Continuous output power – 1000W
Output type – modified sine wave
Rated DC voltage – 12V
Rated DC current – 4A
Rated output current – 4.354A
Rated power factor – 1
Performance Class – G1
Quality Class – A
Noise Level(LWA) -58dB(A)
(taken at 7 m)
IP Rating – IP23M
Package Contents:
InverterGenerator
12Volt Connecting Lead Assembly
Spark Plug Box Spanner
Cross-Head Screwdriver
Intended Use
Designed to generate electric energy
Using equipment in ways other than its
intended use the user and not the
manufacture will be liable for any damage or
injuries caused.
Also note that this equipment is not designed
for commercial or industrial use. Warranty will
be voided if used for these purposes.
1.Air vent knob
2.Fuel cap
3.Fuel valve knob
4.Starting handle
5.Side maintenance cover
6.Top maintenance cover
7.Muffler
8.Choke
9.Engine ON/OFF switch
10.Earthing point
11.Economy control switch
12.AC socket
13.DC socket
14.DC circuit breaker
15.Output indicator
16.Overload indicator
17.Oil alarm indicator
18.Primer bulb

IG950i/IG1200i/IG2000i 08
MACHINE DETAILS AND PRODUCT FEATURES

IG950i/IG1200i/IG2000i 09
MACHINE DETAILS AND PRODUCT FEATURES
Machine Details
Specifications:
IG2000i
Engine
Engine model – XY152F-4
Type – petrol
Displacement – 99m3
Ignition type – C.D.I
Fuel tank capacity – 4.1L
Maximum run time at 3/4 load – 4.5h
Engine oil capacity – 0.52L
Generator
Rated Frequency – 50Hz
Rated AC voltage – 230V
Max output power – 2000W
Continuous output power – 1700W
Output type – modified sine wave
Rated DC voltage – 12V
Rated DC current – 4A
Rated output current – 7.39A
Rated power factor – 1
Performance Class – G1
Quality Class – A
Noise Level(LWA) -58dB(A)
(taken at 7 m)
IP Rating – IP23M
Package Contents:
InverterGenerator
12Volt Connecting Lead Assembly
Spark Plug Box Spanner
Cross-Head Screwdriver
Intended Use
Designed to generate electric energy
Using equipment in ways other than its
intended use the user and not the
manufacture will be liable for any damage or
injuries caused.
Also note that this equipment is not designed
for commercial or industrial use. Warranty will
be voided if used for these purposes.
1.Air vent knob
2.Fuel cap
3.Fuel valve knob
4.Starting handle
5.Side maintenance cover
6.Top maintenance cover
7.Muffler
8.Choke
9.Engine ON/OFF switch
10.Earthing point
11.Economy control switch
12.AC socket
13.DC socket
14.DC circuit breaker
15.Output indicator
16.Overload indicator
17.Oil alarm indicator
18.Primer bulb

IG950i/IG1200i/IG2000i 10
MACHINE DETAILS AND PRODUCT FEATURES

IG950i/IG1200i/IG2000i 11
Assembly
Before using the generator
IMPORTANT: Generators should ALWAYS be
earthed. Make sure you earth the generator.
Before using your generator check that:
-The generator is in good condition and free
from any damage.
-The generator is clean and free from fuel or oil
spillage.
-The generator is correctly located for use
-There is no leakage.
Note: To avoid accidental spillage offuel, always
use a funnel tofill the fuel tank. If fuel is spiltit
must be removed from the unit before
attempting to start the engine.
Earthing
WARNING: It is advisable to properly earth your
generatorbefore starting using a wire anda
small metal earth spike. The wire and earth are
not supplied with the unit.
An earth spike and cable can be purchased at
your localcamping supplier, oralternatively an
earth spike can be made, and itissuggested you
get advice from a qualified electrician.
Tomake a spike use a copper tube orcopper rod
12mm diameter, a minimum length of 200mm
and with an M6 machine screw one end.
The cableused should bea maximum length of1
metre anda minimum of 1.0mm2to carry a 10
amp load.
Attach the cable to the generator at the earth
point screw on the generator.
When pushing the spike into the ground the
generator must not be running and it is suggested
that the spike is pushed into the ground by at least
100mm.
Earthing of generators is covered in BS7430:2011,
If you have any doubts about this subject consult a
qualified electrician.
Checking the air filter
1. Remove the side maintenance panel.
2. Remove the air filter cover screw shown on the
right.
3.Slide out the air filter panel.
4. Remove the air filter element.

IG950i/IG1200i/IG2000i 12
Assembly
5. If the air filter is damaged contact the
Autojack spare parts department for a
replacement.
- If the filter isdirty, wash it ina solution of
warm water and mild detergent and rinse
thoroughly. Leave the filter to dry completely.
Once it is dry immerse the filter in clean engine
oil and squeeze the filter toremove excess oil.
WARNING: Do not use flammable solvents or
petrol to clean the air filter.
6. Replace the filter into its original position and
secure the air filter cover. Reattach the side
maintenance panel.
Checking the Engine oil level
WARNING: Your generator may not be supplied
with oil, always ensure that there is sufficient
oil before use.
WARNING: To carry out this check, the engine
must be off.
1. Remove the side maintenance panel.
2.Turn the oil filler cap anti-clockwise and remove
from the oil reservoir, wipe the dipstick with a
clean cloth.
3.Insert the dipstick back into the oil filler tube and
then remove it again.
4.If the oil is below the Min. level on the dipstick,
top up the oil reservoir with fresh oil.
-Do not fill above the max level mark(0.3 litres)
-We recommend the use of SAE30 oil in this
generator.
5.Replace the oil filler cap.
6.Replace the left side maintenance panel.
Checking the fuel level
WARNING: Make sure there is fuel in the tank
when using the generator. Running out of fuel or
stopping the engine suddenly with a load
connected could cause serious damage.
1.To check the fuel level, open the fuel filler cap.
2.Slowly add fuel to the fuel tank (maximum 2.1 litres)
-Do not overfill the fuel tank.

IG950i/IG1200i/IG2000i 13
Assembly / Operation
3.Replacethe fuel filler cap securely.
WARNING: Fuel is highly flammable and
poisonous.
WARNING: SEE “GENERAL SAFETY RULES” and
read them carefully before refueling.
WARNING: Do not fill above the top of the fuel
filter orit may overflow when the fuel heats up
and expands.
WARNING: Wipe up any spilt fuel immediately.
WARNING: After refueling,make sure the fuel
filler cap is tightened securely.
Recommended fuel
Your generator has been designed to use regular
unleaded petrol with a octane number of 86 or
higher.
Starting the engine
1.Remove all connections from the AC sockets.
2.Hold the fuel tank cap so that it will not move,
and turn the air vent knob to the ‘open’ position.
3.Turn fuel valve to the ON position (Pointing
right).
4.Set the engine switch to ‘ON’.
5. Move the choke lever to the right, to the ‘choke’
position.

IG950i/IG1200i/IG2000i 14
Operation
6. If this isthe first time you are using the
generator or if the generator had run out of fuel
the last time you used it, pump the primer bulb a
minimumof 6 times tointroduce fuel into the
carburetor.
7. Hold the generator handle firmly and pull the
starting handle lightly until you start to feel
resistance and then pull up sharply to start the
engine.
NOTE: you may have to do this more than once.
WARNING: Once the generator has started,
release the handle slowly to avoid
injury/damage as it whips back.
NOTE: When you first start the generator, the
overload indicator may light up for a few
seconds, this is normal. If the overload indicator
is still lit after 5 seconds, stop the engine and
contact your AUTOJACK dealer.
8. Once the engine has warmed up, move the
choke lever to the left, to the “run” position.
Economy switch:
ON: Recommended to minimisefuel
consumption and further reduce noise levels
when no load is applied to thegenerator. Engine
speed varies with the load.
OFF: The smart throttle system does not operate.
CAUTION: The economy control does not work
effectively if the electrical appliance requires
‘BURSTS’ of power.
CAUTION: Turn the economy control feature off
when connecting high load appliances or when
connecting to the DC output.
Connecting electrical devices
The generator can supply both 230V AC and 12V
DC
AC power
1.Start the engine.
2.Make sure the appliance is turned off before
connecting it to the generator.
3.Connect the appliance (max load 800W) to the
generator.

IG950i/IG1200i/IG2000i 15
Operation
Caution: Make sure that the appliance being
connected isingood working order ifit begins
to act abnormally orstops suddenly. Disconnect
it from thegenerator.
Caution: Make sure the appliance does not
exceed the maximum rated load for the
generator.
Caution: Any device which contains an
inductiveload e.g. devices that contain a motor
may require more current on startup.
DC power
1.Set the economy control switch to ‘OFF’.
2.Start the generator.
3.Make sure the appliance is turned off before
connecting it to the generator.
4.Connect the 12V appliance (max 4A) to the
generator.
DC power (Topping up car batteries)
WARNING: For your safety perform the
following instructions in the order shown.
WARNING: You should only use this generator
to ‘Top up’ the battery, also trying to charge a
completely flat battery may cause the fuse to
blow.
1.Set the economy control switch to 'OFF'.
2.Start the generator.
3.Connect the battery charging leads to the
battery.
-Make sure you clamp the red wire to the
positive(+) terminal and the black wire to the
negative (-) terminal of the battery
4.Connect the battery charging leads to the
generator.
-The battery will begin to charge.
5.Monitor the voltage across the battery regularly
during charging and disconnect the battery when
the voltage reaches 14.4 volts.
CAUTION: When disconnecting the battery,
always disconnect the negative lead first.
DC over load protector
If the DC overload protector activates, wait for a
few minutes and then press the reset button
shown on the right.

IG950i/IG1200i/IG2000i 16
Operation
Indicator lights
Output
The output indicator(Green) will remain on
during normal operation.
Overload
The overload indicator(Red) will light up if there
is an overload or a short circuit in the connected
appliance.
If this happens, proceed as follows:
1.Turn off any connected electrical devices and
stop the engine.
2.Reducethe total wattage ofconnected
electric devices towithin the rated output of
the generator.
3.Check air inlet and around the control unit. If
any blockages arefound, remove them.
4.After checking, restart the engine.
Oil alert
The oil alert indicator(Red) will light up when the
oil level is low.
-To add oil
Shutting down the generator
To stop the generator in an emergency simply set
the engine switch to ‘OFF’
NOTE: Turn off any electric devices.
NOTE: Set the economy control switch to the
‘O’(OFF) position.
1.Disconnect any electric devices.
2.Turn the fuel valve knob to ‘OFF’(pointing left).
3.Turn the air vent knob to the ‘Close’ position.
4.Set the engine switch to the “O”(OFF) position.

IG950i/IG1200i/IG2000i 17
MAINTENANCE AND SERVICE
Engine oil(every 20 hours of use)
CAUTION: Prolonged exposure to used engine
oil dangerous, always wash your hands
thoroughly after handling used engine oil.
1.Remove the maintenance panel shown on the
right.
2.Turn the oil filler cap anti-clockwise and remove
from the oil tank.
3.Tilt the generator to allow the oil to drain out
of the oil reservoir into a suitable container.
NOTE: You may need assistance with this step
as the generator is heavy.
4.Fill the oil reservoir with fresh oil.
-Do not fill above the max level mark(0.3 litres).
-We recommend the use of SAE30 oil in this
generator.
5.Replace the oil filler cap and maintenance
panel.
Environmental protection
One of the most damaging sources of pollution is
oil. Do not throw away used engine oil in with your
domestic waste or down drains and sinks. Place it
in a leak proof container and dispose of it
according to local regulations.
Air filter(every 50 hours of use)
1.Remove the maintenance panel shown on the right..
2.Remove the air filter cover screw.
3.Remove the air filter panel.
4.Remove the air filter element.
5.If the air filter is damaged contact the AUTOJACK
spare parts department for a replacement.
WARNING: Do not use flammable solvents or
petrol to clean the air filter.
6.Replace the filter into its original position and
replace and secure the air filter cover.

IG950i/IG1200i/IG2000i 18
MAINTENANCE AND SERVICE
Spark plug (every 50 hours of use)
CAUTION: Allow the engine to cool before
removing the spark plug.
1.Remove the top maintenance panel.
2.Remove the spark plug cap from the spark
plug.
3.Fit the spark plug box spanner over the spark
plug as shown.
4.Remove the side panel and use the
screwdriver supplied to turn the spark plug box
spanner as shown.
5.When the spark plug has been removed, check
for discoloration and use a wire brush to remove
any carbon build up.
6.Check the spark plug gap (a) with a feeler gauge, it
should be between 0.6 and 0.7 mm.
-Adjust if necessary.
7.Check the overall condition of the spark plug and
replace if damaged.
8.Reinstall the spark plug and replace the spark
plug cap and top panel.
Fuel tank filter(every 100 hours of use or
every 6 months)
Just inside the fuel tank is a fuel filter, check this
filter periodically and remove any contaminants
which may have accumulated.
1. Remove the fuel tank cap
2. Lift out the filter inside.
3. Clean the filter with solvent.
4. Replace the filter and fuel tank cap.
