RAM™ 16-F & 16-Fp Space Saver Frozen Fry Dispensers
Copyright © 2019 Automated Equipment LLC All rights reserved. Published 8/19 1
Introduction
This manual contains important information on the proper installation, operation, and care of the RAM Space
Saver Frozen Fry Dispenser. Following the instructions and procedures in this document will ensure that
your dispenser provides years of reliable service. If any problems with the dispenser arise, this manual will
also provide troubleshooting tips and service information.
Unpacking & Installation
Remove all packing material from Dispenser. Open Cabinet Door. Disassemble, clean, sanitize and dry the
Hopper and dispensing components. Clean, sanitize and dry Fry Baskets. (see pages 5 and 8 for
disassembly & cleaning). Reassemble all components (see page 7 for startup and operation).
The equipment must be installed by qualified personnel, in accordance with the manufacturer’s instructions.
Local electrical installation and safety regulations must be observed. Before installing check that voltage
and frequency on the data plate match the electrical supply.
Intended Use
The Frozen Fry Dispenser must only be used for the temporary frozen storage and dispensing of non-meat
based food products at commercial restaurants and similar locations. Any other use would be deemed as
inappropriate. The dispenser is designed for installation and use indoors, in a restaurant environment
protected from weather, excessive heat, excessive humidity and salt air.
HAZARD COMMUNICATION STANDARD:
Hazard Communication Standard (HCS) Procedures in this manual may include the use of chemical
products. These chemical products will be highlighted with boldface letters followed by the abbreviation
(HCS) in the text of the procedure. See the HCS Manual for the appropriate Material Safety Data Sheets
(MSDS).
FCC STATEMENT
WARNING: This equipment generates, uses, and can radiate radio frequency energy and, if not installed
and used in accordance with the instruction manual, may cause interference to radio communications.
EMC STATEMENT
This equipment meets EMC directives:
- EN 55014-1:2006 + A1:2009
- EN55014-2:1997 + A1:2001 + A2:2008-Category II
Serial Number: The information on the serial number identification label is as follows:
Example: s/n 16FR1512A00025
16F = Model 12 = Month
R = Manu. Facility A = Revision Level
15= Year 00025 = Sequence #
Example: s/n 16PR1705A00045
16P = Model 05 = Month
R = Manu. Facility A = Revision Level
17= Year 00045 = Sequence #
Warning!
Only personnel qualified, trained and licensed in refrigeration, may diagnose or repair the
refrigeration systems on this equipment.
Service functions described in this manual could cause irreversible damage to the equipment
and/or injury to personnel if performed improperly.
If the power cord is damaged, it must be replaced by the manufacturer, or its service agent, or
a similarly qualified person in order to avoid a hazard.

RAM™ 16-F & 16-Fp Space Saver Frozen Fry Dispensers
Copyright © 2019 Automated Equipment LLC All rights reserved. Published 8/19
2
Equipment Safety
Turn the Power Switch off and disconnect the Dispenser Power Cord from the wall outlet
before cleaning, moving or servicing the Dispenser.
Inspect the Dispenser on a regular basis to identify potential problems before they occur.
Keep the Dispenser clean.
Keep hands away from the Outlet Door and Dispenser Drum while the Dispenser is
operating. Disconnect power before clearing a blocked Outlet Door or Dispenser Drum.
Fry Baskets may be hot. Pick them up by the handles only.
Do NOT roll the Dispenser to the back sink for cleaning, this will cause unnecessary wear on
the Dispenser.
If the Power Cord is damaged it must be replaced by the manufacturer or its service agent or
a similarly qualified person in order to avoid a hazard.
Use only the Power Cord that came with the Dispenser. Do NOT use an extension cord.
Do NOT modify the Power Cord
In a safety emergency, immediately disconnect the Dispenser Power Cord from the wall
outlet.
Do NOT obstruct access to the wall outlet or place pressure on the Power Cord.
Only trained and/or qualified personnel should service the electrical system.
DO NOT SPRAY THE DISPENSER WITH LIQUID OR SOLVENTS.
It is not sealed against jetting fluids and contamination may get into sensitive components.
Spraying the dispenser may void the warranty.
Use caution when handling heavy parts such as back and top panels.
Always reinstall service panels when maintenance is complete.
Do NOT drill or otherwise puncture cabinet walls or top.
Keep unit upright at all times.
Keep ventilation openings in the appliance enclosure, particularly in the bottom back panel,
clear of obstruction.
Do NOT use mechanical devices or other means to accelerate the defrosting process, other
than those recommended by the manufacturer. Do NOT drill or otherwise puncture cabinet
walls or top.
Do NOT damage the refrigerant circuit.
Do NOT use electrical appliances inside the food storage compartments of the appliance,
unless they are of the type recommended by the manufacturer.
Do NOT store explosive substances such as aerosol cans with a flammable propellant in this
appliance.
This appliance is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been
given supervision or instruction concerning use of the appliance by a person responsible for
their safety. Children should be supervised to ensure that they do not play with the
appliance.

RAM™ 16-F & 16-Fp Space Saver Frozen Fry Dispensers
Copyright © 2019 Automated Equipment LLC All rights reserved. Published 8/19 3
Equipment Safety Cont.
Label is located near Power Cord inlet.
CAUTION, RISK OF ELECTRIC SHOCK.
DISCONNECT POWER BEFORE SERVICING UNIT.
Label is located on the top and bottom Rear Access Panels, Side Access Panel Top Cover and near
Power Cord inlet.
CAUTION, RISK OF ELECTRIC SHOCK.
INDICATES HAZARDOUS VOLTAGE WITHIN
DISCONNECT POWER BEFORE SERVICING UNIT.
Label is located on the rear access panel and applies to both the drum motor and outlet door
assemblies within the enclosure.
CAUTION, MOVING PARTS.
DO NOT OPERATE WITH PANEL REMOVED
Label is located on the front and applies to the outlet door assembly.
CAUTION, MOVING PARTS.
HANDS SHOULD NOT BE PLACED NEAR OR BELOW THE OUTLET DOOR.
US and Canada
US and Canada
International
International
US and Canada International

RAM™ 16-F & 16-Fp Space Saver Frozen Fry Dispensers
Copyright © 2019 Automated Equipment LLC All rights reserved. Published 8/19
4
Equipment Safety Cont.
Label is located on the Rear Access Panel and applies to the refrigeration system.
CAUTION, RISK OF FIRE
KEEP OPEN FLAME FROM EXPOSED INSULATION WHEN SERVICING
REFRIGERENT IS FLAMMABLE (MODEL 16-FP ONLY, R290 REFRIGERANT)
US and International
Warning: Keep ventilation openings in the
appliance enclosure, particularly in the
back-bottom panel, clear of obstruction.
Caution: The 16-Fp utilizes R290 (propane)
as a refrigerant. Release of refrigerant into
the atmosphere is strictly prohibited.
Caution: Propane (R290) is highly
flammable.

RAM™ 16-F & 16-Fp Space Saver Frozen Fry Dispensers
Copyright © 2019 Automated Equipment LLC All rights reserved. Published 8/19 5
Dispenser Assembly
Note: Before assembling the Dispenser it is recommended that all parts be cleaned, sanitized,
dry, and handled in a sanitary manner. Refer to the Cleaning Procedures for more information.
Install the Drip Tray under the cabinet outlet, lifting it slightly over the cabinet supports. Position the
Drip Tray Spacer on the Drip Tray in the mounting slots.
With the dispenser turned off, align the Outlet Door with the Door Alignment Arrow and slide the Outlet
Door over the shaft toward the back wall engaging the Alignment Arrow. (See page 10 if the alignment
Arrow is in the closed position.) With your hands removed, turn the dispenser on, the Outlet Door will
retract into the closed position.
Install the Drum into the Hopper making sure the square opening in the drum is pointed toward the rear
of the Hopper. Install the Fry Diverter in the Hopper by sliding the Fry Diverter tabs into the slots
located on the inside Hopper wall. Install the hopper assembly into the cabinet by sliding them onto the
hopper supports. DO NOT force the drum on to the shaft. Rotate the drum in the hopper until the
square opening meshes with the drum motor shaft, then slide the hopper assembly backward until it
drops into place.
Drum Fry Diverter Hopper Assembly
Drip Tray
Outlet Door
Door Alignment Arrow
Drip Tray Spacer

RAM™ 16-F & 16-Fp Space Saver Frozen Fry Dispensers
Copyright © 2019 Automated Equipment LLC All rights reserved. Published 8/19
6
Operator Panel and Controls
The Operator Panel consists of the On/Off Switch, the Temperature Controller with Display and the
Dispense Button.
The On/Off Switch is the main power switch and turns the dispenser power on and off. The switch
illuminates when on.
The Temperature Controller maintains the cabinet temperature and displays the current cabinet
temperature. The dispenser’s controller can also detect an abnormal refrigeration condition. When an
error condition is detected the display will state the error that has occurred.
The Dispenser Button operates both the Dispensing Drum and the Outlet Door. When the Dispense
Button is pressed the Outlet Door moves to the dispensing (open) position and the drum begins to turn
in the hopper. When the desired amount of frozen fries have dispensed into the basket, the Dispense
button is released, the Dispenser Drum stops rotating and the Outlet Door closes.
On / Off Switch Temperature
Controller Dispense Switch

RAM™ 16-F & 16-Fp Space Saver Frozen Fry Dispensers
Copyright © 2019 Automated Equipment LLC All rights reserved. Published 8/19 7
Start up and Operation
When the dispenser is in place, lock both front casters.
Make sure Power Switch, located on the left side of the operator panel, is turned off.
Assemble the Dispenser (see page 5).
Plug the Power Cord into an approved outlet and turn the Dispenser on.
Note: Turn Dispenser on a minimum of 90 minutes (depending on ambient temperature
conditions) before loading frozen product into the Dispenser. Once the temperature display has
dropped to 10F (-12C) load frozen product into Dispenser and use the Dispenser.
Note: This machine is to be used only for dispensing frozen fries or other approved product.
Any other use may cause injury to personnel or damage to the machine.
The Frozen Fry Dispenser is intended to maintain and dispense frozen fries on demand eliminating the
need for staging full baskets of fries. Dispensing and cooking fries direct from the freezer results in
improved fry quality, consistency and yield.
Do not stage full baskets of fries on the side mount basket rack, if equipped. The side mount
basket rack should be used for empty fry basket storage only.
Loading the Hopper
Note: To achieve optimum fry yield and the
most consistent basket loads, it is important
to use the following technique for loading
frozen fries into the Hopper.
For each bag or box of fries:
1. Remove the bag of fries from the case. Be
careful not to crush the fries.
2. Open the top of the bag or box completely.
(A partially open bag may retain fries.)
3. Hold the opened end of the bag closed with
your hand and lay it in the Hopper with the
opening toward the side opposite of the
Diverter.
4. Release the opened end of the bag or box.
5. Empty the bag into the Hopper by pulling it
evenly toward the diverter. When adding
multiple bags of fries, alternate the
placement of the bag in the Hopper
opposite of the previous bag. The second
bag of fries should be emptied into the
Hopper with the opening toward the
Diverter, and pulling it evenly toward the
Hopper wall opposite the Diverter.
This crisscross loading method assures an
even distribution of fry lengths in the Hopper
and the Baskets
The dispenser hopper holds 36 lbs (16.3 kg)
Hopper capacity may vary depending on the
product.
Warning: Pinch Hazard. Personnel should
take care not to place hands or fingers near
the Drum inside the Hopper while this
machine is in operation. Hands or fingers
could be pinched between the Drum and the
Hopper as the Drum turns.
Note: Do NOT shake or drop fries from the
bag or box into the Hopper, this will result in
unnecessary fry breakage.
Operation
1. Place a basket under the Outlet Door in the
loading position.
2. Press and hold the Dispense Button until
the desired amount of fries are dispensed
into the basket.
3. Release the Dispense Button.
4. Remove the basket.

RAM™ 16-F & 16-Fp Space Saver Frozen Fry Dispensers
Copyright © 2019 Automated Equipment LLC All rights reserved. Published 8/19
8
Daily Closing: Disassembly, Defrost & Cleaning
IMPORTANT! These cleaning instructions
are intended as a guide. Refer to your local,
state, and federal regulations for any
additional instructions and for cleaning
frequency requirements.
Remove all Baskets from the dispense area
and basket rack. Open the Cabinet Door and
remove the Hopper Assembly by lifting the front
of the Hopper up slightly and pulling forward on
assembly.
Remove any unused product from the Hopper
by emptying the product into an approved
storage container. Place the storage container
immediately into a freezer to maintain frozen
product.
Defrost
Because the dispenser employs a cold wall
design, it will be necessary to manually defrost
the cabinet daily.
1. Press the On/Off Switch to the Off position
and unplug the dispenser power cord.
2. With the dispenser off and the remaining
product removed, move the Outlet Door into the
open position
3. Remove the Outlet Door from the mounting
shaft.
4. Lift and remove the Drip Tray and Drip Tray
Spacer.
5. Open the Cabinet Door and allow 1 hour to
defrost.
Caution: Never use a sharp object to remove
frost build-up. Never drill or otherwise
puncture cabinet walls or top.
Take the removable components from the
Dispenser to the washing area. Wash them
with a hot solution of detergent and water.
Rinse each component with clear water and
sanitize (wash/rinse/sanitize) (HCS). Allow
components to air dry.
NOTE: The removable components are NOT
dishwasher safe.
Move the Dispenser out from the wall to clean
behind and underneath it.
Do NOT roll the dispenser to the back sink for
cleaning, this will cause unnecessary wear on
the dispenser.
Once the cabinet is free of frost, wipe down the
internal and external of the cabinet with a hot
solution of detergent and water. Rinse with
clear water and repeat wipe down with
sanitizing solution (HCS) and allow to air dry.
Warning: Do not spray the Dispenser with
Liquid or Solvents. The Dispenser does not
provide a water tight seal. Contaminants
and moisture may get into sensitive
components.
Dry all components and reassemble the
Dispenser (see page 4). Move Dispenser back
into place.
Notice: The dispenser must be accessible
from all sides for routine cleaning and
maintenance. A minimum of 1” (26 mm)
clearance on both sides and 2” (50 mm)
behind the dispenser is recommended.

RAM™ 16-F & 16-Fp Space Saver Frozen Fry Dispensers
Copyright © 2019 Automated Equipment LLC All rights reserved. Published 8/19 9
Temperature Controller Operation and Menu Structure
The Space Saver Frozen Fry Dispenser uses an electronic temperature controller to operate the
refrigeration system. It directly controls the compressor. The following sections will cover basic
operation and programming of this controller.
Displaying and changing set point temperature
The set point is the temperature at which the refrigeration system will turn off. The recommended set
point is 0 degrees Fahrenheit (-18 degrees Celsius). The set point can be viewed and adjusted with the
SET key. Press and immediately release the SET key to view the current set point. To change the set
point, press and hold the SET key for 4 seconds or until the display is flashing. The set point can be
adjusted by using the up and down arrow keys. The new set point is stored by pressing the SET key
again
Locking the Controller
The controller keys may be locked by pressing both the up and down keys for 3 seconds. The display
will flash PoF. The keys are now locked and cannot be used to change any parameter (the set point is
still visible by pressing the set key). To unlock the keys, once again press both the up and down keys
for 3 seconds. The display will show Pon and the keys will be unlocked.
Key and LED descriptions
Set key Displays current set point, allows set point changes
Up key Increases displayed value; browses up lists of parameters
Down key Decreases displayed value; browses down lists of parameters
Compressor Enabled LED On: Compressor enabled
Flashing:
A
nti-short cycle delay enabled
A
larm LED On:
A
larm is occurring
Measurement Units Displays the current measurement unit
Temperature Display Displays the current temperature
Set Key
Up Key
Down Key
Not Used
Not Used
Not Used
Compressor
Enabled LED
Alarm LED

RAM™ 16-F & 16-Fp Space Saver Frozen Fry Dispensers
Copyright © 2019 Automated Equipment LLC All rights reserved. Published 8/19
10
Error Detection
Note: Errors relating to the refrigeration systems, while requiring corrective action, will not
disable the fry dispensing portion of the equipment.
The temperature controller is capable of detecting conditions that fall outside normal operation. In such
cases, the controller will display an alarm message to warn the operator that corrective action should
be taken. The alarm consists of a flashing message on the controller display. The flashing message will
remain until the error is corrected. Some alarm conditions may be easily fixed, while others may require
the attention of a qualified service technician. The chart below provides an explanation of each error
message and what action may be needed to correct the problem.
Alarm Messa
g
e Cause Corrective Action
“P1” flashing Thermostat probe failure Power off; wait one minute, power on.
Check probe connections on back of controller (Pins 11
and 12. See schematic at end of manual
)
.
Replace probe.
“HA” alternating
with freezer
temperature
Maximum temperature alarm Power off; wait one minute, power on.
Check that cabinet door seals properl
y
.
Check and clean the condenser filter and condenser
Verif
y
condenser fan operation
Verif
y
compressor operation
“LA” alternating
with freezer
temperature
Minimum temperature alarm Power off; wait one minute, power on.
Check/replace compressor isolation relay.
WARNING! Do NOT change the temperature scale (Fahrenheit or Celsius) on the controller.
WARNING! Only qualified and trained personnel should attempt repairs to any of the systems in the
Dispenser. Call the Technical Support Line for service issues.

RAM™ 16-F & 16-Fp Space Saver Frozen Fry Dispensers
Copyright © 2019 Automated Equipment LLC All rights reserved. Published 8/19 11
Troubleshooting
The following is a list of possible problems that may occur, probable causes, and corrective action that may
eliminate the problem. If, after performing the corrective action, the problem persists, call our Technical Support
Hotline for assistance. Technical Support Hot Line: 1-800-248-2724 (U.S./Canada) or 651-385-2273.
Problem Possible Causes Corrective Actions
No power Dispenser not plugged in Verify plug is in the outlet, the on/off switch is on
Faulty electrical outlet Check the circuit breaker. Try plugging the unit in another outlet.
Faulty power cord or plug Have a qualified electrician test and/or replace the power cord
Dispenser not
reaching
temperature
(HA Alarm)
or slow to cool
Dirty or clogged condenser or
condenser filter
Clean condenser and condenser filter
Cabinet Door not closing Verify hopper is properly installed
Check the door gasket, if damaged replace.
Check for damage to the door.
Outlet Door not installed Install Outlet Door
Faulty probe Verify probe accuracy, calibrate probe.
Faulty Temperature Controller or
refrigeration relay
Call AE for assistance
Condensing unit problem Call AE for assistance
Dispenser
temperature too cold
(LA Alarm)
Check the Compressor Enabled
LED on the controller
If the Compressor Enabled LED is off and the compressor is
running, suspect a stuck refrigeration relay or controller fault
If the Compressor Enabled LED is on and the temperature
reading is below the set point, suspect the controller.
Not dispensing fries Hopper is empty Verify product is in the hopper
Fries are bridged in the hopper Re-distribute fries to break up the bridge
Drum not turning Verify Dispensing Drum socket is not damaged
Verify the motor shaft is turning when the Dispense Switch is
pressed. If not suspect a faulty Dispense Switch, wiring or a
faulty drum motor. Call AE for assistance.
Outlet Door not opening Verify proper installation of Outlet Door
Verify the door shaft is turning when the Dispense Switch is
pressed. If not suspect a faulty Dispense Switch, faulty relay
PCB, wiring or a faulty door motor. Call AE for assistance.
Check for damage to the Outlet Door.
Outlet door not
closing
Product caught in outlet Disassemble Outlet Door and Hopper.
Outlet door
alignment arrow in
closed position
Dispenser turned on while outlet
door removed
To position the alignment arrow for door placement, first verify
there are no fries in the hopper, then turn the dispenser on and
press the dispense button. While depressing the dispense
button, shut off the on/off switch. Alignment arrow should be in
the proper position to install the outlet door.
Overfilling baskets Missing diverter or installed
incorrectly
Reassemble Hopper assembly
Drum continues to turn after the
Dispense Button is released
Verify Dispense Button is not sticking
Suspect a faulty relay PCB. Call AE for assistance.

RAM™ 16-F & 16-Fp Space Saver Frozen Fry Dispensers
Copyright © 2019 Automated Equipment LLC All rights reserved. Published 8/19
12
Part Identification
Dispenser Cabinet Assembly
Item Qty. Part # Description
1
1
4
4
296486
213559
294092
Top Cover
Screw, Truss head, Phillips, #10-32x1/2”
Screw, Truss head, Phillips
21 292246 On/Off Switch 15A
3 1 296515 Dispense Switch
4
1 310082
310083
Temperature Controller, Domestic (°F)
Temperature Controller, International (°C)
5
1
2
4
296444
293706
293855
Door Gasket
Hinge, Door
Screw, Truss Head, Phillips, 3/8-16x½”
6 1 296484 Support, Cabinet, Right
7 1 296483 Support, Cabinet, Left
8
1
1
1
2
296512
296505
296506
296508
Kit, Basket Rack, Side Mount
Basket Rack, Side Mount
Drip Tray
Support Pins, Basket Rack
9 1 310125
296671
Drip Tray
Drip Tray Spacer
10 1
1
296480
295845
Access Plate, Condenser Filter
Filter, Condenser
11 1
2
296581
294092
Door, Side Access
Screw, Flat Head, Slotted, #8-32 x 1 In.
12
4
16
16
16
293434
200774
290012
216159
Caster
Screw, Hex-Head 5/16-18x3/4”
Nut, Hex, 5/16-18
Washer, 5/16
Not
shown
1 296533 Door Heater Wire (Dom.120V)
Not
shown 1 296511 Label Set
1
3
10
7
4
5
2
11
12
8
9
6

RAM™ 16-F & 16-Fp Space Saver Frozen Fry Dispensers
Copyright © 2019 Automated Equipment LLC All rights reserved. Published 8/19 13
Parts identification Cont.
Outlet Assembly
Item Qty. Part# Description
1 1 296650 Outlet Door
2 1 310125 Drip Tray
3 1 296671 Drip Tray Divide
r
Interior Parts - Front View
Item Qty. Part# Description
1 1 291411 Probe, Temperature
2 1 291284 P-Clip
3 1 295234 Spacer
4 1 292058 Grommet
5
1
1
1
296525
296178
202366
Hopper
Diverter
Drum
6 4
295699
293720
Hopper Support
Screw, FH, Slotted 10-32x1"
Not
shown 1 293966 Rack, Hashbrown, Optional
2
1
3
4
6
5
2
3
1

RAM™ 16-F & 16-Fp Space Saver Frozen Fry Dispensers
Copyright © 2019 Automated Equipment LLC All rights reserved. Published 8/19
14
Parts identification Cont.
Dispenser Cabinet interior (rear view)
Item Qty. Part # Description
1 1 292246 On/Off Switch
2 1 296515 Dispense Switch
3 1
310082
310083
Controller, Temp., 24V, °F, Dom.,
115V 60HZ
Controller, Temp., 24v, °C, Intl.,
220V 50HZ
4 2 296579 Terminal Block
5
1
1
1
2
296512
296505
296506
296508
Kit, Basket Rack, Side Mount
Basket Rack, Side Mount
Drip Tray
Support Pins, Basket Rack
6 1 293405 Refrigeration Relay
7 1 380051 Power Supply
8 1 380048
Kit, Relay Board (Replacement for 3
and 4 relay control boards)
9 1
See
page 18 Drum Motor Assembly
10 1 See
page 18 Outlet Door Assembly
11 1 295681 Kit, Bumper, Wall (set of 2)
12 1
294339
294723
296329
Compressor Dom. (120V 60HZ, 1/2hp)
Compressor Intl. (240V 50HZ, 1/2hp)
Compressor Intl. (240V 60HZ, 1/2hp)
13 1 292501 Filter Drier
14
4
16
16
16
293434
200774
290012
216159
Caster
Screw, Hex-Head 5/16-18x3/4”
Nut, Hex, 5/16-18
Washer, 5/16
Not
shown 1 293399
294129
Power Cord (Dom.120V)
Power Cord (Int. 240V Euro)
Not
shown
1
1
8
296487
295653
294824
Upper Back Panel
Handle, Plastic
Screw, Truss Head, #10-32 x 3/8”
Not
shown
1
1
6
296482
295653
294824
Lower Back Panel
Handle, Plastic
Screw, Truss Head, #10-32 x 3/8”
Not
shown 1 296572 Terminal Block, Lower
Not
shown 1296575 Harness,120VAC / 220VAC power
Not
shown 1296576 Harness, 24VDC power
10
11
8
1
9
12
13
2
14
4
7
3
6
5

RAM™ 16-F & 16-Fp Space Saver Frozen Fry Dispensers
Copyright © 2019 Automated Equipment LLC All rights reserved. Published 8/19 15
Parts Identification Cont.
Operator Panel Components
Item Qty Part# Description
1 1 296515 Dispense Button
2 1 310082
310083
Temperature Controller, Domestic (°F)
Temperature Controller, International (°C)
3 1 292246 On/Off switch
Not
Shown 1 298533 Door Heater Wire.
Outlet Door Assembly
Item Qty Part# Description Item Qty Part# Description
1 1 290133 Motor, Gear, 24 VDC 4 3 203249 Switch, Micro
2 1 296496 Bracket, Motor Mount Not
shown 1 296493 Shaft, Door Drive
3 1 296495 Plate, Switch Mount Not
shown 1 296500 Door Drive
2
3
1
4
2
1
3

RAM™ 16-F & 16-Fp Space Saver Frozen Fry Dispensers
Copyright © 2019 Automated Equipment LLC All rights reserved. Published 8/19
16
Parts identification Cont.
Drum Motor Assembly
Item Qty Part# Description Item Qty Part# Description
1 1 292546 Motor, Gear, Brushless, 24 VDC 4 4 213136 Cap Screw, Socket HD, #10-
32x1¼”
2 1 202797 Bracket, Mount, Drum motor. 5 1 293318 Drum Shaft
3 4 213140 Washer, Lock, #10 6 2 290653 Set Screw, 3/8”-24 x 3/8”

RAM™ 16-F & 16-Fp Space Saver Frozen Fry Dispensers
Copyright © 2019 Automated Equipment LLC All rights reserved. Published 8/19 17
Refrigeration System
General Operation
The RAM Space Saver employs a cold wall
system. Through the refrigeration process,
heat is transferred to the condensing unit at the
bottom of the cabinet, where it is expelled to the
surrounding outside air. It is extremely
important to allow unrestricted airflow for the
refrigeration process to function properly.
A minimum of 1.0” (26 mm) clearance on both
sides, 2.0” (50 mm) behind the dispenser and
24” (61 cm) to the ceiling is recommended.
The temperature control for the RAM Space
Saver is capable of detecting conditions that fall
outside of normal operation. In such cases, the
controller will generate and display an error to
warn the operator that an abnormal condition
exists and corrective action may need to be
taken. Some error conditions are easily fixed,
while others may require the attention of a
qualified service technician.
See pages 10-12 for a list of error codes and a
troubleshooting guide.
CAUTION: Only trained and/or qualified
personnel, licensed in refrigeration, should
perform service to the refrigeration systems
of this equipment.
The set point or turn off temperature is the
temperature the refrigeration system will
attempt to maintain inside the cabinet. The
default set point temperature is 0°F (-18°C),
and has a range of -10°F to 20° F(-23°C to -
7°C). The set point can be changed using the
Set Button on the Temperature Controller.
Cabinet temperature is displayed on the
Temperature Controller during normal
operation.
Defrost
Because the dispenser employs a cold wall
design, it will be necessary to manually defrost
the cabinet daily. First, remove the product.
Turn the On/Off Switch. Remove Baskets,
Hopper, Outlet Door, Drip Tray and Drip Tray
Divider. Open the Cabinet Door and allow 1
hour to defrost.
Caution: Never use a sharp object to remove
frost build-up. Never drill or otherwise
puncture cabinet walls or top.
Wipe the cabinet dry and sanitize when defrost
is complete.
Required Maintenance
Daily:
Shut off, clean, defrost and inspect cabinet.
(see page 8)
Monthly:
Clean and inspect the condenser filter.
Replace as necessary.
Every 3 months, or as needed as determined
by environmental conditions:
Inspect the door gasket for proper sealing.
Adjust door hinges and/or replace gasket if
needed.
Clean the condenser coils, located behind
the condenser filter. (See below.)
Cleaning the Condenser Filter and Coil
Monthly cleaning of the condensing unit filter will
aid the heat transfer characteristics of the
refrigeration system, increase its efficiency, and
extend the life of the compressor.
Remove the front louvered panel by removing the
retaining screw. Lift and remove the louvered
panel. Slide the condenser filter to the left and
remove.
The filter can be cleaned in warm soapy water
(HCS). Rinse and shake off the excess water.
Replace the filter and access panel.
Every 3 months clean the condenser coils. The
coils are located behind the condenser filter. The
condenser coils should be cleaned with a vacuum
or a soft brush.
Failure to keep the condenser filter and coil
clean and clear of obstructions could result in
temperature loss and damage to the
compressor and may void the warranty.
Warning: Keep ventilation openings in the
appliance enclosure, particularly in the
back-bottom panel, clear of obstruction.

RAM™ 16-F & 16-Fp Space Saver Frozen Fry Dispensers
Copyright © 2019 Automated Equipment LLC All rights reserved. Published 8/19
18
Refrigeration System Components
Condensing Unit Assembly
Item Qty. Part # Description
1 1 295596 Condenser
2 1 295603 Fan Shroud
3 1
294339
294723
296329
Compressor Dom. (120V 60HZ,
1/2hp 404A)
Compressor Intl. (240V 50HZ,
1/2hp 404A)
Compressor Intl. (240V 60HZ,
1/2hp 404A)
Compressor Intl. (240V 50HZ
1/2HP R290 only)
4
1
1
1
295773
295608
295601
293982
Condenser Fan Motor (Dom.120V)
Condenser Fan Motor (Int. 240V)
Blade, Condenser Fan
Bracket, Condenser Fan
5 1 292740 High Pressure Switch
6
1
1
1
294739
294781
296606
295666
294738
294780
296349
295667
293985
294779
296348
295665
Overload Switch (1/2hp Dom.120V
404A)
Overload Switch (1/2hp Int. 240V 50HZ
404A)
Overload Switch (1/2hp Int. 240V 60HZ
404A)
Overload Switch, (Model 16-Fp, R290
only) (1/2hp Int. 240V 50HZ)
Start Relay (1/2hp Dom. 120V 404A)
Start Relay (1/2hp Int. 240V 50HZ
404A)
Start Relay (1/2hp Int. 240V 60HZ
404A)
Start Relay, (Model 16-Fp, R290 only)
(1/2hp Int. 240V 50HZ)
Start Capacitor (1/2hp Dom. 120V
404A)
Start Capacitor (1/2hp Int. 240V 50HZ
404A)
Start Capacitor (1/2hp Int. 240V 60HZ
404A)
Start Capacitor (Model 16-Fp, R290
only) (1/2hp Int. 240V 50HZ)
7 1 292501 Filter Drier (not pictured)
not
shown
1
293907
Per inch
293907
per inch
293907
per inch
293907
per inch
Capillary Tube 86” (218cm) 0.093”
O.D., 0.040” I.D. (Domestic 120V
60HZ, 1/2 HP Comp.)
Capillary Tube 105” (267cm) 0.093”
O.D., 0.040” I.D. (International
240V 50HZ, 1/2 HP Comp.)
Capillary Tube 86” (218cm) 0.093”
O.D., 0.040” I.D. (International
240V 60HZ, 1/2 HP Comp.)
Capillary Tube 122” (267cm) 0.093”
O.D., 0.040” I.D. (International
240V 50HZ, 1/2 HP Comp., R290
only)
1
2
4
3
7
6
