AUTOPMALL MV55G User manual
MV55G User Manual V1.0
Learn howto set up your newAutopmallTracker
Copyright ©2022 Autopmall | All Rights Reserved
1. Main Features
4G+3G
+2G
Vibration
Alarm
Real-time
Tracking
Movement
Alarm
Historical Route
Playback
Plug Out
Alarm
140mAh 4G WiFi Hot spot
(Optional)
Geo-fence Engine Start/
Flame-out Alarm
Overspeed
Alarm
2.Specifications
Device Information
Model
MV55G
Weight
80g
Dimensions
59mm(L) * 45mm(W) * 22mm(H)
Battery Working Time
Tracking Mode：1-2 hours
Working Parameters
WorkingVoltage
DC 9V - 50V
Battery Capacity
3.7V140mAh Lion Polymer battery
Working Temperature
-20℃ - 75℃
Working Humidity
10%-85%RH non-condensing
Cellular Specifications
Working Frequency
MV55G(EU):
4G LTE-FDD: B1/B3/B7/B8/B20/B28;
4G LTE-TDD: B38/B40/B41;
3G WCDMA: B1/B8;
2G GSM/EDGE: B3/B8;
MV55G(AU):
4G LTE-FDD: B1/B2/B3/B4/B5/B7/B8
/B28/B66;
4G LTE-TDD: B40;
3G WCDMA: B1/B2/B4/B5/B8;
2G GSM/EDGE: B2/B3/B5/B8;
SIMCard
Micro SIM Card
Cellular Antenna
Built-in
ON / O F F
GNSS Specifications
Positioning Type
GPS+BEIDOU+LBS
GPS Antenna
Built-in
Cold Start
≤32 Seconds
Hot Start
≤1 Second
Tracking sensitivity
-162 dBm
GPS Channels
64
Position Accuracy
5-10m
3. Activate Device
Install the SIM card via the correct direction as below:
LED
Event
State
POWER LED (RED)
Charging
Solid
Charger inserted and battery has been fully charged
Dark
Charger has not been inserted
Dark
CELL LED
(YELLOW)
Searching for network
Flash every 1 second
Network has been registered
Solid
GPS LED (BLUE)
GPS is in fixing
Flash every 1 second
GPS has fixed
Solid
ALLLED
Deviceis working but stopped more than 5min
ALL LED TURN OFF
Devicehas not been turn on
Deviceran out ofbattery
Please get the exact correct APN name from local SIM card provider.Take the tracker
to a good signal place for operation and configure the APN for it as below:
SMS Command
Format
Reply
Example
Note
APN,ApnName,User,
Password#
SET APN OK
APN,orange,
orange,orange#
If the SIM card has APN user and APN
password, then use this command.
APN,ApnName#
SET APN OK
APN,internet#
If the SIM card operator doesn't have APN
user and APN password, then please use this
command.
Note: The APN information is very important, it must 100% correct to match with the sim
card of the tracker, if you configured wrong APN, the tracker also will reply "SET APN ok"
but it will can't get online!
4. Package Content
GPS Main Unit x 1
User Manual x 1
Quick Start Guide x 1
Package Box x 1
5. Functions Explanation
Please follow with the quick user guide carefully!
a. VibrationAlert：
This vibration alert function just work under
stationary status.How to use this function:
*
First Step:
Configure SOS numbers for
the tracker by this sms command：
SOS,A,1st number,2ndnumber,3rd number#
3 SOS numbers supports atthe most.
*
SecondStep:
Enable the device to enter into arm
mode by this sms command: ARM#
For example:
*
ThirdStep:
Configure the alarm ways by thissms command：SENALM,[A][,M]#
A=ON/OFF, default: OFF;
M=0/1/2, way of alarming,( 0 :Platform only, 1: SMS+Platform,
2: Platform+SMS+phone call, Default:1)
*
Fourth Step:
Keep the device under stationary status more than 5min to let it enter into sleep arm
mode;
*
Five Step:
Vibrate the device thenthe tracker will send the vibration alarm messages.
SOS,A,12345678910#
SET SOS NUMBER OK
ARM#
SET ARM MO DE OK
SENALM,ON,1#
SET VIBRATE ALARM OK
MV55G
b. EngineStatus ChangeDetection：
Once the OBD tracker detected engine start or flame-out it will send alarm message out, and
the alarm ways isconfigurable by SMS, call and tracking platform.
*
First Step:
Configure SOS numbers for
the tracker by this sms command：
SOS,A,1st number, 2nd number,3rd number#
3 SOS numbers supports atthe most.
* Second Step:
Configure thealarm ways via
this SMS command
：
ACCALM,ON,A,M,N#
Alarm ways: A=ON/OFF, Default:ON;
M=0/1/2(wayof alarm)( 0 : GPRS only, 1: SMS+GPRS,
2: GPRS+SMS+CALL, Default:1);
For example:
N=0/1/2;(0: ACC ON&OFF Alarm; 1: ACC ONAlarm; 2: ACC OFF Alarm; Default:0 )
c. Plug out alarm：
If someone plug out thedevice it will send alarm message out, and the alarmwaysisconfig-
urable by SMS,calland tracking platform.
*
First Step:
Configure SOS numbers for t
he tracker by this sms command：
SOS,A,1st number,2nd number,3rd number#
3 SOS numbers supports at the most.
* Second Step:
enable this function by this command：PWRALM,A,B#
A=ON/OFF,Default:ON;
Ways of alarming:
B=0/1/2 (0: Platform only, 1: SMS+Platform,
2:Platform+SMS+Call,Default:2)
For example:
SOS,A,12345678910#
SET SOS NUMBER OK
PWRALM,ON,1#
SET POWER ALA RM OK
MV55G
SOS,A,12345678910#
SET SOS NUMBER OK
ACCALM,ON,1#
SET ACC ALA RM OK
MV55G
6. Installation Recommendation
Area D/E
A few cars...
Area C
Dongfeng Citroen,etc.
Area B
Honda,Lexus,etc.
Where is the OBD interface?
Most of the car‘s OBD interface is located in A and B,
A small part of the car will be in C,D and E.
Area A
VW、Ford、Toyota、Hyundai 、Citroen、BMW、
etc./Most cars.
7. Troubleshooting
Type
Use
Unable to connect to
tracking platform
Check the APN and settings.
Check whether the data service of SIM card is enabled.
Check the balance of SIM card.
Tracker shows offline
Check whether external power is still connected.
Check if the vehicle entered network blind area.
Check the balance of SIM card.
Unable to locate
Make sure the top side facing upward without metallic things
shielded.
Make sure it’s not in area without satellite coverage.
Location drift
In area with poor GNSS signal (tall building around or
basement), drifting may happen.
Check whether vibration happens around totrigger the
accelerator.
No command reply
Make sure command format is correct.
Vehicle may be in network blind area.
Make sure SIMcard is well inserted and has SMS service.
8. Full SMS Commands List
Functions
Command Format
Explanation
APN Setting
APN,Network name[,name,password]#
APN,CMNET# (if no name & Password)
APN,internet,internet,internet# (if with name
& Password)
Server Setting
If set with Domain Name:SERVER,1,
Domain,Port#
SERVER,1,d.micodus.net,7700#
If set with IP: SERVER,0,IP,Port#
SERVER,0,47.254.77.28,7700#
Check IMEI
IMEI#
Restore factory settings
FACTORY#
Restart device
RESET#
Internet Traffic Switch
INTERNET,ON#
INTERNET,OFF#
Functions
Command Format
Explanation
Version Inquiry
VERSION#
Parameter Inquiry
PARAM#
Status Inquiry
STATUS#
BATTERY: XX% (Built-inBattery PowerPercent)
INTERNET: CLOSED (No Network) FAILED (Conn-
ecting Network orFailure) SUCCESS (Connected
to Network）
NET: NONE (No GSM Signal),HIGH / MED /
LOW (Signal Strength)
GPS: CLOSED (GPS Module Closed) , FIXED,
N (Positioned and satellite number), UNFIX,
0 (Not Positioned yet)
SPEED:30KM/H
ACC: ON / OFF (ACC on or off)
POWER: CONNECTED / DISCONNECTED (Power
Connected or Disconnected), 12.5V (Vehicle
battery voltage)
SENSOR: ON/OFF (Sensor on or off), LEVEL:
3 (Sensitivity level 1-9)
FORTIFIED STATE: ARM (Arm or Disarm)
Latitude&Longitude
Inquiry
WHERE#
Map URL Inquiry
URL#
Address Inquiry
POSITION#
NOTE: Reply message’s language is determined by
device’s language setting, if get position content
failed, device will reply Google Map location link.
Time Zone Setting
GMT,Time zone orientation,
Whole Time Zone[,Half Time Zone]#
GMT,E,8# (if no half time zone)
GMT,W,9,30# (ifhas half timezone)
NOTE: Parameter : E / W；0~ 12; 0/15/30/45
Set the angle upload
ANGLEREP,[X][,A][,B]#
X=ON/OFF, default：ON; A=5～180 degrees,
diversion angle degree, default：30 degrees；B=2～
5 seconds, detecting time, default：3 seconds,
ANGLEREP,OFF#
Mileage Statistics
MILEAGE,[A],[B]#
A=ON/OFF, On/Off mileage calculation, default: Off
B=0～999999，Mileage initial value , unit：km ;
default: 0, mileage return to zero
MIELEAGE#
Query current mileage
Add Center Number
CENTER,A,center number#
CENTER,A,13800138000#
NOTE: Center number is only used for cutting off
power & oil, it can only be set by SOS Administrator
when using this command by SMS.
Functions
Command Format
Explanation
Delete Center Number
CENTER,D#
Add SOS Administ-
rator Number
SOS,A,1st number,
2nd number,3rd number#
Set 3 numbers at a time:
SOS,A,13800138000,1380013800 1,13800138002#
Set the first numberseparately:
SOS,A,13800138000#
Set thesecond number separately:
SOS,A,,13800138001#
Means to set 3rd number separately:
SOS,A,,,13800138002#
DeleteSOS Admin-
istratorNumber
SOS,D,1st number,
2nd number,3rd number#
or SOS,D,1,2,3#
Directly delete the number:
SOS,D,13800138000#
Delete 1st number:
SOS,D,1#
Delete 2nd number:
SOS,D,2#
Delete the 2nd and 3rd number:
SOS,D,2,3#
Data Upload Time
Interval
TIMER,T1,T2#
T1(upload interval when acc on):0 or5-18000(seconds),
0 means no upload, default is 10;
T2(upload interval when acc off):0 or5-18000(seconds),
0 means no upload, default is 180;
HeartbeatPacketUpload
HBT,time#
HBT,3#
NOTE: Range :1-60min, default 3min.
Sensor Sensitivity
LEVEL,A#
LEVEL,2#
NOTE: A：Sensitivity Level 1-9 (1-9 is from week to
strong vibration)
Arm manually
ARM#
Set the device into arm mode
Disarm manually
DISARM#
Set the device out of armmode
Vibration Alarm Setting
SENALM,[A][,M]#
A=ON/OFF, default: OFF;
M=0/1/2, way of alarming, 0 :GPRS only, 1: SMS+GPRS,
2 : GPRS+SMS+phone call, default:2
SENALM,OFF#
Shift Alarm Setting
SHIFT,[A][,B][,M]#
Example: SHIFT,ON,100,1# ( Means Setting 100 meters
shift alarm range, when the ignition turned off, vehicle’s 100
meters’ shift will trigger the alarm. )
A=ON/OFF; default:ON
B=Shift Distance (Range: 100-9999m)
M=0/1/2; way of alarm, 0 : GPRS only, 1: SMS+GPRS,
2: GPRS+SMS+CALL, default:1
SHIFT,OFF#
Functions
Command Format
Explanation
Auto Arm By ACC
ACCARM,ON,M#
M=5-1800s, default: 60s
ACCARM,OFF#
Close auto arm by acc function
ACCStatus Change
Alarm
ACCALM,ON,A,M,N#
A=ON/OFF, Default: ON;
M=0/1/2 (way of alarm); 0: GPRS only, 1: SMS+GPRS,
2: GPRS+SMS+CALL, Default:1;
N=0/1/2; 0: ACC ON&OFF Alarm; 1: ACC ON Alarm;
2: ACC OFFAlarm; Default:0
ACCALM,OFF#
Close engine start/flame-out alarm
Power Disconnect
Alarm
PWRALM,A,B#
A=ON/OFF, default ON;
B=0/1/2, ways of alarming, 0: GPRS only, 1: SMS+GPRS,
2 : GPRS+SMS+phone call, default：2；
PWRALM,OFF#
Close power disconnect alarm
9. Any Questions?
E-mail: support@autopmall.com
Skype: autopmall
10. Download the APP
Search "MiCODUS" in iOS APP store or Google Play
Store, or just scan the QR code as below to download
MiCODUS APP:
Download on the
APP Store
Download for
Android
