AV-Box MMX1616 User manual

www.av-box.ru
AV-BOX MMX1616
Modular Matrix Switcher 16x16
User Manual

Modular Matrix Switcher 16x16
Preface
Read this user manual carefully before using the product. Pictures are shown in this
manual for reference only. Different models and specifications are subject to real
product.
This manual is only for operation instruction, please contact the local distributor for
maintenance assistance. The functions described in this version were updated till July,
2018. In the constant effort to improve the product, we reserve the right to make
functions or parameters changes without notice or obligation. Please refer to the
dealers for the latest details.
Trademarks
Product model, AV-BOX and logo are trademarks of AV-BOX. Any other trademarks
mentioned in this manual are acknowledged as the properties of the trademark
owner. No part of this publication may be copied or reproduced without the prior
written consent of AV-BOX.
FCC Statement
This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference
to radio communications. It has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a commercial
installation.
Operation of this equipment in a residential area is likely to cause interference, in
which case the user at their own expense will be required to take whatever measures
may be necessary to correct the interference.
Any changes or modifications not expressly approved by the manufacture would void
the user’s authority to operate the equipment.

Modular Matrix Switcher 16x16
SAFETY PRECAUTIONS
To ensure the best from the product, please read all instructions carefully before using
the device. Save this manual for further reference.
Unpack the equipment carefully and save the original box and packing material for
possible future shipment
Follow basic safety precautions to reduce the risk of fire, electrical shock and injury
to persons.
Do not dismantle the housing or modify the module. It may result in electrical shock
or burn.
Using supplies or parts not meeting the products’ specifications may cause damage,
deterioration or malfunction.
Refer all servicing to qualified service personnel.
To prevent fire or shock hazard, do not expose the unit to rain, moisture or install this
product near water.
Do not put any heavy items on the extension cable in case of extrusion.
Do not remove the housing of the device as opening or removing housing may
expose you to dangerous voltage or other hazards.
Install the device in a place with fine ventilation to avoid damage caused by
overheat.
Keep the module away from liquids.
Spillage into the housing may result in fire, electrical shock, or equipment damage. If
an object or liquid falls or spills on to the housing, unplug the module immediately.
Do not twist or pull by force ends of the optical cable. It can cause malfunction.
Do not use liquid or aerosol cleaners to clean this unit.Always unplug the power to
the device before cleaning.
Unplug the power cord when left unused for a long period of time.
Information on disposal for scrapped devices: do not burn or mix with general
household waste, please treat them as normal electrical wastes.

Modular Matrix Switcher 16x16
Table of Contents
1. Product Introduction....................................................................................................1
1.1. Features ...........................................................................................................1
1.2. Signal Card.......................................................................................................2
1.3. Package List.....................................................................................................3
2. Panel Description........................................................................................................4
2.1. Matrix Front Panel ............................................................................................4
2.2. Matrix Rear Panel.............................................................................................5
2.3. Signal Card.......................................................................................................6
2.3.1. 4I-VA.......................................................................................................6
2.3.2. 4O-VG ....................................................................................................7
2.3.3. 4O-VS.....................................................................................................8
2.3.4. 4I-VH & 4O-VH.......................................................................................8
2.3.5. 4I-HS & 4O-HS.....................................................................................10
2.3.6. 4I-UH & 4O-UH.....................................................................................11
2.3.7. 4I-SS & 4O-SS .....................................................................................12
2.3.8. 4I-SH & 4O-SH.....................................................................................13
2.3.9. 4I-AV & 4O-AV......................................................................................14
2.3.10. 4I-DS & 4O-DS...................................................................................14
2.3.11. 4I-BT & 4O-BT....................................................................................17
2.3.12. 4I-BTS & 4O-BTS...............................................................................19
2.3.13. 4I-UFS & 4O-UFS...............................................................................20
3. System Connection...................................................................................................22
3.1. Usage Precaution...........................................................................................22
3.2. Connection Diagram.......................................................................................22
4. Button Control...........................................................................................................23
5. IR Remote Control....................................................................................................24
6. RS232 Control..........................................................................................................25
6.1. RS232 Communication Port...........................................................................25
6.2. RS232 Control Software.................................................................................25
6.3. RS232 Communication Command .................................................................27

Modular Matrix Switcher 16x16
6.3.1. System Control Command....................................................................28
6.3.2. Signal Switching Command..................................................................28
6.3.3. Preset Command..................................................................................29
6.3.4. EDID Management Command..............................................................29
6.3.5. 4I-VA Input Card Command..................................................................30
6.3.6. 4O-VS Output Card Command.............................................................31
6.3.7. 4I-VH Input Card Command.................................................................33
6.3.8. 4O-VH Output Card Command.............................................................35
6.3.9. 4I-HS Input Card Command.................................................................37
6.3.10. 4O-HS Output Card Command...........................................................38
6.3.11. 4I-UH Input Card Command...............................................................39
6.3.12. 4I-SH Input Card Command...............................................................39
6.3.13. 4O-SH Output Card Command...........................................................40
6.3.14. 4I-AV Input Card Command................................................................43
6.3.15. 4O-AV Output Card Command...........................................................44
6.3.16. 4I-DS Input Card Command...............................................................44
6.3.17. 4O-DS Output Card Command...........................................................45
6.3.18. 4I-SS Input Card Command ...............................................................48
6.3.19. 4O-SS Output Card Command...........................................................49
6.3.20. 4I-BT Input Card Command................................................................49
6.3.21. 4I-BTS Input Card Command.............................................................49
6.3.22. 4O-BTS Output Card Command.........................................................51
6.3.23. 4I-UFS Input Card Command.............................................................53
6.3.24. 4O-UFS Output Card Command ........................................................54
7. TCP/IP Control (Optional).........................................................................................58
7.1. Control Mode..................................................................................................58
7.2. TCP/IP Communication Software ...................................................................60
7.3. TCP/IP Configuration......................................................................................61
8. Specification .............................................................................................................62
8.1. Main Unit ........................................................................................................62
8.2. Signal Card.....................................................................................................62

Modular Matrix Switcher 16x16
8.2.1. 4I-VA.....................................................................................................62
8.2.2. 4O-VG ..................................................................................................63
8.2.3. 4O-VS...................................................................................................63
8.2.4. 4I-VH & 4O-VH.....................................................................................64
8.2.5. 4I-HS & 4O-HS.....................................................................................64
8.2.6. 4I-UH & 4O-UH.....................................................................................65
8.2.7. 4I-SS & 4O-SS .....................................................................................66
8.2.8. 4I-SH & 4O-SH.....................................................................................66
8.2.9. 4I-AV & 4O-AV......................................................................................67
8.2.10. 4I-DS & 4O-DS...................................................................................68
8.2.11. 4I-BT & 4O-BT....................................................................................68
8.2.12. 4I-BTS & 4O-BTS...............................................................................69
8.2.13. 4I-UFS & 4O-UFS...............................................................................70
9. Troubleshooting & Maintenance ...............................................................................71
10. Customer Service...................................................................................................73

Modular Matrix Switcher 16x16
1
1. Product Introduction
The MMX1616 is a high-performance video and audio modular matrix switcher
supporting max 16 input signal sources and 16 output display synchronously. It
supports different video signals with cross switching. Every video or audio signal is
transmitted and switched independently to decrease signal attenuation. The matrix
supports various changeable cards including HMDI, DVI, VGA, SDI and HDBaseT etc.
Users can choose to insert different signal card for different application.
The matrix boasts power off memory and audio signal can be switched separately or
jointly with video signal. It has 1 RS232 port and 1 optional TCP/IP port for convenient
control from third-party.
With its flexible design, the matrix can be used for different project and tend to be an
all-in-one solution. It is the combo solution for multimedia conference rooms, control
rooms, broadcasting rooms, shopping center etc. It will handle all the audiovisual
management, including the switching, driving, scaling etc.
1.1. Features
Modular chassis with configurable I/O slots, ranging from 4x4 to 16x16.
Various I/O cards, includes HDMI, HDBaseT, SD/HD/3G-SDI, DVI and VGA cards
(Compatible with YUV, YC & CVBS.) to configure any matrix.
Truly cross-point switching, any input to any output, regardless signal format.
Supports HDMI1.4 and 1080P 3D.
Integrated HDBaseT technology.
Controllable via button, RS232 & optional TCP/IP, also compatible with 3rd parties
control.
HDCP compliant.
LCD display.

Modular Matrix Switcher 16x16
2
1.2. Signal Card
The matrix supports multiple signal cards as listed in the following charts:
Signal
Model
Description
VGA
4I-VA
1080P seamless VGA input card with 4 VGAand 4
external L+R audio ports.
4O-VG
1080P VGA output card with 4 VGA and 4 external stereo
audio ports.
4O-VS
1080P seamless VGA output card with 4 VGA and 4
external L+R audio ports.
VGA+HDMI
4I-VH
1080P seamless VGA+HDMI input card with 2 VGA, 2
HDMI and 4 external L+R audio ports.
4O-VH
1080P seamless VGA+HDMI output card with 2 VGA, 2
HDMI and 4 external L+R audio ports.
HDMI
4I-HS
1080P seamless HDMI input card with 4 HDMI and 4
external L+R audio ports.
4O-HS
1080P seamless HDMI output card with 4 HDMI and 4
external L+R audio ports.
4I-UH
4K HDMI input card with 4 HDMI, and 4 external L+R
audio ports.
4O-UH
4K HDMI output card with 4 HDMI and 4 external L+R
audio ports.
SDI
4I-SS
1080P seamless SDI input card with 4 SDI input and 4
loop output ports.
4O-SS
1080P seamless SDI output card with 4 SDI output and 4
loop output ports.
SDI+HDMI
4I-SH
1080P seamless SDI+HDMI input card with 2 SDI, 2 SDI
LOOP, 2 HDMI and 2 external L+R audio ports.
4O-SH
1080P seamless HDMI+SDI output card with 2 SDI, 2 SDI
LOOP, 2 HDMI and 2 external L+R audio ports.
CVBS
4I-AV
1080P seamless CVBS input card with 4 CVBS and 4
external L+R audio ports.

Modular Matrix Switcher 16x16
3
4O-AV
1080P seamless CVBS output card with 4 CVBS and 4
external L+R audio ports.
DVI
4I-DS
1080P seamless DVI input card with 4 DVI ports.
4O-DS
1080P seamless DVI output card with 4 DVI ports.
HDBaseT
4I-BT
4K HDBaseT input card with 4 HDBT, 4 RS232 and 4
external stereo audio ports.
4O-BT
4K HDBaseT output card with 4 HDBT, 4 RS232 and 4
external stereo audio ports.
4I-BTS
1080P seamless HDBaseT input card with 4 HDBT, 4
RS232 and 4 external stereo audio ports.
4O-BTS
1080P seamless HDBaseT output card with 4 HDBT, 4
RS232 and 4 external stereo audio ports.
OPTICAL
4I-UFS
1080P seamless OPTICAL input card with 4 OPTICAL
ports.
4O-UFS
1080P seamless OPTICAL output card with 4 OPTICAL
ports.
1.3. Package List
1x Modular Matrix Switcher 16x16
1x IR Remote
1x RS232 Cable
4x Plastic Cushions
1x Power Cord
1 x User Manual
Note: Please contact your distributor immediately if any damage or defect in the
components is found.

Modular Matrix Switcher 16x16
4
2. Panel Description
2.1. Matrix Front Panel
No.
Name
Description
①
IR
Built-in IR sensor to receive IR signal sent from IR remote.
②
Power LED
The LED illuminates red when power is applied.
③
LCD Screen
Shows real-time operation status.
④
INPUTS
Back-lit buttons for input selection, ranges from 0~ 9, 16
selectable channels in total.
⑤
OUTPUTS
Back-lit buttons for output selection, ranges from 0 ~ 9, 16
selectable channels in total.
⑥
MENU
AV: Switch AV signal from AV signal card & audio signal from
audio card synchronously.
‚: Division button, to divide the output channels when switching
to more than one channel.
UNDO: Undo button, to resume to the status before the
command just performed.
ENTER: confirm switching operation. Operation will not be
executed by the matrix without confirmation.
ALL: select all input/output channel
THROUGH: To transfer the signals directly to the
corresponding output channels.
: Backspace button, to backspace the last press.
INPUTS
OUTPUTS
MENU
AV
Enter
1 2 3456 7 8 9 0
1 2 3456 7 8 9 0
IR
SYSTEM MONITOR ,Undo
All Through
1346
25

Modular Matrix Switcher 16x16
5
2.2. Matrix Rear Panel
No.
Name
Description
①
INPUTS
Signal card slots to insert necessary input cards.
②
OUTPUTS
Signal card slots to insert necessary output cards.
③
Power Switch
Switch between AC110V and AC230V to access different
power
④
TCP/IP
(Optional) Used for TCP/IP control port
⑤
RS232
Serial control port, connect with RS232 port of control device.
⑥
Power ports
Connect with household alternating current power, including
one redundant power.
Note: There are only 4 input and 4 output slots for the matrix, which enables only 4
input cards and 4 output cards to be installed. The input/output cards can be changed
based on your requirements and supports hot plug and play.
OUTPUTS OUTPUTS
VGA 3VGA 2VG A 1 VGA 4
OUTPUTS OUTPUTS
HDMI 3
HDMI 2HDMI 1 HDMI 4
INPUTS INPUTS
DVI 1 DVI 2 DVI 3 DVI 4
INPUTS INPUTS
HDMI 3
HDMI 2HDMI 1 HDMI 4
INPUTS INPUTS
VGA 3VGA 2VG A 1 VGA 4
OUTPUTS
DVI 1 DVI 2 DV I 3 DVI 4
OUTPUTS
RS232
TCP /IP CON TROL
AC110 AC230
Opt ical 1 Opt ical 2 Opt ical 3 O ptica l 4
Tx Rx Tx Rx
Aud io 1 Aud io 2 Aud io 3 Aud io 4
IN
IN IN IN
RS23 2
1
2
RS23 2
1
2
INPUTS INPUTS
Opt ical 1 Opt ical 2 Opt ical 3 O ptical 4
Tx Rx Tx Rx
Aud io 1 Aud io 2 Aud io 3 Aud io 4
OUT OUT OUT OUT
RS23 2
1
2
RS23 2
1
2
OUTPUTS OUTPUTS
123
4
5
6

Modular Matrix Switcher 16x16
6
2.3. Signal Card
The matrix supports expansion through various changeable input/ output cards of
different signals including DVI, HDMI, VGA, twisted pair, SDI etc. Here is a brief
introduction to the changeable cards.
2.3.1. 4I-VA
1080P seamless VGA input card with 4 VGA and 4 external L+R audio ports.
4I-VA
Supports seamless switching, it can be used in combination with other seamless
output signal card.
Supports video upscaling, converting input video to 1080P or 1920x1200P.
Supports input resolution selection.
Manually select VGA (RGBHV), YPbPr, S-VIDEO or C-VIDEO signal format.
Compatible with HDMI and DVI signal input.
Supports YCBCR or RGB chrominance space.
Supports VGA input signal auto correction.
Supports 4 external L+R audio inputs and audio channel control.
Pin layout of female VGAconnector:
Pin
Signal
Pin
Signal
1
RED
9
KEY/PWR
2
GREEN
10
GND
3
BLUE
11
ID0/RES
4
ID2/RES
12
ID1/SDA
5
GND
13
HSync
6
RED_RTN
14
VSync
7
GREEN_RTN
15
ID3/SCL
8
BLUE_RTN

Modular Matrix Switcher 16x16
7
When connecting to YPbPr or C-VIDEO signal, insert converting cables according to
specific pin definitions (see the figures below):
VGA- YPbPr:
Pin
Signal
Pin
Signal
1
RED
6
GND
2
GREEN
7
GND
3
BLUE
8
GND
Other pins are not used.
VGA- C-VIDEO:
Pin
Signal
Pin
Signal
1
RED
6
GND
7
GND
8
GND
Other pins are not used.
2.3.2. 4O-VG
1080P VGA output card with 4 VGA and 4 external stereo audio ports.
4O-VG
Only supports VGA video format.
The bandwidth is up to 350MHz (-3dB).
The default output resolution is 1920x1080P@60Hz.
Supports 4 external stereo audio outputs.

Modular Matrix Switcher 16x16
8
2.3.3. 4O-VS
1080P seamless VGA output card with 4 VGA and 4 external L+R audio ports.
4O-VS
Supports seamless switching, it can be used in combination with other seamless
input signal card.
Supports output resolution selection.
Manually select VGA (RGBHV), YPbPr, S-VIDEO or C-VIDEO signal format.
Supports 4 external L+R audio outputs and audio channel control.
When it is used with 4I-VA input card, the ratio of input and output is 1:1.
Supports NTSC or PAL.
Note: When the 4O-VS output card is used with the seamless input card except 4I-AV,
the video resolution of all input sources should be set to same resolution by RS232
commands to ensure the seamless output.
2.3.4. 4I-VH & 4O-VH
1080P seamless VGA+HDMI input card with 2 VGA, 2 HDMI and 4 external L+R
audio ports.
4I-VH
Supports seamless switching, it can be used in combination with other seamless
output signal card.
Supports HDMI 1.3 and HDCP 1.3.
Compatible with HDMI and DVI signal input.
Manually select VGA (RGBHV), YPbPr, or C-VIDEO signal format, and supports
video upscaling, converting input source to 1080P or 1920x1200P.
Supports input resolution selection.
Supports YCBCR or RGB chrominance space.

Modular Matrix Switcher 16x16
9
Supports image brightness, contrast, chrominance, sharpness, color temperature,
aspect ratio, and image mode setting.
Supports 4 external L+R audio inputs and audio channel control.
1080P seamless VGA+HDMI output card with 2 VGA, 2 HDMI and 4 external L+R
audio ports.
4O-VH
Supports seamless switching, it can be used in combination with other seamless
input signal card.
Supports HDMI 1.2 and HDCP 1.3.
Manually select VGA (RGBHV), YPbPr, or C-VIDEO signal format.
Supports output resolution selection, and it is up to 1920x1080P@60Hz.
Supports 4 external L+R audio outputs and audio channel control.
Pin layout of the HDMI connectors (female).
No.
Signal
No.
Signal
1
TMDS Data 2+
20
SHELL
2
TMDS Data 2
Shield
19
Hot Plug Detect
3
TMDS Data 2-
18
+5V Power
4
TMDS Data 1+
17
Ground
5
TMDS Data 1
Shield
16
DDC Data
6
TMDS Data 1-
15
DDC Clock
7
TMDS Data 0+
14
No Connect
8
TMDS Data 0
Shield
13
CEC
9
TMDS Data 0-
12
TMDS Clock-
10
TMDS Clock+
11
TMDS Clock
Shield

Modular Matrix Switcher 16x16
10
2.3.5. 4I-HS & 4O-HS
1080P seamless HDMI input card with 4 HDMI and 4 external L+R audio ports.
4I-HS
Supports seamless switching, it can be used in combination with other seamless
output signal card.
Supports HDMI 1.3 and HDCP 1.2.
Compatible with DVI signal input.
Supports input resolution selection, and it is up to 1920x1080P@60Hz.
Supports image brightness, contrast, chrominance, sharpness, color temperature,
aspect ratio, and image mode setting.
Supports 4 external L+R audio inputs and audio channel control.
1080P seamless HDMI output card with 4 HDMI and 4 external L+R audio ports.
4O-HS
Supports seamless switching, it can be used in combination with other seamless
input signal card.
Supports HDMI 1.3 and HDCP 1.2.
Supports output resolution selection, and it is up to 1920x1080P@60Hz.
Supports 4 external L+R audio outputs and audio channel control.
Note: When the 4O-HS output card is used with the seamless input card except 4I-HS,
the video resolution of all input sources should be set to same resolution by RS232
commands to ensure the seamless output.

Modular Matrix Switcher 16x16
11
2.3.6. 4I-UH & 4O-UH
4K HDMI input card with 4 HDMI, and 4 external L+R audio ports.
4I-UH
Supports HDMI 1.4 and HDCP 1.4.
Compatible with DVI signal.
Input resolution is up to 4Kx2K, and supports 1080P 3D.
Synchronously switch audio and video.
Supports 4 external L+R audio inputs and audio channel control.
Note: When the 4I-UH input card is used with the 1080P output card, the video
resolution must be set to 1080P to ensure reliable output.
4K HDMI output card with 4 HDMI, and 4 external L+R audio ports.
4O-UH
Supports HDMI 1.4 and HDCP 1.4.
Compatible with DVI signal.
Output resolution is up to 4Kx2K, and supports 1080P 3D.
Synchronously switch audio and video.
Supports 4 external L+R audio outputs.

Modular Matrix Switcher 16x16
12
2.3.7. 4I-SS & 4O-SS
1080P seamless SDI input card with 4 SDI input and 4 loop output ports.
4I-SS
Supports seamless switching, it can be used in combination with other seamless
output signal card.
Supports input resolution selection, and the input resolution can be upscaled to
1920x1080P@60Hz.
Automatically recognize SDI, HD-SDI or 3G-SDI signal format.
Supports image brightness, contrast, chrominance, sharpness, color temperature,
aspect ratio, and image mode setting.
1080P seamless SDI output card with 4 SDI output and 4 loop output ports.
4O-SS
Supports seamless switching, it can be used in combination with other seamless
input signal card.
Supports output resolution selection, it is up to 1920x1080P@60Hz.
Automatically recognize SDI, HD-SDI or 3G-SDI signal format.
Note: When the 4O-SS output card is used with the seamless input card except 4I-SS,
the video resolution of all input sources should be set to same resolution by RS232
commands to ensure the seamless output.

Modular Matrix Switcher 16x16
13
2.3.8. 4I-SH & 4O-SH
1080P seamless SDI+HDMI input card with 2 SDI, 2 SDI LOOP, 2 HDMI and 2
external L+R audio ports.
4I-SH
Supports seamless switching, it can be used in combination with other seamless
output signal card.
Supports HDMI 1.3 and HDCP 1.3.
Compatible with DVI signal.
Supports input resolution selection, and the default is 1920x1080P@60Hz.
Automatically recognize SDI, HD-SDI or 3G-SDI signal format.
Supports image brightness, contrast, chrominance, sharpness, color temperature,
aspect ratio, and image mode setting.
Supports 2 external L+R audio inputs and audio channel control.
1080P seamless SDI+HDMI output card with 2 SDI, 2 SDI LOOP, 2 HDMI and 2
external L+R audio ports.
4O-SH
Supports seamless switching, it can be used in combination with other seamless
input signal card.
Supports HDMI 1.3 and HDCP 1.3.
Compatible with DVI signal.
The default output resolution is 1920x1080P@60Hz.
Automatically recognize SDI, HD-SDI or 3G-SDI signal format.
The transmission distance of 1080P SDI signal is up to 60 meters.
Supports 2 external L+R audio outputs and audio channel control.

Modular Matrix Switcher 16x16
14
2.3.9. 4I-AV & 4O-AV
1080P seamless CVBS input card with 4 CVBS and 4 external L+R audio ports.
4I-AV
Supports seamless switching, it can be used in combination with other seamless
output signal card.
Supports input resolution selection, and it is up to 1920x1080P@60Hz.
Supports image brightness, contrast, chrominance, sharpness, color temperature,
aspect ratio, and image mode setting.
Supports 4 external L+R audio inputs and audio channel control.
1080P seamless CVBS output card with 4 CVBS and 4 external L+R audio ports.
4O-AV
Supports seamless switching, it can be used in combination with other seamless
input signal card.
The output resolution supports 480i or 576i.
Supports NTSC or PAL.
Supports 4 external L+R audio outputs and audio channel control.
2.3.10. 4I-DS & 4O-DS
1080P seamless DVI input card with 4 DVI ports.
4I-DS
Supports seamless switching, it can be used in combination with other seamless
output signal card.
Supports HDMI 1.3 and HDCP 1.4.
