Apantac HDM2.0-4x4-UHD-II User manual

HDM2.0-4x4-UHD-II
APANTAC LLC, 10200 SW Allen Blvd. Suite C, Beaverton, OR 97005 USA
[e-mail], TEL: [phone], FAX: [phone]
4x4 UHD with HDR HDMI Matrix
HDM2.0-4x4-UHD-II
User Manual
V1.1

HDM2.0-4x4-UHD-II
APANTAC LLC, 10200 SW Allen Blvd. Suite C, Beaverton, OR 97005 USA
[email protected], TEL: [phone], FAX: [phone]
1
Table of Contents
1.0 What’s in the Box ..................................................................................... 2
2.0 Key Features............................................................................................. 2
3.0 Specifications........................................................................................... 2
4.0 Front Panel .............................................................................................. 3
5.0 Rear Panel ................................................................................................ 4
5.1 IR Blaster Pin Definitions.................................................................................4
5.2 IR Receiver Pin Definitions ............................................................................ 5
5.3 RS-232..................................................................................................................... 5
5.4 Network Configuration ................................................................................... 5
5.5 Telnet...................................................................................................................... 6
5.6 TCP .......................................................................................................................... 6
5.7 Web .........................................................................................................................6
5.8 RS-232 amd TCP/IP commands...........................................................................7
Copywright & Trademark ............................................................................ 11
Warranty Statement ................................................................................... 11
Comformity .................................................................................................. 12
Limitation of Liability .................................................................................. 12
Contact Apantac Technical Support .......................................................... 13

HDM2.0-4x4-UHD-II
39
1.0 What’s in the Box
QTY
PRODUCT
1
HDM2.0-4x4-UHD-II
2 Rack Ears
4
Foot Pads
1 IR Receiver Cable
1
Remote Control
2.0 Key Features
–Supports resolutions up to UHD@60Hz (4:4:4)
–Supports pixel-clock up to 600 MHz
–Supports HDR
–Supports LPCM, Dolby TrueHD, and DTS-HD Master audio
–HDCP 1.4/2.2 compliant
–Supports 3D pass-through
–EDID management – Copy from output 1 or built-in internal EDID
–Supports RS-232 control
–Supports IP control via Telnet, TCP and built-in web server
–Supports IR remote control for switching
–Firmware upgradable
–Supports up to 4 presets
3.0 Specifications
FUNCTION
HDM2.0-4x4-UHD-II
HDMI outputs 4
HDMI inputs
4
RS-232 control 1 x DB9
IP control
1 x RJ45
IR control 1 x 3.5mm stereo jack
IR Matrix outputs
4 x 3.5 mm stereo jack
IR Matrix inputs 4 x 3.5 mm stereo jack
Display
LCD Module
Maximum resolution UHD@60Hz (4:4:4 8 bit, 4:2:2/4:2:0 12 bit)

HDM2.0-4x4-UHD-II
APANTAC LLC, 10200 SW Allen Blvd. Suite C, Beaverton, OR 97005 USA
[email protected], TEL: [phone], FAX: [phone]
3
HDCP compliance HDCP 1.4/2.2
Audio support
LPCM, Dolby TrueHD, Dolby Deigital/Plus/Ex, DTS, DTS-HD
Master audio
Baud rate 115200 bps; 8 data bits, 1 stop bit, no parity
IP control
Telnet, TP, Web interface
Power supply 90 ~ 240 VAC
Weight
2.5 kg
Dimension 440x198x43 mm
4.0 Front Panel
OUT Buttons: Specify the HDMI output destination
IN Buttons:Specify the HDMI input source
ALL Button: This key allows user to set a single source to all outputs destinations
OFF Button: Disable LCD Module backlight
SAVE Button:Saves all current status to a preset
LOAD Button: Load one of the presets
- LOAD + Number key 1 ~ 4 (IN OR OUT)
EDID Button: Select the EDID mode for all source
-UHD Mode: EDID Resolution up to UHD
-OUT1 Mode: Copy Output1’s EDID to all the sources
-FHD Mode: EDID Resolution up to Full HD 1080p.
-4K30 Mode: EDID Resolution up to 4K30.
-HDR Mode: EDID Resolution up to 4K Ultra HD with HDR.
MENU Button:Switches menus to get information or settings. Different menus can
display the input / output status, IP address, keypad lock setting, reset to factory default
and firmware version.
ENTER Button:Confirm the setting of the MENU button

HDM2.0-4x4-UHD-II
APANTAC LLC, 10200 SW Allen Blvd. Suite C, Beaverton, OR 97005 USA
[email protected], TEL: [phone], FAX: [phone]
4
5.0 Rear Panel
Power: 100V ~240VAC
RS-232: To connect a computer/controller’s serial port and matrix via RS-232 for control
LAN: To connect a computer/controller to the matrix via IP (RJ45)
IR EXT: Connect the IR Receiver cable for the matrix’s Remote Controller.
IR Matrix: Connect the IR Blaster and IR Receiver cables for IR Matrix from outputs to
inputs.
HDMI IN: Matrix inputs (HDMI)
HDMI OUT: Matrix ouputs (HDMI)
DIP Switch:
Pin 1: Switch RS-232 port connection.
Pin 2: Switch LAN port connection.
Pin 3: Reserve.
Pin 4: Reset the web server IP address to the factory default value. The IP address will
restore to the default: 192.168.0.3
The steps are as follows:
1. Adjust pin 4 to ON then power cycle
2. After the matrix is powered on for about 10 seconds.
3. Adjust pin 4 to OFF then power cycle again
4. The IP address will be restored to the default: 192.168.0.3
5.1 IR Blaster Pin Definitions
1: IR LED+
2: IR LED-

HDM2.0-4x4-UHD-II
APANTAC LLC, 10200 SW Allen Blvd. Suite C, Beaverton, OR 97005 USA
[email protected], TEL: [phone], FAX: [phone]
5
5.2 IR Receiver Pin Definitions
1: Signal
2: GND
3: +5V
5.3 RS-232
Follow these steps to log onto the matrix with a RS-232 terminal emulation program (the
example as below is Hyper Terminal):
1. Please switch the DIP Switcher PIN 1 to ON for RS-232 control.
2. Connect the matrix to your control PC with RS-232 cable.
3. Power on both Matrix Switcher and PC.
4. Launch a terminal emulation program (e.g. HyperTerminal) on your PC.
5. New Connection – Hyper Terminal screen will appear. Input the connection name
and select a representative icon. Then click OK.
6. Select the connecting port that you want to use, click OK. Default port is COM1.
7. Set the Baud Rate to 115200, Data Bits to 8 (Default), Parity to None (Default), Stop bits
to 1 (Default) and Flow Control to None from the drop-down list, click OK.
Description
Setting
Baud Rate
115200
Data Bits 8
Parity
None
Stop bits 1
Flow Control
None
Note: The RS-232 connection is defined by DCE, only TXD, RXD, and GND pins are used.
5.4 Network Configuration
The matrix supports IP-based control using Telnet, TCP, or the built-in Web Server
interface. Network settings can be configured via web or Telnet command. The default
network settings are as follows:
Description
IP Address / Port
IP Address 192.168.0.3
Subnet Mask
255.255.255.0
Gateway 192.168.0.1

HDM2.0-4x4-UHD-II
APANTAC LLC, 10200 SW Allen Blvd. Suite C, Beaverton, OR 97005 USA
[email protected], TEL: [phone], FAX: [phone]
6
DNS Server 8.8.8.8
DHCP Client
Disable
TCP Port 5000
Telnet Port
23
HTTP Port 80
Note: Depending upon the network, all related IP, Telnet, and TCP settings will need to be
assigned. Consult your network administrator to obtain the proper settings.
5.5 Telnet
You can operate and configure the matrix via a remote terminal session using Telnet.
Follow the steps as below to log onto the matrix by Telnet session:
1. Switch the DIP Switch PIN 2 to ON for LAN configuration.
2. Connect the matrix’s to LAN port of your network with RJ45 cable.
3. Power on both Matrix Switcher and control PC.
4. Launch a terminal session (command line) on your control PC.
5. Type in the matrix’s IP address as below:
telnet [IP Address]:192.168.0.3
6. Press Enter
Note: Telnet port is 23.
5.6 TCP
For programmer familiar with network communication, you can program your own
TCP/IP application to control Matrix Switcher.
Note: TCP port is 5000.
5.7 Web
1. Open a Browser on your PC and type in the default IP address http://192.168.0.3/ to
connect the IPM web.

HDM2.0-4x4-UHD-II
APANTAC LLC, 10200 SW Allen Blvd. Suite C, Beaverton, OR 97005 USA
[email protected], TEL: [phone], FAX: [phone]
7
Note: HTTP port is 80
2. Type in the selected input number in the Matrix Settings Current Input fields, and then
click “Apply” button.
3. To switch all Outputs to the same Input, select from the All Outputs drop-down menu
at the bottom, and then click “Apply” button.
5.8 RS-232 amd TCP/IP commands
These commands are based on ASCII code for RS-232, Telnet and TCP Interfaces. Every
command must include a carriage return (0d) at the end to execute the command. If a
new command is received, a prompt will appear

HDM2.0-4x4-UHD-II
APANTAC LLC, 10200 SW Allen Blvd. Suite C, Beaverton, OR 97005 USA
[email protected], TEL: [phone], FAX: [phone]
8
1. Command List
Once the connection with matrix is established, type “help” in the Hyper Terminal screen,
and then press “Enter” Key to show the command list.
-----------------------------------------------------------
Command Description
-----------------------------------------------------------
help
Display help information
reset
Reset the device
info
Display device information
status Display device status
r
Set routing status
rs
Display routing status
save
Save the current status to Preset
load Load settings from Preset
edid Select input EDID mode
default Reset to factory default settings
For more information, type '/h' or '?' after each command
-----------------------------------------------------------
2. Command descriptions
2-1 command "r"
Usage:
r x y: Set Input x to Output y
r x: Set all Outputs to Input x
r Displays the current route status
r x y1 .. yn : Set Input x to Output y1, .. , yn
x = [0-1] (0: disable), y = [0-n] (0: all outputs)
Examples: r 1 2
Examples: r 0

HDM2.0-4x4-UHD-II
APANTAC LLC, 10200 SW Allen Blvd. Suite C, Beaverton, OR 97005 USA
[email protected], TEL: [phone], FAX: [phone]
9
2-2command "rs"
Usage:
rs: Displays the current route status
rs x: Displays the Preset x route status
rs x y: Displays the Preset x Output y route status
x=[0-0] (0: current status)
y = [0-4] (0: all outputs)
Examples: rs
Examples: rs 0
2-3command "save"
Usage:
save x: Save current route status to Preset x
x = [1-4] (Preset Position x)
Examples: save 1
2-4command "load"
Usage:
load x: Load the route status from Preset x
x = [1-4] (Preset Position x)
Examples: load 1
2-5command "edid"
Usage:
edid: Display input EDID mode x
edid x: Select input EDID mode x
x = [0-4] 0: 4K Ultra HD
1: Copy from Output 1
2: Full HD
3: 4K30
4: 4K HDR
Examples: edid 0
3. Other commands have no parameters.

HDM2.0-4x4-UHD-II
APANTAC LLC, 10200 SW Allen Blvd. Suite C, Beaverton, OR 97005 USA
[email protected], TEL: [phone], FAX: [phone]
10
4. TCP/IP Configuration (Telnet Console Only)
ipconfig Display the TCP/IP configuration
setip Renew the IP Address
setmask Renew the Subnet Mask
setgateway Renew the Default Gateway
setdns Renew the DNS Servers
setdhcp Set DHCP client Enable or Disable

HDM2.0-4x4-UHD-II
APANTAC LLC, 10200 SW Allen Blvd. Suite C, Beaverton, OR 97005 USA
[email protected], TEL: [phone], FAX: [phone]
11
Copywright & Trademark
Copyright © 2020 Apantac LLC. All rights reserved by APANTAC LLC, Beaverton, Oregon,
USA. No part of this document may be reproduced in any form or by any means without
written permission from the product manufacturer. Changes are periodically made to the
information in this document. They will be incorporated in subsequent editions. The
product manufacturer may make improvements and /or changes in the product
described in this document at any time.
Apantac, Tahoma, MT Hood and Crescent are registerd trademarks of Apantac LLC. All
other trademarks are the property of their respective holders.
Warranty Statement
Apantac LLC (herein after referred to as “Apantac”) warrants to the original purchaser of
the products manufactured by Apantac (the “Product,”) will be free from defects in
material and workmanship for a period of three (3) year from the date of shipment of the
Product to the purchaser.
If the Product proves to be defective during the three (3) year warranty period, the
purchaser’s exclusive remedy and Apantac’s sole obligation under this warranty is
expressly limited, at Apantac’s sole option, to:
(a) repair the defective Product without charge for parts and labor or,
(b) provide a replacement in exchange for the defective Product or,
(c) if after a reasonable time, is unable to correct the defect or provide a replacement
Product in good working order, then the purchaser shall be entitled to recover
damages subject to the limitation of liability set forth below.

HDM2.0-4x4-UHD-II
APANTAC LLC, 10200 SW Allen Blvd. Suite C, Beaverton, OR 97005 USA
[email protected], TEL: [phone], FAX: [phone]
12
Comformity
Apantac products has been tested and found to comply with the following,
FCC-Class A part 15
CE/C-tick
California Propersition 65
REACH SVHC
EU RoHS 10 Substances Amendment
Limitation of Liability
Apantac’s liability under this warranty shall not exceed the purchase price paid for the
defective product. In no event shall Apantac be liable for any incidental, special or
consequential damages, including without limitation, loss of profits for any breach of this
warranty.
If Apantac replaces the defective Product with a replacement Product as provided under
the terms of this Warranty, in no event will the term of the warranty on the replacement
Product exceed the number of months remaining on the warranty covering the defective
Product.
Equipment manufactured by other suppliers and supplied by Apantac carries the
respective manufacturer’s warranty. Apantac assumes no warranty responsibility either
expressed or implied for equipment manufactured by others and supplied by Apantac.
This hardware warranty shall not apply to any defect, failure or damage:
a) Caused by improper use of the Product or inadequate maintenance and care of
the Product;
b) Resulting from attempts by those other than Apantac representatives to install,
repair, or service the Product;
c) Caused by installation of the Product in a hostile operating environment or
connection of the Product to incompatible equipment;

HDM2.0-4x4-UHD-II
APANTAC LLC, 10200 SW Allen Blvd. Suite C, Beaverton, OR 97005 USA
[email protected], TEL: [phone], FAX: [phone]
13
Contact Apantac Technical Support
For technical inquiries including product and system issues, hardware and software information
and more.
Technical Support Hours:
Monday - Friday
7:00 AM to 5:00 PM (PT)
Technical Support Assistance:
Phone: [phone]
Email: [e-mail]
Randall Durand
Technical Support Manager / Applications Engineer
Phone: [phone]
Email: [e-mail]
Daryn Edwards
Technical Support Engineer
Phone: [phone]
Email: Daryn.Edward[email protected]
