AV TOOL AVT-4214A User manual

Instruction Manual
AVT-4214A
1x4 PC Distribution Amplifier

Table of Contents
1.0 Introduction 2
2.0 Specifications 3
3.0 Package Contents 4
4.0 Connecting the Hardware 4
5.0 Operating The Unit 5
6.0 Troubleshooting 5
7.0 Limited Warranty 6
8.0 Regulatory Compliance 7
9.0 Contact Information 7

2
1.0 INTRODUCTION
Thanks for purchasing this AVT-4214A PC Distribution Amplifier from the AV Toolbox
division of TV One. The unit provides four PC outputs from a single input. DDC2 monitor
interface is provided and additional outputs can be provided by cascading additional
Distribution Amplifiers. AV Toolbox offers a wide range of video, audio and multimedia
products.
1.1 Liability Statement
Every effort has been made to ensure that this product is free of errors. AV Toolbox
cannot be held liable for the use of this hardware or any direct or indirect consequential
damages arising from its use. It is the responsibility of the user of the hardware to check
that it is suitable for his/her requirements and that it is installed correctly. All rights
reserved. No parts of this manual may be reproduced or transmitted by any form or
means electronic or mechanical, including photocopying, recording or by any
information storage or retrieval system without the written consent of the publisher.
AV Toolbox reserves the right to revise any of its hardware and software following its
policy to modify and/or improve its products where necessary or desirable. This
statement does not affect the legal rights of the user in any way.
All third party trademarks and copyrights are recognised. The AV Toolbox logo is a
trademarks of AV Toolbox. All other trademarks are the property of their respective
holders.
1.2 Features
The AVT-4214A Distribution Amplifier has many features that enable it to perform in a
superior manner. Among those features you will find:
•250MHz Bandwidth
•Supports RGBHV signal types
•Supports Resolutions to 1920x1440
•Output Range up to 165 feet
•Supports DDC, DDC2, DDC2B (Output 1 Only)
•Amplifiers may be cascaded
•Rugged Metal Housing
•Ultra Compact Size

3
2.0 SPECIFICATIONS
Video Input
Signal Type RGBHV
Connector 1x HD-15 Female Connector
R-G-B Level Range 0.5-2.0 Vp-p
Maximum Resolution 1920x1440
Video Outputs
Signal Type RGBHV
Connectors 4x via HD-15 Female Connectors
General
R-G-B Bandwidth 250 MHz
Maximum Distance Up to 165’ (50 meters) from amplifier(Note 1)
DDC Capability DDC, DDC2, DDC2B (Port 1)
Mechanical
Dimensions (H-W-D) 43x131x75mm (1.7"x5.2"x2.95")
Weight (Net) 400 g (0.88 lbs)
Environmental
Operating Temperature 0° to +40° C (+32° to +104° F)
Operating Humidity 0% to 80%, Non-condensing
Storage Temperature -5° to +70° C (23° to +140° F)
Storage Humidity 0% to 80%, Non-condensing
Warranty
Limited Warranty 1 Years Parts and Labor
Power Requirement
External Power Supply [email protected]
Regulatory Approvals
Amplifier Units FCC, CE, RoHS
Power Supplies UL, CUL, CE, PSE, GS, RoHS
Accessories Included
1x Power Adapter US, UK or Euro
1x Operations Manual
Product Item Number
AVT-4214A 4-Output PC Signal Splitter
1) To achieve the max rated distance, use premium cables.

4
3.0 CHECKING PACKAGE CONTENTS
Before attempting to use this unit, please check the packaging and make certain the
following items are contained in the shipping carton:
•1x Distribution Amplifier
•1x Power Adapter with 9VDC Output
•1x User Manual
Note: Please retain the original packing material should the need ever arise to return the unit. If
you find any items are missing, contact your reseller or AV Toolbox immediately. Have the
Model Number, Serial Number and Invoice available for reference when you call.
4.0 CONNECTING THE HARDWARE
The rear of the device has a single LED that indicates when power is applied. The rear
panel also has the power connection, input connection and four output connections.
Please take a moment to familiarize yourself with the location of the various signal
connectors and the power input connector. Make certain you connect only the supplied
power adaptor to the device as serious damage can result by using improper voltages.

5
5.0 OPERATING THE UNIT
5.1 Connect the Unit as follows:
1. Turn off power to Source Device (such as PC) and to all Destination Devices
(such as Monitors).
2. Connect the output of the Source Device to the Amplifier’s Input with an HD-15
cable.
3. Connect the input of the Destination Devices to the Output Connectors of the
Amplifier with high quality HD-15 cables.
4. Plug the DC Connector from the 9VDC Power Adapter provided into the
Amplifier.
5. Plug the Power Adapter into an AC Outlet.
6. Turn on power to the Source and Destination Devices.
Note: If you connect a DDC Monitor to Output 1 of the Amplifier, all the other Monitors
must be able to support the same high resolution as the DDC monitor.
5.2 Cascading
To display the same image on more Monitors than available amplifier outputs permit,
you may cascade additional amplifiers. Connect the input of the additional amplifier with
an HD-15 cable to an output of the original Amplifier. Caution - Signal degradation may
occur if too many Amplifiers are cascaded.
6.0 TROUBLESHOOTING
A problem with the AVT-4214A Distribution Amplifier is rare. Most of the time, problems
are caused by the use of low grade cable, too long of a cable run, bad connectors on
the cable or occasionally by damaged cables. Bad grounds or use of different AC power
sources for the Distribution Amplifier, Signal Source and/or Display Device(s) may also
cause problems due to ground loops.
After trying the above suggestions should the problem still persist, contact your dealer
for additional suggestions before contacting AV Toolbox. Should the dealer’s technical
personnel be unable to assist you, contact AV Toolbox via the TV One support website:
http://tvone.crmdesk.com. Create a technical support request on the site and our
support team will respond within a short period of time.

6
7.0 LIMITED WARRANTY
LIMITED WARRANTY – AV Toolbox warrants the original purchaser that the equipment
it manufactures will be free from defects in materials and workmanship for a period of
one year from the date of purchase. Should this product, in AV Toolbox’s opinion,
prove defective within this warranty period, AV Toolbox, at its option, will repair or
replace this product without charge. Any defective parts replaced become the property
of AV Toolbox. This warranty does not apply to those products which have been
damaged due to accident, unauthorized alterations, improper repair, modifications,
inadequate maintenance and care, or use in any manner for which the product was not
originally intended.
If repairs are necessary under this warranty policy, the original purchaser must obtain a
Return Authorization Number from AV Toolbox and return the product to a location
designated by AV Toolbox, freight prepaid. After repairs are complete, the product will
be returned, freight prepaid.
LIMITATIONS - All products sold are "as is" and the above Limited Warranty is in lieu of
all other warranties for this product, expressed or implied, and is strictly limited to one
year from the date of purchase. AV Toolbox assumes no liability to distributors, dealers
or end-users for any loss of use, revenue or profit.
AV Toolbox makes no other representation of warranty as to fitness for the purpose or
merchantability or otherwise in respect of any of the products sold. The liability of AV
Toolbox with respect to any defective products will be limited to the repair or
replacement of such products. In no event shall AV Toolbox be responsible or liable for
any damage arising from the use of such defective products whether such damages be
direct, indirect, consequential or otherwise, and whether such damages are incurred by
the reseller, end-user or any third party.
8.0 REGULATORY COMPLIANCE
The AVT-4214A Distribution Amplifier has been tested for compliance with appropriate
FCC and CE rules and regulations. The Power Adaptor/Supplies have been tested for
compliance with appropriate UL, CUL, CE, PSE, GS Rules, Regulations and/or
Guidelines. These Products and Power Adapters are RoHS Compliant.

7
9.0 CONTACT INFORMATION
Should you have questions or require assistance with this product in areas not covered
by this manual, please contact AV Toolbox at the appropriate location.
AV Toolbox
A division of TVOne
2791 Circleport Drive
Erlanger, KY 41018
USA
Tel [phone]
Fax [phone]
[email protected]
www.avtoolbox.com
AV Toolbox
A division of TV One Ltd
Continental Approach
Westwood Industrial Estate
Margate, Kent CT9 4JG, UK
Tel [phone]
Fax [phone]
[email protected]
www.avtoolbox.co.uk
AV Toolbox Latin America
A division of TV One L.A.
6991 NW 82 Avenue #8
Miami, FL 33166
USA
Tel [phone]
Fax [phone]
[email protected]
www.avtoolboxla.com
TV One Mercosur
Av. Diaz Velez 3965 #PB
(1200) Capital Federal
Buenos Aires, Argentina
Tel [phone]
Fax [phone]
[email protected]
www.tvonela.com
TV One Asia
16F-4, NO.75, Sec. 1
Hsin Tai Wu Road, Hsichih
Taipei Hsien 22101
Taiwan R.O.C.
Tel [phone]
Fax [phone]
[email protected]
www.tvoneasia.com
TV One China
Rm. 1007, Golden Peach Bldg.
No. 1900 Shangcheng Road
Pudong, Shanghai
China 200120
Tel [phone]
Fax [phone]
Email: [email protected]
www.tvonechina.com
End of Manual
