Avacom H50 series User manual

1
H50 Series H.264 IP Cameras
Quick Start Guide
Installation & Configuration Guide
With USA Technical Support & Warranty Information
AVACOMTECH INC. www.avacomtech.com

2
Hardware Installation
Please check to see that you have the following:
You will also need:
1. A computer with a CD-ROM drive or active Internet connection
2. A WiFi router with at least one other available Ethernet port
3. A screwdriver
Preparation for Plug＆Play Installation or Network/WiFi settings
1. Connect Ethernet cable between the camera and your router or WiFi router
2. Connect the antenna to camera
3. Connect the power adapter to camera and plug it into a power outlet
H5060W H5080AW
H5060W IP Camera H5080AW IP Camera with bracket
Antenna Antenna
Ethernet cable Ethernet cable
5V power adapter 12V power adapter
Mounting bracket and screws Screws
CD-ROM with setup software CD-ROM with setup software

3
Android/iPhone/iPad APP Plug & Play Installation
1. Make sure your Android phone, iPhone or iPad has installed barcode scanner APP
2. Scan Android APP or iPhone/iPad APP QR code on the box
3. Run the APP, to add a camera select “Add device”. You can “Search device in LAN”
and choose the camera serial number from the list or “Scan device QR code”, the
device QR code is located on the back of the camera, enter the User and Password
(default user name is “admin”, password is blank), then click icon.

4
Setup WiFi SSID/Password in APP
1.Click on device list into setting page, then click into WiFi setting page,
click , then select the SSID that the camera would connect to, input
the password (Share Key) of the SSID, the device status should changes to “Already
connected” in a few seconds.

5
Change User Name/Password in APP (IMPORTANT)
1.Click on device list into setting page
2.Click into user setting page, setup “administration” and “operator” user name
and password, then click icon.

6
Viewing Live Video, Pan/Tilt or Push to Talk in APP
1.Click device list into preview page, drag the image to pan or tilt the camera
2.Click the screen to enable or disable tools menu, click to enable or disable
push to talk, push icon to talk, release icon to listen.

7
