Avanti FLW22V0W User manual

1
Model
FLW22V0W
Washing Machine
INSTRUCTION MANUAL
BEFORE USE, PLEASE READ AND FOLLOW ALL SAFETY RULES AND
OPERATING INSTRUCTIONS.
Avanti has a policy of continuous improvement on its products and reserves
the right to change materials and specifications without notice.
Avanti Products LLC
3265 Meridian Pkwy # 114
Weston, FL 33331
www.avantiproducts.com

2
CONTENTS
HELP US HELP YOU....................................................................................................... 3
1.SAFETY INSTRUCTIONS ............................................................................................... 1
1.1 General Safety Warnings ..............................................................................................4
1.2 During Use ....................................................................................................................9
2.TECHNICAL SPECIFICATIONS.................................................................................... 12
3.INSTALLATION............................................................................................................. 13
3.1 Removing the Transit Bolts..........................................................................................13
3.2 Adjusting the Feet / Adjusting Adjustable Stays...........................................................13
3.3 Electrical Connection...................................................................................................13
4.GROUNDING INSTRUCTIONS ..................................................................................... 14
4.1 Water Inlet Hose Connection.......................................................................................14
4.2 Water Discharge Connection.......................................................................................15
5.CONTROL PANEL OVERVIEW .................................................................................... 15
5.1 Detergent Drawer........................................................................................................16
5.2 Sections.......................................................................................................................16
5.3 Program Dial................................................................................................................17
5.4 Electronic Display........................................................................................................17
6.USING YOUR WASHING MACHINE............................................................................. 17
6.1 Preparing Your Laundry...............................................................................................17
6.2 Putting Laundry in the Machine...................................................................................18
6.3 Adding Detergent to the Machine ................................................................................18
6.4 OPERATING INSTRUCTIONS....................................................................................19
6.5 Selecting a program. ...................................................................................................19
6.6 Half-Load Detection System........................................................................................19
6.7 Auxiliary Functions.......................................................................................................19
6.8 Child Lock....................................................................................................................23
6.9 If you want to pause/cancel a running program or add laundry: ..................................23
6.10 Program End .............................................................................................................23
7.PROGRAM TABLE........................................................................................................ 24
8.User-maintenance instructions................................................................................... 25
8.1 Warning.......................................................................................................................25
8.2 Water Inlet Filters ........................................................................................................25
8.3 Pump Filter..................................................................................................................26
8.4 Detergent Drawer........................................................................................................26
9. TROUBLESHOOTING................................................................................................. 28
10.AUTOMATIC FAULT WARNINGS AND WHAT TO DO .............................................. 29
11.SERVICE FOR YOUR WASHER................................................................................. 30
12.PRODUCT WARRANTY.............................................................................................. 31

3
HELP US HELP YOU...
Read this guide carefully.
It is intended to help you operate and
maintain your new appliance properly.
Keep it handy to answer your questions.
If you don't understand something or you
need more help, please call:
Avanti Customer Service
800-220-5570
Keep proof of original purchase date
(such as your sales slip) with this guide
to establish the warranty period.
Write down the model and serial
numbers.
You'll find them on a plate located on the
rear outside wall of the appliance.
Please write these numbers here:
_
Date of Purchase
_
Model Number
_
Serial Number
Use these numbers in any
correspondence or service calls
concerning your appliance.
If you received a damaged appliance,
immediately contact the dealer (or builder)
that sold you the appliance.
Save time and money. Before you call for
service, check the Troubleshooting Guide.
It lists causes of minor operating problems
that you can correct yourself.
CAUTION:
THIS APPLIANCE IS NOT
DESIGNED FOR THE
STORAGE OF MEDICINE OR
OTHER MEDICAL PRODUCTS.
IF YOU NEED SERVICE
We're proud of our service and want you
to be pleased. If for some reason you
are not happy with the service you
receive, here are some steps to follow
for further assistance.
FIRST, contact the people who serviced
your appliance. Explain why you are not
pleased. In most cases, this will solve
the problem.
NEXT, if you are still not pleased, write all
the details, including your telephone
number, and send it to:
Customer Service
Avanti Products
3265 Meridian Pkwy # 114
Weston, FL 33331 USA

4
1.SAFETY INSTRUCTIONS
Operating voltage / frequency
110 - 120 V~/60Hz
Total current (A)
10
Water pressure (Mpa)
Maximum 1 Mpa /Minimum
0. 1Mpa
Totalpower(W)
1200
•Do not install your machine on a carpet or such grounds that would
prevent the ventilation of itsbase.
•The appliance is not intended for use by people (including children) with
reduced physical, sensory or mental capabilities, or lack of experience
and knowledge unless they have been given supervision or instruction
concerning use of the appliance by a person responsible for theirsafety.
•Children of less than 3 years should be kept away unless continuously
supervised.
•Call the nearest authorized service center for a replacement if the
power cord malfunctions.
•Use only the new water inlet hose coming with your machine when making
water inlet connections to your machine.
•Never use old, used or damaged water inlet hoses.
•Children should not play with the appliance. Cleaning and user
maintenance should not be made by children without supervision.

5
IMPORTANT SAFETYINSTRUCTIONS
WARNING: To reduce the risk of fire, electricshock, or injury to
persons when using your appliance, follow basic precautions, including
the following:
1. Read all instructions before using the appliance.
SAVE THESE INSTRUCTIONS.
2.Do not wash articles that have been previously cleaned in, washed in,
soaked in, or spotted with gasoline, dry-cleaning solvents, or other
flammable or explosive substances, as they give off vapors that could
ignite or explode.
3.Do not add gasoline, dry-cleaning solvents, or other flammable or
explosive substances to the wash water. These substances give off
vapors that could ignite or explode.
4.Under certain conditions, hydrogen gas may be produced in a hot-water
system that has notbeen used for 2 weeks or more.
HYDROGEN GAS IS EXPLOSIVE. If the hot-water system has not been
used for such a period, before using a washing machine, turn on all hot-water
faucets and let the water flow from each for several minutes. This will release
any accumulated hydrogen gas.As the gas is flammable, do not smoke or
use an open flame during this time.
5.Do not allow children to play on or in the appliance. Close
supervision of children is necessary when the appliance is used
near children.
6.Before the appliance is removed from service or discarded, remove the
door.
7.Do not reach into the appliance if the tub or agitator is moving.
8.Do not install or store this appliance where it will be exposed to the
weather.
9. Do not tamper with controls.
10. Do not repair or replace any part of the appliance or attempt any
servicing unless specifically recommended in the user- maintenance
instructions or in published user- repair instructions that you understand
and have the skills to carry out.
11. To reduce the risk of electric shock, disconnect this appliance from the
power supply before attempting any user maintenance. Turning the
controls to the OFF position does not disconnect this appliance from the
power supply.
12. Do not wash or dry articles that have been previously cleaned in,
washed in, soaked in, or spotted with gasoline, dry-cleaning solvents, other
flammable or explosive substances as they give off vapors that could ignite

6
or explode.
13. Do not allow children to play on or in the appliance. Close
supervision of children is necessary when the appliance is used
near children.
WARNING: Improper connection of the equipment-grounding conductor can
result in a risk of electric shock. Check with a qualified electrician or
serviceman if you are in doubt as to whether the appliance is properly
grounded.
Do not modify the plug provided with the appliance ifit will not fit the outlet,
have a proper outlet installed by a qualified electrician.
Your machine is for domestic use only. Using it for commercial
purposes will cause your warranty to be cancelled.
This manual has been prepared for more than one model therefore
your appliance may not have some of the features described within.
For this reason, it is important to pay particular attention to any
figures while reading the operating manual.

7
1.1 GENERAL SAFETY WARNINGS
•The necessary ambient temperature for operation of your Washing
Machine is 59-77 °F.
•Where the temperature is below 32 °F, hoses may split or the
electronic card may not operate correctly.
•Please ensure that garments loaded into your Washing Machine are
free from foreign objects such as nails, needles, lighters and coins.
•It is recommended that for your first wash, you select the 90˚
Cotton Program without laundry and fill half compartment II of the
detergent drawer with a suitable detergent.
•Residue may build up on detergent and softeners exposed to air
for a long period of time. Only put softener or detergent in the
drawer at the beginning of each wash.
•Unplug your Washing Machine and switch off the water supply if the
Washing Machine is left unused for a long time. We also recommend
that you leave the door open to prevent build up of humidity inside the
Washing Machine.
•Some water may be left in your Washing Machineas a result of quality
checks during production. This will not affect the operation of your
Washing Machine.
•The packaging of the machine could be hazardous to children. Do not
allow children to play with the packaging or small parts from the
Washing Machine.
•Keep the packaging materials in a place wherechildren cannot reach
them, or dispose of them appropriately.
•Use pre-wash programs only for very dirty
laundry.
Never open the detergent drawer while the machine is running.
•In the event of a breakdown, unplug the machine from the mains supply
and turn the water supply off. Do not attempt to carry out any repairs.
Always contact an authorized service agent.
•Do not exceed the maximum load for the washing
Program you have chosen.
Never force the door open when your Washing Machine is running.
•Washing laundry containing flour may damage your machine.
•Please follow the manufacturers’ instructions regarding the use of
fabric conditioner or any similar products that you intend to use in
your Washing Machine.
•Make sure that the door of your Washing Machine is not restricted and can

8
be opened fully.
•Install your machine in a location that can be fully ventilated and
preferably has constant air circulation.
Door emergency opening function
When the machine is running, any power cut or when the program is not yet
complete, the door will remain locked.
To open the door;
1.Please turn off the machine. Take off the power plug from the mains
socket.
2.To drain the waste water, follow the instructions given in cleaning the
pump filter section.
3.Pull the down the emergency opening mechanism with the help of a
tool and open the door at the same time.
4.Doors, move the emergency opening handle to the open position
after being closed again,if the door remains locked.

9
Read these warnings. Follow the advice given to protect yourself
and others from risks and fatal injuries.
RISK OF BURNS
Do not touch the drain hose or any discharged water while your
Washing Machine is running. The high temperatures involved pose a burn
risk. RISK OF DEATH FROM ELECTRICALCURRENT
•
•Do not connect your Washing Machine to the mains electricity supply
using an extension lead.
•Do not insert a damaged plug into a socket.
•Never remove the plug from the socket by pulling the cord.
•Always hold the plug.
•Never touch the power cord/plug with wet hands as this could
cause a short circuit or electric shock.
•Do not touch your Washing Machine if your hands or feet are wet.
•A damaged power cord/plug can cause fire or give you an electric
shock. When damaged it must be replaced, this should only be done
by qualified personnel.
•Connectto Individual Branch-Circuit.
Risk of flooding
•Check the speed of water flow before placing the drain hose in a sink.
•Take necessary measures to prevent the hose from slipping.
•Water flow may dislodge the hose if it is not properly secured. Make sure
the plug in your sink does not block the plug hole.
Danger of Fire
•Do not store inflammable liquids near your machine.

10
•The sulfur content of paint removers may cause corrosion. Never use
paint removing materials in your machine.
•Never use products that contain solvents in your machine.
•Please ensure that garments loaded into your Washing Machine are
free from foreign objects such as nails, needles, lighters and coins.
Risk of falling and injury
•Do not climb on your Washing Machine.
•Make sure hoses and cables do not cause a trip hazard.
•Do not turn your Washing Machine upside down or on its side.
•Do not lift your Washing Machine using the door
or detergent drawer.
The machine must be carried by at least 2 people.
Child safety
•Do not leave children unattended near the machine. Children might
lock themselves in the machine resulting in risk of death.
•Do not allow children to touch the glass door during operation. The surface
becomes extremely hot and may cause damage to skin.
•Keep packaging material away from children.
•Poisoning and irritation may occur if detergent and cleaning materials
are consumed or come into contact with the skin and eyes.
•Keep cleaning materials out of the reach of children.
