Avaya WLAN 8100 Quick Start Guide
1.1.0.0
NN47251-106, 02.02
October 2011

©2011 Avaya Inc.
All Rights Reserved.
Notice
While reasonable efforts have been made to ensure that the
information in this document is complete and accurate at the time of
printing,Avaya assumes no liability for any errors.Avaya reserves the
right to make changes and corrections to the information in this
document without the obligation to notify any person or organization of
such changes.
Documentation disclaimer
“Documentation” means information published by Avaya in varying
mediumswhichmayincludeproductinformation,operatinginstructions
and performance specifications that Avaya generally makes available
to users of its products. Documentation does not include marketing
materials. Avaya shall not be responsible for any modifications,
additions, or deletions to the original published version of
documentation unless such modifications, additions, or deletions were
performed byAvaya. End User agrees to indemnify and hold harmless
Avaya,Avaya's agents, servants and employees against all claims,
lawsuits, demands and judgments arising out of, or in connection with,
subsequentmodifications,additionsordeletions tothisdocumentation,
to the extent made by End User.
Link disclaimer
Avaya is not responsible for the contents or reliability of any linked Web
sites referenced within this site or documentation provided by Avaya.
Avaya is not responsible for the accuracy of any information, statement
or content provided on these sites and does not necessarily endorse
the products, services, or information described or offered within them.
Avayadoesnotguaranteethattheselinkswillworkallthetimeandhas
no control over the availability of the linked pages.
Warranty
Avaya provides a limited warranty on its Hardware and Software
(“Product(s)”). Refer to your sales agreement to establish the terms of
the limited warranty. In addition, Avaya’s standard warranty language,
as well as information regarding support for this Product while under
warranty is available toAvaya customers and other parties through the
Avaya Support Web site: http://support.avaya.com. Please note that if
you acquired the Product(s) from an authorizedAvaya reseller outside
of the United States and Canada, the warranty is provided to you by
said Avaya reseller and not by Avaya.
Licenses
THE SOFTWARE LICENSE TERMSAVAILABLE ON THE AVAYA
WEBSITE, HTTP://SUPPORT.AVAYA.COM/LICENSEINFO/ ARE
APPLICABLE TO ANYONE WHO DOWNLOADS, USES AND/OR
INSTALLS AVAYA SOFTWARE, PURCHASED FROM AVAYA INC.,
ANY AVAYAAFFILIATE, OR AN AUTHORIZED AVAYA RESELLER
(AS APPLICABLE) UNDER A COMMERCIAL AGREEMENT WITH
AVAYA OR AN AUTHORIZED AVAYA RESELLER. UNLESS
OTHERWISE AGREED TO BY AVAYA IN WRITING, AVAYA DOES
NOT EXTEND THIS LICENSE IF THE SOFTWARE WAS OBTAINED
FROMANYONEOTHERTHANAVAYA,ANAVAYAAFFILIATEORAN
AVAYAAUTHORIZED RESELLER; AVAYA RESERVES THE RIGHT
TO TAKE LEGALACTION AGAINST YOU AND ANYONE ELSE
USING OR SELLING THE SOFTWARE WITHOUT A LICENSE. BY
INSTALLING, DOWNLOADING OR USING THE SOFTWARE, OR
AUTHORIZING OTHERS TO DO SO, YOU, ON BEHALF OF
YOURSELFAND THE ENTITYFOR WHOM YOUARE INSTALLING,
DOWNLOADING OR USING THE SOFTWARE (HEREINAFTER
REFERRED TO INTERCHANGEABLYAS “YOU” AND “END USER”),
AGREE TO THESE TERMSAND CONDITIONS AND CREATE A
BINDING CONTRACT BETWEEN YOU ANDAVAYA INC. OR THE
APPLICABLE AVAYAAFFILIATE ( “AVAYA”).
Copyright
Except where expressly stated otherwise, no use should be made of
materials on this site, the Documentation, Software, or Hardware
provided byAvaya.All content on this site, the documentation and the
Product provided by Avaya including the selection, arrangement and
design of the content is owned either by Avaya or its licensors and is
protectedbycopyright and otherintellectualpropertylaws includingthe
sui generis rights relating to the protection of databases. You may not
modify, copy, reproduce, republish, upload, post, transmit or distribute
in any way any content, in whole or in part, including any code and
software unless expressly authorized by Avaya. Unauthorized
reproduction, transmission, dissemination, storage, and or use without
the express written consent of Avaya can be a criminal, as well as a
civil offense under the applicable law.
Third-party components
Certain software programs or portions thereof included in the Product
may contain software distributed under third party agreements (“Third
Party Components”), which may contain terms that expand or limit
rights to use certain portions of the Product (“Third Party Terms”).
Information regarding distributed Linux OS source code (for those
Products that have distributed the Linux OS source code), and
identifyingthecopyright holdersoftheThirdPartyComponents andthe
Third Party Terms that apply to them is available on theAvaya Support
Web site: http://support.avaya.com/Copyright.
Trademarks
The trademarks, logos and service marks (“Marks”) displayed in this
site, the Documentation and Product(s) provided by Avaya are the
registered or unregistered Marks of Avaya, its affiliates, or other third
parties. Users are not permitted to use such Marks without prior written
consent from Avaya or such third party which may own the Mark.
Nothing contained in this site, the Documentation and Product(s)
shouldbeconstrued as granting,byimplication,estoppel, orotherwise,
any license or right in and to the Marks without the express written
permission of Avaya or the applicable third party.
Avaya is a registered trademark ofAvaya Inc.
All non-Avaya trademarks are the property of their respective owners,
and “Linux” is a registered trademark of Linus Torvalds.
Downloading Documentation
For the most current versions of Documentation, see the Avaya
Support Web site: http://support.avaya.com.
Contact Avaya Support
Avaya provides a telephone number for you to use to report problems
or to ask questions about your Product. The support telephone number
is 1-800-242-2121 in the United States. For additional support
telephonenumbers,seetheAvayaWebsite: http://support.avaya.com.
2 Avaya WLAN 8100 Quick Start Guide October 2011
Comments? [email protected]

Contents
Chapter 1: Introduction...................................................................................................... 5
Avaya WLAN 8100 system components................................................................................................... 5
Avaya WLAN 8100 system configuration options..................................................................................... 6
Configuration requirements....................................................................................................................... 6
WLAN network design............................................................................................................................... 6
Chapter 2: Completing the preliminary controller configuration................................... 9
Chapter 3: Configuring the Wireless Controller using the CLI....................................... 13
Chapter 4: Configuring the Wireless Controller using the WMS.................................... 21
Installing the Wireless Management System software............................................................................. 21
Licensing the Wireless Management System software............................................................................ 22
Configuring the Wireless Controller using the WMS................................................................................. 22
Chapter 5: Configuring the Wireless Controller using the EDM..................................... 47
Appendix A: DHCP server configuration for access points........................................... 67
Appendix B: Licensing the Wireless Controller............................................................... 69
Obtaining a license for the Wireless Controller......................................................................................... 69
Applying the Wireless Controller license file............................................................................................. 70
Appendix C: Licensing the Wireless Management System software............................ 73
Obtaining a Wireless Management System software license................................................................... 73
Avaya WLAN 8100 Quick Start Guide October 2011 3

4 Avaya WLAN 8100 Quick Start Guide October 2011

Chapter 1: Introduction
Use this Quick Start Guide to configure the Avaya WLAN 8100 system to provide basic Wireless LAN
services using Open Authentication. This document does not cover all the functionality required for a
typical enterprise network and is intended to be used in a demo/test environment.
To configure the Wireless LAN services on the WLAN 8100, complete the following steps:
• complete the preliminary configuration on the WLAN Controller (WC) 8180.
• configure the WC 8180 using the command line interface.
• configure the WC using the Wireless Management System.
• configure the WC using the Enterprise Device Manager.
Avaya WLAN 8100 system components
The WLAN 8100 Solution comprises the following components:
• WLAN Controller 8180
• WLANAccess Point 8120
• Access Point 8120 with ExternalAntenna
• WLAN Management Software 8100
Warning:
The AP8120 and the AP8120 with External Antenna are both designed for indoor use only
and must not be installed outdoors.
Warning:
The AP8120 with External Antenna must be installed by a professional installer.
For more information about these components and the complete solution, see the WLAN 8100
product documentation suite at www.avaya.com.
Important:
The WC 8180 Controller requires licenses to manage the Access Points. The license
activationcode for thecontroller and theinstructions to generatethe license fileare included
in the paper package that is included as part of the controller shipment. You must have the
license file to complete the configuration described in this document.
Avaya WLAN 8100 Quick Start Guide October 2011 5

Avaya WLAN 8100 system configuration options
You can use one of the following tools to configure the WLAN 8100:
• command line interface (CLI)
• WLAN Management System 8100 (WMS) software
• Enterprise Device Manger (EDM)
You must use the CLI to complete the preliminary configuration to connect the Wireless
Controller (WC) 8180 to the network. After you have configured the WC 8180 to connect to
the network, you can use the CLI, WMS, or EDM to configure wireless services.
Configuration requirements
The following components are required to achieve the configuration described in this
document:
• Wirelesss Controller (WC) 8180
• Access Point (AP) 8120 and 8120 with ExternalAntenna
• Power over Ethernet PoE) switch or power injector forAP
• DHCP server
• wireless client
• WLAN Management System (WMS) software server (optional)
• wired client (optional , for WMS or EDM use)
WLAN network design
This guide provides procedures on how to configure the following types of network design.
Introduction
6 Avaya WLAN 8100 Quick Start Guide October 2011
Comments? [email protected]

WLAN 8100 network example 1
WLAN network design
Avaya WLAN 8100 Quick Start Guide October 2011 7

Introduction
8 Avaya WLAN 8100 Quick Start Guide October 2011
Comments? [email protected]

Chapter 2: Completing the preliminary
controller configuration
This chapter provides the procedure to complete the preliminary configuration on the Wireless Controller
(WC) 8180 before you complete the wireless configuration.
Before you begin
Remove the WC 8180 from its packaging and ensure you have the following components and materials:
• WC 8180 device
• console cable
Procedure
1. Power on the WC 8180.
2. When the WC 8180 is up, connect the console cable.
3. Press Ctrl+Y to start.
4. From the MENU screen, select Command Line Interface to go to the CLI.
You are now connected to the WC 8180 device.
5. Use the following command sequence to configure the Layer 2 VLAN. The following example
uses vlan 20 as the VLAN to provide management and wireless services.
WC8180>en
WC8180#configure t
Enter configuration commands, one per line. End with CNTL/Z.
WC8180(config)#vlan create 20 name mgmt-wireless type port
WC8180(config)#vlan members remove 1 1-26
WARNING: STP configuration may be lost on selected ports. You may
need to reconfigure the ports manually.
WC8180(config)#vlan members add 20 1-4
WC8180(config)#vlan mgmt 20
Note:
Before you create the interface IP, select Management Vlan.After you create the interface
IP, you cannot make further changes to the management VLAN.
6. Use the following command sequence to configure Layer 3.
WC8180(config)#interface vlan 20
WC8180(config-if)#ip address 20.20.20.45 255.255.255.0
WC8180(config-if)#exit
WC8180(config)#ip route 0.0.0.0 0.0.0.0 20.20.20.1 1
WC8180(config)#ip route 0.0.0.0 0.0.0.0 20.20.20.1 enable
WC8180(config)#ip routing WC8180(config)#show ip route
===============================================================================
Ip Route
===============================================================================
Avaya WLAN 8100 Quick Start Guide October 2011 9

DST MASK NEXT COST VLAN PORT PROT TYPE PRF
-------------------------------------------------------------------------------
0.0.0.0 0.0.0.0 20.20.20.1 10 20 12 S IB 5
20.20.20.0 255.255.255.0 20.20.20.45 1 20 ---- C DB 0
Total Routes: 2
-------------------------------------------------------------------------------
TYPE Legend:
I=Indirect Route, D=Direct Route, A=Alternative Route, B=Best Route, E=Ecmp Rou te,
U=Unresolved Route, N=Not in HW
WC8180(config)#
WC8180(config)#show vlan ip
==============================================================================
Vid ifIndex Address Mask MacAddress Offset Routing
==============================================================================
Primary Interfaces
------------------------------------------------------------------------------
20 10020 20.20.20.45 255.255.255.0 00:24:B5:1F:7F:80 1 Enabled
------------------------------------------------------------------------------
% Total of Primary Interfaces: 1
WC8180(config)#
7. Use the following command sequence to verify controller connectivity.
WC8180#ping 20.20.20.1
Host is reachable
WC8180#
8. Use the following command sequence to enable TELNET and SNMP access.
WC8180(config)#
WC8180(config)#telnet-access enable
WC8180(config)#
WC8180(config)#snmp-server enable
WC8180(config)#
9. Install and verify the license.
You mustplace theWC 8180license fileon aTFTPserverthatthe WCcan reach.Alternatively,
you can load the license file onto the WC from a USB stick where the license is stored.
For more details on generating the license for the WC, see Obtaining a license for the Wireless
Controller on page 69
After you load the license onto the WC, the WC reboots.
In the following example, 640024B51F7F00.lic is the 64 AP License file downloaded for the
controller.
WC8180#copy tftp license address 20.20.20.9 filename 640024B51F7F00.lic
License successfully downloaded.
NOTE: system must be rebooted to activate license.
WC8180#boot Reboot the unit(s) (y/n) ? yRebooting . . .
Or
WC8180#copy usb license filename 640024B51F7F00.lic
License successfully downloaded.
NOTE: system must be rebooted to activate license.
WC8180#boot Reboot the unit(s) (y/n) ? yRebooting . . .
10. Verify that the licenses are installed correctly. TheAP License Count should indicate the
number of APs the controller is licensed to connect to.
WC8180#show wireless controller license-info
Platform AP Capacity : 256
Licensed AP Capacity : Unlimited
AP License Count : 64
Completing the preliminary controller configuration
10 Avaya WLAN 8100 Quick Start Guide October 2011
Comments? [email protected]

AP License Used Count : 0
WC8180#
11. Enable the Wireless system and configure the Wireless system interface.
Use VLAN 20 for the Management interface, Wireless system interface, and Wireless client
connectivity. In production networks, these can be separate VLANs to isolate network
management traffic from wireless traffic.
WC8180#conf t
Enter configuration commands, one per line. End with CNTL/Z.
WC8180(config)#wireless
WC8180(config-wireless)#interface-ip 20.20.20.45
WC8180(config-wireless)#enable
WC8180(config-wireless)#
WC8180(config-wireless)#show wireless
Status : Enabled
Interface IP : 20.20.20.45
TCP/UDP base port : 61000
WC8180(config-wireless)#
12. Configure the controller to be MDC capable.
WC8180(config-wireless)#
WC8180(config-wireless)#controller mdc-capable
% Domain password should be between 10-15 characters long.
% Password must contain a minimum of 2 upper, 2 lowercase letters
% 2 numbers and 2 special characters like !@#$%^&*()
Enter domain password: *****
Verify Domain password: *****
WC8180(config-wireless)#
The WC 8180 is now configured to provision the controller for Wireless services.
Avaya WLAN 8100 Quick Start Guide October 2011 11

Completing the preliminary controller configuration
12 Avaya WLAN 8100 Quick Start Guide October 2011
Comments? [email protected]

Chapter 3: Configuring the Wireless
Controller using the CLI
Completethis procedureto configurethe WirelessController (WC)8180 usingthe command lineinterface
(CLI).
Before you begin
You must complete the preliminary controller configuration before you can configure the WC.
Procedure
1. Use the following command sequence to join the WC with the Mobility Domain.
WC8180#wireless controller join-domain domain-name AVAYA mdc-address 20.20.20.45
Enter Domain Secret: *****
Use 'show wireless controller domain-membership' to see join status.
WC8180#show wireless controller domain-membership
Domain Name : AVAYA
Domain Role : Active MDC
Domain Action Status : Join Success
Action Failure Reason : None
WC8180#
2. Connect Access Points (AP) to the network.
Note:
The AP 8120 is powered by Power over Ethernet (PoE). You can connect a PoE switch or
an external power injector to the AP.
3. Configure the DHCP server forAP discovery.
TheAvayaAP8120 discovers the controller IP addresses using DHCP option 43 or DNS.This
following example uses the DHCP option. The Option 43 setting must be 08 08 41 56 41 59
41 20 41 50 01 04 14 14 14 2D, where 14 14 14 2D is the HEX representation of the controller
IP 20.20.20.45. For details on how to configure the DHCP server, see DHCP server
configuration for access points on page 67.
4. Discover the APs. Power on the APs by connecting them to the PoE switch or external power
injector.
5. Ensure the APs are connected to the DHCP server.
6. Once theAP receives the controller information from the DHCPserver, theAP connects to the
controller.
All the discovered APs are placed in the discovered AP Table on the controller.
7. Use the following command sequence to verify that the connected AP is discovered by the
controller.
WC8180(config-wireless)#show wireless domain ap discovered
Total number of discovered AP: 3
Avaya WLAN 8100 Quick Start Guide October 2011 13

--------------------------------------------------------------------------
AP MAC AP IP Model Serial Number
----------------- --------------- ------- --------------------------------
00:24:B5:65:65:60 54.54.54.5 AP8120 LBNNTMJXAC004V
00:24:B5:65:65:C0 54.54.54.6 AP8120 LBNNTMJXAC006L
5C:E2:86:0F:51:60 54.54.54.8 AP8120 LBNNTMJXAC018N
--------------------------------------------------------------------------
WC8180(config-wireless)#
8. Use the following command sequence to auto-promote discovered APs to the domain AP
database.
WC8180(config-wireless)#
WC8180(config-wireless)#domain auto-promote-discovered-ap
% Warning: AP database will be synchronized after running config-sync
command.
WC8180(config-wireless)#
Note:
You can also manually add APs to the domain AP database (insert x-ref to step: which will
be explained later in the flow of this section).
9. Use the following command sequence to display the AP status. The following commands
display the Managed Status of the APs and other relevant information. All APs must have a
status of Managed to provide the configured Wireless services.
WC8180#show wireless ap status
Total APs: 3, Managed APs: 3, Failed APs: 0
------------------------------------------------------------------------------
AP MAC AP IP Controller IP Status Need Image
Upgrade
----------------- --------------- --------------- ------------- ----------
00:24:B5:65:65:60 54.54.54.5 20.20.20.45 Managed Yes
00:24:B5:65:65:C0 54.54.54.6 20.20.20.45 Managed Yes
5C:E2:86:0F:51:60 54.54.54.8 20.20.20.45 Managed Yes
------------------------------------------------------------------------------
WC8180#
10. Use one of the following command sequences to perform either a bulk or single AP image
upgrade.
Bulk AP image upgrade
WC8180#
WC8180#wireless domain ap image-update start
WC8180#
Single AP image upgrade
WC8180#
WC8180#wireless ap image-update ?
H.H.H AP MAC Address
WC8180#wireless ap image-update 00:24:B5:65:65:60
11. After you have applied the image upgrade to the AP, use the following command sequence to
verify the upgrade status.
WC8180#show wireless ap status
Total APs: 3, Managed APs: 3, Failed APs: 0
------------------------------------------------------------------------------
AP MAC AP IP Controller IP Status Need Image
Upgrade
----------------- --------------- --------------- ------------- ----------
Configuring the Wireless Controller using the CLI
14 Avaya WLAN 8100 Quick Start Guide October 2011
Comments? [email protected]

00:24:B5:65:65:60 54.54.54.5 20.20.20.45 Managed No
00:24:B5:65:65:C0 54.54.54.6 20.20.20.45 Managed No
5C:E2:86:0F:51:60 54.54.54.8 20.20.20.45 Managed No
------------------------------------------------------------------------------
WC8180#
12. Complete steps 13 through 23 to create profiles. These steps are optional and provided for
demontration purposes.
13. Use the following command sequence to create a mobility VLAN.
WC8180(config-wireless)#
WC8180(config-wireless)#domain mobility-vlan Mobile-Clients
WC8180(config-wireless)#
WC8180(config-wireless)#show wireless domain mobility-vlan
---------------------------------------------------
Mobility VLAN Name Status
-------------------------------- -----------------
default-MVLAN Active
Mobile-Clients Active
---------------------------------------------------
WC8180(config-wireless)#
14. Use the following command sequence to create a network profile.
WC8180(config-wireless)#network-profile 2
Creating network-profile (id = 2) ...
WC8180(config-network-profile)#profile-name AVAYA-Demo
WC8180(config-network-profile)#ssid AVAYA-Demo
WC8180(config-network-profile)#mobility-vlan Mobile-Clients
WC8180(config-network-profile)#exit
WC8180(config-wireless)# WC8180(config-wireless)#show wireless network-profile 2
-------------------------------------------------------------------------
Id Profile Name Mobility VLAN Security Mode Captive Portal
--- ------------------- ------------------- -------------- --------------
2 AVAYA-Demo Mobile-Clients open Disabled
-------------------------------------------------------------------------
WC8180(config-wireless)#
WC8180(config-wireless)#show wireless network-profile 2 detail
Network Profile ID : 2
Name : AVAYA-Demo
SSID : AVAYA-Demo
Hide SSID : No
Mobility Vlan Name : Mobile-Clients
No Response to Probe Request : Disabled
Captive Portal Mode : Disabled
User Validation : open
Captive Portal Profile Id : 0
Local User Group : Default
RADIUS Authentication Profile Name :
RADIUS Accounting Profile Name :
RADIUS Accounting Mode : Disabled
Security Mode : open
MAC Validation : Disabled
Wireless ARP Suppression : Disabled
WC8180(config-wireless)#
15. Use the following command sequence to create a radio profile.
WC8180(config-wireless)#radio-profile 3 access-wids a-n
Creating a radio-profile (id = 3) ...
WC8180(config-radio-profile)#profile-name A-N
WC8180(config-radio-profile)#exit
WC8180(config-wireless)#radio-profile 4 access-wids bg-n
Creating a radio-profile (id = 4) ...
Avaya WLAN 8100 Quick Start Guide October 2011 15

WC8180(config-radio-profile)#profile-name BG-N
WC8180(config-radio-profile)#exit
16. Use the following command sequence to view the radio profiles created in step 15.
WC8180(config-wireless)#show wireless radio-profile 3 detail
Radio Profile Id: 3
Name : A-N
Operation Mode : access-wids
IEEE 802.11 Mode : 802.11a/n
RF Scan - Other Channels : No
Broadcast/Multicast Rate Limiting : Disabled
Broadcast/Multicast Rate Limit (Normal): 50 pkts/sec
Broadcast/Multicast Rate Limit (Burst) : 75 pkts/sec
Beacon Interval : 100 msec
DTIM Period : 10
Fragmentation Threshold : 2346
RTS Threshold : 2347
Short Retry Limit : 7
Long Retry Limit : 4
Max Transmit Lifetime : 512 msec
Max Receive Lifetime : 512 msec
Max Clients : 200
Auto Channel Adjustment Mode : Yes
Auto Power Adjustment Mode : Yes
Non-Auto Transmit Power : 80 %
WMM(Wi-Fi Multimedia Mode) : Enabled
Load Balancing Mode : Disabled
Load Balance Utilization Threshold : 60 %
Station Isolation Mode : Disabled
Channel Bandwidth : 40 MHz
Primary Channel : Lower
802.11n Protection Mode : Auto
SGI(Short Guard Interval) : Disabled
STBC(Space Time Block Code) Mode : Enabled
Multicast Transmit Rate : Auto
APSD(Auto Power Save Delivery) Mode : Enabled
No ACK for Incorrectly Received Frames : Disabled
RRM(Radio Resource Measurement) : Enabled
WC8180(config-wireless)#
WC8180(config-wireless)#show wireless radio-profile 4 detail
Radio Profile Id: 4
Name : BG-N
Operation Mode : access-wids
IEEE 802.11 Mode : 802.11bg/n
RF Scan - Other Channels : No
Broadcast/Multicast Rate Limiting : Disabled
Broadcast/Multicast Rate Limit (Normal): 50 pkts/sec
Broadcast/Multicast Rate Limit (Burst) : 75 pkts/sec
Beacon Interval : 100 msec
DTIM Period : 10
Fragmentation Threshold : 2346
RTS Threshold : 2347
Short Retry Limit : 7
Long Retry Limit : 4
Max Transmit Lifetime : 512 msec
Max Receive Lifetime : 512 msec
Max Clients : 200
Auto Channel Adjustment Mode : Yes
Auto Power Adjustment Mode : Yes
Non-Auto Transmit Power : 80 %
WMM(Wi-Fi Multimedia Mode) : Enabled
Load Balancing Mode : Disabled
Load Balance Utilization Threshold : 60 %
Configuring the Wireless Controller using the CLI
16 Avaya WLAN 8100 Quick Start Guide October 2011
Comments? [email protected]

Station Isolation Mode : Disabled
Channel Bandwidth : 20 MHz
Primary Channel : Lower
802.11n Protection Mode : Auto
SGI(Short Guard Interval) : Disabled
STBC(Space Time Block Code) Mode : Enabled
Multicast Transmit Rate : Auto
APSD(Auto Power Save Delivery) Mode : Enabled
No ACK for Incorrectly Received Frames : Disabled
RRM(Radio Resource Measurement) : Enabled
WC8180(config-wireless)#
17. Use the following command sequence to create anAP profile, and to assign radio profiles and
a network profile to it.
WC8180(config-wireless)#ap-profile 2
Creating ap-profile (id = 2) ...
WC8180(config-ap-profile)#profile-name AP-Profile-2
WC8180(config-ap-profile)#radio 1 profile-id 3 enable
WC8180(config-ap-profile)#radio 2 profile-id 4 enable
WC8180(config-ap-profile)#network 1 1 profile-id 2
WC8180(config-ap-profile)#network 2 1 profile-id 2
WC8180(config-ap-profile)#exit
WC8180(config-wireless)#show wireless ap-profile network 2
--------------------------------------------------------------------
AP Profile Id Radio Id VAP Id Network Profile Id Radio Operation
------------- -------- ------ ------------------ ---------------
2 1 1 2 On
2 2 1 2 On
--------------------------------------------------------------------
WC8180(config-wireless)#show wireless ap-profile radio 2
-------------------------------------------------------
AP Profile Id Radio Id Radio Profile Id Radio Status
------------- -------- ---------------- ------------
2 1 3 On
2 2 4 On
-------------------------------------------------------
18. Use the following command sequence to manually add APs to the Domain AP Database.
You must add all the APs to the Domain AP Database to provide wireless services. Using this
menu, you can also modify other AP parameters. These parameters are not shown in the
following sample code.
WC8180(config-wireless)#domain ap 00:24:B5:65:65:60
Entering domain AP (mac = 00:24:B5:65:65:60) configuration mode...
WC8180(config-domain-ap)#profile-id 2
WC8180(config-domain-ap)#exit
WC8180(config-wireless)#
19. Use the following command sequence to apply the wireless configuration to the AP.
Do config-sync to apply changes to AP.
WC8180#
WC8180#wireless controller config-sync
WC8180#
20. IfthedomainAPrelatedparametershavechanged(forexample,iftheAPprofilehaschanged),
then you must reset the APs for the configuration to take effect.
WC8180#
WC8180#wireless domain ap reset start
WC8180#
21. Use the following command sequence to display the AP status.
Avaya WLAN 8100 Quick Start Guide October 2011 17

ThefollowingcommandsshowtheManagedStatus,andother relevantinformation,oftheAPs.
All APs must have a Managed status to be able to provide the configured wireless services.
WC8180#show wireless ap status
Total APs: 3, Managed APs: 3, Failed APs: 0
------------------------------------------------------------------------------
AP MAC AP IP Controller IP Status Need Image
Upgrade
----------------- --------------- --------------- ------------- ----------
00:24:B5:65:65:60 54.54.54.5 20.20.20.45 Managed No
00:24:B5:65:65:C0 54.54.54.6 20.20.20.45 Managed No
5C:E2:86:0F:51:60 54.54.54.8 20.20.20.45 Managed No
------------------------------------------------------------------------------
WC8180#
WC8180#show wireless ap status detail
Total APs: 3, Managed APs: 3, Failed APs: 0
---------------------------------------------------------------
AP (MAC=00:24:B5:65:65:60)
IP Address : 54.54.54.5
Status : Managed
Hardware Type : Avaya AP8120
Software Version : 1.0.0.0
Serial Number : LBNNTMJXAC004V
Location :
Age (since last update) : 0d:00:00:03
System Up Time : 0d:00:31:33
Discovery Reason : Controller IP via DHCP
Managing Controller : Local Controller
Controller IP Address : 20.20.20.45
Profile Id : 2
Profile Name : ap_002
Configuration Apply Status : Success
Protocol Version : 2
Authenticated Clients : 0
Last Failing Configuration Elements : 0
Configuration Failure Error :
Reset status : Not Started
Code Download Status : Not Started
Image Upgrade Needed : No
Ap Techdump Status : Not Started
---------------------------------------------------------------
WC8180#
22. Use the following command sequence to display the AP VAP (SSID) status.
WC8180#show wireless ap vap status
AP MAC Address: 5C:E2:86:0F:51:60
------------------------------------------------------------------------
Radio
# of Auth
VAP Id VAP MAC Address SSID Clients
-------- ----------------- -------------------------------- ---------
1 / 1 5C:E2:86:0F:51:60 AVAYA-Demo 0
2 / 1 5C:E2:86:0F:51:70 AVAYA-Demo 1
------------------------------------------------------------------------
Total Number of AP(s): 1
WC8180#
23. Use the following command sequence to display the AP radio status
WC8180#show wireless ap radio status
----------------------------------------------------------------------------
AP MAC Radio Operation Channel Power 802.11 Mode Auth Clients
----------------- ----- --------- ------- ----- --------------- ------------
2 On 5 80 802.11b/g/n 1
Configuring the Wireless Controller using the CLI
18 Avaya WLAN 8100 Quick Start Guide October 2011
Comments? [email protected]

----------------------------------------------------------------------------
WC8180#
24. Use the following command sequence to verify wireless client connectivity.
At this point the wireless network is ready for client connectivity. Scan for wireless networks
and connect a wireless client to the network “AVAYA-Demo”. Verify the client status and details
on the WC.
WC8180#show wireless client status
Total number of clients: 1
-------------------------------------------------------------------------------
Client Client Associated Mobility Status
MAC Address IP Address Controller VLAN
----------------- --------------- --------------- --------------- -------------
00:21:91:7F:02:B4 20.20.20.203 20.20.20.45 Mobile-Clients Authenticated
-------------------------------------------------------------------------------
WC8180#
WC8180#show wireless client status detail
Total number of clients: 1
Client (MAC=00:21:91:7F:02:B4)
Client IP Address : 20.20.20.203
User Name :
SSID : AVAYA-Demo
Mobility Vlan : Mobile-Clients
Status : Authenticated
Captive Portal Authenticated User : No
Transmit Data Rate : 130 Mbps
Inactive Period : 0d:00:00:01
Age (since last update) : 0d:00:00:00
Network Time : 0d:00:17:41
Associating Controller : Local Controller
Controller IP Address : 20.20.20.45
Controller MAC Address : 00:24:B5:1F:80:74
802.11n Capable : Yes
STBC Capable : No
AP MAC Address : 5C:E2:86:0F:51:60
BSSID : 5C:E2:86:0F:51:70
Radio Interface : 2
Channel : 5
Network Profile ID : 2
NetBios Name : VISHNUK1
Radio Resource Measurement (RRM) : Unsupported
Location Report Requests : Unsupported
AP Detection via Beacon Table Report : Unsupported
Beacon Active Scan Capability : Unsupported
Beacon Passive Scan Capability : Unsupported
Channel Load Measurement : Unsupported
WC8180#
Avaya WLAN 8100 Quick Start Guide October 2011 19

Configuring the Wireless Controller using the CLI
20 Avaya WLAN 8100 Quick Start Guide October 2011
Comments? [email protected]
