AVE ATM Interface TCPIP232 User manual

OPERATION MANUAL
September 2012
TT
TT
TCPIP232CPIP232
CPIP232CPIP232
CPIP232
Client SerClient Ser
Client SerClient Ser
Client Servv
vv
verer
erer
er

AVE Multiview UK
Endeavor House 3rd Floor
Coppers End Rd.,Stansted,
Essex, CM24 1SJ, UK
Tel: [phone]
Fax: [phone]
Email: [email protected]
www.multiview.net
AVE Thailand Co., Ltd.
147 Soi On-Nut 44
Sukhumvit 77 Rd., Suan Luang
Bangkok 10250,Thailand
Tel: [phone]
Fax: [phone]
Email: [email protected]
http://www.ave.co.th (Thai)
http://www.avethailand.com (English)
AVE Multiview USA
2300 Central Parkway C
Houston, Texas, 77092
Tel: [phone]
Fax: [phone]
Email: [email protected]
http://www.americanvideoequipment.com
AVE Europe LTD
123 Millennium Business Park
Ballycoolin, Dublin 15, Ireland
Tel:[phone] Fax: [phone] Email; [email protected] Website: www.ave-europe.eu
TCPIP232 Client Server
Copyright C AVE Thailand Co., Ltd. 2012
2
TO PREVENT ELECTRIC SHOCK, DO NOT REMOVE
THE COVER. DO NOT EXPOSE THE EQUIPMENT TO
RAIN OR MOISTURE. NO USER SERVICEABLE PARTS
ARE INSIDE. REFER SERVICING TO QUALIFIED
PERSONNEL.
CAUTION!
RISK OF ELECTRICAL SHOCK!
DO NOT OPEN!
WARNING!
THIS EQUIPMENT GENERATES, USES, AND CAN RADIATE RADIO
FREQUENCY ENERGY AND IF NOT INSTALLED AND USED IN AC-
CORDANCE WITH THE INSTRUCTION MANUAL MAY CAUSE INTER-
FERENCE TO RADIO COMMUNICATIONS. IT HAS BEEN TESTED
AND FOUND TO COMPLY WITH THE LIMITS FOR A CLASS A COM-
PUTING DEVICE PURSUANT TO SUBPART J OF PART 15 OF FCC
RULES, WHICH ARE DESIGNED TO PROVIDE REASONABLE PRO-
TECTION AGAINST SUCH INTERFERENCE WHEN OPERATED IN A
COMMERCIAL ENVIROMENT. OPERATION OF THIS EQUIPMENT IN
A RESIDENTIAL AREA IS LIKELY TO CAUSE INTERFERENCE IN
WHICH CASE THE USER AT HIS/HER OWN EXPENSE WILL BE RE-
QUIRED TO TAKE WHATEVER MEASURES MAY BE REQUIRED TO
CORRECT THE INTERFERENCE.

CONTENTS
Introduction.................................................................................................................................4
TCPIP232ClientServer LEDIndicators...............................................................................4
TCPIP232Client Server Connections..................................................................................5
ServerMode Connect withClientMode................................................................... 5
ServerMode ConnectwithMaster / HydraMode ................................................... 5
Client Mode Connect with DVR with Multiple Listening Port .............................. 6
Master / Hydra Mode connect with DVR with Multiple Listening Port .............. 6
TCPIP232ClientServer Settings ........................................................................................... 7
Client Server Programming via Serial Terminal Software ................................... 7
TCPIP232 Client Server PC/DVR Cable(AVE P/N: 021-037-SF) ......................... 7
TCPIP232Client ServerProgrammingvia Telnet.................................................. 8
TCPIP232ClientServer Menu settings...............................................................................11
LANSettings...................................................................................................................11
IPAddressSettings............................................................................................12
ModeSettings .................................................................................................... 13
TelnetSettings...................................................................................................17
POSSettings ..................................................................................................................18
ExceptionReport..............................................................................................18
AlarmNotification ..............................................................................................20
Communicationsettings.............................................................................................21
RS232Settings.................................................................................................. 22
RS485Settings.................................................................................................23
PacketOutput .................................................................................................... 24
Typical ExamplesofPacket Outputs ............................................. 25
AboutFirmware...........................................................................................................26
CablesandPinAssignments ............................................................................................... 26
RS-232PinOut.............................................................................................................26
RS-485PinOut.............................................................................................................. 27
AVERS485 Network Protocol ...............................................................................................28
Warranty......................................................................................................................................26
FIGURES
Figure1. Server ModeConnectwith Client Mode..............................................................5
Figure 2. Server Mode Connect with Master / Hydra Mode ............................................. 5
Figure3. ClientMode Connecting with Multiple PortDVR ..............................................6
Figure 4. Master / Hydra Mode Connecting with Multiple Port DVR .............................. 6
Figure 5. TCPIP232 Client Server Connecting with Serial Terminal Software ............. 7
Figure 6. TCPIP232 Client Server PC/DVR Programming Cable (021-037-SF) .......... 7
Figure 7. TCPIP232 Client Server Connecting with Telnet Direct to PC ...................... 8
Figure 8. TCPIP232 Client Server Connecting with Telnet through Router ............... 8
Figure9.RS-232 DB9F PinOut ............................................................................................26
Figure10. TCPIP232 ClientServerPCB Layout............................................................... 27
Figure11.RS-485RJ45PinOut ............................................................................................ 27
3

Introduction
TheTCPIP232ClientServer Interfaceis designedtodeliver POS/ CashRegisterTransac-
tionDatato a compatible DVRoveran existing EthernetLANconnection in several config-
uresand protocols.
Client Mode
TheClientModeconnectsdirectlytoaPOS/CashRegisterviaRS-232orRS-485torecieve
thePOS transactiondata.Thisconfigurationis oneClient forone POS.Italsohastheability
toconnect totheAVERS-485 Networkas aMaster orHydra whichallows oneClient toread
data from up to 16 VSI-Pro Max. The POS transaction data for either configuration can be
assigneda singleIP addresswith aunique Portnumber foreach POSso acompatibleDVR
candetermine the originationof thePOStransaction data.
ThePOS transactiondatafor eitherconfiguration canalsobe assignedan IDandassigned
asingle IPaddress witha singlePortnumberwhichthenistranslatedbythe ServerMode to
outputdata ofup to16 POSintheAVEProtocol ofGenericASCII, VSI-ADD orVnet viaRS-
232 or RS-485 to compatible DVRs..
Server Mode
TheServer Modehas theability toread thePOS transactiondata thatany Clienthas placed
ontheLANnetworkin eitherTCPor UDPformatandoutputthisdataineither RS-232orRS-
485format withtheAVEGenericASCII,VSI-ADD orVnetprotocol.This datathenconnects
toa compatibleDVRor aVSI-Pro Maxforoverlay. TheServer merelypassesthe data to its
Serial port that is sent from any Client or Hydra on the LAN. Therefore you must set the
protocolappropriately andsimilarlyfor allClients ontheLAN.
Summary
The TCPIP232 Client Server is one device that can be configured in numerous ways as
eithera ClientorServer connectingdirectly toPOS/ CashRegisters orvia theAVERS-485
Network.Multiple Clientsor multipleServerscanbeplacedonthe samenetwork toachieve
anyconfiguration or dataspeed required.
TCPIP232 Client Server LED Indicators(sequence from left to right)
GREEN POWER TCPIP-232Client ServerPowerStatus
RED NET Sending / Receiving RS-232 / RS-485 Data Packet
LAN Network LEDs
YELLOW SPEED OFF=10Mbps, ON=100Mbps Ethernet.
GREEN LINK LANStatus, ON=Ready OFF = Notready
RED RECEIVE TCPIP-232ClientServer Send/Receive data fromLAN
4

Server Mode connect with Client Mode
The DVR receives RS232 or RS485 input in the VSI-ADD or Vnet protocol for Database
storageorTextInsertion fromthe Servermode.The Serverhasreceivedadatapacketfrom
Clientoverthe LAN with amaximumof TCP Clientconnectionsis 3 and UDPClientis 16.
Server Mode Connect with Clients in Master / Hydra Mode
The DVR receives RS232 or RS485 input in the VSI-ADD or Vnet protocol for Database
storageorTextInsertion fromthe Servermode.TheServerhasreceivedadatapacketfrom
the Client configured as a Master / Hydra mode that connects with up to16 AVE RS-485
networkdevices liketheVSI-Pro Max.For thismode youmustset theClient astheMaster/
Hydraandturn Multipleports OFFandPacket output mustset to beVSI-ADD orVNET.
Figure 2. Server Mode connect with Clients as Master / Hydra Mode
Figure 1. Server Mode connect with Client mode
TCPIP232 Client Server Connections
5
Rounter/Network
Switcher
CAT-5
TCPIP232 Client
192.168.0.101
Destination IP
192.168.0.200
Destination
Port 10101
TCPIP232 Client
192.168.0.102
Destination IP
192.168.0.200
Destination
Port 10101
TCPIP232 Client
192.168.0.116
Destination IP
192.168.0.200
Destination
Port 10101
CAT-5
CAT-5
CAT-5
RS232 or RS485
VSI-ADD or Vnet DVR
TCPIP232
Server
TCP or UDP
192.168.0.200
Listening on port
10101
Rounter/Network
Switcher
DVR
TCPIP232 Server
192.168.0.200
Listening on port
10101
RS-485
VSI-PRO
MAX
ID1
TCPIP232
Hydra
Destination IP
192.168.0.200
Destination
Port 10101
CAT-5
RS-485 CAT-5
VSI-PRO
MAX
ID16
RS232 or RS485
VSI-ADD or Vnet

Master / Hydra Mode connect with DVR with multiple listening port text insertion
TheDVRsupports multipleIPPorts forreceivingdata packetsfromup to 16Clients. For
thismode youmustsettheClient asthe Master/ HydraandturnMultipleports ONand
Packetoutput mustset tobegeneric.
Client Mode connect with DVR with multiple listening port text insertion
TheDVRsupports multipleIPPorts forreceivingdata packetsfromup to16Clients.
6
Figure 3. Client mode connect with multiple port DVR.
Figure 4. Master / Hydra mode connect with multiple port DVR.
Rounter/Network
Switcher
CAT-5
TCPIP232 Client
192.168.0.101
Destination IP
192.168.0.200
Destination
Port 10101
TCPIP232 Client
192.168.0.102
Destination IP
192.168.0.200
Destination
Port 10102
TCPIP232 Client
192.168.0.116
Destination IP
192.168.0.200
Destination
Port 10116
CAT-5 CAT-5
CAT-5
192.168.0.200
Listening on port
10101 - 10116
DVR
CAT-5
192.168.0.200
Listening on port
10101 - 10116
DVR
Rounter/Network
Switcher
RS-485
VSI-PRO
MAX
ID1
TCPIP232
Hydra
Destination IP
192.168.0.200
Destination
Port 10101 -10116
RS-485 CAT-5
VSI-PRO
MAX
ID16

Pressthe“Arrow”keyto movethecursororchange theconfigurations.Pressthe“Enter” key
toselect orsavetheconfigurations.
TCPIP232 Client Server Settings via Serial Terminal Software
Connect the PC/DVR cable (021-037-SF) which comes with the TCPIP232 Client Server
adapterto yourserialteminal software.
TCPIP232 Client Server Settings
Figure 5. TCPIP232 Client Server Connecting with Serial Terminal Software
Turn on yourcomputer andrun serial terminalsoftware using VT-100 emulation mode.The
defaultbaudrate forRS232 programmingis19200,noparity, 8-bitdataand1stop bitand no
hardwarehandshaking. Power upyour TCPIP232ClientServer and PressESC key(1BH)
,[(5Bh) andPor p(upperor lowercase)(50H) within5second to enterto the MainMenu.
When you power up the TCPIP232 Client Server the Speed/Link/Recieve LEDs will briefly
illuminateandthengoout andthe“NET” LEDwilllight.Thevalidtimeforentering theESC[P
isfromwhen the“NET” LED isilluminated which is5 seconds.
7
RS232
Serial
TCPIP232
SerialTerminalsoftware
TCPIP232 Client Server
* LAN
- Pos
-Communication
-AboutFirmware
-Exit
TCPIP232 Client Server PC/DVR Cable(AVE P/N: 021-037-SF)
ThisisandRS232Cable toprogramthe IPAddressonTCPIP232and thenremoveandplug
totheDVR toinsertASCIItext onVideo forstandalone application.
TCPIP232 Port PC Port
DB9 Male DB9 Female
Pin-5(GND)-------------------------------------------------- Pin-5(GND)
Pin-2(RXD)--------------------------------------------------Pin-3(TXD)
Pin-3(TXD)--------------------------------------------------Pin-2(RXD)
Figure 6. TCPIP232
Client Server PC/
DVR Programming
Cable (021-037-SF)
Note: Ifyoudo not entertoMain Menu within5 seconds thesystemwill start initializingthe
RS232port againdepending ontheconfigurationsofRS232 communicationsettings menu
but for Master/Hydra mode is still able to program via RS232 port. While in the RS-232
programmingmode theTCPIP232 ClientServerwilldisableallfunctionsincluding LANand
Telnetaccess.Make sureyou ExittheRS-232 programmingmode before anyusage.

PowerupyourTCPIP232 ClientServerand your computerandopen theTelnet Clientpro-
gramonthecomputerandthenTelnettothedefaultIP192.168.0.222Port23oftheTCPIP232
Client Server. Telnet Client program will appear and ask for the Password that the default
telnetpasswordof TCPIP232ClientServer is 9999.
Ifyouare usingHyperTerminalthen setthe “ConnectTo” screen belowto the followingset-
tings.
TCPIP232 Client Server Settings via Telnet
Connectthe CAT-5Cross Cableto theTCPIP232Client Serveradapter toyourTelnetClient
softwarerunningonyourPC.Ifyouareconnectingthrougha routerorswitch thenyoudo not
need to use a Cross Cable and can use a standard CAT-5 cable.
Figure 7. TCPIP232 Client Server connecting with Telnet Client Software on PC
Directly
Figure 8. TCPIP232 Client Server connecting with Telnet Client Software on PC
through Router
TCPIP232ClientServer
CAT-5CrossCable
Telnet ClientSoftwareon PC
TCPIP232ClientServer
CAT-5Cable
Telnet ClientSoftwareon PC
Rounter/NetworkSwitcher
CAT-5Cable
8

PowerupyourTCPIP232 ClientServerand your computerandopen theTelnet Clientpro-
gramonthecomputerandthenTelnettothedefaultIP192.168.0.222Port23oftheTCPIP232
Client Server. Telnet Client program will appear and ask for the Password that the default
telnetpasswordof TCPIP232ClientServer is 9999.
NOTE:
Allthe abovesettingsare basedon thefactorydefault configurationof theTCPIP232 Client
Serverand allcanbe changedby theuser.Thereforeif anythinghas beenchanged youwill
haveto usethe SerialProgrammingmethodtoaccesstheTCPIP232ClientServer tocheck
thesettingsthat havebeenchanged andsetthe aboveaccordingly.IftheTCPIP232 Client
Serveris set forHydra mode theTelnet functionisdisabled andmust use Serial.
Ifyour laptopisconfigured foranother networkorset forObtainthe IPAddressautomati-
callyyou willhave toconfigure asbelow.
Rightclick onthe NetworkConnectionsiconusuallyatthebottom rightof yourscreen and
thelarge “NetworkConnections” windowbelowwilldisplay.Then rightclick ontheLocal
AreaConnection Iconwhichishighlightedand select“Network ProtocolTCP/IP” high-
lightedbelow inthesmall box“LocalArea ConnectionProperties”lower tothe left.Then
clickon “Properties” andthe windowtothe lowerright will display. Changethe settingsas
shownin thebox, saveand exit.
9

Pressthe “Arrow”buttonto movethe cursoror changetheconfigurations.Pressthe “Enter”
buttonto selector savethe configurations.
After you enter the correct password which the default is 9999 then the following Menu will
appearon theTelnetclientprogram screen.
8
Note :TelnetClientmustbe installedand enableontheTelnetClientsoftwarePCfirst.If you
changethe defaultTelnet IPandforgetthenyouwill haveto usethe SerialProgrammethod
onthepreceeding page toremember or change.
TCPIP232 Client Server
* LAN
- POS
-Communication
-AboutFirmware
-Exit
10
Note : Allthemenu settingsthat appearontheTelnetclient programwill bethesame with
themenusettingsoftheserialterminalsoftware.Howeveronceyou enablethe Hydramode
via Telnet and Exit the Telnet mode which means the TCPIP232 Client Server will reboot
withthenewHydramode. WhentheTCPIP232 ClientServerisin theHydramodetheTelnet
programmingmodeis no longersupported. Therefore anyfurtherchanges willneedto be
doneviathe Serial Programmingmode.
The Telnet can remain active while theTCPIP232 Client Server is operational and will not
effectitsoperation.

TCPIP232 Client Server Menu Settings
Press the “Up” or “Down” button to move the cursor to the menu you need to program and
pressthe “Enter”button toentertheselectedsubmenu.
TheTCPIP232Client Serversettingmenuwillappearlikebelow ifthe“Mode”selectin“Mode
Setting”menu(refer to page10)is select tobe “Client”.
TheTCPIP232Client Serversettingmenuwillappearlikebelow ifthe“Mode”selectin“Mode
Setting”menu(refer topage10) isselectedto be“Server”or “Hydra”.
LAN Settings
ToselecttheLANSettingmenu pressthe “Up”or “Down”button tomove thecursorto“LAN”
andpress the“Enter” button.The LANSettings submenu willappear.
The “LAN” setting menu will appear like below if the “Mode’ select in :Mode Setting” menu
(refer to page 10) is selected to be “Client” or “Server”
11
TCPIP232 Client Server
* LAN
- POS
-Communication
-AboutFirmware
-Exit
TCPIP232 Client Server
* LAN
-Communication
-AboutFirmware
-Exit
LAN Settings
* IPAddress
- Mode
-Telnet
-Exit

IPAddress Settings
To define an IPAddress, Subnet Mask and Gateway of the TCPIP232 Client Server, press
the “Up” or “Down” button to move the cursor to “IPAddress” and press the “Enter” button.
The“IPAddressSettings”sub menuwill appear likebelow.
The “IPAddress” setting menu will appear like below if the “Mode” select in “Mode Setting”
menu(referto page 10)is selected tobe“Client” or “Hydra”
The “IPAddress” setting menu will appear like below if the “Mode” select in “Mode Setting”
menu (refer to page 10) is selected to be “Server”
The “LAN” setting menu will appear like below if the “Mode” select in “Mode Setting” menu
(refer to page 10) is selected to be “Hydra”
12
LAN Settings
* IPAddress
- Mode
-Exit
IPAddress Settings
* IPAddress 192.168.0.0
- Destination IP 192.168.0.0
- Subnet Mask 255.255.0.0
- Gateway 192.168.1.1
-Exit
IPAddress Settings
* IPAddress 192.168.0.0
- Subnet Mask 255.255.0.0
- Gateway 192.168.0.0
-Exit

IPAddress
Todefinethe IPAddressof theTCPIP232ClientServer,pressthe “Up”or“Down” buttonto
move the cursor to “IPAddress” and press the “Enter” button. The cursor will start to flash.
Pressthe“Up” or “Down”orpress the numberbuttonon your keyboardtodefine the IPAd-
dressfrom 0 -255 andthenpress the“Enter” buttonwhenthe desiredvalue is displayed.
Destination IP
TodefinetheDestinationIPof theTCPIP232ClientServer,press the“Up”or“Down”buttonto
movethecursor to“DestinationIP”andpressthe“Enter”button.Thecursor willstartflashing.
Pressthe “Up”,“Down”orpress thenumber buttonon yourkeyboardtodefinethe Destina-
tionIP from 0- 255andpress the“Enter” button whenthe desiredvalueis displayed.
Subnet Mask
TodefinetheSubnetMaskoftheTCPIP232 ClientServer.Pressthe“Up”or“Down”buttonto
movethecursor tothe“Subnet Mask”andpressthe“Enter”button.Thecursorwillstartflash-
ing.Pressthe“Up”,“Down”orpressthenumberbuttononyourkeyboardtodefinetheSubnet
Maskfrom0 -255 and pressthe “Enter”buttonwhen thedesiredvalue isdisplayed.
Gateway
To define the Gateway of the TCPIP232 Client Server. Press the “Up” or “Down” button to
movethe cursorto the“Gateway” andpressthe“Enter”button.Thecursorwillstart flashing.
Pressthe “Up”, “Down”or pressthe numberbuttononyourkeyboardtodefinetheGateway
from0 - 255and press the“Enter” buttonwhenthe desiredvalueis displayed
Mode Settings
Toselectanoperating modeoftheTCPIP232Client Server.Pressthe“Up”or “Down”button
tomove thecursor tothe“Mode”andpressthe“Enter” button.The ModeSettings submenu
willappear.
13
Mode
The“Mode”settingsconfigurestheTCPIP232ClientServerintooneofthreeoperatingmodes,
theClient, Serveror Hydra.
Client Mode
The Client mode allows the device to connect to one POS / Cash Register, VSI-Pro or VSI-
ProMax viaRS-232 orRS-485 andsend thisdata overthe LANin eitherTCP orUDP Proto-
col with an IPAddress and Port Number assigned to that device. The Client has different
performance specifications depending on the configuration, see the following page for de-
tails.
Mode Setting
* Mode Client
-Protocol TCP
-DestinationPort 10101
-LocalID N/A
-Exit

Server Mode
The Server mode allows the device to recieve data from multiple Clients or Hydras on the
LAN network and send this data out via RS-232 or RS-485 to a compatible DVR or device.
The protocol of this output is configured on the Client or Hydra device so all need to be set
similarly.This mode supportseitherTCPor UDPprotocol.
Note: TheServrer hasdifferent performancespecificationsbasedonthesystemconfigura-
tion,see below.
Hydra Mode
The Hydra Mode is a special type of a Client mode that supports theAVE RS-485 Network
protocolto connect upto 16VSI-ProMax withone device.Inthis modeit canbeconfigured
to send all 16 POS data to the Server Mode using only one IP:Port or assign a single IP
addressandunique:PorttoeachPOS. Thelatermethod iscommonlyused todeliverdata to
compatible DVRs. This mode supports either TCP or UDP protocol. See below for the per-
formancespecifications basedonsystem configuration.
Performance Based on Configuration
TheServer hasdifferentperformancespecificationsfor differentconfigurations.
Servercan supportonly 3ClientswithuniqueIP:PORTandTCP Protocol
Servercan support 16Clientswith uniqueIP:PORT andUDPProtocol
ServercansupportHydraconnected to16 VSI-ProMaxwithoneIP:PORT withTCPorUDP
Servercan supportonly 3Hydras withunique IP:PORTand TCPProtocol
Servercan support16Hydraswithunique IP:PORTand UDPProtocol
Servercan support only3unitsof anycombinationof Clientor HydrasusingTCP.
Servercan support upto 16unitsof anycombinationof Clientor Hydras usingUDP
The Hydra when supporting Multiple Ports with TCP protocol with many VSI-Pro Max con-
nectedas slaves mayexhibit aslowdown ofthe updateofthe POSdata inhightransaction
rateinstallations. Ifthis isthecaseyoumust reducethe numberof VSI-ProMax slavescon-
nected to one Hydra and add additional Hydra units to accomodate the remaining VSI-Pro
Maxup to16 maximum.Thereforeinthistype ofinstallation hightransaction ratePOS units
should be connected with low transaction rate POS units to one Hydra to balance the data
throughput.UDP Protocoldoes notexhibit thisslowdowntoanysignificantlevel.
14

Mode setting menu will appear like below if Mode is selected to be “Server”.
Mode setting menu will appear like below if Mode is selected to be “Hydra”.and “Multiple
Ports” in Mode Setting menu is selected to be “ON” (refer to page 12).
15
Modesetting menuwill appearlike belowifModeselectinModesettingmenuis selectto be
“Hydra”.AndMultiple PortsinMode settingmenuis selecttobe “OFF”(refertopage12).
Mode Setting
* Mode Hydra
-Protocol TCP
- Multiple Ports OFF
-DestinationPort 10101
-Exit
Mode Setting
* Mode Hydra
-Protocol TCP
- Multiple Ports ON
-ID Settings
-Exit
Mode Setting
* Mode Server
-Protocol TCP
- Listening Port 10101
-Exit
Mode setting menu will appear like below if Mode is selected to be “Client”.
Mode Setting
* Mode Client
-Protocol TCP
-DestinationPort 10101
-LocalID N/A
-Exit
Toselectthe Modeof theTCPIP232Client Server.Press the“Up” or“Down” buttontomove
thecursorto“Mode”and pressthe“Enter”button.Thecursorwillstartflashing.Pressthe“Up”
,“Down”to changethemode to“Client”, “Server”or “Hydra” and Pressthe“Enter” button
whenthe desiredvalueis displayed,

16
Protocol
To selecttheprotocol of TCPIP232Client Server. Press the“Up”or “Down” button tomove
thecursor to“Protocol” andpress the“Enter”button.Thecursorwillstart flashing.Press the
“Up”,“Down”tochangetheProtocolto“TCP” or“UDP”andpress the“Enter”buttonwhen the
desired value is displayed
Listening Port
Ifthe Modeselectis setto “Server” thentheListening Portwill appear.Todefinethe Listen-
ingPort pressthe “Up”or “Down”button tomove thecursor tothe “ListeningPort” andpress
the“Enter”button. Thecursor willstart flashing.Press the“Up”,“Down”orpressthenumber
button on your keyboard to change the Listening port port from 0 - 65535 then press the
“Enter”button whenthe desiredvalue isdisplayed
Destination Port
If the Mode select is set to “Client” or Mode select to set to be “Hydra” and Multiple Ports is
setto “OFF”thentheDestinationPortwillappear.TodefinetheDestinationportofTCPIP232
Client Server.Press the“Up”or “Down”button tomovethe cursorto “Destination Port”and
pressthe“Enter” button. The cursorwillstart flashing. Press the“Up”, “Down” or pressthe
numberbutton onyourkeyboardtochange theDestinationportfrom0-65535 press“Enter”
button whenthe desiredvalueis displayed.
Local ID
Ifthe Modeselectissetto “Client”thenLocalIDwill appear.TodefinetheLocalID. Pressthe
“Up” or “Down” button to move the cursor to “Local ID” and press the “Enter” button. The
cursorwill startflashing. Pressthe “Up”,“Down”tochangetheIDfromN/A,1- 16and press
the“Enter”button whenthedesired valueisdisplayed. N/AacutallyNonesoifselectednoID
will be added to the data.
Multiple Ports
If the Mode is selected to be “Hydra” then Multiple Ports will appear. To select the Multiple
Ports. Press the “Up” or “Down” button to move the cursor to “Multiple Port” and press the
“Enter”button.The cursorwillstart flashing.Pressthe “Up”, “Down” tochange the Multiple
Portsto “ON” or“OFF” andpressthe “Enter”button whenthedesired valueis displayed
ID Settings
Ifthe Mode isselected tobe“Hydra” andMultiple Portsisset to“ON” thenIDSettings Ports
willappear.Toselect theIDsetting.Pressthe “Up”or“Down”buttontomovethe cursorto“ID
Settings”and pressthe“Enter” button.TheID Settingsubmenuwillappear likebelow.
ID Settings
* ID 1
- Destination Port 10101
-Exit

Telnet Port
TodefinetheTelnetPort. Pressthe “Up”or “Down”button tomove thecursor to“TelnetPort”
andpress the “Enter”button. Thecursorwill startflashing.Press the“Up” , “Down”or press
the number on your keyboard to change the Telnet Port from 0-65535 and the Telnet Port
defaultis23thenpressthe“Enter”button whenthedesiredTelnetportis displayed.Ifyou set
theTelnet portto zerothen itwill bedisabledforzerois notallowed tobe assignedas aport.
Change Password
TodefinetheTelnetpassword.Pressthe “Up”or“Down”buttontomovethecursorto“Change
Password”andpress the “Enter”button.Then the ChangePassword submenu willappear
and asking for input a New Password then press the ”Enter” button will ask again to input
ConfirmPasswordagain. TheTelnet passworddefaultis 9999.
ID
To define the ID. Press the “Up” or “Down” button to move the cursor to “ID” and press the
“Enter”button. Thecursor willstart flashing.Press the“Up” ,“Down” tochange theID from1
-16 and press the“Enter” buttonwhenthe desiredvalueis displayed
Destination Port
Todefine theDestinationPort ofeachID.Pressthe “Up”or“Down” buttontomovethecursor
to “Destination Port” and press the “Enter” button. The cursor will start flashing. Press the
“Up”, “Down”or pressthenumberonyour keyboardto changethe DestinationPort from0 -
65535 andpress the “Enter”button whenthedesired valueisdisplayed
17
Telnet Settings
Pressthe “Up”or“Down”buttontomovethe cursorto“TelnetSettings”and pressthe“Enter”
button.TheTelnetSettingsmenu willappear.
Change Password
NewPassword:
Telnet Setting
*Telnet Port 23
-ChangePassword
-Exit
Exit
Pressthe“Up” or“Down”button tomovethe cursorto“Exit” andpressthe “Enter”buttonto
exitfrom the LANSettings menuandback toTCPIP232 ClientServerMain Menu.

POS Settings
To select a POS Setting menu by press the “Up” or “Down” button to move the cursor to
“POS”and pressthe“Enter” button.The POSSetting submenuwill appear
Exception Report ADDRESS
TheException Reportgivesyou theoption toassign textoutput,triggeranalarming device,
sendinternet datapacketorsenddatatoanother serialdevice onanyquestionabletransac-
tion that you have preprogrammed into the TCP232 Client Server. The TCPIP232 Client
Server will allow programming of up to 24 separate exceptions. These exceptions can be
VOIDS, REFUNDS, COUPONS, PAID OUT, RETURNS, individual departments, specific
items,orany transactionthat you determine(by programming)tobe “exceptional”orques-
tionable.
Exception NO
Toselectthe ExceptionNo. that youwish toprogramfrom 1to 24, pressthe “Up”or“Down”
buttontomovethecursorto“Exception NO.”andpress “Enter”.Thecursor willstartflashing.
Usethe “Up” &“Down” buttontosequencefrom1to24. Make yourselection andpress the
“Enter”button.
Output
TheOutput controlsdatafrom theTCPIP232Client ServerONor OFF.Typicallythis issent
to an RS232/RS485 device or a Network device.
Tomakeyourselection,pressthe“Up”or“Down”buttontomovethecursorto“OUTPUT”and
press“Enter”. Pressthe“Up” or“Down” buttonto togglebetween“ON”or“OFF”. Makeyour
selectionand pressthe “Enter”button 18
POS Settings
*Exception Report
-AlarmNotification
-Exit
Exception Report
*Exception NO 1
-Output ON
-Operator NONE
-Value 0.00
-Exception String
NO SALE
-Exit
Note : POS Setting menu will appear if Mode selcet to be Client in Mode setting
menu only.

Operator
TheOperator determinesthebehaviorofthe valueset inthe Valuesetting.
Youcandefine rangesforyour exceptionsandhave theTCPIP232 ClientServeralarm when
anexception fallswithin therange’sparameters.Thechoices are“Greater Than(>)” ,“Less
Than (<)”, “Equal To (=) ” , “GreaterThan or Equal (>=)” , “LessThan or Equal (<=)” , “Not
Equal (NE)”and “NONE”.Toprogram theoperator,press the“Up” or“Down”buttontomove
thecursor to“OPERATOR”andpressthe“Enter”button.The cursorwillstartflashing. Press
the “Up” or “Down” button to cycle through the operator selections and press the “Enter”
buttonwhen thedesired valueisdisplayed.
Value
TheValuedefinesfrom0-99,999,999.99the limitsoftheOperator.Theseare numericonly.
To program the value, press the “Up” or “Down” button to move the cursor to “Value” and
press the “Enter” key. The first “0” in the range starts to flash. This means it is active and
readyforprogramming. Pressthe“Up” or “Down”button to cyclethroughthe valuesoruse
yourkeypad to enterin thenumericvalue. Usethe “Right” or“Left” keystomove tothe next
numerial.Press the“Enter”buttonwhenthe desiredvalue isdisplayed tosave.
Exception String
TheTCPIP232 Client Servercompares the data entered in the Exception String to the
incomingdatafrom thePOS.The ExceptionStringcanalsobe usedwithout adefinedrange.
Exampleofthiswouldbe toassignaword“ VOID”asanexception. TCPIP232Client Server
willlook forthatstringsorange definitionis notnecessary.However,exceptionstring“ VOID”
couldbe furtherdefinedbyassigningaRange,i.e. all“VOID” over$20.Youcanalsodefinea
globalexception toremove thetransactions.
You canalso usea wildcard symbol“*”,anasteriskonanydatalocationor “?”for anysingle
character.An exampleof thiswould beinstead ofassigning eightdifferent exception strings
for dept 00 to dept 07, you can assign only one exception string e.g. “dept *” or “dept 0?”.
Thatwild cardexceptionstringwillhandle exceptionsfor alleight departments.
To program the exception string, press the “Up” or “Down” button to move the cursor to
“Exception String” and press “Enter”. The first 40 character exception will become active
afterflashing.
Exit
Press the “Up” or “Down” button to move the cursor to “Exit” and press “Enter” key for exit
fromthe POSsettingmenu andback totheTCPIP232 ClientServer mainmenu.
19

Alarm NO
TheTCPIP232ClientServerallowsyouupto16alarmsthatmaybeusedwithanyof theuser
programmed exceptions. However there are only 2 hardwired alarm outputs and these
correspondtoAlarm1 &2only.Theother 14alarmscan beusedto send triggertext, serial
dataoutor flashthe screen.To selecttheAlarmNO thatyouwanttoprogram, pressthe “Up”
or“Down” buttontomovethecursor to“ALARMNO.” andpress“Enter”. Thecursor willstart
flashing.Press the“Up”or“Down”button tocycle throughthe valuesfrom1 to16 andpress
“Enter”when thedesiredvalue isdisplayed.
Alarm Trigger
AnAlarmTriggeris thesource of activityprogrammed to activatea certainalarm.The alarm
triggertells the TCPIP232Client Serverwhatexception touse totriggerthe alarmingdevice
orthe on-screenflag.
Exceptions1-12 :alarmswhen dataisreceived thatmatches any dataset in
Excep tion 1-12.
Exceptions13-24:alarmswhendata isreceive thatmatchany dataset in
Exception13-24.
Exceptions1-24 :alarmswhen dataisreceived thatmatches any dataset in
Exception.
RTS:Externalalarminput.The TCP232ClientServer has1alarminput,if youarenot
usingthe handshakingfunction.Acontact closureto groundon pin7(pin5isground)
willtrigger thisalarm. Coupledwith theRTS Triggeredtext, youcan nowdisplaya40
charactermessage froman externalalarm input.
Alarm Notification
Toselect aAlarm Notification menubypress the“Up” or“Down”button tomove thecursorto
“Alarm Notification” and press the “Enter” button. TheAlarm Notification sub menu will ap-
pear;
20
Alarm Notification
*Alarm NO 1
-Alarm Trigger EX 1
- Triggered Text ON
-Exit
