NEC Univerge SV8100 R2 Installation guide

SV8100 R2
Release Overview
Date: 17 April 2009
Version: V2.01

Copyright 2008 NEC Philips Unified Solutions B.V. Exclusively for use by NEC Philips channel partners
All rights are reserved. Reproduction whole or in part is prohibited without the written consent of the copyright owner. 2 of 19
Contents
1. PRODUCT SUMMARY ........................................................................................................................ 4
2. OVERVIEW........................................................................................................................................... 4
3. NEW AND ENHANCED BUSINESS FEATURES............................................................................... 5
3.1 3KSU .......................................................................................................................................... 5
3.1.1 Benefits.............................................................................................................................. 5
3.1.2 Required Software and Hardware ..................................................................................... 5
3.2 ETIA.......................................................................................................................................... 5
3.2.1 Benefits.............................................................................................................................. 6
3.2.2 Required Software and Hardware ..................................................................................... 6
3.2.3 Training Course Required ................................................................................................. 6
3.3 RTB (InRouter) ......................................................................................................................... 6
3.3.1 Benefits.............................................................................................................................. 7
3.3.2 Requirements..................................................................................................................... 7
3.3.3 Training Course Required ................................................................................................. 7
3.4 Hotel/Motel (PMS Adaptor)...................................................................................................... 7
3.4.1 Benefits.............................................................................................................................. 8
3.4.2 Requirements..................................................................................................................... 8
3.4.3 Training Course Required ................................................................................................. 8
3.5 Flexible Length DDI ................................................................................................................. 8
3.5.1 Benefits.............................................................................................................................. 8
3.5.2 Requirements..................................................................................................................... 8
3.6 InMail –Voice Mail to e-mail................................................................................................... 8
3.6.1 Benefits.............................................................................................................................. 8
3.6.2 Requirements..................................................................................................................... 8
3.7 VoIP Encryption........................................................................................................................ 8
3.7.1 Benefits.............................................................................................................................. 9
3.7.2 Requirements..................................................................................................................... 9
3.8 DECT M155 Terminal ............................................................................................................ 10
3.8.1 Benefits............................................................................................................................ 10
3.8.2 Requirements................................................................................................................... 10
3.9 Gigabit Adaptor....................................................................................................................... 10
3.9.1 Benefits............................................................................................................................ 11
3.9.2 Requirements................................................................................................................... 11
3.10 Bluetooth Cordless.................................................................................................................. 11
3.10.1 Benefits............................................................................................................................ 11
3.10.2 Required Software and Hardware ................................................................................... 11
3.11 PSA Adaptor............................................................................................................................ 12
3.11.1 Benefits............................................................................................................................ 12
3.11.2 Requirements................................................................................................................... 12
3.12 Screensaver.............................................................................................................................. 12
3.12.1 Benefits............................................................................................................................ 12
3.12.2 Requirements................................................................................................................... 12
3.13 Port Down ............................................................................................................................... 12
3.13.1 Benefits............................................................................................................................ 12
3.13.2 Requirements................................................................................................................... 12
3.14 Terminal Side Panels............................................................................................................... 12
3.14.1 Benefits............................................................................................................................ 13
3.14.2 Requirements................................................................................................................... 13
3.15 Directory Card Holder............................................................................................................. 13
3.15.1 Benefits............................................................................................................................ 13
3.15.2 Requirements................................................................................................................... 13

Copyright 2008 NEC Philips Unified Solutions B.V. Exclusively for use by NEC Philips channel partners
All rights are reserved. Reproduction whole or in part is prohibited without the written consent of the copyright owner. 3 of 19
3.16 PC Pro ..................................................................................................................................... 13
3.16.1 Benefits............................................................................................................................ 13
3.16.2 Required Software and Hardware ................................................................................... 13
3.17 BCT Integration........................................................................................................................ 13
3.17.1 Benefits............................................................................................................................ 14
3.17.2 Required Software and Hardware ................................................................................... 14
3.18 MyCalls .................................................................................................................................... 14
3.18.1 Benefits............................................................................................................................ 15
3.18.2 Required Software and Hardware ................................................................................... 15
3.19 Tiger Software Compatibility.................................................................................................. 15
3.19.1 Benefits............................................................................................................................ 15
3.19.2 Required Software and Hardware ................................................................................... 15
4. SOFTWARE AND HARDWARE ........................................................................................................16
5. TECHNICAL DOCUMENTATION ....................................................................................................18
6. TECHNICAL COURSES .....................................................................................................................19

Copyright 2008 NEC Philips Unified Solutions B.V. Exclusively for use by NEC Philips channel partners
All rights are reserved. Reproduction whole or in part is prohibited without the written consent of the copyright owner. 4 of 19
1. PRODUCT SUMMARY
Business today demands efficient, seamless communication to enable rapid decision-making and
customer responsiveness. NEC’s UNIVERGE®360 is our approach to help small to medium-sized
businesses succeeds at this accelerated level by unifying all aspects of business communication. The
UNIVERGE SV8100 Communications Server is an integral part of this initiative.
The SV8100 Communications Server is the ideal system for small to medium-sized businesses that
wish to compete and grow their businesses over time. This robust, feature-rich solution is scalable and
can be expanded to meet your communications needs both now and in the future.
Designed to be both versatile and scalable for growing business needs, the SV8100 supports IP, TDM
video, wired or wireless. It also provides high-powered features and applications that can be
transparently shared between branch or remote locations. Individuals, departments and locations can
work more efficiently by using this feature to communicate seamlessly in real time.
The UNIVERGE® SV8100 Communications Server provides converged communications - telephony,
data and video over an IP infrastructure. The solution is targeted at the small to medium sized business
and supports between 8 and 512 users on a single site, and a variety of networking possibilities.
2. OVERVIEW
SV8100 R1 series software was introduced with the release of the UNIVERGE SV8100. The SV8100
continues to provide new and enhanced features with the release of 8100 R2 series software and new
hardware items.
R2 software and hardware includes the new and enhanced features :-
SV8100 Hardware - 3KSU, ETIA (Gigabit Switch), RTB (InRouter), Hotel/Motel (PMS Adaptor)
SV8100 Software - Flexible Length DDI, InMail Voice Mail to e-mail, VoIP Encryption
Terminals - DECT M155 Terminal, Gigabit Adaptor, Bluetooth Cordless (Handset/Hub), PSA
Adaptor, Screensaver, No port down, VoIP Encryption
Application - PC Programming, BCT Integration, Tiger Software Compatibility, MyCalls
For additional information on the SV8100 please refer to Product Overview SV8100 R2 document. All
training courses against new items require the relevant pre-requisite courses.

Copyright 2008 NEC Philips Unified Solutions B.V. Exclusively for use by NEC Philips channel partners
All rights are reserved. Reproduction whole or in part is prohibited without the written consent of the copyright owner. 5 of 19
3. NEW AND ENHANCED BUSINESS FEATURES
3.1 3KSU
The 3 KSU is a half size cabinet aimed at the smaller business market. It consists of :-
9.5 inch 2U System 1 CPU and 2 optional slots
Uses the same CPU as the 19” 2U Rack System
On Board VoIP resources (via Optional IPLA daughterboard, no slots required)
On Board Voice Mail (via Optional InMail daughterboard, no slots required)
Not upgradeable to 19” rack
32TDM Ports 512 IP Ports
3.1.1 Benefits
Aimed for the smaller user. Small footprint, easily wall mountable. Quiet (no fan).
3.1.2 Required Software and Hardware
3KSU
SV8100 R2 Software
3.2 ETIA
The ETIA is an 8 Port Ethernet Switch providing up to gigabit connectivity and POE (802.3af). It uses
a slot of the SV8100 Chassis (upto 3 cards can be placed in each chassis).
The ETIA offers:-
Ethernet Ports :-
•8 Gigabit Ethernet (10/100/1000 auto negotiating) ports
•Status LEDs indicating link, speed and activity
•8-port PoE (802.3af) with dynamic PoE control (allows setting the proper PoE classifications
for each port to stay within the system power budget)
•Auto-MDI/MDIX –automatically detects and corrects crossover cables
Layer 2 Switch Functionality :-
•802.1Q (VLAN Bridging)
•Independent VLAN Learning Support
•802.1P (Priority Queuing)
•Port Mirroring

Copyright 2008 NEC Philips Unified Solutions B.V. Exclusively for use by NEC Philips channel partners
All rights are reserved. Reproduction whole or in part is prohibited without the written consent of the copyright owner. 6 of 19
•802.3x Flow Control
Blade Management :-
•Multi-unit stacking (multiple blades (3 in a stack) in a system are managed from the
•same user interface)
•Switch management through Web-based GUI
•Software upgrades via Web-based interface
•Configuration Upload/Download
3.2.1 Benefits
Provides an in skin Ethernet Switched hub providing all the LAN functionality and power required for
an IP telephony (DT7XX) installation.
3.2.2 Required Software and Hardware
CD-ETIA
SV8100 R2 Software
3.2.3 Training Course Required
SV8100 ETIA
3.3 RTB (InRouter)
The RTB (InRouter) is a router card providing :-
CD-RTB Router
•4-port switching hub with 10Base-T/100Base-TX (10Mbps / 100Mbps)
•In-skin solution for converged high voice quality networking services
•Stateful packet inspection firewall and VPN based security
•Easy remote monitoring and troubleshooting, e.g. detailed MOS statistics
•T1 or 10 / 100 Mbps Ethernet WAN connectivity
•Power over Ethernet
•Max nr of CD-RTB blades:

Copyright 2008 NEC Philips Unified Solutions B.V. Exclusively for use by NEC Philips channel partners
All rights are reserved. Reproduction whole or in part is prohibited without the written consent of the copyright owner. 7 of 19
3.3.1 Benefits
Provides an in skin router providing generic router functionality and high level VoIP monitoring and
shaping tools.
3.3.2 Requirements
CD-RTB
SV8100 R2 Software
3.3.3 Training Course Required
SV8100 Router
3.4 Hotel/Motel (PMS Adaptor)
The PMS is an external unit providing conversion of the SV8100 hotel interface to a Fidelio standard
interface. The interface is Fidelio Certified.
LAN
Serial Interface
I-Series Protocol
Fidelio Protocol
PMS
Adapter

Copyright 2008 NEC Philips Unified Solutions B.V. Exclusively for use by NEC Philips channel partners
All rights are reserved. Reproduction whole or in part is prohibited without the written consent of the copyright owner. 8 of 19
3.4.1 Benefits
Provides Fidelio standard interface allowing a variety of Hotel features.
3.4.2 Requirements
PMS Adaptor
Hotel License
SV8100 R2 Software
3.4.3 Training Course Required
SV8100 Hotel
3.5 Flexible Length DDI
Provides ISDN Overlap receiving Flexible Length DDI popular in territories such as Germany and
Austria.
3.5.1 Benefits
Allows the SV8100 to be sold in territories/carriers utilising the Overlap Flexible Length DDI
functionality of ISDN.
3.5.2 Requirements
SV8100 R2 Software
3.6 InMail –Voice Mail to e-mail
The InMail now allows voice mails notification to be sent to an e-mail address. The notification can be
with or without the .wav file voice message.
3.6.1 Benefits
Give expand possibilities for notification. Allows one point of access for notification and listening of
voice mails.
3.6.2 Requirements
SV8100 R2 Software
InMail
Any InMail license (there is no specific license for this feature, as long as the InMail is licensed for
normal operation, this feature will work).
3.7 VoIP Encryption
The RTP and SIP signalling can now be encrypted (128bit AES). This is joint feature between DT7XX
and IPLA. Encryption can occur to the SV8100 or Peer to Peer between DT7XX’s. User can see if in
secure speech mode by key present on the DT7XX display.

Copyright 2008 NEC Philips Unified Solutions B.V. Exclusively for use by NEC Philips channel partners
All rights are reserved. Reproduction whole or in part is prohibited without the written consent of the copyright owner. 9 of 19
3.7.1 Benefits
Provides secure speech as with Encryption enabled, it will not be possible to listen to conversations by
capturing packets on the network.
3.7.2 Requirements
SV8100 R2 Software
DT7XX V2.2.1.0 Firmware
Encryption License
PSTN
Peer to Peer RTP Encrypted
DT7XX to IPLA - RTP Encrypted

Copyright 2008 NEC Philips Unified Solutions B.V. Exclusively for use by NEC Philips channel partners
All rights are reserved. Reproduction whole or in part is prohibited without the written consent of the copyright owner. 10 of 19
3.8 DECT M155 Terminal
The M155 DECT Terminal has been released. This is an extremely portable DECT device with wrist
strap (worn as a watch). Able to take speech calls and make calls to pre-configured numbers
3.8.1 Benefits
Extremely portable, easy wearing.
3.8.2 Requirements
M155
DAP
IP Terminal License
3.9 Gigabit Adaptor
An Adaptor for DT7XX’s providing gigabit connection ports for PC connectivity. Attaches to DT7XX
by replacing legs. Allow tilt levels.

Copyright 2008 NEC Philips Unified Solutions B.V. Exclusively for use by NEC Philips channel partners
All rights are reserved. Reproduction whole or in part is prohibited without the written consent of the copyright owner. 11 of 19
Contents:-
3.9.1 Benefits
Allows gigabit to the desktop PC and a connection to the DT700 via one customer data socket.
3.9.2 Requirements
Gigabit Adaptor (GBA-L)
Gigabit Adaptor Power Supply
AC Adaptor Cable
3.10 Bluetooth Cordless
The Bluetooth functionality is only supported on the DT330 terminals. The Bluetooth functionality
comes in two unique modes. The first is a Bluetooth handset with integrated Bluetooth hub. When this
adapter is installed on the DT330 it will acquire both ports 1 and 2 of the terminal. The second adapter
is the Bluetooth hub (only). This allows for 3rd party peripheral devices (wireless headsets) which
support audio only functionality connectivity to the DT330 terminal.
3.10.1 Benefits
Device allows users the ability for Bluetooth functions with their system extension.
3.10.2 Required Software and Hardware
DTL-12BT-2P (BK) TEL (Phone with Bluetooth headset pre-built)
Or use existing DT330 with
BCH-LP (BK) UNIT (for Handset) or BHA-L (for Hub)

Copyright 2008 NEC Philips Unified Solutions B.V. Exclusively for use by NEC Philips channel partners
All rights are reserved. Reproduction whole or in part is prohibited without the written consent of the copyright owner. 12 of 19
3.11 PSA Adaptor
The power fail adaptor (PSA) is a replacement handset cradle available for use with DT330/730
terminals (more typically a DT730). This connects to an analogue port allowing calls to be
made/received if for example the VoIP link could not be used due to an ADSL problems (where the
analogue line is still functional).
3.11.1 Benefits
Allows call connectivity if power fail or IP connectivity problems
3.11.2 Requirements
DT330/730
PSA
3.12 Screensaver
The DT7XX now allows a screensaver to be displayed after a configured (at phone) time. At present
this will display Zzz…
As soon as any activity occurs the phone will change to the relevant state.
An option to refer to a URL has been included, with the screensaver functionality. Example URL
connections are under investigation.
3.12.1 Benefits
On availability of URL information it would be possible to display items such as company logo.
3.12.2 Requirements
DT7XX V2.2.1.0 Firmware
3.13 Port Down
No longer is the PC port connection deactivated until the phone is fully optional. While the phone
reboots the PC port will stay active for a majority of the cycle. There is a slight
disconnection/reconnection during the boot cycle.
3.13.1 Benefits
PC will not see connection loss if running through the PC port on the phone.
3.13.2 Requirements
DT7XX V2.2.1.0 Firmware
3.14 Terminal Side Panels
Coloured side panels are now available. These are available in colours silver, red, blue, wood effect and
clear. Each colour available as
Colour side panel for Base(Silver)
Colour side panel for DT330/730 LCD(Silver)
Colour side panel for DT750 LCD(Silver)

Copyright 2008 NEC Philips Unified Solutions B.V. Exclusively for use by NEC Philips channel partners
All rights are reserved. Reproduction whole or in part is prohibited without the written consent of the copyright owner. 13 of 19
3.14.1 Benefits
Customize phone to colour, executives may want wood effect, other colours may match companies
colours.
3.14.2 Requirements
Panels required
3.15 Directory Card Holder
A terminal attachable card holder allowing personal directory information to be written on. Extends out
for use and stows away at rear of terminal when not in use.
3.15.1 Benefits
Allows users with preference for paper number storage to easily store/access information
3.15.2 Requirements
VAL Directory Card - Directory Card Holder for DT330/730 Series
ECO Directory Card - Directory Card Holder for DT310/710 Series
3.16 PC Pro
The SV8100 PC Programming (“PC Pro”) has been enhanced to allow configuration of all the new
features within R2. The relevant Easy Edit pages have been created , along with the online help.
3.16.1 Benefits
PC Pro enhancements allow configuration of R2 features.
3.16.2 Required Software and Hardware
PC Pro
3.17 BCT Integration
Ability to add BCT’s off board functionality to the SV8100 to give a more complete solution to
customers requiring more than the telephony functionality of the SV8100, such as PC Operator Console
positions, Presence functionality, Contact Centre working, etc
• Contact Center
• Operator
• Employee
• Presence Management
• Extensive Directories
• Phone Control
• Integrated Voicemail
• Instant Messaging
• DECT Corporate Directory (through the unique integration with NEC’s IP DECT product)
• Single Server
• Easy to Install
• Single point of Management
• Little Training
• DECT Messaging (through the unique integration with NEC’s IP DECT product)
• Multi Lingual
• Extensive Reporting
• Skill Based Routing
• E-mail Routing
• Call Routing

Copyright 2008 NEC Philips Unified Solutions B.V. Exclusively for use by NEC Philips channel partners
All rights are reserved. Reproduction whole or in part is prohibited without the written consent of the copyright owner. 14 of 19
• Back Office Integrations
3.17.1 Benefits
Ability to add BCT’s off board functionality to the SV8100 to give a more complete solution to
customers requiring more than the telephony functionality of the SV8100, such as PC Operator Console
positions, Presence functionality, Contact Centre working, etc
For further information please refer to Sales/Product Information on BusinessNet and Prophix
3.17.2 Required Software and Hardware
BCT
SIP Terminal License
SV8100 R2 Software
3.18 MyCalls
MyCalls is a complete call management package that can be used to monitor phone system activity and
performance. It works by gathering call information from the SV8100 and storing it in a database. The
MyCalls application can then be used to run reports and view real time information from the MyCalls
database. There are different levels of the product available starting from MyCalls up to MyCalls Calls
Call Centre. A summary of the features in the different levels of the product are as follows:
MyCalls
Real Time Status displays for Extensions, DDI’s and trunks.
Real Time Statistics, Single Value Windows and Combination Value Windows
Basic Alarms
Basic Reporting
MyCalls Call Manager
All the features of MyCalls plus:
Enhanced reporting
Enhanced alarms
Call costing
Users
Licensable options for Wallboards / Additional application users
MyCalls Enterprise
All the features of MyCalls Call Manager plus:
Multi site capable
Scalable up to approx 300 PBX’s
MyCalls Call Centre / Agent Control
All the features of MyCalls Call Manager plus:
Reporting on ACD working on the SV8100
Detailed ACD group / Agent reports
Login to ACD using MyCalls Agent Control
ACD Supervisor users
MyCalls Call Recorder
Allows call playback of recorded calls through MyCalls
Exclude calls from recording based on DDI / Extension / CLI
Configurable user playback options
For further details on MyCalls, please refer to Sales literature and Prophix.

Copyright 2008 NEC Philips Unified Solutions B.V. Exclusively for use by NEC Philips channel partners
All rights are reserved. Reproduction whole or in part is prohibited without the written consent of the copyright owner. 15 of 19
3.18.1 Benefits
Allows full monitoring and reporting of telephone system activity, allowing historical reports, real time
status (so can react immediately), call recording, call costing, etc
3.18.2 Required Software and Hardware
MyCalls (Relevant Items)
SV8100 R2 Software
3.19 Tiger Software Compatibility
Tiger Software’s hospitality package has been tested with our direct hotel interface (bypassing the PMS
adaptor). NEC and Tiger have produced a compatibility report which details the interconnection of the
Tiger software with the SV8100 PMS interface and UM8000 PMS Interface.
3.19.1 Benefits
Provides an integrated PMS applications and provides interfaces to multiple 3rdparty PMS
Applications.
3.19.2 Required Software and Hardware
Hotel License
Tiger Software
SV8100 R2 Software

Copyright 2008 NEC Philips Unified Solutions B.V. Exclusively for use by NEC Philips channel partners
All rights are reserved. Reproduction whole or in part is prohibited without the written consent of the copyright owner. 16 of 19
4. SOFTWARE AND HARDWARE
Description
Comments
New Software
LK-SYS-HM-LIC
Hotel/Motel License
LK-SYS-ENCRYPTION-LIC
Encryption License
LK-MyCalls-1st year License
MyCalls Free 1year Basic License
LK-MyCalls-Annual License
Renewal
Renewal of Basic License for another year
LK-MyCalls-Call Manager
License for Call Manager Product
LK-MyCalls-Additional Application
User
License for Additional Client User Positions
LK-MyCalls-Additional Application
Users (5)
License for Additional Client User Positions (5 Pack)
LK-MyCalls-Agent Desktop User
License for Agent Desktop User Positions
LK-MyCalls-Agent Desktop Users (5)
License for Agent Desktop User Positions (5 Pack)
LK-MyCalls-Enterprise Main Site
License for Enterprise Site –Allows linking of multiple
sites as one.
LK-MyCalls-Call Centre - 5 Agents
License for MyCalls Call Centre functionality for 5 users
LK-MyCalls-Call Centre - 10 Agents
License for MyCalls Call Centre functionality for 10 users
LK-MyCalls-Call Centre - 20 Agents
License for MyCalls Call Centre functionality for 20 users
LK-MyCalls-Call Centre - 30 Agents
License for MyCalls Call Centre functionality for 30 users
LK-MyCalls-Call Centre - 40 Agents
License for MyCalls Call Centre functionality for 40 users
LK-MyCalls-Call Centre - 50 Agents
License for MyCalls Call Centre functionality for 50 users
LK-MyCalls-Call Centre –Additional
Agents (10)
License for Additional MyCalls Call Centre functionality
for 10 users
LK-MyCalls-Call Centre –Additional
Agent
License for Additional MyCalls Call Centre functionality
for 1 user
LK-MyCalls-Additional ACD
Supervisor
License for Additional MyCalls Call Centre functionality
for 1 Supervisor
LK-MyCalls-Additional ACD
Supervisors (5)
License for Additional MyCalls Call Centre functionality
for 5 Supervisor
LK-MyCalls-Agent Control
License to allow Agent Control Functionality From
Mycalls
LK-MyCalls-Wallboard
License for MyCalls Wallboard
New Hardware
CHS2U B-EU
3KSU - 3 Slot 9.5” Chassis
CD-ETIA
Gigabit POE switched Hub Card
CD-RTB
InRouter Card
PMSU
PMS Adaptor
M155
M155 DECT Terminal
DTL-12BT-2P (BK) TEL
DT330 - Digital 12D + BCH (BK): The digital 12 button
display Multiline Terminal with Blue Tooth Handset has
12 programmable line keys.

Copyright 2008 NEC Philips Unified Solutions B.V. Exclusively for use by NEC Philips channel partners
All rights are reserved. Reproduction whole or in part is prohibited without the written consent of the copyright owner. 17 of 19
Description
Comments
BCH-LP (BK)
DT330 - Black Bluetooth Handset
PSA-LP (BK)
Power Fail Adaptor Black
PSA-LP (WH)
Power Fail Adaptor White
GBA-L
Gigabit Adaptor
BHA-LP Unit
Bluetooth Hub
PANEL(Silver-Base)-L UNIT
Colour side panel for Base(Silver)
PANEL(Silver-VLCD)-L UNIT
Colour side panel for DT330/730 LCD(Silver)
PANEL(Silver-SLCD)-L UNIT
Colour side panel for DT750 LCD(Silver)
PANEL(Red-Base)-L UNIT
Red side panel for Base (Qty 10)
PANEL(Red-VLCD)-L UNIT
Red side panel for DT330/730 LCD (Qty 10)
PANEL(Red-SLCD)-L UNIT
Red side panel for DT750 LCD (Qty 5)
PANEL(Blue-Base)-L UNIT
Blue side panel for Base (Qty 10)
PANEL(Blue-VLCD)-L UNIT
Blue side panel for DT330/730 LCD (Qty 10)
PANEL(Blue-SLCD)-L UNIT
Blue side panel for DT750 LCD (Qty 5)
PANEL(Wood-Base)-L UNIT
Wood side panel for Base (Qty 10)
PANEL(Wood-VLCD)-L UNIT
Wood side panel for DT330/730 LCD (Qty 10)
PANEL(Wood-SLCD)-L UNIT
Wood side panel for DT750 LCD (Qty 5)
PANEL(Clear-Base)-L UNIT
Clear side panel for Base (Qty 10)
PANEL(Clear-VLCD)-L UNIT
Clear side panel for DT330/730 LCD (Qty 10)
PANEL(Clear-SLCD)-L UNIT
Clear side panel for DT750 LCD (Qty 5)
VAL DIRECTORY CARD UNIT(L)
Directory Card Holder for DT330/730 Series
ECO DIRECTORY CARD UNIT(L)
Directory Card Holder for DT310/710 Series
MyCall Call Recorder Rack Mount
Kit
MyCall Call Recorder Rack Mount Kit
New Packages
MyCalls Call Recorder 2 BRI (4ch)
Package
4 Channel BRI Call Recorder Box plus 4 Channel License
MyCalls Call Recorder 4 BRI (8ch)
Package
8 Channel BRI Call Recorder Box plus 8 Channel License
MyCalls Call Recorder 8 BRI (16ch)
Package
2 x 8 Channel BRI Call Recorder Boxes plus 16 Channel
License
MyCalls Call Recorder 8h PRI
Package
8 Channel PRI Call Recorder Box plus 16 Channel License
MyCalls Call Recorder 16ch PRI
Package
16 Channel PRI Call Recorder Box plus 16 Channel
License
MyCalls Call Recorder 30ch PRI
Package
30 Channel PRI Call Recorder Box plus 30 Channel
License
MyCalls Call Recorder 60ch PRI
Package
2 x 30 Channel PRI Call Recorder Boxes plus 60 Channel
License

Copyright 2008 NEC Philips Unified Solutions B.V. Exclusively for use by NEC Philips channel partners
All rights are reserved. Reproduction whole or in part is prohibited without the written consent of the copyright owner. 18 of 19
5. TECHNICAL DOCUMENTATION
Description
Revision
SV8100 System Hardware Manual
2.0
SV8100 Features and Specification Manual
2.0
SV8100 Regulatory Manual
1.0
SV8100 Licensing Procedure
1.1
SV8100 ACD Manual
1.0
SV8100 VoIP Manual
2.0
SV8100 InMail System Guide
2.1
SV8100 InMail Quick Ref Guide for Administrator
1.0
SV8100 Hotel Manual
1.0
SV8100 SIP DECT Engineer Guide
1.0
SV8100 SIP DECT Admin Guide
1.0
SV8100 SIP DECT Quick Reference Guide
1.0
SV8100 IP DECT Site Survey Manual
1.0
SV8100 IP DECT Site Survey Additional Information Manual
1.0
SV8100 DMLS Installation Manual
1.0
SMB8000 PoE Manual
1.0
SV8100 InRouter Quick Start Guide
1.0
SV8100 InRouter VOS Manual
1.0
SV8100 NEC InRouter Installation Guide
1.0
SV8100 PSA Adaptor Guide
1.0
SV8100 Bluetooth Hub Connection Manual
1.0
SV8100 Gigabit Adaptor Installation Manual
1.0
SV8100 MyCalls Installation Manual
2.1
SV8100 MyCalls Call Centre Installation Manual
2.1
SV8100 Desktop Applications Manual
1.0

Copyright 2008 NEC Philips Unified Solutions B.V. Exclusively for use by NEC Philips channel partners
All rights are reserved. Reproduction whole or in part is prohibited without the written consent of the copyright owner. 19 of 19
6. TECHNICAL COURSES
SV8100 InMail User Guide
1.0
SV8100 MyCalls User Guide
1.0
SV8100 Bluetooth Handset User Guide
1.0
SV8100 M155 User Guide
1.0
SV8100 C124 DECT Handset User Guide
1.0
SV8100 Hotel Guest –Room Telephone Guide
1.0
SV8100 Hotel –Receptionist Guide
1.0
SV8100 Hotel Staff –Room Telephone Guide
1.0
SV8100 MLT Quick User Guide
1.3
SV8100 MLT User Guide
1.0
SV8100 Mobile Extension User Guide
1.0
SV8100 SLT User Guide
1.0
SV8100 SIP DECT User Guide
1.0
Description
No. of Days
SV8100 ETIA
0.5
SV8100 Router
1.5
SV8100 Hotel
1
SV8100 MyCalls Basic
1
SV8100 MyCalls Advanced/Enterprise/CC
1
SV8100 MyCalls ACD/Agent Control
1
SV8100 MyCalls Call Recorder
1
SV8100 MyCalls update Workshop
1
