Avery Weigh-Tronix TT-830 User manual

TT-830 Bench Scale
Service Manual

2TT-830 Bench Scale Service Manual

3
TT-830 Bench Scale Service Manual
Table of Contents
Table of Contents ..................................................................................... 3
Specifications............................................................................................4
Introduction ............................................................................................... 5
About This Manual ...............................................................................5
Front Panel Keys and Functions...............................................................5
Hard Keys............................................................................................. 5
Soft Keys.............................................................................................. 6
Accessing Setup Levels............................................................................7
User level .............................................................................................8
Configure level ...................................................................................13
Calibrate level..................................................................................... 23
Test Menu............................................................................................... 25
Disassembly and Reassembly Instructions ............................................27
To Remove the PC Board ..................................................................27
To Remove the Weight Sensor ..........................................................27
To Remove the Display ......................................................................27
Reassembly........................................................................................ 27
Appendix 1: Display Samples ................................................................. 28
Appendix 2: Tips on Using Harmonizer ..................................................30
Technical Illustrations:
10 lb/ 5 kg Parts and Assembly .............................................................. 31
Draft Shield Parts and Assembly ............................................................32
50 lb / 25 kg and 100 lb / 50 kg Parts and Assembly..............................33
System Wiring Block Diagram ................................................................34
Main Computer & I/O, Remote Analog,
Internal Battery Charger PC Boards...................................................35
Display & Interface Bd., Display Assy., Keypad Assy.............................36
Internal Battery & Charger PC Bd Parts and Assembly..........................37
Dimensional Outline for 12" x 14" Base..................................................38
COM2 Interface Cable Options and Pin-outs..........................................39
COM 1 Interface Cables, 830 to Quartzell Base and
830 to Eltron Printer Cable Assemblies..............................................40
BP-25R External Battery.........................................................................41
SSCU Parts and Assembly.....................................................................43
SSCU-8 Remote Expanded Control I/O Board....................................... 44
SSCU External (16) I/O Cutoff Expansion Board....................................45
OPTO-22 Control Interface Devices .......................................................46
Wiring Diagram for Input and Output Modules .......................................47
Remote (TTL) Keyboard Options............................................................48

4TT-830 Bench Scale Service Manual
Power Input
Operational Keys
Operational Annunciators
Display
Display rate
A to D Conversion Rate
Unit of Measure
Capacity Selections
Incremental Selections
Displayed Resolution
Audio Output
Time and Date
Internal Resolution
Harmonizer™digital filtering:
Standard input and outputs:
Available Options
Operating Temperatures
Dimensions
Weight
Agencies
Warranty
115 Volts AC, 50/60 Hz single phase
Optional 230 Volts AC, 50/60 Hz single phase
Zero, Tare, Print, Units, Select, Enter, Escape, Clear, 0-9,
Decimal Point and Five Soft Keys labeled per selected operational routine.
Displayed symbols indicate motion, center of zero, unit of measure and more.
5" W x 1.33" H dot matrix LCD, cold cathode flourescent backlight (240 X 64
dot layout)
Selectable, 0.1 to maximum readable updates
60 times per second
Pounds, kilograms, grams, ounces, pounds and ounces and two selectable
custom units
10 (5); 50 (25); 100 (50); lbs (kg)
Multiples and sub multiples of 1, 2, 5
NTEP pending at 10,000d / configurable
Audio tone for key contact assurance or operational alarms
Battery protected real time clock is standard
1,000,000 counts analog, QuartzellTM transducer = 2,000,000
Fully programmable to ignore noise and vibration
Four communications choices:
Com 1: RS232, RS-485/422
Com 2: RS232, 20 mA current loop
(One bi-directional signal per port)
- DC operation at 10 to 32 VDC, 3.5 Amp
- OPTO 22 I/O Modules
- Remote Expanded Control Interface for 8, 16, 24, or 32 OPTO 22 I/O Mod-
ules
- Alpha-numeric, PC style serial keyboard
14 to 104° F (-10 to 40° C), 10 to 90% relative humidity
Platform: 12" x 14" (50- and 100-lb models)
Platform: 8.5" dia. (10-lb models)
Overall: 14" W x 17" D x 4.5" H (35.6cm W x 43.2cm D x 11.4cm H)
18.5 lb, 8.4 kg
UL/CUL pending
CE pending
NTEP pending
2 year
Specifications

5
TT-830 Bench Scale Service Manual
Introduction
Front Panel Keys and Functions
This manual covers the information you need to configure and service your
TT-830 bench scale.
Major sections of this manual are headed by titles in a black bar like Intro-
duction above. Subheadings appear in the left column. Instructions and text
appear on the right side of the page. Occasionally notes, tips, and special
instructions appear in the left column.
The front panel is shown in Figure 1.
About This Manual
Plug the TT-830 into an easily
accessible grounded outlet
only. Never use the unit without
an appropriate earthground
connection. The keys on the front panel of the TT-830 are of two types; hard keys and
soft keys. Hard keys are labeled directly and soft key labels appear on the
display. Soft keys function differently at different times so their labels change
as needed.
Below are brief descriptions for each of the hard key functions:
Repeatedly press the SELECT key to scroll through the
available weight reading displays. (Examples - gross, net,
tare, minimum, maximum, etc.)
Press the UNITS key to scroll through the available units
of measure
Press the PRINT key to send data to a connected printer.
Figure 1
TT-830 Front Panel
Hard Keys
Press any key to power up the
scale.

6TT-830 Bench Scale Service Manual
Press the TARE key to enter a tare weight, then press
SELECT to see the net display mode.
Press the ZERO key to establish a zero reference. A
center-of-zero icon will be displayed. During motion an M
will appear below the center-of-zero icon.
Press the ESCAPE key to back out of menus or cancel a
numeric entry without accepting the value.
Press the CLEAR to clear values from the display.
Press the ENTER key to enter a keyed in value or accept
a displayed choice.
Press and hold the ON/OFF key for five seconds to turn
the unit off. Press any key to power up the scale.
The numeric keypad is for entering numbers.
Soft keys are so-called because their function is not fixed. Function can
change as the mode of operation changes or as the program for your
particular setup changes.
Their are five soft keys located directly below the display. If the keys are
needed during any operation, a label for each active key appears in the
display directly above. There are only five key labels available at one time
but this does not limit the potential usefulness of these keys. Programs can
be created to enable one key to access another level of operation with five
more key names and functions.
Soft Keys

7
TT-830 Bench Scale Service Manual
There are three levels of TT-830 setup you can access through the front
panel:
User level
The first level is the User level. These are the most commonly
changed values and parameters that you will use in the course of
operating the TT-830.
Configuration level
The second level is the Configuration level. These items deal with
some of the basic functions of the TT-830 and do not need to be
accessed very often.
Calibration level
The third level is the Calibration level. This section will need to be
accessed only when the scale is being calibrated, or if you change
scale capacity or division size.
A different password is needed to access each level. Once you access the
level you want, the display presents a series of soft key choices. By pressing
the appropriate soft key and following text prompts on the display, you can
set up your TT-830 to suit your needs.
Following are the instructions you need to access the setup of the TT-830.
1. Press and hold the ESCAPE key
until the TT-830 beeps. . . The display asks for a password and
looks like Figure 2.
Figure 2
Password display
Below are the passwords and details for the three setup levels.
Accessing Setup Levels
You must key in the password
within 5 seconds of accessing
the password screen or the TT-
830 returns to normal opera-
tion.
IMPORTANT NOTE
The TT-830 can be sealed for
legal for trade use and the
software protected from
change by using switch S1.
The current status is viewed in
the USER menu.

8TT-830 Bench Scale Service Manual
The default User password is 111.
Key in 111 and press ENTER. . . the screen in Figure 3 is displayed.
Figure3
User level main display
Figure 4 shows what soft keys or choices appear as you press the soft keys
shown in Figure 3.
Figure 4
Soft keys in the User level
User level
The values under SELECT in
the flowchart to the right are
not saved after a power down
and power up.
The User level is not affected
by the Seal status of the scale.

9
TT-830 Bench Scale Service Manual
Press the CLOCK soft key to access the time and date setting function.
1. The display shows the current
hour value. If this is not correct
key in a new value and press
ENTER or press ENTER to
accept the current value. . . The display shows the minutes
value.
2. Repeat step 1 for minutes,
seconds, year, month, and
day. . . Display returns to display shown in
Figure 3.
Press the SELECT soft key to access the USER-SELECT soft key group:
• DISP Press this key to set the current display mode.
• SCALE Press this key to select the scale number you want to use.
• TARE Press this key to enter a known tare weight.
• UNIT Press this key to select the active units of measure.
• EXIT Press this key to go back to the previous soft key set.
Following is a detailed description of the four functions listed above.
If you press the DISP soft key, follow these instructions:
1. The display shows the current
display mode number. Press
ENTER to accept this value or
key in a new number from the list
in Appendix 1, then press
ENTER to accept it. The display asks for the ACTIVE
VALUE. This is the active display
value.
2. Choose one of the following
active display values by keying in
0-13, then press ENTER. . . The display returns to the USER-
SELECT screen.
0 = Gross 4 = Max 8 = Count Total 12 = Piece Weight
1 = net 5 = Rate of Change 9 = Trans Total 13 = ADC
2 = Tare 6 = Gross Total 10 =Count
3 = Min 7 = Net Total 11 = Variable
If you press the SCALE soft key the display will ask you to select a scale
number. The currently active scale number is displayed. You can simply
type a new scale number and press the ENTER key. If you have multiple
scales attached to the indicator, this function chooses which scale's weight
is displayed and which one the ZERO and TARE keys will affect.
USER-CLOCK level
Enter the year using all four
digits.
USER-SELECT level
The display mode you pick
may not be the one that
appears on the display. A
display mode called out in the
WT BASIC program overrides
the setting you make through
the front panel.
While in the this level the
display will show USER-
SELECT in the top left to
remind you of where you are in
the USER level.
Variable (#11) is a variable
value called out in a WT-BASIC
program. ADC (#13) stands for
Analog to Digital Counts.
DISP (Display Mode)
SCALE
You cannot select a scale
number unless it has been
activated in the SimPoser
program and downloaded to
the TT-830.

10 TT-830 Bench Scale Service Manual
If you press the TARE soft key the display will show the current tare value
for the active scale. You may key in a new tare weight and press the ENTER
key to override the previous tare weight.
If you press the UNIT soft key the display will ask you to key in a number (0-
6) which represents the value you want to be active. Below are the seven
units to choose from and the corresponding number you need to key in for
this function:
0- lb 4- lb oz
1- kg 5- custom 1
2- g 6- custom 2
3- oz
Press the EXIT soft key to return to the USER level soft key group.
Press the SET soft key to access the USER-SET soft key group shown
below:
• GRAPH Press this key to set the parameters for bar graph and
checkweighing functions.
• PEAKS Press this key to reset the Min/Max.
• ACCUM Press this key to set the accumulator totals.
• PCWT Press this key to set the pieceweight for counting func-
tions.
• EXIT Press this key to go back to the previous soft key set.
Following is a detailed description of the four functions listed above.
If you press the GRAPH soft key, follow these instructions:
1. The current MIN setting is
displayed. Press ENTER to
accept this value or key in a new
value and press ENTER. . . The UNDER value is displayed.
2. Repeat step one, accept or
change the value, for UNDER,
OVER, MAX, and BASIS values.
BASIS is same as the active
values (0-13) shown below. These values now apply when using
the bar graph or checkweighing
display.
0 = Gross 4 = Max 8 = Count Total 12 = Piece Weight
1 = net 5 = Rate of Change 9 = Trans Total 13 = ADC
2 = Tare 6 = Gross Total 10 = Count
3 = Min 7 = Net Total 11 = Variable
USER-SET Level
Variable (#11) is a variable
value called out in a WT-
BASIC program. ADC (#13)
stands for Analog to Digital
Counts.
TARE
UNIT
GRAPH
The display will ask for a scale
number if Multiscale is enabled.

11
TT-830 Bench Scale Service Manual
If you press the PEAKS soft key the display asks if you want to reset the
MIN and MAX values now in memory. You are given the choice of YES or
NO. After choosing the display returns to the USER-SET level display.
If you press the ACCUM soft key, follow these instructions:
1. The display shows you the
current GROSS TOTAL in the
accumulator. You can change
this by keying in a new number
and pressing ENTER or press
ENTER to move to the next
ACCUM value. . . The display shows the NET TOTAL
value.
2. Repeat step 1 for NET TOTAL,
COUNT TOTAL, and
TRANS(action) TOTAL. . . The display returns to the USER-
SET screen.
If you press the PCWT soft key the display shows the current value for the
piece weight. Accept this by pressing the ENTER key or key in a new piece
weight and press ENTER.
Press the EXIT key to return to the USER level soft key group.
PCWT
ACCUM
PEAKS
The display will ask for a scale
number if Multiscale is enabled.

12 TT-830 Bench Scale Service Manual
Press the VIEW soft key to access the USER-VIEW soft key group:
• VERS Press this key to see TT-830 firmware revision date and
time. Serial number is currently not used. Configuration
information is displayed if a program has been down-
loaded from SimPoser software.
• SEAL Press this key to view the sealed state the scale. Only
while viewing this parameter can you toggle the sealed
state using the S1 button under the sealed access hatch
under the scale platter.
• VARS Press this key to view the BASIC variables.
• STORES Press this key to view the numeric and string values used
with store and recall.
• EXIT Press this key to go back to the previous soft key set.
Following is a detailed description of the four functions listed above.
If you press the VERS soft key you will see the firmware version number.
Serial number is currently not used. When you press any key, if you have
never downloaded a file from SimPoser, you will see only the word CON-
FIGURATION and no other information. If you have downloaded a file, the
following information is displayed:
License # of the SimPoser software.
Name of license holder.
Version number of the SimPoser software.
Name of the downloaded file (application program).
Time and date of the last download.
The display will show Sealed or Unsealed. Press S1 on the main board
through the access hole in the load bridge to change the seal status.
If you press the VARS soft key you will be able to scroll through the vari-
ables you have in your basic program. Press the FIRST soft key to see the
first one and the NEXT soft key to scroll to the next one. Repeat this until
you are through and press the EXIT soft key to return to the USER-VIEW
level.
If no variables are defined the screen will show NO VARIABLES DEFINED.
If you press the STORES soft key, follow these instructions:
1. The display asks if you want to
DISPLAY NUMERICS?, and
gives you the choice of YES or
NO. If you press YES the display
will look like this:
VERS
SEAL
STORES
VARS
USER-VIEW Level

13
TT-830 Bench Scale Service Manual
2. Press PREV (previous) to see
the previous numeric record.
Press NEXT to see the next
numeric record. Press SELECT
and the display will let you enter
a specific numeric record
number. When you press
ENTER that record number will
bedisplayed.
3. If you press NO in step one the
following screen is displayed:
4. This screen lets you view all the
strings stored in your BASIC
program. View them the same
way you did the numeric values.
5. Press EXIT to return to the
USER-VIEW level.
Press EXIT to return to the USER level. Press EXIT one more time and you
are back to normal operation. You have now seen all the parts of the USER
level. The next section of the manual covers front panel configuration.
The deafult password for the Configure level is 2045.
1. Press and hold the ESCAPE key
for 3-5 seconds. You will hear a
2nd beep and the display will
change. Key in 2045 and press
ENTER. . . The screen in Figure 5 is displayed.
If not displayed your system is
sealed or you've used an incorrect
password.
Figure 5
Configuration level display
When your changes are
completed, secure and protect
them by changing the seal
status. See Seal in the previ-
ous section
You must key in the password
within 5 seconds of accessing
the password screen or the TT-
830 returns to normal opera-
tion.
Configure level
There are two types of
memory:
• Standard
• Expanded
Standard memory has loca-
tions
0-8191for numeric storage and
0-4095 for string storage.
Expanded memory has loca-
tions
8191-16383 for numeric
storage and 4096-8191 for
string storage.
If you do not have the ex-
panded memory installed, the
expanded memory location
returns a zero.

14 TT-830 Bench Scale Service Manual
Figure 6 is a flowchart showing what soft keys or choices appear as you
press the soft keys shown in Figure 5.
Figure 6
Soft key flowchart for Configure level
Press the MENU1 soft key to access the following soft key group:
• SCALE Press this key to set display update rate, zero range, print
return to zero, and accumulate return to zero.
• UNITS Use this key to enable/disable units of measure.
• SETPT Use this key to show setpoints, if used.
• SERIAL Use this key to set port #, baud rate, parity, databits,
handshake, mode, and EOM character.
• EXIT Press this key to go back to the previous soft key set.
Following are detailed instructions for setting these parameters.
Under Misc. (print format) in
the flowchart to the right, the
default print format 0 shows
gross, tare and net weights. If
you choose another print
format (1-16) you need to
define the format in SimPoser
and download it to the TT-830.
CONFIGURE-MENU 1 Level
When your changes are
completed, secure and protect
them by changing the seal
status. See Seal in the previ-
ous section

15
TT-830 Bench Scale Service Manual
SCALE
Any value for display update
rate greater than 2 will be
considered as the maximum
update rate or 99.
If you press the SCALE soft key, follow these instructions (see note at left):
1. The display will show the current
display rate (.1, .25, .5, 1, 2, 99).
Accept this by pressing the
ENTER key or key in a new
value and press the ENTER
key. . . The display shows the zero range
value. If a non-valid number is keyed
in the value will default to 99.
2. Repeat step one for zero range
(0-100% allowed). . . This is the percentage of capacity
that you are allowed to zero using
the ZERO key.
3. Repeat step one for print return to
zero (0-100% of cap. allowed). . . If you press the PRINT key, the
weight must fall below this percent-
age of scale capacity before another
print operation will be allowed.
4. Repeat step one for accumulate
return to zero (0-100% allowed). . . If you perform an accumulation, the
weight must fall below this percent-
age of scale capacity before another
accumulation operation will be
allowed.
If you press the UNITS key, follow these instructions:
1. The display asks if you want to
enable the LB unit of measure
and shows you the current state
(ON or OFF). If the condition is
as you want it, simply press the
ENTER key. If you want to
change the condition, press the
YES or NO soft key, then the
ENTER key to move to the next
unit of measure. . . The kilogram unit of measure is the
next one shown.
2. Repeat step 1 for kilograms,
grams, ounces, pounds &
ounces, and custom units 1 and
2. The display asks for the
conversion factor for each
custom unit. Key in a value and
press ENTER. . . The display returns to the
CONFIGURE-MENU1display.
If you press the SETPT soft key the display asks you SHOW SETPOINTS?
What this means is, if you say yes, the display will show when setpoints turn
on and off by lighting small dots in the upper right corner. Press the YES soft
key if you want to see these dots, and press NO if you do not.
Custom unit names must be
defined by SimPoser software
program.
The custom conversion factor
is the number to be multipied
by the weight (in calibration
units) to get the desired
custom unit. Example: 1 lb = 5
inches of a certain steel rod.
Custom unit is inches. Calibra-
tion unit is lb. Conversion factor
is 5. With six lbs of weight on
the scale, 30 inches would be
displayed.
(Six lbs x 5 = 30 inches of
steel)
Setpoint operations must be
defined by the TT-830
SimPoser software program.
UNITS
By default, when the PRINT
key is pressed, a print opera-
tion and an accumulation take
place. If you do not want the
accumulation to occur, a WT-
BASIC program assigning only
the DO PRINT command to the
PRINT key needs to be down-
loaded to the TT-830. A WT-
BASIC program can also
define an ACCUM. soft key
and assign accumulation to
that key only.
SETPT
The display will first ask for a
scale number if Multiscale is
enabled.

16 TT-830 Bench Scale Service Manual
If you press the SERIAL soft key, follow these instructions:
1. The display prompts you for
serial port # to configure. Press
ENTER if displayed port is OK or
key in a new port number and
press ENTER. . . The baud rate code number is
displayed.
2. Press ENTER to accept the
baud rate or key in a new baud
rate code number from the table
below and press ENTER. . . The parity code number is displayed.
Baud Rate Codes
0 = 300 4 = 9600
1 = 1200 5 = 19,200
2 = 2400 6 = 38,400
3 = 4800 7 = 56,700
3. Press ENTER to accept the
parity or key in a new parity
code number from the table
below and press ENTER. . . The databits setting is displayed.
Parity Codes
0 = NONE 3 = SET
1 = ODD 4 = CLEAR
2 = EVEN
4. Press ENTER to accept the
databits setting or key in the new
databits value (7 or 8) and press
ENTER. . . The handshake protocol code
number is displayed.
5. Press ENTER to accept the
handshake protocol setting or
key in a new code number for
the handshake from the table
below and press ENTER. . . The mode code number is dis-
played.
Handshake Protocol Codes
0 = NONE 2 = Xon / Xoff
1 = CTS 3 = BOTH
6. Press ENTER to accept the
mode setting or key in a new
code number from the table
below and press ENTER. . . The EOM (end of message) value is
displayed.
Serial Mode Codes (Port 1) Serial Mode Codes (Port 2)
0 = BASIC control 0 = BASIC
1 = Keyboard 1 = Keyboard
2 = Disabled 2 = Disabled
5 = Split
6 = Dual
SERIAL
Setting this parameter to SET
will simulate 2 stop bits and no
parity detection.
CTS is a hardware handshake
(ready/busy) which requires
two extra wires in your cable.
Xon/Xoff is a software hand-
shake requiring no additional
hardware.

17
TT-830 Bench Scale Service Manual
BASIC Control -Control of the serial port is through the BASIC program
executing in the TT-830.
Keyboard - Control of the serial port is through an attached keyboard.
Disabled - The serial port is not in use for this configuration.
Split - Port 2 is split between two devices; keyboard and BASIC
control.
Dual - Port 2 allows detecting for data on two input lines for BASIC
control.
7. Press ENTER to accept the
EOM character or key in a new
number from 0-256 and press
ENTER. . . The display returns to the
CONFIGURE-MENU1display.
This completes the instructions for all the parameters of Menu 1.
Press the MENU2 soft key to access the following soft key group (See note
at left):
• MOTION Use this key to set the motion detection window size in
divisions and the time window in seconds.
For example: If you set divisions to 3 and seconds to 1, if
the weight value does not change more than 3 divisions
in one second, the scale or weight is considered stable.
• AZT Use this key to enable AZT. If you enable AZT you can
set the division size and seconds. The division size you
pick defines a range above and below zero. When scale
weight is inside this range for the number of seconds you
picked, ½ of the weight will be zeroed. The indicator will
repeat removing ½ the weight every X seconds. X being
the number of seconds you have picked.
• FILTER Use this key to set up the Harmonizer filtering. A full
explanation is given below. See Appendix 2 for tips on
using Harmonizer.
For a remote analog base the A-D weight conversion
happens 60 times per second in the TT-830. AVG is the
number of conversions you want to average. For ex-
ample, if you pick 30, the unit will average the weight
values from the last 30 conversions or ½ second and
uses that value for displayed data.
The next choice you have is for turning the Harmonizer
filtering on or off. If you turn the Harmonizer filtering on
you need to set the Harmonizer Constant. Typical values
are between 0-10. Set the number low for small vibration
problems and higher for more dampening effect.
The purpose of the Harmonizer Threshold is so the
indicator will respond quickly to large weight changes.
Harmonizer Threshold is the amount of weight change, in
calibration units, beyond which the Harmonizer will be
temporarily disabled. For example, if you set this to 10
EOM ASCII code #13 is
carriage return.
In the SimPoser software the
Harmonizer constant choices
are 0 through 10. This setting
is to be made in the "real
world" on a working system so
there are more levels available
from the front panel.
CONFIGURE-MENU 2 Level
For all the parameters in the
this menu level the display will
ask for a scale number if
Multiscale is enabled.

18 TT-830 Bench Scale Service Manual
lbs, a weight change over 10 pounds occuring during the
sample time (½ sec. in our example) will disable the
Harmonizer until the weight change during the sample
time drops below 10 lbs.
• TMOUT Use this key to set Zero Timeout, Tare Timeout, Print
Timeout and Accumulate Timeout. This is the amount of
time the TT-830 will wait for motion to cease and perform
the function after the key is pressed.
For example, if Zero Timeout is set to 3 seconds, when
the ZERO key is pressed the unit will zero the scale if
there is no motion. If there is motion and motion ceases
within 3 seconds the unit will zero the scale. If motion
doesn't cease the key press is ignored.
• EXIT Press this key to go back to the previous soft key set.
Following are detailed instructions for setting these parameters.
If you press the MOT'N soft key, follow these instructions:
1. The current value for the motion
window size, in divisions, is
shown. Press ENTER to accept
this value or key in a new value
and press ENTER. . . The current time window in seconds
is displayed.
2. Press ENTER to accept this time
period or key in a new value and
press ENTER. . . The display returns to the
CONFIGURE-MENU2display.
If you press the AZT soft key, follow these instructions:
1. The current value for the AZT
window size, in divisions, is
shown. Press ENTER to accept
this value or key in a new value
and press ENTER. . . The current time window in seconds
for AZT is displayed.
2. Press ENTER to accept this time
period or key in a new value and
press ENTER. . . The display returns to the
CONFIGURE-MENU2display.
If you press the FILTER soft key, follow these instructions:
1. The display shows the current
value for the number of samples
to average. Press ENTER to
accept this value or key in a new
value and press ENTER. . . The display shows the state of the
Harmonizer filtering( ON or OFF).
MOT'N (motion)
AZT (auto zero tracking)
FILTER
The display will ask for a scale
number if Multiscale is enabled.
The display will ask for a scale
number if Multiscale is enabled.
The display will ask for a scale
number if Multiscale is enabled.

19
TT-830 Bench Scale Service Manual
2. Press YES to enable Harmonizer
or NO to disable the Harmonizer
parameter, then press
ENTER . . . The current Harmonizer Constant
value is displayed.
3. Press ENTER to accept this
value or key in a new value and
press ENTER. . . The current Harmonizer Threshold
value is displayed. This value is in
calibration units.
4. Press ENTER to accept this
value or key in a new value and
press ENTER. . . The display returns to the
CONFIGURE-MENU2display.
If you press the TMOUT soft key, follow these instructions:
1. The current value for
Accumulate Timeout is
displayed. Press ENTER to
accept this value or key in a new
value and press ENTER.
2. Repeat step 1 for Print Timeout,
Zero Timeout, and Tare
Timeout. . . The display returns to the
CONFIGURE-MENU2display.
Press the EXIT soft key to return to the CONFIGURE display.
Press the MENU3 soft key to access the following soft key group:
• KEYS Press this key to enable or disable front panel keys.
• VALS Press this key to enable or disable the display values
(gross, net, min., max., ect.)
• DMODE Press this key to pick a power-up display mode from the
over 35 available. See Appendix 1: Display Samples.
• EXIT Press this key to go back to the previous soft key set.
Following are detailed instructions for setting these parameters.
If you press the KEYS soft key, follow these instructions:
1. The current setting (enabled ON
or OFF) for the SELECT hard
key is displayed. Press YES to
enable the key or NO to disable
the key, then press ENTER . . The current setting for the UNITS
hard key is displayed.
TMOUT (timeout)
CONFIGURE- MENU 3 Level
KEYS
When your changes are
completed, secure and protect
them by changing the seal
status. See Seal.
The display will ask for a scale
number if Multiscale is enabled.

20 TT-830 Bench Scale Service Manual
The default print format 0
shows gross, tare and net
weights. If you choose another
print format (1-16) you need to
define the format in SimPoser
and download it to the TT-830.
VALS
DMODE
CONFIGURE-MENU 4
Level
FMTPT
2. Repeat step 1 for UNITS,
PRINT, TARE, ZERO,
AUTOTARE, and KEYPAD
TARE. . . The display returns to the
CONFIGURE-MENU3display.
If you press the VALS soft key, follow these instructions.
1. The current setting (enabled ON
or OFF) for the GROSS display
value is displayed. Press YES to
enable the active value or NO to
disable this active display value,
then press ENTER . . The current setting for the NET
active value is displayed.
2. Repeat step 1 for all the display
values (NET, TARE, MIN., MAX.,
ROC, G-TOT, N-TOT, C-TOT,
#-TOT, COUNT, VARIABLE,
PCWT, and ADC. . . The display returns to the
CONFIGURE-MENU3display.
If you press the DMODE soft key, press ENTER to accept the display mode
number shown or key in a new number (see Appendix 1) and press ENTER.
The display returns to the CONFIGURE-MENU3 display. Press the EXIT key
to return to the CONFIGURE display.
Press the MENU4 soft key to access the CONFIGURE-MENU 4 soft key
set.
If you press the FMTPT soft key, follow these instructions:
1. The current serial port number
assigned to Format 1 is
displayed. Press ENTER to
accept this serial port or key in a
new serial port number and
press ENTER. . . The serial port assignment for
Format 2 is displayed.
2. Repeat step 1 for up to 16 print
formats and press the ENTER
key. . . The display returns to the
CONFIGURE-MENU4display.
The display will ask for a scale
number if Multiscale is enabled.
