AVGear AVG-UDA2 V2 User manual

AVG-UDA2 V2
The AVG-UDA2 V2 is a 4K HDMI splitter with the
ability to transmit a HDMI or DVI source to 2
displays simultaneously. Compliant with HDMI2.0 &
HDCP2.2, AVG-UDA2 V2 provides comprehensive
resolution capacities up to 4K, 1080p & 3D.
Features
2 simultaneous HDMI outputs
HDMI2.0 & HDCP2.2 compliant,
and backwards compatible with
previous versions
Transmits 4Kx2K HDMI up to
10m
Max. Resolution 4Kx2K@60Hz
4:4:4
High bandwidth: 18Gbps
HDCP compliant
Auto-identify input resolution
Supports EDID management,
automatically adopts the
resolution of the first connected
display
Intuitive indicator for connection
status & input HDCP compliance
status
Easy firmware update

AVG-UDA2 V2
PLEASE READ THIS PRODUCT MANUAL CAREFULLY
BEFORE USING THIS PRODUCT.
This manual is only for operation instruction only, and
not to be used in a maintenance capacity. The
functions described in this version are current till May
2017. Any changes of functions and operational
parameters will be updated in future manual versions.
Please refer to your dealer for the latest product
details.
Version 1.0 12/5/17

AVG-UDA2 V2
SAFETY OPERATION GUIDE
In order to guarantee the reliable operation of the equipment and safety of the
user, please abide by the following procedures in installation, use and
maintenance:
1. The system must be earthed properly. Please do not use two blade plugs
and ensure the AC power supply ranges from 100v to 240v and from 50Hz
to 60Hz.
2. Do not install the switcher in an environment where it will be exposed to
extreme hot or cold temperatures.
3. This unit will generate heat during operation, please ensure that you allow
adequate ventilation to ensure reliable operation.
4. Please disconnect the unit from mains power if it will be left unused for a
long time.
5. Please DO NOT try to open the casing of the equipment, DO NOT attempt to
repair the unit. Opening the unit will void the warranty. There are high
voltage components in the unit and attempting to repair the unit could result
in serious injury.
6. Do not allow the unit to come into contact with any liquid as that could result
in personal injury and product failure.

AVG-UDA2 V2
TABLE OF CONTENTS
Introduction ..............................................................................................................1
Introduction to the AVG-UDA2 V2 ................................................................ 1.1
Features ....................................................................................................... 1.2
Whats in the Box ......... ……………………………………………………………………2
Product Appearance of the AVG-UDA2 V2 ............................................................3
System Connection..................................................................................................4
Usage Precautions ....................................................................................... 4.1
Connection Diagram..................................................................................... 4.2
Connection Procedure..................................................................................4.3
EDID Management .......................................................................................4.4
Application.................................................................................................... 4.5
Specifications...........................................................................................................5
Supported Video Input Formats.................................................................... 5.1
Panel Drawing ..........................................................................................................6
Troubleshooting & Maintenance.............................................................................7

AVG-UDA2 V2
1. Introduction
1.1. Introduction to the AVG-UDA2 V2
The AVG-UDA2 V2 is a 4K HDMI splitter with the ability to transmit a HDMI or DVI
source to 2 displays synchronously. Compliant with HDMI2.0 & HDCP2.2, AVG-
UDA2 V2 provides comprehensive resolution capacities up to 4K and 1080p 3D. It’s
capable of automatically recognising the resolution and the HDCP compliant status
of the input signal. The Input signal is equalised for reliable transmission with its
EDID Management.
The AVG-UDA2 V2 can be easily updated via its USB port.
1.2 Features
1 HDMI Input and 2 simultaneous HDMI outputs
Hot plugging supported
HDMI2.0 & HDCP2.2 complaint, and backwards compatible with previous
versions
Transmits 4Kx2K HDMI up to 10m
Max. Resolution 4Kx2K@60Hz 4:4:4
High bandwidth: 18Gbps
HDCP compliant
Auto-identify input resolution
Supports EDID management, automatically adopts the resolution of the first
connected display
Intuitive indicator for connection status & input HDCP compliance status
Convenient online firmware update
2. What’s in the Box
1 x AVG-UDA2 V2
2 x Mounting ears (separate from AVG-UDA2 V2)
4 x Screws
4 x Rubber feet
1 x Power Adapter (DC 5V 2A)
1 x User Manual
Note: Please confirm if the product and the accessories are all included, if not,
please contact your dealer.

AVG-UDA2 V2
3. Product Appearance
No.
Name
Description
①
Power
indicator
Illuminates red once powered on
②
Input HDCP
compliant
Indicator
Indicates the HDCP compliant status of the input signal
Iluminates green when the input signal has HDCP
Blinks green when the input signal does not have
HDCP
OFF: No HDMI traffic (no picture) or abnormal
connection
③
Output signal
Indicators
Illuminates green when there is HDMI output, corresponds
with HDMI OUTPUT 1~2 separately
④
Micro USB
Plug a DC 5V power supply for power.
Or use a U-disk for firmware updating.
⑤
OUT1 and
OUT2
HDMI output ports, connect to your HDMI displays.
⑥
IN
HDMI input port, connect your HDMI or DVI source here.
OUT 2 OUT 1
IN
DC 5V
IN 2 1
1
456
23

AVG-UDA2 V2
Note:
a) Pictures shown in this manual are for reference only, different models may vary
slightly.
b) The Output HDCP compliant status depends on the input signal. When the input
signal is with HDCP, then output signal is with HDCP and vice versa.
c) HDMI signal contains both HDMI video signal and embedded audio signal (PCM,
Dolby Digital, DTS, DTS-HD), while the DVI signal contains only a video signal.
d) The AVG-UDA2 V2 can switch input signal formats according to the displays.
For example, when the input signal is HDMI and the display can only support a
DVI signal, the AVG-UDA2 V2 will change the signal to the DVI format.
e) EDID Management: automatically manages the output signal (e.g. output
resolution) to fit all displays.

AVG-UDA2 V2
4. System Connection
4.1 Usage Precautions
1. System should be installed in a clean environment with temperature and humidity
maintained to within equipment specification.
2. All of the power switches, plugs, sockets and power cords should be insulated and
safe.
3. All devices should be connected before power on.
4.2 Connection Diagram
The following diagram illustrates typical input and output connections that can be
utilised with the AVG-UDA2 V2.
OUT 2 OUT 1 IN
DC 5V
7

AVG-UDA2 V2
4.3 Connection Procedures
Step1. Connect a HDMI/ DVI source device (e.g. Blu-ray DVD) to the HDMI
INPUT socket of AVG-UDA2 V2 with a HDMI cable.
Step2. Connect the HDMI displays to HDMI OUTPUT sockets of AVG-UDA2 V2
with HDMI cables.
Step3. Plug a DC 5V power adapter to the power port of AVG-UDA2 V2.
Note: All the ports support hot-plug. It’s important to know that hot plugging a display
may result in splash screen at the output ends.
4.4 EDID Management
The AVG-UDA2 V2 comprises of 1 HDMI input port and 2 HDMI output ports. It also
possess built-in EDID management.
1. When all output ports are connected to the displays, the source device will
acquire the EDID data from the display connected to the output 1 port. At this
point, if you disconnect the output 1 display and want the source device to gain
the EDID from output 2, the AVG-UDA2 V2 will need to be restarted.
2. All connected displays should be compatible, for example: when output 1
connects with a 1080p display, the AVG-UDA2 V2 will select 1080p as output
resolution and distribute 1080p signal to the displays connected to outputs 1~2. If
the display connected to output 2 doesn’t support a 1080p signal, there will be no
output on the display.
4.5 Application
Robust performance for signal transmission makes the AVG-UDA2 V2 ideal in the
custom installation industry, IT computer space, signal monitoring, big screen
displays, conference systems, television broadcast, education, banking and security
institutions etc.

AVG-UDA2 V2
5. Specification
Video Input
Input
1 HDMI
Input Connector
1 female type A HDMI 2.0
Video Output
Output
2 HDMI
Output Connector
2 female type A HDMI 2.0
Video General
Max data rate
18 Gbit/s
Max Resolution
4Kx2K@60Hz 4:4:4
HDCP
Compliant with HDCP2.2 and is backwards compatible with
HDCP1.4
EDID
In-built EDID management
General
Temperature
0 ~ 55℃
Reference Humidity
10% ~ 90%
Power Consumption
4.5 W (Max)
Power Supply
Input: 100V –240V AC
Output: DC 5V 2A
Weight
97g
Dimensions (W*H*D)
102 x 11 x 70mm

AVG-UDA2 V2
5.1 Supported Input Video Formats
Input Resolution
HDMI
DVI
720 x 480@60Hz


720 x 480I@30Hz


720 x 576@50Hz


720 x 576I@25Hz


1280 x720@50Hz


1280 x720@60Hz


1920 x 1080@25Hz


1920 x 1080@50Hz


1920 x 1080@60Hz


1920 x 1080I@25Hz


1920 x 1080I@30Hz


3840 x 2160@25Hz

3840 x 2160@30Hz

3840 x 2160@60Hz

1080P 3D@60Hz

Note: The AVG-UDA2 V2 supports 4K and 3D HDMI signals, please use good
quality HDMI cables compliant with HDMI2.0 for reliable operation when connecting
4K or 3D sources.

AVG-UDA2 V2
6. Panel Drawing

AVG-UDA2 V2
7. Troubleshooting & Maintenance
Problems
Causes
Solutions
Colour loss or no video
signal output on the HDMI
display
The connecting cables
may not be connected
correctly or it may be
broken.
Check whether the cables
are connected correctly
and in working condition.
No HDMI signal output in
AVG-UDA2 V2 while local
HDMI input is in normal
working state
Splash screen displayed
on output devices
Poor quality connecting
cable.
Change for another good
quality cable.
Static becomes stronger
when connecting the video
connectors
Bad grounding
Check the grounding and
make sure it is connected
properly.
If your problem persists after following the above troubleshooting steps, seek further
help from authorized dealer or our technical support.
