Avia RS-485 User manual
Enable from LCD menu
2
- Press & hold SERVICE+MODE for 5 seconds to open Program menu
- Press SERVICE multiple times for “Pump Control” option
- Press DOWN to enable “Pump Control”
- Press MODE to exit
Pump to Heater RS-485 Modbus Connection
1
Metallic
ring
Panel
knockout Sealing
ring
Sealing
nut
Outside cabinetInside cabinet
VENT
TEMP
OUTPUT
TEMP
INTPUT
TEMP
P3 P2 P1
FLOW COM
CHEM
VENT
TEMP
OUTPUT
TEMP
INTPUT
TEMP
P11 P12
P3 P2 P1
To
Protégé
Pump
Pump side
Remove unit top and
control board cover to
expose “P12” Port
Use knockout to route
RS-485 Modbus harness
Properly line up connectors
and twist-on watertight seal
QUICK START
GUIDE
Control your Pump from Raymote
3
QUICK START
GUIDE
Manual & Scheduled control
from the Raymote app.
Available for:
www.raypak.com
2151 Eastman Avenue | Oxnard, CA 93030 | 805-278-5300
Litho in U.S.A. ©2022 Raypak, Inc. P/N 242049 Rev 1 Effective 04-15-22 Replaces NEW
- Control Raymote-connected heaters from the palm of your hand
- Create automation routines or control pump speed from Raymote app.
Scan Here
Try these suggestions to improve your Wi-Fi signal:
- Keep your heater always connected to power and Wi-Fi to run online-scheduled task.
- Confirm that your Wi-Fi signal strength is strong enough to reach the heater
(walls and fences may affect Wi-Fi signal)
- Reduce distance between Wi-Fi router and the heater
- Add a Wi-Fi range extender
- Enable a new Wi-Fi access point
For more support visit: www.raypak.com/raymote
