Avid Technology System 5 User manual

System 5 and Pro Tools Guide
®

Legal Notices
This guide is copyrighted ©2011 by Avid Technology, Inc.,
(hereafter “Avid”), with all rights reserved. Under copyright
laws, this guide may not be duplicated in whole or in part
without the written consent of Avid.
003, 96 I/O, 96i I/O, 192 Digital I/O, 192 I/O, 888|24 I/O,
882|20 I/O, 1622 I/O, 24-Bit ADAT Bridge I/O, AudioSuite,
Avid, Avid DNA, Avid Mojo, Avid Unity, Avid Unity ISIS,
Avid Xpress, AVoption, Axiom, Beat Detective, Bomb Factory,
Bruno, C|24, Command|8, Control|24, D-Command, D-Control,
D-Fi, D-fx, D-Show, D-Verb, DAE, Digi 002, DigiBase,
DigiDelivery, Digidesign, Digidesign Audio Engine, Digidesign
Intelligent Noise Reduction, Digidesign TDM Bus, DigiDrive,
DigiRack, DigiTest, DigiTranslator, DINR, DV Toolkit, EditPack,
Eleven, HD Core, HD Process, Hybrid, Impact, Interplay, LoFi,
M-Audio, MachineControl, Maxim, Mbox, MediaComposer,
MIDI I/O, MIX, MultiShell, Nitris, OMF, OMF Interchange, PRE,
ProControl, Pro Tools M-Powered, Pro Tools, Pro Tools|HD,
Pro Tools LE, QuickPunch, Recti-Fi, Reel Tape, Reso,
Reverb One, ReVibe, RTAS, Sibelius, Smack!, SoundReplacer,
Sound Designer II, Strike, Structure, SYNC HD, SYNC I/O,
Synchronic, TL Aggro, TL AutoPan, TL Drum Rehab,
TL Everyphase, TL Fauxlder, TL In Tune, TL MasterMeter, TL
Metro, TL Space, TL Utilities, Transfuser, Trillium Lane Labs,
Vari-Fi, Velvet, X-Form, and XMON are trademarks or registered
trademarks of Avid Technology, Inc. Xpand! is Registered in the
U.S. Patent and Trademark Office. All other trademarks are the
property of their respective owners.
Bonjour, the Bonjour logo, and the Bonjour symbol are
trademarks of Apple Computer, Inc.
Product features, specifications, system requirements, and
availability are subject to change without notice.
Guide Part Number 9329-65158-00 REV B 08/11
Documentation Feedback
At Avid, we are always looking for ways to improve our
documentation. If you have comments, corrections, or
suggestions regarding our documentation, email us at
[email protected].

Contents iii
contents
Chapter 1. Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
System Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
About This Guide. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
About www.avid.com . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Chapter 2. Software Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Rename the Pro Tools Workstation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Startup Sequence . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Enabling EUCON in Pro Tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Chapter 3. Track and Session Basics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Basics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Assigning Pro Tools Tracks to Console Strips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Layouts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Using the Transport . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Navigating Through a Session. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Fader Strip Controls. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Track Basics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Chapter 4. Recording . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Chapter 5. Plug-Ins and Sends . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Working with Plug-In Inserts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Working with Sends. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Chapter 6. Automation and Mixing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

System 5 and Pro Tools Guideiv

Chapter 1: Introduction 1
chapter 1
Introduction
Avid’s EUCONTM (Extended User Control) adapter enables fully integrated control of Pro Tools®from
EUCON-compatible work surfaces, including System 5.
This guide explains how to enable EUCONTM (Extended User Control) in Pro Tools 9.0 or higher and
control Pro Tools from your System 5.
System Requirements
The features described in this guide require the following:
• Avid System 5 Digital Audio System
• Pro Tools or Pro Tools HD version 9.0 or higher
• EUCON Workstation and eMix software (version 5.0 or higher)
For downloads and other resources, visit:
www.avid.com/proseriessupport
Avid can only assure compatibility and provide support for hardware and software it has tested and
approved. For complete system requirements and a list of qualified computers, operating systems,
hard drives, and third-party devices for Pro Tools, visit:
www.avid.com/compatibility

System 5 and Pro Tools Guide2
About This Guide
This guide explains how to enable EUCON and use System 5 with Pro Tools.
The following resources are also available:
• For complete information on your System 5, see the electronic PDF version of the
System 5 User Guide.
• For additional EUCON software setup and configuration information, see the EUCON Application
Setup.pdf.
• For instructions on connecting and configuring Pro Tools, see the software installation and hard-
ware user guides that came with your Avid system. For information about using Pro Tools soft-
ware, see the Pro Tools Reference Guide (in Pro Tools, choose Help > Pro Tools Reference Guide).

Chapter 1: Introduction 3
Conventions Used in This Guide
All of our guides use the following conventions to indicate menu choices and key commands:
:
The names of Commands, Options, and Settings that appear on-screen are in a different font. The
names of hardware keys on System 5 are in bold (such as Wave).
The following symbols are used to highlight important information:
Convention Action
File > Save Choose Save from the File menu
Control+N Hold down the Control key and press the N key
Control-click Hold down the Control key and click the mouse button
Right-click Click with the right mouse button
User Tips are helpful hints for getting the most from your system.
Important Notices include information that could affect your data or the performance of your system.
Shortcuts show you useful keyboard or mouse shortcuts.
Cross References point to related sections in this and other Avid guides.

System 5 and Pro Tools Guide4
About www.avid.com
The Avid website (www.avid.com) is your best online source for information to help you get the most
out of your Pro Tools system. The following are just a few of the services and features available.
Product Registration Register your purchase online.
Support and Downloads Contact Avid Customer Success (technical support); download software up-
dates and the latest online manuals; browse the Compatibility documents for system requirements;
search the online Knowledge Base or join the worldwide Pro Tools community on the User Confer-
ence.
Training and Education Study on your own using courses available online or find out how you can
learn in a classroom setting at a certified Pro Tools training center.
Products and Developers Learn about Avid products; download demo software or learn about our De-
velopment Partners and their plug-ins, applications, and hardware.
News and Events Get the latest news from Avid or sign up for a Pro Tools demo.
For Artist Series support, visit www.avid.com/artistsupport. For Pro Series, visit
www.avid.com/proseriessupport.

Chapter 2: Software Configuration 5
chapter 2
Software Configuration
Before you proceed, make sure you have completed the following:
• Installed Pro Tools or Pro Tools HD version 9 or higher
• Installed the current version of EUCON Workstation software (provided with the eMix
application) onto the Pro Tools workstation
• Confirmed the installation of your System 5 hardware and eMix v5.0. or higher
• Confirmed that your other DAWs (such as Nuendo) are updated to the correct versions
Rename the Pro Tools Workstation
Before proceeding, it is highly recommended that you give each workstation a unique name. This is
recommended to avoid confusion when attaching workstations to the System 5, and to be able to
more easily identify exactly which workstation is or is not attached to the system.
Mac On Mac, you rename the workstation by editing the “hostconfig” file in the “etc” folder (which
is a hidden folder). See “To rename a Mac workstation:” on page 5.
Windows On Windows, you can rename the workstation in the Properties window for your computer.
See “To rename a Windows 7 workstation:” on page 6.
To rename a Mac workstation:
1 From the Finder, choose Go > Go To Folder (or press Command + Shift + G on your computer key-
board).
2 Type /Etc/ (slash, Etc, slash).
3 Click Go (or press Enter). The etc folder appears.
4 In the etc folder, find hostconfig and drag it to your desktop.
5 From the desktop, double-click on hostconfig.
6 Add the following line at the bottom of the list, or modify the entry if it already exists:
HOSTNAME=my_name_here (where “my_name_here” is the desired name for the workstation)

System 5 and Pro Tools Guide6
7 Save the file and drag it back to the etc folder, replacing the original.
8 When you reboot, the new name will appear. This is the name you will see within System 5 when
you attach the workstation.
To rename a Windows 7 workstation:
1 Go to Start > Computer.
2 Right-click on Computer and choose Properties.
3 In the section Computer name, domain, and workgroup settings, click Change Settings.
4 Make sure the tab Computer Name is selected; if it is not, click the tab Computer Name.
5 Click Change in the section To rename this computer or change its domain or workgroup.
6 Enter a new name for the workstation into the Computer name field.
7 Click OK.
Startup Sequence
To start up System 5 and Pro Tools:
1 With all system components turned off, turn on the Ethernet switch and allow it to complete its
startup diagnostics.
2 Turn on the SC264 System Computer and all I/O units.
3 Double-click the eMix icon on the desktop.
4 Turn on all Surface Modules, the CO600 Changeover Switch (if present), and the DF66(s) or DF70.
5 Do one of the following, as appropriate:
• If system modules have been saved as default, eMix continues to boot when all modules reach
100%. If no modules appear as Unexpected, click Continue to finish booting eMix. The startup se-
quence is now complete.
• If any modules appear as Unexpected, go to “Resolving Unexpected Modules” on page 7.
On Hybrid systems’ SC264, confirm that EUCON Discovery is set to use the second LAN connection
and that it is not on the System 5 connection.

Chapter 2: Software Configuration 7
Resolving Unexpected Modules
To resolve any modules that appear as Unexpected during startup:
1 Control-click each Unexpected module until all are selected.
2 Click Save selected as default, and confirm the selection by clicking OK.
3 Click Continue to finish booting eMix.
4 Power up the workstation computer running Pro Tools.
5 Power up the workstations running other DAWs (if any).
6 Follow the instructions in “Enabling EUCON in Pro Tools” on page 7.
Enabling EUCON in Pro Tools
To enable EUCON control in Pro Tools:
1 Make sure MC Client and EUCON Discovery software are running.
2 Launch Pro Tools.
3 Choose Setup > Peripherals, and click the Ethernet Controllers tab.
4 Select Enable EUCON.
When eMix launches, the control surface is temporarily disabled and audio is muted. Launching eMix
automatically by putting it in the Windows Startup folder may produce undesirable behavior if the
System Computer reboots during a broadcast or session.
On Hybrid systems’ SC264, confirm that EUCON Discovery is set to use the second LAN connection
and that it is not on the System 5 connection.
Enabling EUCON in the Peripherals dialog

System 5 and Pro Tools Guide8
5 Click OK. You do not need to configure any other Ethernet Controllers settings. These settings do
not apply to EUCON.
Pro Tools scans your system until it identifies attached EUCON-compatible hardware. When
Pro Tools finishes scanning your system, your controllers are ready to use with Pro Tools.
Confirm Installation
To confirm installation and communication:
1 Make sure you have enabled EUCON as explained in “Enabling EUCON in Pro Tools” on page 7.
2 Open a Pro Tools session if one is not already open.
3 On the System 5 CM401 Main Panel, select EUCON Setup and attach to your Pro Tools workstation.
(If you do not know how to attach a workstation, see “Attaching the Pro Tools Workstation to System
5” on page 10.)
4 Verify the Pro Tools Mix window displays a blue-green border around all Pro Tools tracks.
5 Verify that the CM401 Main Panel EUCON channels display the correct Pro Tools tracks.
Using System 5 with Pro Tools version 8.x and lower utilized the HUI (MIDI Controller) protocol. This
is no longer necessary with Pro Tools 9.0 and higher.
Color outlines in the Mix window showing currently-banked tracks
See the Pro Tools Installation Guide for system optimization recommendations.

Chapter 3: Track and Session Basics 9
chapter 3
Track and Session Basics
This chapter provides examples of the following:
System Basics Basics for System 5 Projects and Titles for use with Pro Tools, including how to attach
a Pro Tools workstation to the system.
Layouts How to assign Pro Tools tracks to System 5 DSP channels, and how to create a Layout.
Using the Transport How to use the Transport controls to play, stop, cue, record arm, and more (see
“Using the Transport” on page 12).
Banking the Faders How to view tracks on the fader strips (see “Navigating Through a Session” on
page 14).
Fader Controls How to adjust track volume and pan, and solo and mute tracks (see “Fader Strip Con-
trols” on page 14).
Track Basics How to select tracks and assign input and output routing (see “Track Basics” on page 15).

System 5 and Pro Tools Guide10
Basics
On System 5, you first designate the drive on which you want to create and store Projects.
Projects are where you create Titles, and Titles store and recall Mixes. Titles also contain the Layouts
you create (the arrangement of DAW channels across the System 5 faders and other surface controls).
If you are unfamiliar with any of these concepts, see the System 5 User Guide before proceeding.
Attaching the Pro Tools Workstation to System 5
To attach the Pro Tools workstation to System 5:
1 On the CM401, press MAIN Panel to show the MAIN panel.
2 Select EUCON, then Setup. All workstations recognized on the network are listed.
3 Hold down the Workstation button (below the panel), then press the Select button to the left of the
displayed name of the computer (workstation) on which Pro Tools is installed.
4 The button flashes until communication has been established.
Once the Pro Tools workstation has been attached, you can assign Pro Tools tracks to console strips
and save assignments as Layouts as explained in the next section.
Assigning Pro Tools Tracks to Console Strips
To assign Pro Tools tracks to the System 5 channel strips:
1 Press the Main Panel key in the center section.
2 Select EUCON, then Channels. The Channel Assign Panel appears.
3 In the Channel Assign Panel Viewer, press the key next to the channel you want to assign.
(To display additional channels, press the Page keys.)
4 Activate the Main or Swap channel on the desired strip, then press its Chan Select key.
5 Repeat steps 3 and 4 to assign multiple channels.
To assign multiple, consecutive Pro Tools tracks to the console:
1 Press the Main Panel key at the bottom of the Panel Viewer.
2 Press the Channels key in the Main Panel. The Channel Assign panel appears.
We recommend giving each workstation a unique name (instead of typical default names such as
“Mac HD” or similar). For instructions, see “Rename the Pro Tools Workstation” on page 5.

Chapter 3: Track and Session Basics 11
3 Press the Auto key so that it lights.
4 Press the key next to the first desired track channel to designate it as the “starting” channel.
5 Position your finger over the Chan Select key for the first (left-most) fader strip you want assigned
on the console. Because this technique requires a two-key sequence beginning with Chan Select and
moving to the right to the Swap key, the first fader strip must be at the far left of those being assigned.
6 Begin by pressing the Chan Select key on the first (left-most) fader strip, but continue moving your
finger to the right across to the Swap key on the last strip you want to assign. As you “sweep” your fin-
ger across fader strips, each Chan Select key should light. If one or more do not, hold any already lit
Chan Select key and then press the ones you missed until they each stay lit.
You have just assigned the Main fader layer on each strip. Pressing the Swap key lets that same strip
be assigned to another DAW track as follows:
7 Move your finger back to the first fader strip’s Chan Select key and repeat the same sequence of key
presses.
This maps the next series of DAW tracks to the Swap layer on the same strips that you previously as-
signed via its Main layer. For example, if the first sequence mapped tracks 1–8 to the Main layer on
eight fader strips, the second sequence would map tracks 9–16 to the Swap layer on the same fader
strips.
Layouts
This section explains how to create a new Layout to store your assignments of Pro Tools tracks to
strips.
To create a new Layout:
1 From the Main Panel, press the Layout key. The Layout Panel is displayed. The button next to the last
recalled Layout is lit.
2 Press the New key at the bottom left of the Layout Panel. The New key flashes.
3 Select the channels to include in the new Layout by doing the following:
• To select all console strips, press the ALL key at the bottom-right of the Layout Panel.
– or –
• To select individual strips, press the Wave key in each desired strip.
4 To save the new Layout, press the desired Layout key in the Layout Panel. The New key becomes unlit
and the Name key lights. Unused locations are unlit and have a default name (such as “L 13”).
5 Use the console keyboard to name the new Layout.
To learn how to recall, modify, rename, or delete a Layout, see the System 5 User Guide.

System 5 and Pro Tools Guide12
Using the Transport
The Avid MachineControl™ Option is required to use the CM401 Machine control section to control
the Pro Tools transport. When your Pro Tools workstation is attached and the MachineControl op-
tion is configured, the transport switches on System 5 control the Pro Tools Transport. You can use
the System 5 Smart Switches for EUCON machine control. For Pro Tools these are on bank 10, or from
the bank 1 TRANS key. EUCON track arming is done from the individual strip’s Link/Rec switch.
The System 5 uses the TT002 (single operator) or TT003 (dual operator) machine control interface.
This provides one 9-pin, MIDI and LTC I/O (note, however, that this interface is not a synchronizer).
The CM401 machine control section does not use EUCON commands. Source, Frame rate, track arm-
ing message length and FF/RW speed are controlled from the eMix System Preferences page. Record
from the CM401 as well as track arming from the CM402 or CM403 post panel sends the appropriate
machine control command to the designated master or record enabled machine (such as Pro Tools).
Loop points (Return) are set using the Mark in/out keys. Loop points, as well as Roll Back time and Ti-
tle start/end, can be entered manually into the System 5 Locate Registers.
System 5 Machine Control panel
4 5 6
23
1

Chapter 3: Track and Session Basics 13
1 RTZ (Return to Zero) Go to the Title Start Time entered in the Locate Registers.
2 Rewind Moves the play cursor earlier.
3 Fast Forward Moves the play cursor later.
4 Stop Stops playback.
5 Play Starts playback.
6 Record Toggles the Pro Tools Transport (master) record state on (armed) or off.
Using the Transport Controls
The following commands require the Avid MachineControl option on the Pro Tools workstation.
Playback
To play from the current location:
Press Play.
To stop playback:
Press Stop.
Session Time Navigation
To jump to the beginning of the session:
Enter the Session Start Time in the System 5 CM401 Locate Registers.
To rewind or fast-forward:
Press Rew or FFW.
Recording
To record arm the Pro Tools Transport:
Press Record.
Pro Tools provides preference settings to optimize rewind and fast forward (such as Audio During Fast
Forward/Rewind, and Back/Forward Amount). For more information, see the Pro Tools Reference
Guide.
For additional recording features, see Chapter 4, “Recording.”

System 5 and Pro Tools Guide14
Navigating Through a Session
On System 5, you use Layouts to store and recall assignments of Pro Tools tracks to console strips.
For instructions on how to create a new Layout and assign Pro Tools tracks, see “Assigning Pro Tools
Tracks to Console Strips” on page 10. For complete information on how to recall, modify, rename,
and delete layouts, and additional information on assigning tracks to strips, see the System 5 User
Guide.
Fader Strip Controls
Fader strips let you adjust track volume, pan, solo, and mute Pro Tools tracks. (You can also control
plug-ins and track automation. For plug-ins, see Chapter 5, “Plug-Ins and Sends.” For automation, see
Chapter 6, “Automation and Mixing.”)
Adjusting Track Volume and Pan
This section shows how to adjust track volume and pan.
To adjust Pro Tools track volume:
1 Recall a Layout containing your Pro Tools tracks.
2 Press the Main or Swap key to bring that track to the strip.
3 Adjust the fader for that track.
To adjust track pan:
1 Press the PAN function key.
2 Rotate encoder 1 (Pan F) for the track you want to pan. Stereo tracks default to Left pan.
Using the Joysticks
To assign strips to the System 5 joysticks, there are two modes: cycle and direct. These modes are found
in the CM401 Strips menu.
Cycle Assign Uses the strips wave key. For stereo Pro Tools channels, press the wave key twice (assign-
ing the track to both joysticks), then use the right joystick up arrow to select the right paner.
Direct Assign Works the same way as strip assignment from the CM401 EUCON page.
System 5 strips offer many options for pan control that are available on the two pages of Pan settings
in each strip. For more information, see the System 5 User Guide.

Chapter 3: Track and Session Basics 15
Track Basics
This section shows how to select Pro Tools track input and output routing.
Selecting Tracks
To select a track:
1 Recall the Layout that contains the desired track.
2 Press any fader Chan Select key.
The track is selected in Pro Tools. You can use standard Pro Tools shortcuts in combination with the
fader Chan Select keys to do the following.
To select all tracks:
Hold Option (Mac) or Alt (Windows) on your computer keyboard and press any unlit track
Chan Select key.
To deselect a track:
Hold Command (Mac) or Start (Windows) on your computer keyboard and press a lit track
Chan Select key.
To deselect all selected tracks:
Hold Option (Mac) or Alt (Windows) on your computer keyboard and press any lit track
Chan Select key.
To select a range of tracks:
1 Press the Chan Select key on the first track (usually, the left-most track you want to select).
2 Hold the Shift key on your computer keyboard and press the Chan Select key on the last (right-
most) track. All tracks between the two are selected.
To select non-adjacent tracks (add to a selection):
1 Press and hold the Chan Select key to select the first desired track.
2 Press Chan Select on other strips.

System 5 and Pro Tools Guide16
Track Input and Output Routing
Routing Track Input and Output
These examples show how to assign Pro Tools track input and output from the console strip.
To assign Pro Tools track input:
1 Recall the Layout that contains your Pro Tools tracks.
2 Press the Input key in a CM401 knob cell. The lowest three knob cells display the top level of Input
choices for Pro Tools tracks: no input, hardware, and bus.
3 Press the knob for the desired type of input:
• To assign no input to the track, press the knob next to no input.
• If you want to assign a hardware input to the track, press the knob next to hw I/O.
• To assign a bus input to the track, press the knob next to busses.
If you selected hw I/O or busses, the screen displays the available hardware or bus inputs. If there are
more than eight available choices for the selected input type, use the Page key to display the addi-
tional choices.
4 Press the knob for the desired input choice to assign it as the track input.
To assign Pro Tools track output:
1 Recall the layout that contains your Pro Tools tracks.
2 Press the Mix function key. The lowest three knobs display the top level of Output choices for
Pro Tools tracks:
3 Press the knob for the desired type of output:
• To assign no output to the track, press the knob next to no output.
• If you want to assign an Output bus to the track, press the knob next to hw I/O. The knobs display
available Output bus choices (such as Out 1-2) on the knobs. To see additional choices, press the
PAGE key.
• To assign an internal bus output to the track, press the knob next to busses. The knobs display
internal bus choices on the knobs. To see additional choices, press the PAGE key.
4 When the desired output choice is displayed, press its knob.
Multiple Output Path Assignments
Pro Tools tracks can have multiple Main output paths assigned to them. When assigning track output
from a EUCON unit, you can simply repeat the previous instructions and the new assignment will be
added to the current assignments. When reassigning outputs, you must first assign no output, then as-
sign the new output path.
