Cable Requirements (by others):
1. E-Motive 4-Wire output signal: 4-Wire
(Min CSA 0.75mm2)
2. Network Cable: Cat5e/Cat6 Cable
Screen Size 12.1” 15”
Overall Dimensions X x Y x Z (mm) 290 x 250 x 38 357 x 289 x 42
Mounting Holes Dimensions A x B (mm) 100 x 241 100 x 280.5
Recommended* Cut-Out Dimensions (mm) 246 x 185 304 x 228
Fault Finding:
1. If power is applied, the display will light up
and then the unit will boot up.
2. If the LCD boots up without a layout so
only a blue screen with arrow and oor
legend are visible then check to see if the
SDHC card is inserted properly.
3. If the LCD does not display Lift Info then
check the EMD Input D Dr connection.
Caution
1. Risk of electric shock. Never remove the
casing of the unit.
2. Ensure that the Power Supply is connected
properly and that the voltage is correct
before turning on the unit.
Mechanical Mounting
Wiring and Setup
1. Prepare the COP cut-out and the mounting
studs according to the mechanical drawing
of the screen used.
2. Next, mount the lens onto the LCD.
Please note that the lens is optional
and does not come with the screen. The
lens is recommended for the additional
protection and improved aesthetics of the
COP/Transom.
3. Mount the S1V LCD unit. Please note the
mounting position is indicated by a label
“This Side Up” at the back of the LCD.
4. Connect cable from the E-Motive Encoder
/ Converter to EMD of the S1V LCD.
5. Connect the 24VDC Power Supply Unit
provided to the INPUT port.
6. Connect the 8ohm speaker provided to the
Audio Output AUD-R.
7. Connect the Network cable CAT5e/6 into
the LAN port. (If network is required)
Mechanical Drawing - Multimedia LCD S1V
Picture used for illustration only
*Recommended cut-out dimensions is provided based on landscape mounting.
*For portrait mounting, take note of the viewing angle
Table 5: S1V Mechanical Dimensions
X (mm)
Y (mm)
Z (mm)
B (mm)
A (mm) 4 x Ø4.5 x 12mm
S1V
Lens
COP / Transom
