Avita NT19 User manual

TOUCH FREE Infrared Thermometer
NT19
EN
RoHS REACH
MDSS GmbH
Schiffgraben 41
30175 Hannover Germany
AViTA Corporation
9F., No. 78, Sec. 1, Kwang Fu Rd.,
San Chung Dist., New Taipei City 24158, Taiwan
China, AViTA(WUJIANG)
Importer
Distributor
INSTRUCTION MANUAL
Please read this instruction manual carefully
before using your forehead thermometer

Contents
Introduction ........................................................................................................................ 1
Important Information before Use ........................................................................... 2
Product Identification ..................................................................................................... 4
Description of LCD Display........................................................................................... 5
Battery Installation ........................................................................................................... 6
Switching Between Fahrenheit or Celsius .............................................................. 7
Switching between 4 Kinds of Measuring Mode................................................ 7
Tips for Measuring Human Temperature............................................................... 8
Measuring Human Temperature................................................................................ 9
Measuring Object/Liquid Temperature ................................................................10
Memory Function ...........................................................................................................11
Cleaning and Disinfecting...........................................................................................12
Error Codes........................................................................................................................13
Technical Specification .................................................................................................14
EMC Tables.........................................................................................................................15
Explanation of Symbols................................................................................................17

1
Introduction
This Touch Free Infrared Thermometers is intended for home use and
the intermittent measurement of human body forehead temperature in
people of all ages.
1. Multi functions
Human Body/ Object/ Night Mode Option/ Fever Alarm/ Backlight
2. Night Mode Option
Switch to Night mode can mute the sound to reduce the
interference of buzzer during your baby sleeping.
3. LED Light for Fever Alarm
This device has the LED light to remind user their readings are over
38°C and plus the beep sound only in Human Body Mode.
4. 30 sets Memory
5. Illuminated Backlight Display
6. °C/°F Switch-able Function
7. One-second Reading
8. Auto power off for power saving
9. Low-battery Indicator
Indicate for battery condition and measuring range.
10. Large LCD Display

2
Important Information before Use
When using this product, please be sure to follow all the notes listed
below. Any action against these notices may cause injury or affect the
accuracy.
1. Do not disassemble, repair, or remodel the thermometer.
2. Be sure to clean the thermometer lens each time after usage.
3. Avoid direct finger contact with the lens.
4. No modification of this equipment is allowed.
5. It is recommended that user may take 3 temperatures. If they are
different, use the highest reading.
6. Do not expose the thermometer to extreme temperature, very high
humidity, or direct sunlight.
7. Avoid extreme shock or dropping the device.
8. Before the measurement, patients and thermometer should stay in
steady state room condition for at least 30 minutes.
9. Avoid measuring temperature in 30 minutes after exercise, bathing,
or returning from outdoor.
10. To protect the environment, dispose of empty batteries at
appropriate collection sites according to national or local
regulations.
11. Please use the thermometer solely for its intended purpose.
12. There are no absolute body temperature standards. Keep reliable
records of your personal temperature to serve as a reference for
judging a fever.
13. Under any circumstances, the temperature taking result is ONLY for
reference. Before taking any medical action, please consult your
physician.
14. It is recommended calibrate the device every 1 year.
15. CAUTION: Please keep this device away from pets, pests, and
children.
16. CAUTION: Please keep away from children and pets, because
small parts may be inhaled or swallowed.

3
17. If any serious incident that has occurred in relation to the device
should be reported to the manufacturer and the competent
authority of the Member State in which the user is established.
18. If you would require any assistance during setting up, using or
maintaining, please contact the manufacturer.
19. Avoid using the device near an operating cell phone or microwave
oven.

4
Product Identification
1
LCD Display
2
LED Light
3
Memory Button
4
Measure Button
5
Mode Button
6
Measurement Sensor
7
Sound Hole
8
Battery Compartment Lid

5
Description of LCD Display
Measuring sequence in process
Night Mode (Mute Mode)
Human Mode
Object Mode
Degree of measurement
Celsius Scale
Fahrenheit Scale
Low battery indicator
Frowning Face
(temperature is equal or higher than 38°C)
Smiling Face
(temperature is lower than 38°C)
Memory Symbol and sets of records

6
Battery Installation
Low battery warning:
When the battery power becomes low, the low battery symbol “ ”
will appear on the display. The thermometer can still be used during
this time, but the batteries should be replaced as soon as possible. If the
batteries run out completely, “Lo” will be displayed along with the
low battery symbol “ ”. In this case, the batteries will need to be
replaced before using the thermometer again.
CAUTION:
Risk of explosion if battery is replaced by an incorrect type. Dispose of
used batteries according to the instructions.
Replacing the Battery:
1. Gently slide the battery cover back.
2. Carefully remove the old batteries and properly discard.
3. Insert new batteries (Two 1.5V alkaline AAA(LR03) Size) according to
the proper polarity.
4. Slide the battery cover back on.
NOTE: Battery-operated
1. Please properly dispose of the batteries away from small children
and heat.
2. It is recommended to remove the batteries if the unit will not be
used for an extended period of time.
3. Batteries must be disposed of in accordance with local
environmental and institutional policies.
4. Dispose of used batteries in accordance with the applicable legal
regulations. Never dispose of batteries in the normal household
waste.

7
Switching Between Fahrenheit or Celsius
Your thermometer can display results in either degrees Celsius (°C) or
degrees Fahrenheit (°F). With combination of Memory and Mode
button are able to change the mode to either °C or °F with a beep
sound.
Switching between 4 Kinds of Measuring Mode
1 Under power on status, you can press the Mode Button to switch
different measuring mode. There are 4 kinds of mode which including
Human, Object, Human/Night, and Object/Night Mode (in order).
2. The beep sounds will be off (mute) when your choice in Human/Night
Mode, and Object/Night Mode, and the Moon symbol “ ” will
appears on the LCD in both Night Modes.
NOTE:
Each press will comes with a beep sound to ensure the setting is
activated. (Except both Night Modes)

8
Tips for Measuring Human Temperature
Bear in mind that the thermometer needs to have been in the room in
which the measurement is taken for at least 30 minutes before use.
NOTE:
•Attempting to take temperature readings from sites on the body
other than the forehead may produce inaccurate results.
•The patient should remain still while the reading is being taken.
•Readings taken while asleep should not be compared directly to
readings taken while awake, as body temperature while asleep is
typically lower.
•Do not take body temperature readings within 30 minutes of being
outdoors, exercising or bathing.

9
Measuring Human Temperature
Taking a Measurement
1. Press the Power Button to power on the thermometer. The unit will
run a self-test and the LCD will briefly display all of its symbols during
this time. When the device is ready, “--“appear on the screen, and
the thermometer is ready to take a measurement.
2. Select the desired mode by pressing and releasing the Human/Object
Button.
Note:
- When taking a patient’s temperature, ensure that the thermometer
is in Human Mode; the Human symbol “ ”will appear on the
display.
- If the patient’s skin is covered with hair, sweat, or dirt, clean the area
and wait 10 minutes before taking a measurement.
- Ensure that the thermometer is held firmly during measurement and
that the patient does not move until the measurement is complete.
Movement can impact the measurement.
3. Position the thermometer under 3cm (around 1 inch) from the center
of the patient's forehead with the sensor aimed between the
eyebrows.
4. Press and release the Measure Button. As you hear a short beep
means this temperature reading has been completed and accompany
with a back-light.
5. If the temperature measurement is below 38°C, a “Smiling Face”
will appear next to the reading. If the reading is 38°C or above, a
“Frowning Face” will display and the LED light up to alert.
6. After about 30 seconds after use, the thermometer will automatically
beep and shut off.
Fever Alarm:
Only in Human Mode and Human/Night Mode.

10
Measuring Object/Liquid Temperature
1. Press the “Measure Button” to turn the thermometer on. All
symbols on the display will momentarily appear.
2. Ensure that the thermometer is in Object Mode; the Object symbol
“ ”will be on the display. To alternate between modes press and
release the Human/Object Mode Button until you see the desired
measurement symbol on the display.
3. Position the thermometer under 3cm (around 1 inches) from the
object.
4. Release the “Measure Button” and the temperature reading will be
displayed.
5. After use, the thermometer will automatically beep and shut off after
idling.

11
Memory Function
Memory Recall:
You can recall up to 30 measurements currently stored in memory to
share with your physician or trained healthcare professional.
1. When the device is on, press once briefly on the Memory Button,
then pass it again to show the last measurement accompanied by
“ ” symbol.
2. The “ ” symbol or “ ” symbol will appear with each
measurement stored in memory to indicate whether a person or
object temperature was taken.
3. Each press of the same button recalls a previous measurement.
Memory Deletion:
1. Under power on status, you may hold press the “Memory button”
to delete all the readings. The LCD shows “- -” with one beep
sound to indicate that all memories are cleared.
2. Remove batteries, memory will be cleared.
NOTE:
All the readings will be cleared no matter record in Human Mode or
Object Mode.

12
Cleaning and Disinfecting
For home use device disinfection, 75% alcohol (available in the
pharmacy) can be used.
•Measurement Sensor
Clean the measurement sensor with an alcohol swab before and after
each measurement.
•Thermometer:
Use a soft, dry cloth to clean thermometer body. Never use abrasive
cleaning agents, thinners or benzene for cleaning. Do not scratch the
surface of the probe lens or the display. Do not expose the
thermometer to extreme temperatures, humidity, direct sunlight, or
shock.

13
Error Codes
When a malfunction or incorrect temperature measurement occurs, an
error message will appear as described below.
Display
Cause
Solution
The temperature measured is
higher than measurement range.
Human mode: 43°C (109.4°F)
Object mode: 100°C (212.0°F)
Operate the thermometer
only between the specified
temperature ranges. If
necessary, clean the sensor
tip. In the event of a repeated
error message, contact your
retailer or Customer Services.
The temperature measured is
lower than measurement range.
Human mode: 34°C (93.2°F)
Object mode: 0°C (32.0°F)
The operating temperature is not
in the range:
15°C~40°C (59°F~104°F)
Operate the thermometer
only between the specified
temperature ranges.

14
Technical Specification
•Measuring range :
Human Body : 34°C~43°C (93.2°F~109.4°F)
Object : 0°C~100°C (32.0°F~212.0°F)
•Calibration Accuracy:
Human Body : ±0.2°C(±0.4°F): from 34°C~43°C (93.2°F~109.4°F)
Object : < 20°C ± 2°C; >= 20°C ± 5%
•Display resolution : 0.1°C (0.1°F)
•Operating environment :
15°C~40°C (59°F ~ 104°F)
with relative humidity up to 95% (non condensing)
Atmospheric pressure: 700~1060 hPa
•Storage/ Transportation environment :
-25 to 55 °C(-13 to 131 °F)
with relative humidity up to 95% (non condensing)
•Atmospheric pressure: 700~1060 hPa
•Power supply : 2 x 1.5V AAA size alkaline batteries
•Weight : approx. 80g (with batteries)
•Memory: 30 sets
•Dimensions :
approx. 123mmx50.5mmx49mm (L×W×H)
•Operation Distance : 3 cm
•Reference body site: Ear temperature
•Typical Service Life：3 years
•Battery Operation Time:
about 90 minutes (Depends on different brand of batteries.)
•For Customer Service
It is recommended that the accuracy should be checked by
manufacture every 1 years. To obtain the service please contact AViTA
Corp. for the address of the repair location. Enclose the Proof of
Purchase. Include $10.00 USD for the return shipping and handling.
Include a letter, with your name, address, phone number, and
description of the specific problem. Pack the product carefully to
prevent damage in transit. Because of possible loss in transit, we
recommend insuring the product with return receipt requested.

15
EMC Tables
NT19 is intended for use in the electromagnetic environment specified
below. The customer or the user of NT19 must make sure that it is used
in such an environment.
Guidance and manufacturer’s declaration - Electromagnetic emissions
Phenomenon
Professional healthcare
facility environment a)
HOME HEALTHCARE
ENVIRONMENT a)
Conducted and
radiated RF MISSIONS
a)
CISPR 11
Group 1 Class B
Harmonic distortion
Not applicable
Voltage fluctuations
and flickering
Not applicable
a) The equipment is suitable for use in Home Health Environments and
Professional Health Care Environments limited to patient rooms and
respiratory treatment facilities in hospital or clinics. The more restrictive
acceptance limits of Group 1 Class B (CISPR 11) have been considered
and applied. The equipment is suitable for use in the mentioned
environments when directly connected to the Public Mains Network.
b) The test is not applicable in this environment unless the ME
EQUIPMENT and ME SYSTEM used will be connected to the PUBLIC
MAINS NETWORK and the power input is otherwise within the scope of
the Basic EMC standard.
Guidance and manufacturer’s declaration - Electromagnetic immunity
- Enclosure port
Phenomenon
Basic EMC
standard or
test method
Immunity test levels
Professional
healthcare
facility
environment
HOME HEALTHCARE
ENVIRONMENT
ELECTROSTATIC
DISCHARGE
IEC 61000-4-2
±8kV contact
±2 kV, ±4kV ±, ±8 kV, ±15 kV air
Radiated RF EM
fields
IEC 61000-4-3
a)
10 V/m b) 80MHz - 2.7
GHz 80% AM at 1kHz
Proximity fields
from RF wireless
communications
equipment
IEC 61000-4-3
COMPLIANT
NOTE: Further information about
distances to be maintained between
portable and mobile RF
communications equipment
(transmitters) and the NT19 can be

16
requested from supplier using the
contact information provided in this
manual. However, it is advisable to
keep the electromechanical aerosol
equipment at an adequate distance
of, at least, 0.5 m from mobile phones
or other RF communications
transmitters to minimise possible
interference.
RATED power
frequency
magnetic fields.
IEC 61000-4-8
30 A/m c)
50 Hz or 60 Hz
a) The equipment is suitable for use in Home Health Environments and
Professional Health Care Environments limited to patient rooms and
respiratory treatment facilities in hospital or clinics. The more restrictive
IMMUNITY acceptance limits have been considered and applied.
b) Before modulation is applied.
c) This test level assumes a minimum distance of at least 15 cm between
the ME EQUIPMENT or ME SYSTEM and sources of power frequency
magnetic fields.

17
Explanation of Symbols
The CE marking with the Registration Number of the
Notified Body. This denotes the compliance of European
Medical Device Directive 93/42/EEC
Medical Device
Manufacturer
Authorized representative in the European Community
Date of manufacture
(YYYY-MM-DD or YYYY-MM)
Batch code
(YYMMWWWW)
Serial number
(YYMWWWXXXXX)
Keep dry
Temperature limit

18
Humidity limitation
Atmospheric pressure limitation
Caution
Consult the instruction for use
Disposal information: Should you wish to dispose of the
article, do so in accordance with current regulations. Details
are available from your local authority. WEEE 2012/19/EU
Directives
RoHS
This product fulfilling the requirements of the RoHS
Directive 2011/65/EU.
REACH
This product fulfilling the requirements of the REACH
Directive EC 1907/2006 and its amendments, do not
contain Substances of Very High Concern in concentration
above the limit of 0.1 %. No substance(s) is/are present in
the parts of the product above the concentration of 0.1 %
weight by weight.
Stand-by
Device classification type BF
