AvLab AVLT-MT29-1 User manual

PARTS INCLUDED
Power Input
110V-240V
Max.Speed
25 mm/s
Load Capability
220 lbs / 100 kg
Motion Noise
＜55dB
RATED
●Desktop Dimensions: 108-187cm
●4 Height Position Memory
●Vertical Range: 60 -125cm
Desktop(Optional)
Controller panel
Side plates
Power cord
Connection lines
Table legs
Feet
Controller box
Connecting rods
1.
2.
3.
4.
5.
6.
7.
8.
9.
1pc
1pc
2pcs
1pc
2pcs
scp2
2pcs
1pc
2pcs
SCREWS/FASTENERS (BAG)
Desk Parts
(not included)
Electric Dual Motor Sit-Stand Desk Frame
AVLT-MT29-1
AP4-0084A
INSTALLATION
1
E
1
2
3
4
7
8
5
6
9
M6x12 4PCS
D
B
7
Foot pads
M5×16 screws
(2pcs extra)
(2pcs extra)
M6×12 screws
M6×16 screws
A
B
C
D
E
S=4mm 1pc
14pcs
18pcs
8pcs
4pcs E
E
E
6
C
M6x16 2PCS
Unscrew this first.
Unscrew the two screws but don't unscrew them.
Then lift the table legs.

Press and display real height
Press and display real height
Press until 1 appears, release the button, it runs
to corresponding height and displays current position.
Press until 2 appears, release the button, it runs
to corresponding height and displays current position.
Press until 3 appears, release the button, it runs
to corresponding height and displays current position.
Over-heating
protection
Sensorless
alarm
Overload
protection
Rebound
protection
Overvoltage
alarm
Undervoltage
alarm
Step out alarm
Breaking
protection
Metric and
English
unit conversion
Hot: it alarms when continuous working 2 minutes;
clear automatically after resting 18 minutes.
E1: It alarms when motor hall value cannot be inspected;
clear it after press reset or re-power on.
E2: overload alarm when running up, clear automatically
after 3 seconds; overload alarm when running down,
clear it after press reset or re-power on.
E02: it alarms in reversed compression when running;
clear automatically after rebound 4cm; or press any
button to clear when rebounding.
E03: it alarms when voltage is higher than limit value,
clear automatically after voltage reduced to set value.
E05: it alarms when voltage is lower than limit value;
clear automatically after voltage is higher than set value.
E06: it alarms when height difference between left and
right leg exceeds the set value; clear it after re-power on.
It stops and enters protection state when motor lines or
manual control lines are removed or disconnected
accidentally; back to normal after reconnected and alarm
cleared.
Press for 3 seconds and it will display ---, release ,
press until 1 appears, release the button and it
displays current height. (English unit)
Press for 3 seconds and it will display ---, release ,
press until 0 appears, release the button and it
displays current height. (metric unit)
Protection mode (auto lock screen mode)
Press until 4 appears, release the button, it runs
to corresponding height and displays current position.
Save button,used to enter the save height function
After press , the interface flashes and set memory
position, press until H1 appears, release button and
it displays current height.
INSTALLATION
2
5
3
6
Install the side plate (3) and use the wrench (E)
to lock the screw (C)
Insert the connecting rod (9) into the frame.
Adjust the distance according to the size of the table,
and then tighten the screw (B) with the wrench (E).
4
Mount the desktop (1) with screws (A) on the two side plates
Mount the control box(8) under desktop(1) with screws (A).
Use the screws (A) to install the controller panel(2) under
the desktop (the left and right sides of the desktop can be
chosen)
4
25
A C
H S M 1 M 2
OPERATION
1080-1870mm
B
E
A
M5x16 8PCS
1
A
M5x16 2PCS
AM5x16 2PCS
M6x12 8PCS
Reset
Memory
Position
in condition of E2 or run to basic height position, long
press for 5 seconds, display RES and press still, it
goes down to the lowest and rebound certain height,
reset finish and show basic height.
M
M
M
M M
S=4mm
9
3
C
M6x16
Rip the protective film off before
the monitor is installed.
