Avocent Emerge VSM2000 Installation and maintenance instructions

Avocent Emerge
®VSM2000
Multi-function Video Scaler
Installer/User Guide
Avocent, the Avocent logo and Emerge are registered trademarks of Avocent Corporation.
All other marks are the property of their respective owners.
© 2008 Avocent Corporation. All rights reserved. 590-455-501A

TABLE OF CONTENTS
1.0 DISCLAIMER .................................................................................................1
1.1 Regulatory Agency Acceptance ............................................................................ 1
1.2 FCC Statement ..................................................................................................... 1
1.3 Manual Copyright Notice....................................................................................... 2
2.0 IMPORTANT SAFETY INSTRUCTION.........................................................3
2.1 Power and connections......................................................................................... 3
2.2 Water and moisture............................................................................................... 3
2.3 General care ......................................................................................................... 3
2.4 Location................................................................................................................. 3
2.5 Ventilation ............................................................................................................. 3
2.6 Rack Mount Safety Considerations....................................................................... 4
2.7 Intellectual property............................................................................................... 4
3.0 CAPABILITY, DEVICE FEATURES AND PRODUCT FEATURES ............13
3.1 Device Capabilities.............................................................................................. 13
3.2 Device Features .................................................................................................. 13
4.0 PRODUCT IMAGES ....................................................................................14
5.0 FRONT PANEL CONTROLS.......................................................................15
5.1 Multi-directional switch ........................................................................................ 15
5.2 Special button combinations and functions......................................................... 16
5.2.1 Locking front panel buttons & IR remote control ................................................. 16
5.2.2 Restore power-on settings .................................................................................. 16
5.2.3 Factory Reset...................................................................................................... 16
5.2.4 Forcing default output resolution......................................................................... 16
6.0 VIDEO INPUTS AND OUTPUTS.................................................................17
6.1 Computer & Video inputs .................................................................................... 17
6.2 Computer outputs................................................................................................ 17
6.3 Audio inputs and outputs..................................................................................... 18
7.0 UNPACKING AND INSTALLATION ............................................................19
7.1 Shipping Carton .................................................................................................. 19
7.2 Important Safety Instructions .............................................................................. 19
7.3 Initial Operation Check Using Factory Default Settings ...................................... 19
7.3.1 Initial operation and test of Video Scalers........................................................... 19
8.0 INFRA-RED REMOTE CONTROL ..............................................................21
9.0 MENU LAYOUT AND SETTINGS ADJUSTMENT......................................22

9.1 The High Level Menu Structure .......................................................................... 22
9.2 Group Names and Descriptions .......................................................................... 23
9.3 Items Associated with the Adjust outputs group ................................................. 23
9.4 Items Associated with the Adjust windows group ............................................... 24
9.5 Items Associated with the Adjust sources group................................................. 27
9.5.1 RGB Source Menu Items .................................................................................... 28
9.5.2 CV & YC Source Menu Items.............................................................................. 30
9.5.3 Items associated with the Adjust Ethernet group ................................................ 31
9.6 Items associated with the Adjust resolutions group ............................................ 32
9.7 Items Associated with the System group ............................................................ 35
10.0 RS232 CONTROL .......................................................................................38
10.1 Connection .......................................................................................................... 38
10.2 Communications protocol.................................................................................... 38
11.0 TROUBLESHOOTING AND TECHNICAL SUPPORT................................39
11.1 There is no picture on the output. ....................................................................... 39
11.2 The image is shifted and not fully viewable......................................................... 39
11.3 The output resolutions no longer appear as expected. ....................................... 39
11.4 The Output image is distorted. ............................................................................ 39
11.5 How can I reduce color smearing on CV connections? ...................................... 40
11.6 I can no longer adjust the Output image resolution............................................. 40
11.7 The RGB input is selected but the image is rolling or pink.................................. 40
11.8 The video signal from my DVD player does not appear to work. ........................ 40
12.0 RETURN PROCEDURE..............................................................................41
12.1 Are you sure there's a fault? ............................................................................... 41
12.2 To return a unit for repair .................................................................................... 41
13.0 WARRANTY POLICY ..................................................................................42
14.0 CONNECTOR PINOUTS.............................................................................43
14.1 DVI-I connector ................................................................................................... 43
14.2 HD15 connector .................................................................................................. 43
14.3 RS232 / DB9 socket............................................................................................ 44
14.4 4 Pin mini-DIN S-video connector (YC) input...................................................... 44
14.5 Multi-way audio connector .................................................................................. 44
15.0 SPECIFICATIONS.......................................................................................45
15.1 Video Inputs ........................................................................................................ 45
15.2 Computer Input ................................................................................................... 45
15.3 Computer Outputs............................................................................................... 45

15.4 Audio input/output ............................................................................................... 45
15.5 Locking/Mixing .................................................................................................... 46
15.6 Scaling / sampling / memory ............................................................................... 46
15.7 Warranty.............................................................................................................. 46
15.8 Regulatory Compliance....................................................................................... 46
15.9 Environmental ..................................................................................................... 46
15.10 Power Requirement ............................................................................................ 46
15.11 Control Methods.................................................................................................. 47
15.12 Mechanical .......................................................................................................... 47
15.13 Optional Accessories .......................................................................................... 47

1
1.0 DISCLAIMER
This product is intended for professional and/or home use. This product is not intended for use in a
medical environment and does not have the required certifications for such use. Similarly, use
aboard any aircraft or spacecraft while in flight or as an adjunct to any surface, airborne or marine
navigation system or any offshore marine activity, including control of any watercraft, or any use
similar to those specifically herein mentioned is prohibited. Use in the aforementioned
circumstances would require additional testing and certification.
1.1 Regulatory Agency Acceptance
Emissions: EN 55103-1: 1997(Electromagnetic compatibility. Product family standard for audio,
video, audio-visual and entertainment lighting control apparatus for professional use. Emission)
EN 61000-3-2:2000+A1:2001+A2:2005 (Limits for Harmonic Currents Emissions)
EN 61000-3-3:2000+A1:2001+A2:2005 (Limitation of voltage fluctuations and flicker in low-voltage
supply systems)
Immunity: EN55103-2: 1997 (Electromagnetic compatibility. Product family standard for audio,
video, audio-visual and entertainment lighting control apparatus for professional use. Immunity)
1.2 FCC Statement
Class A Device: This equipment has been tested and found to comply with the limits for a Class A
digital device pursuant to Part 15 of the FCC Rules. These limits are designed to provide a
reasonable protection against harmful interference when the equipment is operated in a
commercial environment. This equipment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the Instruction Manual, may cause harmful
interference to radio communications. Operation of this equipment in a residential area is likely to
cause harmful interference in which case the user will be required to correct the interference at his
own expense.
Caution: This equipment is intended for use in the manner prescribed in the Instruction Manual.
Any user changes or modifications not expressly approved by Avocent Corporation could void the
user’s authority to operate the equipment. Connecting this equipment to external devices requires
no specially shielded cabling for FCC compliance. The Instruction Manual shows or describes the
proper connection of this equipment for operation that insures FCC compliance.
Direct all inquiries regarding FCC compliance to:
Avocent Corporation
4991 Corporate Dr.
Huntsville, AL 35805

2
1.3 Manual Copyright Notice
This Operation Manual is the intellectual property of Avocent Corp. No portion of this manual may
be copied or reproduced in any manner or by any means, including, but not limited to electronic
and electro-mechanical, without the express written permission of Avocent Corp.

3
2.0 IMPORTANT SAFETY INSTRUCTION
To insure the best from this product, please read this manual carefully. Keep it in a safe place for
future reference.
To reduce the risk of electric shock, do not remove the cover from the unit.
No user serviceable parts inside. Refer servicing to qualified personnel.
2.1 Power and connections
This unit is not disconnected from the AC power source as long as it is connected to the wall
outlet. The off state for this unit is called standby mode. In standby mode the unit is designed to
consume a reduced quantity of power compared to normal operating modes.
When not using the unit for a long period of time, insure that the AC power cord is disconnected
from the wall outlet.
The AC wall outlet should be installed near to the unit and be easily accessible.
Do not plug in or attempt to operate an obviously damaged unit.
2.2 Water and moisture
To reduce the risk of fire and personal injury, operation of this device outdoors and/or exposure to
rain, water or excessive moisture is expressly prohibited.
The apparatus shall not be exposed to dripping or splashing and no objects filled with liquids, such
as vases, shall be placed on the apparatus.
2.3 General care
Do not force switches or external connections.
When moving the unit, disconnect the serial port connections first then the power cable and finally
the interconnecting cables to other devices.
Do not attempt to clean the unit with chemical solvents or aerosol cleaners, as this may damage
the unit. Use a clean dry cloth.
2.4 Location
Installation of this unit should be in a cool dry place, away from sources of excessive heat,
vibration, dust, moisture and cold.
2.5 Ventilation
Slots and openings in the sides of the unit are provided for ventilation. To ensure reliable
operation, avoid obstruction of these openings and ensure the unit is installed in a well-ventilated
area.

4
2.6 Rack Mount Safety Considerations
Before installing the appliance and other components in the rack (if not already installed), stabilize
the rack in a permanent location. Install the equipment starting at the bottom of the rack, then work
to the top. Avoid uneven loading or overloading of racks.
Elevated ambient temperature: In a closed rack assembly, the operation temperature of the
rack environment can be greater than room ambient. Use care not to exceed the rated
maximum ambient temperature of the unit.
Reduced air flow: Carefully install the equipment in a rack so that an adequate amount of
airflow is maintained for safe operation of the equipment.
Mechanical loading: Avoid a potentially hazardous condition caused by uneven mechanical
loading by carefully mounting the equipment in the rack.
Circuit overloading: Consider the connection of the equipment to the supply circuit and the
effect that overloading of circuits might have on over-current protection and supply wiring.
Observe equipment nameplate ratings for maximum current.
Reliable earthing: Maintain reliable earthing of rack-mounted equipment. Pay particular
attention to supply connections other than direct connections to the branch circuit (for
example, use of power strips).
2.7 Intellectual property
Some IC chips in this product include confidential and/or trade secret property. Therefore you
may not copy, modify, adapt, translate, distribute, reverse engineer, reverse assemble or
decompile the contents thereof.

5
2.0 IMPORTANT: CONSIGNES DE SECURITE
Afin de tirer le meilleur de ce produit, merci de lire attentivement ce manuel. Gardez-le dans un
endroit sûr pour pouvoir le consulter à nouveau.
Afin de réduire le risque de choc électrique, ne retirez pas l’unité de sa protection.
Aucune pièce réparable par l’utilisateur à l’intérieur. Référez-vous à des personnes qualifiées.
2.1 Alimentation électrique et connexions
Cette unité n’est pas déconnectée de la source de courant électrique tant qu’elle est connectée à
la prise murale. Le mode éteint de cette unité est appelé mode de veille. En mode de veille, cette
unité est conçue pour consommer une quantité réduite de courant par rapport aux modes
normaux d’utilisation.
Lorsque vous n’utilisez pas l’unité pendant une longue période, assurez-vous que le câble
d’alimentation électrique est déconnecté de la prise murale.
La prise murale de courant doit être installée près de l’unité et aisément accessible.
Ne branchez pas et n’essayez pas d’utiliser une unité visiblement endommagée.
2.2 Eau et humidité
Pour réduire les risques d’incendie et de dommages corporels, l’utilisation de cet appareil à
l’extérieur et/ou son exposition à la pluie, l’eau ou une humidité excessive est expressément
interdite.
L’appareil ne doit pas être exposé aux gouttes ou aux éclaboussures et aucun objet contenant de
l’eau, comme par exemple un vase, ne doit être posé sur l’appareil.
2.3 Entretien général
Ne forcez pas les boutons ou connexions externes.
Lorsque vous déplacez l’unité, déconnectez d’abord les connexions de ports en série puis le câble
d’alimentation et enfin les câbles de connexion avec d’autres appareils.
N’essayez pas de nettoyer l’unité avec des dissolvants chimiques ou des produits nettoyants en
aérosol, car cela peut endommager l’unité. Utilisez un chiffon propre et sec.
2.4 Emplacement
L’installation de cette unité doit se faire dans un endroit frais et sec, éloigné de sources
excessives de chaleur, de vibrations, de poussière, d’humidité et de froid.
2.5 Aération
Les rainures et les ouvertures sur les cotés de l’unité servent à l’aérer. Pour permettre une
utilisation sûre, évitez d’obstruer ces ouvertures et assurez-vous que l’unité est installée dans un
endroit bien aéré.

6
2.6 Propriété intellectuelle
Certaines puces IC dans ce produit contiennent des éléments propriétaires confidentiels et/ou des
secrets commerciaux. Vous ne devez donc pas copier, modifier, adapter, traduire, distribuer,
démonter, désassembler, ou décomposer leur contenu.

7
2.0 INSTRUCCIONES IMPORTANTES DE SEGURIDAD
Para sacar el mejor provecho de este producto, léase este manual con detenimiento. Guárdelo en
un lugar seguro para poder hacerle referencia en el futuro.
Para reducir el riesgo de calambre, no quite la cubierta del aparato.
No hay piezas utilizables dentro. Remítase todo mantenimiento a personal cualificado.
2.1 Corriente y conexiones
Mientras esté conectada a una toma de electricidad, el aparato seguirá conectado a la fuente de
corriente CA. A la posición de «off» de este aparato se le denomina posición de espera. En la
posición de espera, el aparato está diseñado a consumir una cantidad reducida de electricidad en
comparación con los modos de operación normales.
Asegúrese de desconectar el cable de corriente CA de la toma de la pared cuando no va a utilizar
el aparato por un periodo largo de tiempo.
La toma CA de la pared ha de estar instalada cerca del aparato y debe ser fácilmente accesible.
No enchufe ni intente operar un aparato que esté evidentemente dañado.
2.2 Agua y humedad
Para reducir el riesgo de fuego o de daños personales, se prohíbe la utilización de este aparato
en el exterior y/o su exposición a la lluvia, al agua o a atmósferas de excesiva humedad.
El aparato no debe situarse cerca de zonas en las que haya riesgo de goteo o salpicaduras.
Tampoco deben colocarse objetos que contengan agua (jarrones, por ejemplo) en el mismo.
2.3 Cuidado general
No forzar interruptores o conexiones externas.
Al mover el aparato, desconecte las conexiones del puerto en serie primero, luego el cable de
electricidad y finalmente los cables interconectados a otros aparatos.
No intente limpiar el aparato con disolventes químicos o productos de limpieza aerosol, ya que
podrían dañar el aparato. Utiliza un paño limpio y seco.
2.4 Ubicación
Este aparato se debe instalar en un lugar seco y fresco, lejos de fuentes de calor excesivas, la
vibración, el polvo, la humedad y el frío.
2.5 Ventilación

8
El aparato viene provisto de ranuras y agujeros en los lados para la ventilación.
Para asegurar una operación eficaz, se debe evitar la obstrucción de estos agujeros y también
asegurar que el aparato se instale en una zona con adecuada ventilación.
2.6 Propiedad intelectual
Algunos chips con circuito integrado de este producto incluyen propiedad confidencial y/o
propiedad de secreto comercial. Por lo tanto queda prohibido copiar, modificar, adaptar, traducir,
distribuir, usar técnicas retroactivas, desmontar, o recopilar los contenidos del mismo.

9
2.0 WICHTIGE SICHERHEITSVORSCHRIFTEN
Lesen Sie diese Bedienungsanleitung bitte sorgfältig, um Ihr Produkt optimal nützen zu können,
und bewahren Sie sie zum späteren Nachschlagen an einem sicheren Ort auf.
Entfernen Sie bitte keinesfalls die Abdeckung, um der Gefahr eines Stromschlags vorzubeugen.
Im Inneren des Geräts befinden sich keine Teile, die vom Benutzer gewartet werden können.
Lassen Sie Wartungsarbeiten nur von Fachpersonal durchführen.
2.1 Stromversorgung und anschlüsse
Solange das Gerät mit einer Steckdose verbunden ist, bleibt die Stromversorgung aufrecht. Der
Ausschaltzustand des Geräts wird als Standbymodus bezeichnet. Im Standbymodus verbraucht
das Gerät weniger Strom als in den üblichen Betriebsarten.
Wird das Gerät über einen längeren Zeitraum hinweg nicht verwendet, ziehen Sie bitte das
Stromkabel aus der Steckdose.
Die Steckdose sollte sich in der Nähe des Geräts befinden und leicht zugänglich sein.
Verbinden Sie ein offensichtlich beschädigtes Gerät keinesfalls mit einer Steckdose und
versuchen Sie auch nicht, es zu bedienen.
2.2 Wasser und feuchtigkeit
Um die Gefahr eines Brandes oder einer Körperverletzung zu verringern, ist es ausdrücklich
verboten, dieses Gerät im Freien in Betrieb zu nehmen und/oder es Regen, Wasser oder hoher
Feuchtigkeit auszusetzen.
Das Gerät darf keinen Tropfen oder Spritzern ausgesetzt werden und es dürfen keine mit
Flüssigkeiten gefüllte Behälter, wie Vasen, auf das Gerät gestellt werden.
2.3 Allgemeine pflege
Wenden Sie bei der Handhabung von Schaltern und Anschlüssen keine Gewalt an.
Beim Umstellen des Geräts entfernen Sie zuerst die seriellen Anschlüsse, dann das Stromkabel
und zum Schluss die Verbindungskabel zu anderen Geräten.
Versuchen Sie keinesfalls, das Gerät mit chemischen Lösungsmitteln oder Sprayreinigern zu
reinigen, da dies das Gerät beschädigen könnte. Verwenden Sie ein sauberes, trockenes Tuch.
2.3 Aufstellung
Das Gerät sollte an einem kühlen, trockenen Ort aufgestellt werden, fern von übermäßiger
Wärme, Vibrationen, Staub, Feuchtigkeit und Kälte.
2.5 Belüftung

10
Seitliche Schlitze und Öffnungen sorgen für die Belüftung des Geräts. Um die ordnungsgemäße
Belüftung zu gewährleisten, dürfen diese Öffnungen nicht verdeckt werden. Sorgen Sie außerdem
dafür, dass das Gerät an einem gut belüfteten Ort aufgestellt wird.
2.6 Gewerbliches eigentum
Einige integrierte Schaltkreise in diesem Produkt enthalten vertrauliche
Informationen und/oder Betriebsgeheimnisse. Sie dürfen daher diese Inhalte nicht kopieren,
modifizieren, adaptieren, übersetzen, verteilen, rückentwickeln, rückassemblieren oder
dekompilieren.

11
2.0 BELANGRIJKE VEILIGHEIDSINSTRUCTIES
Lees deze handleiding zorgvuldig door om het beste uit uw product te halen. Bewaar het op een
veilige plek voor raadpleging in de toekomst.
Haal nooit het omhulsel van de eenheid af, dit om de kans op een elektrische schok te
verminderen. Maak het apparaat nooit open: er bevinden zich geen door de gebruiker in te stellen
onderdelen in het apparaat. Laat service en onderhoud over aan een gekwalificeerde technicus.
2.1 Elektriciteit en aansluiting
Deze eenheid is niet van de wisselstroom voedingsbron gescheiden wanneer de stekker nog in
het stopcontact zit. Wanneer de eenheid uitstaat, staat deze nog in de stand-by modus. In de
stand-by modus vergt de eenheid minder stroom dan in de normale "aan" modus.
Wanneer u de eenheid voor langere tijd niet gebruikt, zorg er dan voor dat de stekker van het
wisselstroomsnoer uit het stopcontact is getrokken.
Het wisselstroom stopcontact moet dichtbij de eenheid geïnstalleerd worden en makkelijk
toegankelijk zijn.
Als de eenheid duidelijk beschadigd is moet u deze nooit op het lichtnet aansluiten of bedienen.
2.2 Water en vocht
Om het risiko op brand en persoonlijk letsel te beperken is het gebruik van dit apparaat buiten
en/of blootstelling aan regen, water of overdadige hoeveelheden vocht uitdrukkelijk verboden.
Het apparaat mag niet worden blootgesteld aan druppels of bespatting en er mogen geen
objecten die gevuld zijn met vloeistoffen, zoals vazen, op het apparaat geplaatst worden.
2.3 Algemeen onderhoud
Forceer schakelaars of externe aansluitingen nooit.
Bij verplaatsing van de eenheid, de seriële poortaansluitingen eerst loskoppelen, dan de
voedingskabel en als laatste de snoeren naar andere apparaten.
Probeer de eenheid nooit met chemische oplosmiddelen of schoonmaakmiddelen in een spuitbus
schoon te maken, omdat dit de eenheid kan beschadigen. Gebruik een schone droge doek.
2.4 Plaatsing
Deze eenheid moet geïnstalleerd worden op een koele droge plaats, uit de buurt van bronnen van
extreme hitte, vibraties, stof, vocht en kou.
2.5 Ventilatie
De sleuven en openingen aan de zijkant van de eenheid zijn voor ventilatie. Zorg er voor dat de
eenheid op een goed geventileerde plek geïnstalleerd wordt zodat deze betrouwbaar werkt.
2.6 Intellectueel eigendom

12
Sommige IC chips in dit product bevatten vertrouwelijke informatie en/of fabrieksgeheimen. U mag
daarom de inhoud hiervan niet kopiëren, wijzigen, aanpassen, vertalen, verspreiden, nabouwen,
of decompileren

13
3.0 CAPABILITY, DEVICE FEATURES AND PRODUCT FEATURES
3.1 Device Capabilities
The VSM2000 scaler uses a proprietary scaling engine to perform its functions. This technology is
a powerful toolset for any application requiring high quality video signal conversion or image
manipulation.
The product features a single video processing and scaling engine. These functions allow the
flexibility for handling a wide range of inputs and outputs, depending on the unit used.
The product is at home in broadcast & display environments. The VSM2000 scaler offers a range
of high-level image processing functions.
This unit allows for a standard television video signal, such as Composite Video, to be input into
the unit and then converted for use on a computer display. When using this function you can
switch back to the computer image by pressing a button. This is known as bypass mode.
3.2 Device Features
General Topography
4:4:4 RGB / YUV sampling provides full bandwidth color which allows precise keying where
included in the unit’s capabilities. This can be achieved through the transparent (soft) keys on the
front of the unit. Each unit’s video inputs accommodate multiple video and computer signal formats
and resolutions – see specifications at end of manual for full details.
Ultimate flexibility
The VSM2000’s output signal format flexibility assures that the native resolution of virtually any
display can be matched. Because of the resolution calculator (included in the Windows® Control
Panel), even new resolutions can be added to the unit. Signal parameter adjustments can be
made for each video input and are stored in individual non-volatile memories for retrieval once the
unit’s power has been removed. The product employs pixel adaptive motion compensation to de-
interlace fast moving images, and automatic 3:2 Pull-down efficiently de-interlaces video from 24
fps NTSC film.
Simple Control
The unit can be controlled in various ways. One option is to control it from the front panel using the
transparent (soft) keys on the front of the unit. Another option would be to control the unit from an
infra-red remote control. It can also be controlled via RS-232 or via Ethernet using the Windows
Control Panel.
The Windows Control Panel is available for download from our Internet site and affords complete
control of the unit and adds Scripting to facilitate long, complex sequence of commands.
Upgradeability
The VSM2000 scaler benefits from firmware upgradeability, thus reducing product obsolescence
by allowing the installation of the latest version of firmware. This not only applies to the software
used to control the unit, but also to the range of resolutions stored inside the unit, the addition of
new features, and upgrades to the heart of the image processing hardware – the scaling engine.
See http://www.avocent.com/support for more detail.

14
4.0 PRODUCT IMAGES
Your VSM2000 scaler should look like the following image.

15
5.0 FRONT PANEL CONTROLS
The range of buttons on the front of the unit provides the user with quick access for selecting a
variety of inputs and features.
The multi-directional switch on the front panel provides the user with a way of navigating the Liquid
Crystal Display menus (LCD) which is detailed in a later section. The RS232 interface and
optional infra-red remote control also provide further ways of controlling the unit, which are
detailed in a later section.
Button controls
A sub-set of the following buttons will be available on the front of the unit, depending on the model
in use:
Button Button Function
Multi-
directional
switch
Press and hold in to store current settings into memory. They
will then be restored on power-on, or when a Restore is done.
See next section for more information.
RGB Selects an RGB input as the current source for conversion.
CV(n) Selects a CV input as the current source for conversion.
(n) Denotes a number. Some units may have more than one CV input
YC(n) Selects a YC input as the current source for conversion.
(n) Denotes a number. Some units may have more than one YC input
YUV Selects a RGB input as the current source for conversion on the
first press and then YUV on the second.
DVI Selects a DVI input as the current source for conversion.
FREEZE Freezes the current image (does not affect any background
image)
ZOOM Jumps to the ‘Zoom’ menu item.
(Further presses step Zoom between 100%, 150%, 200% and
300%)
PAN Jumps to the Zoom pan menu item and allows immediate
panning of a zoomed image using multi-directional switch.
5.1 Multi-directional switch
The LCD is controlled from the front panel by using the multi-directional switch (m/d switch). This
switch can be moved left, right, up or down and also pressed in. These functions let the user
navigate through the menu structure or change a parameter, and are detailed in a later section.

16
5.2 Special button combinations and functions
In addition to the ability to perform a factory reset and forcing certain output resolutions, other
button combinations are available:
These button combinations only work when the unit is switched on and active
i.e. with the STANDBY/ON LED is off. They will not work in Standby mode, or
during power-up.
5.2.1 Locking front panel buttons & IR remote control
This can be performed by pressing STANDBY/ON and FREEZE at the same time. All front panel
buttons and IR remote control commands will be disabled, with the exception of repeating the
above combination to un-lock the unit and for storing the current locked buttons setting (thus
letting you make sure the unit always starts up with the buttons locked). The IR remote’s LOCK
and STORE buttons will always be active, giving another way to turn button/IR remote locking off.
The STANDBY/ON button will flash when the unit’s buttons are locked.
5.2.2 Restore power-on settings
This can be done (without having to turn off the unit) by pressing STANDBY/ON and the multi-
directional switch at the same time until a single beep is heard.
5.2.3 Factory Reset
If you wish to restore all operational parameters to their original condition (for example, if saved
settings prevent the unit from working with your display monitor), hold the STANDBY/ON and the
multi-directional switch in together until two beeps are heard.
All stored settings except resolutions are lost when the unit is reset. A Firmware
update is the only way to perform a complete factory reset (including resolution
data).
5.2.4 Forcing default output resolution
Press and hold the RGB button and button 3 together, then release. The default output resolution
depends on the type of unit you have – see above.
Table of contents
Other Avocent Media Converter manuals
