Schematic diagram of the switch is shown in Figure 1.
It must be supplied with 12VDC. Operation of the
switch is controlled by an Atmega8 microcontroller.
The ULN2003A circuit is used to power relays.
LED1...LED4 indicate which relay is energised. Relays
are switched using the S1...S4 buttons.
The "MODE" jumper is used to select the operation
mode, while the way of switching on a particular
relay is made using jumpers 1...4, switching them to
the "B" position - bistable operation or "M" -
monostable
operation.
The "MODE" jumper set in "SW" mode configures
the device to operate in the switch mode with the
possibility of setting any channel as a monostable
switch (jumper in "M" position - relay
is switched on as long as the button is held down) or
bistable (jumper in "B" position - each time the
button is pressed, the relay changes to the opposite
state). In the next mode, the switch can operate as a
dependent. To activate this function, switch the
"MODE" jumper to the "SEL" position. In this mode,
the 'S' sync input is activated and there is a low level
on this line every time a button is pressed. This
causes all relays to switch off and only the currently
selected relay to switch on. In addition, it is possible
to deactivate dependent operation for a channel in
this mode. It is then necessary to move the selected
jumper to the "B" position - from then on, each press
of the button will change the state of the assigned
relay to the opposite without affecting the other
channels, which will continue to operate in a
dependent manner.
A configurable 4-channel switch circuit, allowing the
attached devices to be controlled in any way. Each
output can operate in monostable, bistable and
dependent modes, and due to the synchronisation
output and input, it is possible to link multiple such
switches together.
• multiple such switches can be connected together
• supply: 12 VDC
dependent
Specifications
• output circuit: 4 relays 230 VAC / 10 A (NC/NO)
• board size: 68×75 mm
• independent configuration of each of the four outputs
• 3 operating modes: monostable, bistable and
Circuit description
Configurable 4-Channel Switch
AVT 1916
1
kits
ASSEMBLY DIFFICULTY
PDF
DOWNLOAD
Fig. 2 Arrangement of components on the PCB
Fig. 1 Schematic diagram
GND
1 2
S1
1 2
S2
1 2
S3
1 2
S4
S1
S2
S3
S4
ULN2003AN
GND +12V
+12V
I1
1
I2
2
I3
3
I4
4
I5
5
I6
6
I7
7
O1 16
O2 15
O3 14
O4 13
O5 12
O6 11
O7 10
CD+ 9
GND
8
IC3
21
REL1
OS
P
21
REL2
OS
P
21
REL3
OS
P
21
REL4
OS
P
OUT1
OUT2
OUT3
OUT4
P1
P2
P3
P4
10k
+5V
MEGA8
GND
100nF
GND
R1
PB5(SCK) 19
PB7(XTAL2/TOSC2)
10
PB6(XTAL1/TOSC1)
9
GND
8
VCC
7
GND
22
AREF
21
AVCC
20
PB4(MISO) 18
PB3(MOSI/OC2) 17
PB2(SS/OC1B) 16
PB1(OC1A) 15
PB0(ICP) 14
PD7(AIN1) 13
PD6(AIN0) 12
PD5(T1) 11
PD4(XCK/T0) 6
PD3(INT1) 5
PD2(INT0) 4
PD1(TXD) 3
PD0(RXD) 2
PC5(ADC5/SCL) 28
PC4(ADC4/SDA) 27
PC3(ADC3) 26
PC2(ADC2) 25
PC1(ADC1) 24
PC0(ADC0) 23
PC6(/RESET)
1
IC2
C5
IR
LED1
LED2
LED3
S1
S2
LED4
LED5
S3
S4
P1
P2
P3
P4
SYN
SEL
PK1
PK2
PK3
PK4
100uF
100nF100nF
+5V
GND
100uF
+12V
1N4007
78L05
C2
C4C3
C1
D1
GND
VI
3
2
VO 1
IC1
+
+
VCC
GND
1k
1k
1k
+5V
1k
R4
R5
LED1
LED2
LED3
R6
LED4
R7
LED1
LED2
LED3
LED4
GND
+5V
1
2
3
4
5
SV1
1
2
3
4
5
SV2
1
2
3
4
5
SV3
SEL
PK1
PK2
PK3
PK4
1k
10k
+5V
R3
R2
SYN
S
2
Schematic diagram of the switch is shown in Figure 2.
Start by soldering resistors and other small
components onto the board and finish by fitting
electrolytic capacitors, screw connectors and relays. A
properly assembled circuit, once the configuration
jumpers have been properly set, is immediately ready
for operation. Changing the operating configuration
of a particular relay is possible at any time during
system operation and takes place independently for
each of the 4 channels.
33
IC2:............................ATmega8
Other:Resistors:
Semiconductors:
LED1-LED4: ............LED 3 mm
IC3:............................ULN2003
REL1-REL4:......................................JQC3FF/012-1ZS
VCC, VCC2, OUT1-OUT4: ..........ARK3/500
C3-C5: .....................100 nF
SV1-SV3:..........................................goldpin 1×5 + jumper
Capacitors:
S1-S4: ...............................................buttonR1, R2:......................10 kΩ
R3-R7: ...................... 1kΩ
D1:.............................1N4007
C1, C2: ....................100 μF
IC1:............................78L05
List of elements
Begin assembly by soldering the components onto the board in order of size from smallest
to largest. When mounting components marked with an exclamation mark, pay attention to
their polarity. Photographs of the assembled kit may be helpful. To access high-resolution images,
download the PDF file.
PDF
DOWNLOAD
4
Notes
The self-assembly kits are intended for educational and demonstration purposes only. They are not intended for use in commercial applications. If they are used in such applications, the
purchaser assumes all responsibility for ensuring compliance with all regulations
AVT SPV reserves the right to make changes without prior notice.Installation and connection of the appliance not in accordance with the instructions, unauthorised modification of
components and any structural alterations may cause damage to the appliance and endanger persons using it. In such a case, the manufacturer and its authorised representatives shall
not be liable for any damage arising directly or indirectly from the use or malfunction of the product.
This symbol means do not dispose of your
product with your other household waste.
Instead, you should protect human health
and the environment by handing over your
waste equipment to a designated collection
point for the recycling of waste electrical
and electronic equipment.
Leszczynowa 11 Street,
03-197 Warsaw, Poland
https://sklep.avt.pl/
AVT SPV Sp. z o.o.
