Extreme Networks Summit1 Manual

Extreme Networks, Inc.
3585 Monroe Street
Santa Clara, California 95051
[phone]
http://www.extremenetworks.com
Summit Switch Hardware
Installation Guide
Published: December 1999
Part number: 120037-00 Rev. A

ii
©1999 Extreme Networks, Inc. All rights reserved. Extreme Networks is a registered trademark of
Extreme Networks, Inc. in certain jurisdictions. ExtremeWare, ExtremeWare Vista, ExtremeWorks,
ExtremeAssist, ExtremeAssist1, ExtremeAssist2, PartnerAssist, Extreme Standby Router Protocol, ESRP,
BlackDiamond, SmartTraps, Summit, Summit1, Summit4, Summit4/FX, Summit7i, Summit24,
Summit48, Summit Virtual Chassis, SummitLink, SummitGbX, SummitRPS and the Extreme Networks
logo are trademarks of Extreme Networks, Inc., which may be registered or pending registration in
certain jurisdictions. The Extreme Turbodrive logo is a service mark of Extreme Networks, which may
be registered or pending registration in certain jurisdictions. All other registered trademarks,
trademarks and service marks are property of their respective owners. Specifications are subject to
change without notice.

III
Contents
PREFACE
Introduction xi
Conventions xii
Related Publications xiii
1S
UMMIT SWITCH OVERVIEW
Summit Switch Models 1-1
Summary of Features 1-2
Memory Requirements 1-2
Port Connections 1-3
Media Types and Distances 1-4
Full-Duplex 1-6
Summit1 Switch Front View 1-7
Summit1/LX Switch Front View 1-8
Summit4 Switch Front View 1-9
Summit4/FX Switch Front View 1-10
Summit24 Switch Front View 1-11
Summit48 Switch Front View 1-12
Summit Switch Rear View 1-13
Power Socket 1-13
Serial Number 1-13
Console Port 1-13
Redundant Power Supply Port 1-14
MAC Address 1-14
Summit Switch LEDs 1-15

IV
Summit7i Switch Front View 1-16
Module Reset Button 1-18
Console Port 1-18
Modem Port 1-18
Management Port 1-18
PCMCIA Slot 1-18
Summit7i Switch LEDs 1-19
Summit7i Switch Rear View 1-20
Power Socket 1-20
Serial Number 1-20
MAC Address 1-20
GBIC Type and Hardware/Software Support 1-21
2I
NSTALLATION AND SETUP
Following Safety Information 2-1
Determining the Switch Location 2-1
Installing the Summit Switch 2-2
Rack Mounting 2-2
Free-Standing 2-5
Stacking the Switch and Other Devices 2-5
Connecting Equipment to the Console Port 2-5
Powering On the Switch 2-7
Checking the Installation 2-7
Logging In for the First Time 2-8
Installing the Gigabit Interface Connector (GBIC) 2-9
AS
AFETY INFORMATION
Important Safety Information A-1
Power A-1
Power Cord A-2
Fuse A-3
Connections A-3
Connections A-3
Lithium Battery A-4

V
BT
ECHNICAL SPECIFICATIONS
Summit1, Summit1/LX, Summit4, Summit4/FX, Summit24, and
Summit48 Switch Specifications B-1
Summit7i Switch Specifications B-2
INDEX

VI

VII
Figures
1-1 Summit1 switch front view 1-7
1-2 Summit1/LX switch front view 1-8
1-3 Summit4 switch front view 1-9
1-4 Summit4/FX switch front view 1-10
1-5 Summit24 switch front view 1-11
1-6 Summit48 switch front view 1-12
1-7 Summit switch rear view 1-13
1-8 Front view of Summit7i switch with 100BASE-TX/1000BASE-T
ports 1-16
1-9 Front view of Summit7i switch with 1000BASE-SX ports 1-17
1-10 Summit7i switch rear view 1-20
2-1 Rack-mount helper bracket 2-3
2-2 Fitting the mounting bracket 2-4
2-3 Null-modem cable pin-outs 2-6
2-4 PC-AT serial null-modem cable pin-outs 2-7
2-5 GBIC modules 2-9

VIII

IX
Tables
1Notice Icons xii
2Text Conventions xii
1-1 Summit Switch Port Configurations 1-4
1-2 Media Types and Distances 1-4
1-3 1000BASE-LX70 Specifications 1-5
1-4 Summit Switch LEDs 1-15
1-5 Summit7i Switch LEDs 1-19
2-1 Console Connector Pinouts 2-6

X

SUMMIT SWITCH HARDWARE INSTALLATION GUIDE XI
Preface
This Preface provides an overview of this guide, describes guide conventions, and lists
other publications that may be useful.
INTRODUCTION
This guide provides the required information to install the Summit™switch.
This guide is intended for use by network administrators who are responsible for
installing and setting up network equipment. It assumes a basic working knowledge of
•Local Area Networks (LANs)
•Ethernet concepts
•Ethernet switching and bridging concepts
•Routing concepts
•Simple Network Management Protocol (SNMP)
For information on configuring the Summit switch, refer to the ExtremeWare Software
User Guide.
If the information in the “Release Notes” shipped with your switch differs from the
information in this guide, follow the “Release Notes.”

XII SUMMIT SWITCH HARDWARE INSTALLATION GUIDE
PREFACE
CONVENTIONS
Table 1 and Table 2 list conventions used throughout this guide.
Table 1: Notice Icons
Icon Notice Type Alerts you to...
Note Important features or instructions.
Caution Risk of personal injury, system damage,
or loss of data.
Warning Risk of severe personal injury.
Table 2: Text Conventions
Convention Description
Screen displays This typeface represents information as it appears on the screen,
or command syntax.
Screen displays bold This typeface represents commands that you type.
The words “enter”
and “type” When you see the word “enter” in this guide, you must type something, and then press the Return or Enter key. Do not press
the Return or Enter key when an instruction simply says “type.”
[Key] names Key names appear in text in one of two ways:
■Referred to by their labels, such as “the Return key” or “the
Escape key”
■Written with brackets, such as [Return] or [Esc]
If you must press two or more keys simultaneously, the key
names are linked with a plus sign (+). Example:
Press [Ctrl]+[Alt]+[Del].
Words in
italicized
type Italics emphasize a point or denote new terms at the place where
they are defined in the text.

SUMMIT SWITCH HARDWARE INSTALLATION GUIDE XIII
RELATED PUBLICATIONS
RELATED PUBLICATIONS
The Summit switch documentation set includes the following:
•ExtremeWare Software User Guide
•ExtremeWare Quick Reference Guide
•Summit Switch“Release Notes”
Documentation for Extreme Networks products is available on the World Wide Web at
the following location:
•Extreme Networks home page http://www.extremenetworks.com/

XIV SUMMIT SWITCH HARDWARE INSTALLATION GUIDE
PREFACE

Summit Switch Hardware Installation Guide 1-1
1Summit Switch Overview
This chapter describes the following:
•Summit switch models
•Summit switch features
•Summit switch memory requirements
•Summit switch front views
•Summit switch rear view
•Summit switch LEDs
•Factory default settings
SUMMIT SWITCH MODELS
The Summit family of switches is comprised of the following models:
•Summit1 switch
•Summit1/LX switch
•Summit4 switch
•Summit4/FX switch
•Summit24 switch
•Summit48 switch
•Summit7i switch

1-2 Summit Switch Hardware Installation Guide
SUMMIT SWITCH OVERVIEW
SUMMARY OF FEATURES
Summit switches support the following ExtremeWare features:
•Virtual local area networks (VLANs) including support for IEEE 802.1Q and IEEE
802.1p
•Spanning Tree Protocol (STP) (IEEE 802.1D) with multiple STP domains
•Policy-Based Quality of Service (PB-QoS)
•Wire-speed Internet Protocol (IP) routing
•IP Multinetting
•DHCP/BOOTP Relay
•Routing Information Protocol (RIP) version 1 and RIP version 2
•Open Shortest Path First (OSPF) routing protocol
•Wire-speed IP multicast routing support
•IGMP snooping to control IP multicast traffic
•Distance Vector Multicast Routing Protocol (DVMRP)
•Protocol Independent Multicast-Dense Mode (PIM-DM)
•IPX, IPX/RIP, and IPX/SAP support
•Load sharing on multiple ports
•Console command-line interface (CLI) connection
•Telnet CLI connection
•ExtremeWare Vista Web-based management interface
•Simple Network Management Protocol (SNMP) support
•Remote Monitoring (RMON)
•Traffic mirroring for all ports
MEMORY REQUIREMENTS
Your Summit switch must have 32MB of DRAM in order to support the features in
ExtremeWare version 4.0 and above. This is not an issue for Summit24 and Summit48
switch models, and all currently shipping switches contain 32MB. Some earlier models
of the Summit switch shipped with 16MB, and must be upgraded to support
ExtremeWare version 4.0 and above.

Summit Switch Hardware Installation Guide 1-3
MEMORY REQUIREMENTS
To determine the memory size in your switch, use the following command:
show memory
For Summit switches running ExtremeWare 4.0 and above, the switch indicates the total
DRAM size in megabytes as part of the output. For Summit switches running previous
ExtremeWare releases, you must calculate the memory by taking the sum of the bytes
listed under current free and adding to it the bytes listed under current alloc. If
the sum is greater than 16,000,000, there is no need to upgrade the memory on the
switch. If this is not the case, please contact your supplier.
PORT CONNECTIONS
The major difference between the models of the Summit switch is the port
configurations on each switch model. Summit switches use a combination of the
following types of ports:
•1000BASE-SX ports using 850nm duplex SC connectors
•1000BASE-LX ports using 1300nm duplex SC connectors
•1000BASE-SX ports using MT-RJ connectors
•Modular 1000BASE-SX and 1000BASE-LX using Gigabit Interface Connectors
(GBICs)
•10BASE-T/100BASE-TX ports using RJ-45 connectors
•100BASE-FX ports using 1300nm duplex SC connectors
•100BASE-TX/1000BASE-T ports using RJ-45 connectors
Table 1-1 describes port configurations available on the different Summit switch models.

1-4 Summit Switch Hardware Installation Guide
SUMMIT SWITCH OVERVIEW
The Summit7i switch can be purchased with either 28 1000BASE-SX ports or 28
100BASE-TX/1000BASE-T ports.
MEDIA TYPES AND DISTANCES
Table 1-2 describes the media types and distances for the different types of Summit
switch ports.
Table 1-1: Summit Switch Port Configurations
Ethernet Ports
Switch
Model
1000BASE
-SX
1000BASE
-LX 100/1000
BASE-T GBIC Redun- dant GBIC
10BASE-T/
100BASE-
TX 100BASE-
FX
Summit1 6 2
Summit1
/LX 6 2
Summit4 6 16
Summit4
/FX 616
Summit24 1 1 24
Summit48 2 2 48
Summit7i
(SX) 28 4
Summit7i
(TX) 28 4
Table 1-2: Media Types and Distances
Standard Media Type Mhz/Km
Rating Maximum Distance
1000BASE-SX 50/125 µm Multimode Fiber
50/125 µm Multimode Fiber
62.5/125 µm Multimode Fiber
62.5/125 µm Multimode Fiber
400
500
160
200
500 Meters
550 Meters
220 Meters
275 Meters

Summit Switch Hardware Installation Guide 1-5
MEMORY REQUIREMENTS
*Extreme Networks proprietary. Connections between two Extreme Networks 1000BASE-LX interfaces can
use a maximum distance of 10,000 Meters. However, it interoperates with standard 1000BASE-LX ports and supports a
maximum distance of 5,000 Meters.
Table 1-3 describes the specifications for the 1000BASE-LX70 interface.
*The transmitter output power level for the 1000BASE-LX70 is +5dBm. The maximum allowable receiver input power level is
-3dBm. Therefore, there is a minimum of 8dB loss required for the link to operate without errors. This minimum required loss
can be achieved using a fiber length of 32km (0.25dB/km provides 8dB loss), or by adding 10dB of fixed optical attenuator at
the receiver end.
1000BASE-LX 50/125 µm Multimode Fiber
50/125 µm Multimode Fiber
62.5/125 µm Multimode Fiber
10u Single-mode Fiber
10u Single-mode Fiber*
400
500
500
550 Meters
550 Meters
550 Meters
5,000 Meters
10,000 Meters
1000BASE-LX70 10u Single-mode Fiber 70,000 Meters
100BASE-FX 50/125 µm Multimode Fiber
(full-duplex operation)
62.5/125 µm Multimode Fiber
(full-duplex operation)
2000 Meters
2000 Meters
1000BASE-T
100BASE-TX
10BASE-T
Category 5 and higher UTP Cable
Category 5 and higher UTP Cable
Category 3 and higher UTP Cable
100 Meters
100 Meters
100 Meters
Table 1-3: 1000BASE-LX70 Specifications
Parameter Minimum Typical Maximum
Transceiver
Optical Output Power 0dBm 3dBm 5dBm*
Center Wavelength 1540nm 1550nm 1560nm
Receiver
Optical Input Power Sensitivity -20dBm
Optical Input Power Maximum -3dBm
Operating Wavelength 1200nm 1560nm
Table 1-2: Media Types and Distances (continued)
Standard Media Type Mhz/Km
Rating Maximum Distance

1-6 Summit Switch Hardware Installation Guide
SUMMIT SWITCH OVERVIEW
FULL-DUPLEX
The Summit switch provides full-duplex support for all ports. Full-duplex allows
frames to be transmitted and received simultaneously and, in effect, doubles the
bandwidth available on a link. All 10/100/1000 Mbps ports on the Summit switch
autonegotiate for half- or full-duplex operation. Gigabit Ethernet and 100BASE-FX ports
operate in full-duplex mode, only.
