Ruijie Networks RG-S6200 Series User manual

Installation Manual
RG-S6200 Series Switch

Copyright Statement
Ruijie Networks Co., Ltd. ©2000-2011
All rights reserved.
Without our written permission, this document may not be excerpted, reproduced, transmitted, or otherwise in all or
in part by any party in any means.
, , , , ,
, , , , ,
,are all registe red trademarks of Ruijie Networks Co., Ltd. and are
protected by law.
Disclaimer
The information contained in this manual may be modified without notification. Ruijie Networks has tried its best to
maintain the accuracy and reliability of this manual on the website. Ruijie Networks takes no responsibility for the
miss, inaccuracy or error and the resulting damage and loss incurred by this manual.

Preface
Thank you for using our switches. This guide (V1.02) provides you with detailed operation guide that allows you
to easily install and use the switches.
Scope
This manual describes the functions and physical features of the switches, and presents the installation procedure,
troubleshooting procedure, technical specifications, and specifications and usages rules of cables and connectors.
It is intended for the users that have some experience in installing and maintaining network hardware and want to
learn the above information. At the same time, it is assumed that the users of this switch are already familiar with
the related terms and concepts of Ethernet.
Document Structure
Chapter 1 "Product Overview" describes the main characteristics, technical specifications, and related
modules of this product.
Chapter 2 "Preparation before Installation" lists the safety, power supply, and site requirements that must
be met before the switch can be installed.
Chapter 3 “Product Installation” describes how to install the integrated switch and modules, and connect its
power cables and grounding lines.
Chapter 4 "System Debugging" describes the debugging after the switch is powered on for the first time.
Chapter 5 "Troubleshooting" describes possible problems, detections and solutions in the switch installation
and application.
Appendix A “Connector and Connection Media”
Appendix B “Mini-GBIC Modules”
Appendix C “SFP+ Modules”
Related Documents
Software manual of switches——covering CLI commands, software configuration guide, and version release notes.
Obtaining Documentation
You can obtain the documentation you need through the following channels:
Internet:
You can obtain the latest on-line documentation of Ruijie Networks at:
http://www.ruijie.com.cn
Documentation CD-ROM:
The documentation of Ruijie Networks switches is stored in the CD-ROM package, which is provided to you together
with the product you purchase. The CD-ROM is updated frequently, and may be more current than the printed
documents.
Obtaining TechnicalAssistance
Ruijie Networks provides excellent technical support services for all our products. You can obtain the technical
assistance you need through any of the following channels:
Ruijie Networks website, from which you can obtain the latest product documentation, causes and problems
analysis of product faults, application solutions, and software upgrade. http://www.ruijie.com.cn/
Online customer services: Log in to Ruijie Networks website and click "Online Customer Services".
Between 9:00a.m. and 6:00p.m. from Monday to Friday, the Online Customer Services provide technical
support such as service-related consulting, remote debugging and troubleshooting, and software maintenance.
You do not need to download a client and can take snapshots in real time, send attachments, and rapidly copy
common handling information. By information exchange, engineers solve problems for you rapidly.

Customer service center of Ruijie Networks, which can provide all customers with needed technical assistance
for products, technologies and solutions. The customer service center provides responsive technical support for
your product installation problems, software configuration problems, and other network performance problems.
http://www.ruijie.com.cn/service.aspx
Customer services hotline: [phone]
Customer services email: [email protected]
Documentation Conventions
The symbols used in this document are described as below:
This symbol draws the attention of readers to some suggestions and references.
This symbol reminds readers to be alert of wrong operations that may lead to loss of data or damage to equipment.

Chapter 1 Product Overview
1.1 Product Overview
The RG-S6200 series switches are the next generation high-density full 10G layer3 IPv6 switches introduced by
Ruijie Networks. They are mainly applicable to the data center and positioned at the EoR (End of Row), as well as at
the ToR (Top of Rack) to provide the convergence access for the servers with 10G interfaces and intranet.
Table 1-1 RG-S6200-48XS series
Model 10/100/1000Base-T
adaptive Ethernet
port
10G
SFP+
port
Console
port
USB2.0
port
Extension
Module
Slot
Redundant
Fan
Redundant
Power
Supply
RG-S6200-48XS 1 32 1 1 1 3+1 3+1
The extension module slot supports 16-port SFP+ extension module.Table 1-2 shows functions of the extension
modules.
Table 1-2 Supported Extension Modules
Module Description External port
M6200-16XS 16-port 10G port’s
extension module 16 SFP+ ports
For the details of supported modules, refer to M6200-16XS Modules.
1.2 Main Technical Specifications of RG-S6200-48XS
Table 1-3 Technical specifications of the S6200-48XS series

Model RG-S6200-48XS
Module type Ethernet 1000M: Mini-GBIC-SX
Mini-GBIC-LX
Mini-GBIC-LH40
Mini-GBIC-ZX50
Mini-GBIC-ZX80
Mini-GBIC-ZX100
1000Base-T：Mini-GBIC-GT
Ethernet 10G: XG-SFP-SR-MM850
XG-SFP-LR-SM1310
Note: the supported module type may change at any time. For the detailed change information,
consult the Ruijie Networks.
Extended Module
Type M6200-16XS
Note: the supported module type may change at any time. For the detailed change information,
consult the Ruijie Networks.
SFP+ Port Supported
SFP Port Supported
RPS type 1+1 redundant power supply
Power supply AC input:
Rated pressure range: 100-240V~
Maximum pressure range: 90-264V~
Maximum DC power supply: 280V
Frequency: 50-60Hz
Rated current: 10 A
Power
consumption
350W (with 16XS module added)
Temperature Working temperature: 0ºC to 50ºC
Storage temperature: -40ºC to 70ºC
Humidity Working humidity: 10% to 90% RH
Storage humidity: 5% to 90% RH
Fan Support adjustment of fan speed and warning of fan trouble.
Support the 3+1 redundant fan.
Temperature
Warning Temperature warning function
EMI GB9254-1998 CLASS A
Security
compliance
GB4943-2001
Dimensions (w x d
x h)
440 x 690 x 44 mm

Weight 13.5Kg
1.3 RG-S6200-48XS Series Switches
1.3.1 Product Appearance
The front panel of the RG-S6200 switch provides thirty two 32 10G ports, one console port, one 10/100/1000Base-T
Ethernet port, and one USB2.0 port. The backpanel provides two power slots and four dual fan slots. Figure1-1
shows the appearance of the M6200-16XS extension module.
Figure 1-1 Appearance of the RG-S6200
1.3.1.1 Ports on the Front Panel
Figure 1-2 Schematic diagram of the RG-6200 front panel
1. Switch status indicator
2. PWR1 status indicator

3. PWR2 2 status indicator
4. MGMT management interface indicator
5. Fan indicator
6. USB2.0 port
7. 10/100/1000Base-T MGMT Ethernet port
8. Console port
9. 10G SFP+ port
10. Port status indicator
11. Extension slot
1.3.1.2 Ports on the Backpanel
The backpanel of the RG-S6200 switch provides the slots for the power supply modules and fan modules. The
RG-S6200 supports two dissipation schemes: front-to-back air passage (-F) and back-to-front air passage (-R).
Therefore, the backpanel is marked with two formats: M6200-FAN-F and M6200-FAN-R. That is, for the –F: the air
flows in from one-side of the front panel port and out from the backpanel; while for the –R: the air flows in from the
backpanel and out from one-side of the front panel port.
Figure 1-3 Schematic diagram of RG-S6200 backpanel with M6200-FAN-F(R) +RG-M6200-AC650I-F(R)
1. Power supply module1 slot (take the RG-M6200-AC650I-F(R) fan module for the example)
2. Fan module slot (take the M6200-FAN-F(R) fan module for the example)
3. Fan module slot (take the M6200-FAN-F(R) fan module for the example)
4. Fan module slot (take the M6200-FAN-F(R) fan module for the example)
5. Fan module slot (take the M6200-FAN-F(R) fan module for the example)
6. Power supply module2 slot (take the RG-M6200-AC650I-F(R) fan module for the example)
7. Grounding pole
8. Power supply module1 RG-M6200-AC650I-F(R) status indicator
9. Fan module M6200-FAN-F(R) status indicator
10. Fan module M6200-FAN-F(R) status indicator
11. Fan module M6200-FAN-F(R) status indicator
12. Fan module M6200-FAN-F(R) status indicator
1.3.1.3 Power Supply System
Power supply requirements:
AC input.
Rated pressure range: 100-240V~
Maximum pressure range: 90-264~
Frequency: 50-60Hz

Maximum DC input: 280V
Rated current: 10A
10A power supply cables
The RG—S6200 supports two power supply modules: RG-M6200-AC650I-F(R), which supports the hot-plugging.
Dual power supply input: the switch can use either one power supply or two power supplies. When both two power
supplies are working normally, the switch is in current balancing mode.
The power supply module of the RG-S6200 series switch has two modes of air direction: -F and –R. The two modes
of power supply can not be mixed. It is strongly recommended that user pay attention to the power supply selection
during installation.
1.3.1.4 Heat Dissipation System
The RG-S6200 supports two heat dissipation schemes: -F and –R. The –F mode combines the front-to-back air
passage with power backward heat dissipation, thereby ensuring the device to function normally in the specified
environment. Sufficient space (20cm distance from both sides and the backplane of the cabinet) should be reserved
to allow air circulation. Figure 1-5 shows the flow scheme of heat dissipation.
Figure 1-5 Flow scheme of –F heat dissipation
The –R mode combines the back-to-front air passage with power forward heat dissipation, thereby ensuring the
device to function normally in the specified environment. Sufficient space (20cm distance from both sides and the
backplane of the cabinet) should be reserved to allow air circulation. Figure 1-6 shows the flow scheme of heat
dissipation.

Figure 1-6 Flow scheme of –R heat dissipation
1.4 Indicators on RG-S6200 Series Switches
Table 1-4 Indicators for the RG-S6200
Indicator Definition Status Meaning
Off The system has no power supply.
Blinking green The switch is being initialized with 3HZ blinking
frequency.
Solid green The system is working normally.
Solid yellow It indicates:
A. The temperature (at the air intake and outlet)
exceeds the normal operating temperature
of the system.
B. The inconsistency of power supply/fan type
occurs. (The inconsistency means the “-F”
and “-R” coexist in the system. Note that the
“-F” and “-R” include both the power supply
and fan.)
Status indicator Indicates the system
status.
Solid red It indicates:
A. Any system fault.
B. The temperature of any local in the internal
system exceeds the maximum temperature
allowed by a component.
PWR1 Indicates the power
module status.
Off It indicates:
A. The power supply is not in position.
B. The power supply is in position but not

Indicator Definition Status Meaning
connected to the AC terminal.
Solid green The power supply is working normally.
Solid yellow It indicates:
A. The working environment temperature of the
power supply exceeds the normal
temperature range.
B. The power supply is not matched correctly.
Solid red Power supply fault (any fault).
Off It indicates:
A. The power supply is not in position.
B. The power supply is in position but not
connected to the AC terminal.
Solid green The power supply is working normally.
Solid yellow It indicates:
A. The working environment temperature of the
power supply exceeds the normal
temperature range.
B. The power supply is not matched correctly.
PWR2
Indicates the power
module status.
Solid red Power supply fault (any fault).
Solid green Gigabit Link.
Blinking green Gigabit ACT.
Solid yellow 10/100M Link
MGMT
Indicates the external
management port
Blinking yellow 10/100M ACT
Solid green The fans are in position and are working
normally.
Solid yellow It indicates:
A. One fan is not in position or in the
powered-off status.
FAN
Indicates the fan
status. Solid red It indicates:
A. Any fan in the system is faulty.
B. Two or more than two fans are not in
position or in the powered-off status.
C. The fan type is configured incorrectly
Solid green It indicates:
A. Port link is up.
B. Data is transmitted on the port.
Link/ACT indicator
Indicates the port
status.
Off Port link is not up.
1.5 Module Types Supported by the RG-S6200Series Switches
The RG-S6200 series switch supports the following modules:
1. M6200-16XS extension module, which is used to support the extension for the RG-6200 series switch.

2. M6200_AC650I-F/R power supply module, which is used to provide the 1+1 redundancy.
3. M6200-FAN-F/R fan module, which is used to provide the 3+1 redundancy.
1.5.1 M6200-16XS Extension Modules
1.5.1.1 Product Name
M6200-16XS: 16 10G port extension module.
Figure1-7 M6200-16XS extension module
1. Port status indicator
2. 10G SFP+ port
1.5.1.2 Features
M6200-16XS comes with the 16-port 10G SFP+ fiber port; the fiber port supports 10GBase-X mode. A variety of
optical transceiver modules of Ruijie Networks are available for different transmission distances.
Features are shown as below:
Extensible SFP+ extension module
Multiple extensible SFP optical modules
IEEE 802.3, SFF-8431/8432 and SFP MSA-compliant
1.5.1.3 Applicable Models
M6200-16XS is applicable for RG-S6200 series and other subsequential switches supporting this module,
including:
RG-S6200-48XS
1.5.1.4 Indicator Description
M6200-16XS comes with 16 SFP+ port indicators, which are defined as below:

1F~16F (green): SFP+ port’s Link/ACT indicator. On means the SFP+ port is linked up or data is transmitted on
the port; off means the port link is not up.
1.5.1.5 Optical Module Types and Transmission Distances Supported
M6200-16XS provides the 16-port 10G SFP+ fiber port and support the SFP, SFP+ optical modules and
Mini-GBIC-GTmodules. For details, refer to theAppendix B andAppendix C.
1.5.2 RG-M6200-AC650I-F(R) Power Supply Modules
1.5.2.1 Product Name
RG-M6200-AC650I-F(R):
Figure1-8 RG-M6200-AC650I-F(R) power supply module
1. Power supply status indicator
2. Power plug
1.5.2.2 Features
RG-M6200-AC650I-F(R) provides the power supply with rated voltage of 12V for the RG-S6200 series switch.
Features are shown as below:
Support the 1+1 redundancy.
Support the power supply alarm function.
Support the identification of the power supply type and model.
Support the hot-plugging of the power supply module.
Support the real-time monitoring of the system consumption.
1.5.2.3 Applicable Models
RG-M6200-AC650I-F(R) is applicable for RG-S6200 series and other subsequential switches supporting this
module, including:
RG-S6200-48XS

1.5.2.4 Indicator Description
RG-M6200-AC650I-F(R) comes with a power supply status indicator, which is defined as below:
Off: No AC input.
Blinking green: Having AC input and no DC output.
Solid green: Normal DC input.
Blinking yellow: Failed DC input.
Solid yellow: Failed fan.
1.5.3 M6200-FAN-F(R) Fan Modules
1.5.3.1 Product Name
M6200-FAN-F(R):
Figure1-10 M6200-FAN-F(R) extension module
1. Fan status indicator
1.5.3.2 Features
M6200-FAN-F(R) provides the heat dissipation schemes of the front and back air passages (back and front air
passages) to enable the intelligent dissipation for the RG-S6200 series switch.
Features are shown as below:
Automatically adjust the rotation speed of the fan according to the temperature.
Support the fan alarm function.
Support the hot-plugging of the fan tray.
Support the fan type identification.
1.5.3.3 Applicable Models
M6200-FAN-F(R) is applicable for RG-S6200 series and other subsequential switches supporting this module,
including:

RG-S6200-48XS
1.5.3.4 Indicator Description
M6200-FAN-F(R) comes with a fan status indicator, which is defined as below:
Automatically adjust the rotation speed of the fan according to the temperature.
Solid green: The fan works normally.
Solid yellow: The module type conflicts with the other fan module types of the system.
Solid red: Fan is faulty.

Chapter 2 Preparation before Installation
2.1 Safety Suggestions
To avoid personal injury and equipment damage, please carefully read the safety suggestions before you install the
RG-S6200 series.
The following safety suggestions do not cover all possible dangers.
2.1.1 Safety Precautions for Installing the System
Keep the chassis clean and free from any dust.
Do not place the equipment in a walking area.
Do not wear loose clothes or any other things that may be caught by the chassis during installation and
maintenance.
Turn off all power supplies and remove the power sockets and cables before dismantling the cabinet.
2.1.2 Movement Safety
Do not frequently move the device.
When moving the device, note the balance and avoid hurting legs and feet or straining the back.
Before moving the device, turn off all power supplies and dismantle all power modules.
2.1.3 Electric Safety
Observe local regulations and specifications when performing electric operations. Relevant operators must be
qualified.
Carefully check any potential danger in the working area, such as ungrounded power supply, unreliable
grounding of the power supply, and damp/wet ground or floor.
Find out the location of the emergency power supply switch in the room before installation. First cut off the
power supply in the case of an accident.
Try to avoid maintaining the switch that is powered-on alone.
Be sure to make a careful check before you shut down the power supply.
Do not place the equipment in a damp location. Do not let any liquid enter the chassis.
1. Any nonstandard and inaccurate electric operation may cause an accident such as fire or electrical shock,
thus causing severe even fatal damages to human bodies and equipment.

2.Direct or indirect touch through a wet object on high-voltage and mains supply may bring a fatal danger.
2.1.4 Static Discharge Damage Prevention
To prevent damage from static electricity, pay attention to the following:
1. Proper grounding of the equipment and floor
2. Indoor dust prevention
3. Proper humidity conditions
2.1.5 Laser Safety
Among the modules supported by the RG-S6200 series, a great number of optical modules are Class I laser
products. Therefore, pay attention to the following when you use them:
When a fiber transceiver works, ensure that the port has been connected with an optical fiber or is covered
with a dust cap, to keep out dust and avoid burning your eyes.
Do not stare into any optical port.
Do not stare into any optical port under any circumstances, as this may cause permanent damage to your eyes.
2.2 Installation Site Requirements
The RG-S6200 series must be used indoors. To ensure the normal working and a prolonged durable life of the
equipment, the installation site must meet the following requirements.
2.2.1 Ventilation Requirements
For the RG-S6200 series, you must ensure that sufficient space(10cm distance from both sides and the backplane
of the cabinet) is reserved at the ventilation openings to ensure the normal ventilation. After various cables have
been connected, they should be arranged into bundles or placed on the cabling rack to avoid blocking the air inlets.
2.2.2 Temperature and Humidity Requirements
To ensure the normal operation and prolong the service life of RG-S6200 series, you should keep proper
temperature and humidity in the equipment room.
If the equipment room has temperature and humidity that do not meet the requirements for a long time, the
equipment may be damaged.
In an environment with high relative humidity, the insulating material may have bad insulation or even leak
electricity. Sometimes the materials may suffer from mechanical performance change and metallic parts may
get rusted.
In an environment with low relative humidity, however, the insulating strip may dry and shrink. Static electricity
may occur easily and endanger the circuit on the equipment.
In an environment with high temperature, the equipment is subject to even greater harm, as its performance
may degrade significantly and its useful life may be shortened in the case of long-term exposure that
expedites the aging process.
Therefore, the ambient temperature and humidity of the RG-S6200 must meet the requirements listed in Table 2-1:
Table 2-1 Temperature and humidity requirements of the RG-S6200 series

Temperature Relative Humidity
0ºC-50ºC 10%-90%
The ambient temperature and humidity are measured at the point that is 1.5 m above the floor and 0.4 m before the
equipment when there is no protective plate in front or back of the equipment rack.
2.2.3 Cleanness Requirements
Dust poses a severe threat to the running of the equipment. The indoor dust falling on the equipment may be
adhered by the static electricity, causing bad contact of the metallic joint. Such electrostatic adherence may occur
more easily when the relative humidity is low, not only affecting the useful life of the equipment, but also causing
communication faults. Table 2-2 shows the requirements for the dust content and granularity in the equipment room.
Table 2-2 Requirements for the dust content and granularity in the equipment room
Maximum diameter (μm) 0.5 1 3 5
Maximum density (Particles/m3) 1.4 x 10 7 x 10 2.4 x 10 1.3 x 10
Apart from dust, the salt, acid and sulfide in the air in the equipment room must also meet strict requirements, as
such poisonous substances may accelerate the corrosion of the metal and the aging of some parts. The equipment
room should be protected from the intrusion of harmful gases such as sulfur dioxide, sulfured hydrogen, nitrogen
dioxide, and chlorine), whose requirements are listed in Table 2-3.
Table 2-3 Requirements for harmful gases in the equipment room
Gas Average (mg/m3) Maximum (mg/m3)
Sulfur dioxide 0.2 1.5
Sulfured hydrogen 0.006 0.03
Nitrogen dioxide 0.04 0.15
Ammonia 0.05 0.15
Chlorine 0.01 0.3
2.2.4 EMI
During applications, the switch may be subject to external interferences that affect the device through conduction
manners such as capacitance coupling, inductive coupling, electromagnetic wave emission, common impedance
(including grounding systems), and wires (power cables, signal cables and outgoing transmission cables). For that
purpose, note that:
For the AC power supply system TN, single-phase three-core power socket with protective earthing
conductors (PE) should be adopted to effectively filter out interference from the power grid through the
filtering circuit.
The switch should be located at places free from large power radio launch pad, radar launch pad, and
high-frequency large-current devices.
If necessary, electromagnetic shielding should be adopted. For example, use interface cables to shield
cables.

Interface cables should be laid inside the equipment room. Outdoor cabling is prohibited, avoiding damages
to device signal interfaces caused by over-voltage or over-current of lightning.
2.3 System Grounding Requirements
A good grounding system is the basis for the stable and reliable operation of the RG-S6200 series. It is the chief
condition to prevent lightning stroke and resist interference. Please carefully check the grounding conditions on the
installation site according to the grounding requirements, and perform grounding operations properly as required.
The correct connection of grounding lines guarantees the lighting and interference resistance of switches and must
be performed with precision.
2.3.1 Safety Grounding
The equipment using AC power supply must be grounded by using the yellow/green safety grounding cable.
Otherwise, when the insulating resistance decreases the power supply and the enclosure in the equipment, electric
shock may occur.
2.3.2 Lightning Grounding
The lightning protection system of a facility is an independent system that consists of the lightning rod, downlead
conductor and the connector to the grounding system, which usually shares the power reference ground and
yellow/green safety cable ground. The lightning discharge ground is for the facility only, irrelevant to the equipment.
2.3.3 EMC Grounding
The grounding required for EMC design includes shielding ground, filter ground, noise and interference suppression,
and level reference. All the above constitute the comprehensive grounding requirements.The grounding resistance
should be less than 1 ohm. The RG-S6200 backplane is reserved with one grounding pole, as shown in 0.
Figure 2-1 Schematic diagram of the RG-S6200 grounding
2.4 Lightning Resistance Considerations
When the AC power cable is imported outdoors and directly connected to the power port of the switch, lightning line
bank should be adopted to prevent the switch from being hit by lightning shocks. The lightning line bank can be fixed

on the the cabinet, work station, or the equipment room's wall through line buckles and screws. In applications, the
AC first enters the lightning line bank and then the switch.
1The lightning line banks are not provided and should be purchased by users as required.
2For the usage of lightning line banks, refer to their related manuals.
2.5 EMI Consideration
Various interference sources, from either outside or inside the equipment or application system, affect the system in
the conductive ways such as capacitive coupling, inductive coupling, and electromagnetic radiation.
There are two types of electromagnetic interferences: radiated interference and conducted interference, depending
on the type of the transmission path.
When the energy, often RF energy, from a component arrives at a sensitive component via the space, the energy is
known as radiated interference. The interference source can be either a part of the interfered system or a completely
electrically isolated unit. Conducted interference results from the electromagnetic wire or signal cable connection
between the source and the sensitive component, along which cable the interference conducts from one unit to
another. Conducted interference often affects the power supply of the equipment, but can be controlled by a filter.
Radiated interference may affect any signal path in the equipment and is difficult to shield.
1. Effective measures should be taken for the power system to prevent the interference from the electric grid.
2. The working ground of the switch should be preferably separated and kept as far as possible from the grounding
device of the power equipment or the anti-lightning grounding device.
3. Keep the equipment away from high-power radio transmitter, radar transmitting station, and high-frequency
large-current device.
4. Measures must be taken to shield static electricity.
2.6 Precaution for Fiber Connections
Before you connect the fibers, check that the optical connector type and fiber type match the optical interface type
used. In addition, pay attention to the Tx and Rx directions of the fiber. The Tx end of this equipment should be
connected to the Rx end of the peer equipment, and the Rx end of this equipment to the Tx end of the peer
equipment.
2.7 Installation Tool Requirements
Table 2-4 List of installation tools
Common tools
Cross screwdriver, straight screwdriver, related electric and
optical cables
Bolts, diagonal pliers, straps
Special-purpose
tools Anti-static tool (anti-static glove)
Meter Multimeter
