Dell EMC PowerSwitch N3200-ON Series User manual

Dell EMC PowerSwitch N3200-ON Series
Installation Guide
August 2020
Rev. A02

Notes, cautions, and warnings
NOTE: A NOTE indicates important information that helps you make better use of your product.
CAUTION: A CAUTION indicates either potential damage to hardware or loss of data and tells you how to avoid
the problem.
WARNING: A WARNING indicates a potential for property damage, personal injury, or death.
© 2020 Dell Inc. or its subsidiaries. All rights reserved. Dell, EMC, and other trademarks are trademarks of Dell Inc. or its subsidiaries. Other
trademarks may be trademarks of their respective owners.

Chapter 1: About this guide........................................................................................................... 6
Related documents..............................................................................................................................................................7
Information symbols............................................................................................................................................................ 7
Chapter 2: N3200-ON Series switch..............................................................................................8
Introduction...........................................................................................................................................................................8
Features................................................................................................................................................................................13
Physical dimensions........................................................................................................................................................... 14
LED display.......................................................................................................................................................................... 14
LED behavior................................................................................................................................................................. 14
Prerequisites........................................................................................................................................................................18
N3200-ON Series switch configurations..................................................................................................................... 18
Luggage tag.........................................................................................................................................................................19
Chapter 3: Site preparations........................................................................................................ 21
Site selection.......................................................................................................................................................................21
Cabinet placement............................................................................................................................................................. 21
Rack mounting................................................................................................................................................................... 22
Switch ground.................................................................................................................................................................... 22
Fans and airflow.................................................................................................................................................................22
Power................................................................................................................................................................................... 22
Storing components......................................................................................................................................................... 23
Chapter 4: N3200-ON Series switch installation..........................................................................24
Unpack................................................................................................................................................................................. 24
Unpacking Steps..........................................................................................................................................................25
Rack or cabinet hardware installation.......................................................................................................................... 25
Ground cable...................................................................................................................................................................... 25
Desktop................................................................................................................................................................................26
N3208PX-ON ceiling-mount switch installation........................................................................................................ 26
N3208PX-ON wall-mount switch installation.............................................................................................................28
DIN buckle rail installation......................................................................................................................................... 29
Standard bracket two-post installation........................................................................................................................ 31
Two-post five-inch-offset switch installation.............................................................................................................31
Two-post flush-mount switch installation...................................................................................................................32
Wall- or ceiling-mount switch installation....................................................................................................................33
One RU ReadyRails installation...................................................................................................................................... 36
1U Tool-less mount ReadyRails installation........................................................................................................... 36
Flush-mount ReadyRail installation..........................................................................................................................37
Center-mount ReadyRail installation...................................................................................................................... 38
Threaded ReadyRails installation............................................................................................................................. 39
Optics installation..............................................................................................................................................................40
Optics removal............................................................................................................................................................. 40
Switch start-up ................................................................................................................................................................. 41
Contents
Contents 3

After switch placement.................................................................................................................................................... 41
Switch replacement...........................................................................................................................................................41
Chapter 5: External power adapter.............................................................................................. 43
Power adapter holder assembly.....................................................................................................................................43
Wall or ceiling installation................................................................................................................................................ 44
DIN rail installation............................................................................................................................................................ 46
Single-EPA and switch four-post installation............................................................................................................. 47
Single-EPA and switch two-post center-mount installation...................................................................................47
Single-EPA and switch two-post front-mount installation..................................................................................... 49
Dual-EPAs two-post front-mount installation............................................................................................................50
Dual-EPAs two-post center-mount installation......................................................................................................... 52
Chapter 6: Power supply............................................................................................................. 55
Components....................................................................................................................................................................... 56
AC or DC power supply installation...............................................................................................................................57
AC or DC power supply replacement........................................................................................................................... 58
550W DC power connections........................................................................................................................................ 58
1300W DC power connections.......................................................................................................................................59
Connect the EPS shelf..................................................................................................................................................... 61
Chapter 7: Fans........................................................................................................................... 66
Components....................................................................................................................................................................... 66
Fan module installation.....................................................................................................................................................67
Fan module replacement............................................................................................................................................68
Chapter 8: Management ports..................................................................................................... 69
RJ45 console port access............................................................................................................................................... 69
MicroUSB Type-B console port access....................................................................................................................... 70
USB storage mount........................................................................................................................................................... 71
Chapter 9: Installation using ONIE...............................................................................................72
Before you install an operating system........................................................................................................................ 72
Check your switch.............................................................................................................................................................73
Uninstall an existing OS................................................................................................................................................... 73
Install a NOS....................................................................................................................................................................... 74
Automatic NOS installation....................................................................................................................................... 74
Manual NOS installation.............................................................................................................................................75
Chapter 10: Specifications........................................................................................................... 77
Chassis physical design.................................................................................................................................................... 77
IEEE standards....................................................................................................................................................................81
Agency compliance............................................................................................................................................................ 81
USA Federal Communications Commission statement....................................................................................... 81
European Union EMC directive conformance statement.................................................................................. 82
Japan VCCI compliance for class A equipment....................................................................................................82
Korean certification of compliance......................................................................................................................... 83
Safety standards and compliance agency certifications......................................................................................... 83
Electromagnetic compatibility .......................................................................................................................................84
4Contents

Product recycling and disposal...................................................................................................................................... 84
Chapter 11: Dell EMC support...................................................................................................... 86
Contents 5

About this guide
This guide provides site preparation recommendations, step-by-step procedures for rack mounting and desk mounting your
switch, inserting modules, and connecting to a power source.
CAUTION: To avoid electrostatic discharge (ESD) damage, wear grounding wrist straps when handling this
equipment.
NOTE: Only trained and qualified personnel can install this equipment. Read this guide before you install and power on this
equipment. This equipment contains two power cables. Disconnect both power cables before servicing.
NOTE: This equipment contains optical transceivers, which comply with the limits of Class 1 laser radiation.
Figure 1. Class 1 laser product tag
NOTE: When no cable is connected, visible and invisible laser radiation may emit from the aperture of the optical
transceiver ports. Avoid exposure to laser radiation. Do not stare into open apertures.
NOTE: Read this guide before unpacking the switch. For unpacking instructions, see Unpack.
Visual display workplaces
This device is not intended for use in the direct field of view at visual display workplaces. To avoid incommoding reflexions at
visual display workplaces this device must not be placed in the direct field of view.
Bemerkung: Dieses Gerät ist nicht für den Einsatz im direkten Sichtfeld am Bildschirmarbeitsplatz vorgesehen. Um störende
Reflexionen am Bildschirmarbeitsplatz zu vermeiden, darf dieses Gerät nicht im direkten Sichtfeld platziert werden.
Regulatory
●Marketing model N3208PX-ON is represented by the regulatory model E30W and the regulatory type E30W001.
●Marketing model N3224T-ON is represented by the regulatory model E31W and the regulatory type E31W002.
●Marketing model N3224F-ON is represented by the regulatory model E31W and the regulatory type E31W003.
●Marketing model N3224P-ON is represented by the regulatory model E32W and the regulatory type E32W002.
●Marketing model N3224PX-ON is represented by the regulatory model E32W and the regulatory type E32W001.
●Marketing model N3248TE-ON is represented by the regulatory model E31W and the regulatory type E31W005.
●Marketing model N3248P-ON is represented by the regulatory model E32W and the regulatory type E32W003.
●Marketing model N3248X-ON is represented by the regulatory model E31W and the regulatory type E31W004.
●Marketing model N3248PXE-ON is represented by the regulatory model E32W and the regulatory type E32W004.
Topics:
•Related documents
•Information symbols
1
6 About this guide

Related documents
For more information about the N3200-ON Series, see the following documents:
●Dell EMC PowerSwitch N3200-ON Series Warnings Guide
●Dell EMC PowerSwitch N3200-ON Series Setup Placemat
●Dell EMC PowerSwitch N3200-ON Series Release Notes
●Open Networking Hardware Diagnostic Guide N2200-ON and N3200-ON Series Switches
●External Power Supply (EPS) Installation for the Dell EMC PowerSwitch N2200-ON and N3200-ON Series Switches
NOTE: For the most recent documentation, see Dell EMC support: www.dell.com/support.
Information symbols
This book uses the following information symbols:
NOTE: The Note icon signals important operational information.
CAUTION: The Caution icon signals information about situations that could result in equipment damage or loss
of data.
NOTE: The Warning icon signals information about hardware handling that could result in injury.
NOTE: The ESD Warning icon requires that you take electrostatic precautions when handling the device.
About this guide 7

N3200-ON Series switch
The following sections describe the Dell EMC N3200-ON Series (N3208PX-ON, N3224T-ON, N322F-ON, N3224P-ON,
N3224PX-ON, N3248TE-ON, N3248P-ON, N3248X-ON, and N3248PXE-ON) switches:
Topics:
•Introduction
•Features
•Physical dimensions
•LED display
•Prerequisites
•N3200-ON Series switch configurations
•Luggage tag
Introduction
The N3200-ON Series switches are compact and full width, one rack unit (RU), full-featured fixed form-factor switches.
Table 1. N3200-ON Series switch summary
Marketing model name (MMN) Description Power supply unit (PSU) and fans
N3208PX-ON ●4 ports 1G BASE-T RJ45 with
802.3bt Type-4 (90W) PoE
●4 ports 5G BASE-T RJ45 multigigabit
ports with 802.3bt Type-4 (90W)
PoE
●2 ports 10G SFP+
●1 fixed AC PSU
●(optional) Up to 2 external power
adapters
●1 fixed fan
N3224T-ON ●24 ports 1G BASE-T RJ45
●4 ports 10G SFP+
●2 ports 100G QSFP28 stacking
●2 pluggable AC PSUs—1 default and
1 optional or 2 optional DC PSUs
●3 pluggable fan modules
●Normal and reverse airflow options
N3224F-ON ●24 ports 1G SFP
●4 ports 10G SFP+
●2 ports 100G QSFP28 stacking
●2 pluggable AC PSUs—1 default and
1 optional or 2 optional DC PSUs
●3 pluggable fan modules
●Normal airflow only
N3224P-ON ●24 ports 1G BASE-T RJ45 ports with
802.3at (30W) PoE
●4 ports 10G SFP+
●2 ports 100G QSFP28 stacking
●2 pluggable AC PSUs—1 default and
1 optional or 2 optional DC PSUs
●3 pluggable fan modules
●Normal airflow only
N3224PX-ON ●24 ports 10M/100M/1G/
2.5G/5G/10G BASE-T RJ45
multigigabit ports with 802.3bt
Type-4 (90W) PoE
●4 ports 25G SFP28
●2 ports 100G QSFP28 stacking
●2 pluggable AC PSUs—1 default and
1 optional or 2 optional DC PSUs
●1 EPS (optional and conected from
MPS-1S or MPS-3S power shelf)
●3 pluggable fan modules
●Normal airflow only
N3248TE-ON ●48 ports 1G BASE-T RJ45
●4 ports 10G SFP28
●2 pluggable AC PSUs—1 default and
1 optional or 2 optional DC PSUs
2
8 N3200-ON Series switch

Table 1. N3200-ON Series switch summary (continued)
Marketing model name (MMN) Description Power supply unit (PSU) and fans
●2 ports 100G QSFP28 stacking ●3 pluggable fan modules
●Normal and reverse airflow options
N3248P-ON ●48 ports 1G BASE-T RJ45
multigigabit ports with 802.3at
(30W) PoE
●4 ports 10G SFP+
●2 ports 100G QSFP28 stacking
●2 pluggable AC PSUs—1 default and
1 optional or 2 optional DC PSUs
●1 EPS (optional and conected from
MPS-1S or MPS-3S power shelf)
●3 pluggable fan modules
●Normal airflow only
N3248X-ON ●48 ports 10M/100M/1G/
2.5G/5G/10G BASE-T RJ45
●4 ports 25G SFP28
●2 ports 100G QSFP28 stacking
●2 pluggable AC PSUs—1 default and
1 optional or 2 optional DC PSUs
●3 pluggable fan modules
●Normal and reverse airflow options
N3248PXE-ON ●48 ports 10M/100M/1G/
2.5G/5G/10G BASE-T RJ45 with
802.3bt Type-4 (90W) PoE
●4 ports 25G SFP28
●2 ports 100G QSFP28 stacking
●2 pluggable AC PSUs—1 default and
1 optional or 2 optional DC PSUs
●1 EPS (optional and conected from
MPS-1S or MPS-3S power shelf)
●3 pluggable fan modules
●Normal airflow only
N3208PX I/O-side view
1. Luggage tag 2. 1GBASE-T RJ45 wtih 802.3bt Type-4 (90W) PoE
3. 5GBASE-T RJ45 with 802.3bt Type-4 (90W) PoE 4. RJ45 serial management port
5. RJ45 Ethernet console port 6. USB Type-A port
7. MicroUSB Type-B port 8. Status LEDs
9. 10G SFP+ ports
N3224T-ON I/O-side view
N3200-ON Series switch 9

1. Luggage tag 2. 1GBASE-T RJ45
3. RJ45 serial management port 4. RJ45 Ethernet console port
5. USB Type-A port 6. Stack ID
7. MicroUSB Type-B port 8. Status LEDs
9. 10G SFP+ ports
N3224F-ON I/O-side view
1. Luggage tag 2. 1G SFP
3. RJ45 serial management port 4. RJ45 Ethernet console port
5. USB Type-A port 6. Stack ID
7. MicroUSB Type-B port 8. Status LEDs
9. 10G SFP+ ports
N3224P-ON I/O-side view
1. Luggage tag 2. 1GBASE-T RJ45 with 802.3at Type-2 (30W) PoE
3. RJ45 serial management port 4. RJ45 Ethernet console port
5. USB Type-A port 6. Stack ID
7. MicroUSB Type-B port 8. Status LEDs
9. 10G SFP+ ports
N3224PX-ON I/O-side view
10 N3200-ON Series switch

1. Luggage tag 2. 10GBASE-T RJ45 with 802.3bt Type-4 (90W) PoE
3. RJ45 serial management port 4. RJ45 Ethernet console port
5. USB Type-A port 6. Stack ID
7. MicroUSB Type-B port 8. Status LEDs
9. 10G SFP28 ports
N3248TE-ON I/O-side view
1. Luggage tag 2. 1GBASE-T RJ45
3. RJ45 serial management port 4. RJ45 Ethernet console port
5. USB Type-A port 6. Stack ID
7. MicroUSB Type-B port 8. Status LEDs
9. 10G SFP28 ports
N3248P-ON I/O-side view
1. Luggage tag 2. 1GBASE-T RJ45 with 802.3at Type-2 (30W) PoE
3. RJ45 serial management port 4. RJ45 Ethernet console port
5. USB Type-A port 6. Stack ID
7. MicroUSB Type-B port 8. Status LEDs
9. 10G SFP+ ports
N3200-ON Series switch 11

N3248X-ON I/O-side view
1. Luggage tag 2. 10GBASE-T RJ45
3. RJ45 serial management port 4. RJ45 Ethernet console port
5. USB Type-A port 6. Stack ID
7. MicroUSB Type-B port 8. Status LEDs
9. 10G SFP28 ports
N3248PXE-ON I/O-side view
1. Luggage tag 2. 10GBASE-T RJ45 with 802.3bt Type-4 (90W) PoE
3. RJ45 serial management port 4. RJ45 Ethernet console port
5. USB Type-A port 6. Stack ID
7. MicroUSB Type-B port 8. Status LEDs
9. 10G SFP28 ports
N3200-ON Series PSU-side views:
N3208PX-ON PSU-side view
1. Fan
2. External power adapter connection
3. AC power connection
N3224F-ON, N3224P-ON, N3224T-ON, N3248TE-ON, and N3248X-ON PSU-side view
12 N3200-ON Series switch

1. 100G QSFP28 stacking ports
2. Fans
3. AC or DC PSUs
N3224PX-ON, N3248P-ON, N3248PXE-ON PSU-side view
1. 100G QSFP28 stacking ports 2. Fans
3. EPS connections 4. AC or DC PSUs
Features
The N3200-ON Series switch offers the following features:
●Ports:
○N3208PX-ON—Compact, four ports 1GBASE-T RJ45 with 802.3bt Type-4 90W PoE, four ports 5GBASE-T RJ45 with
802.3bt Type-4 90W PoE, and two ports 10G SFP+
○N3224T-ON—1U, 24 ports 1GBASE-T RJ45, four ports 10G SFP+, and two ports 100G QSFP28 for stacking
○N3224F-ON—1U, 24 ports 1GBASE-T RJ45, four ports 10G SFP+, and two ports 100G QSFP28 for stacking
○N3224P-ON—1U, 24 ports 1GBASE-T RJ45 with 802.3at Type-2 30W PoE, four ports 10G SFP+, and two ports 100G
QSFP28 for stacking
○N3224PX-ON—1U, 24 ports multigigabit 10GBASE-T RJ45 with 802.3bt Type-4 90W PoE, four ports 25G SFP28, and
two ports 100G QSFP28 for stacking
○N3248TE-ON—1U, 48 ports 1GBASE-T RJ45, four ports 10G SFP+, and two ports 100G QSFP28 for stacking
○N3248P-ON—1U, 48 ports 1GBASE-T RJ45 with 802.3at Type-2 30W PoE, four ports 10G SFP+, and two ports 100G
QSFP28 for stacking
○N3248X-ON—1U, 48 ports 10GBASE-T RJ45, four ports 25G SFP28, and two ports 100G QSFP28 for stacking
○N3248PXE—1U, 48 ports multigigabit 10GBASE-T RJ45 with 802.3bt Type-4 90W PoE, four ports 25G SFP28, and two
ports 100G QSFP28 for stacking
●One MicroUSB Type-B console port
●One USB Type-A port for more file storage
●One RJ45 serial console port
●Two-core Denverton-NS CPU, 4 GB DDR4 SO-DIMM, 8 GB mSATA 2.0/M.2 SSD
●One 10/100/1000BaseT Ethernet management port
●Two pluggable AC or DC PSUs, except N3208PX-ON
●Three pluggable fan modules, except N3208PX-ON
●N3208PX-ON—One fixed AC PSU
●N3208PX-ON—One fan
N3200-ON Series switch 13

●N3208PX-ON—Up to two external power adapters
●N3224PX-ON, N3248P-ON, and N3248PXE-ON—External power supply connectors to connect the MPS-1S or MPS-3S
shelf
●N3224T-ON, N3248X-ON, and N3248TE-ON—Normal and reverse airflow options
●System ground connector
●Switch-monitoring LEDs
Physical dimensions
The N3200-ON Series switch has the following physical dimensions, excluding the PSU and fan tray handle:
●N3208PX-ON:
○43.5 mm x 279.4 mm x 312 mm (H x W x D)
○1.71 in x 11 in x 12.28 in (H x W x D)
●All N3200-ON Series switches except the N3208PX-ON:
○43.5 mm x 434 mm x 400 mm (H x W x D)
○1.71 in x 17.09 in x 15.75 in (H x W x D)
(PSU and fan tray handle adds 30 mm or 1.18 in)
LED display
The N3200-ON Series switch includes LED displays on the I/O and PSU sides of the switch. This section describes open
networking installation environment (ONIE) LED behaviors. Some LED behaviors may change after you install your software.
LED behavior
The following N3200-ON Series switch LED behavior is seen during ONIE operations:
N3208PX-ON LEDs
1. Link status LEDs 2. Console port LEDs on the left side—management port on
the right side
3. SFP+ port activity LEDs 4. Stack Master ID LED
5. System Status/Health LED 6. Power LED
7. Fan LED 8. Locator LED/System Beacon
14 N3200-ON Series switch

N3224F-ON, N3224P-ON, N3224PX-ON, N3224T-ON, N3248P-ON, N3248PXE-ON, and N3248TE-ON LEDs
1. Link status LEDs 2. Console port LEDs on the left side—management port on
the right side
3. SFP+ port activity LEDs 4. Stack ID LED
5. Stack Master LED 6. System Status/health LED
7. Power LED 8. Fan LED
9. Locator LED/System Beacon 10. Stacking port activity LEDs
Table 2. N3200-ON Series switch LED behavior
LED Description
7-Segment LED for stacking ●Off—No power
●Solid green—Hex digit representing the stack unit ID
Stack Master LED ●Off—Switch is in Stacking Slave mode
●Solid green—Switch is in Stacking Master or Standalone
mode
System Status/Health LED ●Solid green—Normal operation
●Flashing green—Booting
●Solid yellow—Critical system error; major fault
●Flashing yellow—Noncritical system error, minor fault, fan
failure, or power supply failure
N3200-ON Series switch 15

Table 2. N3200-ON Series switch LED behavior (continued)
LED Description
Power LED ●Off—No power
●Solid Green—Normal operation
●Solid yellow—POST is in process
●Flashing yellow—Power supply failed
FAN LED ●Off—No power
●Solid green—Normal operation; fan powered and running
at the expected RPM
●Flashing yellow—Fan fault—including incompatible airflow
direction when you insert the PSU, fan trays with differing
airflows, missing a fan, or fan tray not functioning properly
Locator LED/System Beacon ●Off—Locator function disabled
●Flashing blue—Locator function enabled
Table 3. 1000MBase-T and 10/100MBase-T PoE System management Ethernet port LEDs
LED Description
Link LED ●Off—No link
●Solid green—Link operating at a maximum speed,
autonegotiated/forced to 1000MBase-T mode
●Solid yellow—Link operating at a lower speed,
autonegotiated/forced or 10/100MBase-T mode
Activity LED ●Off—No activity
●Solid Yellow—No port activity and PoE power on
●Flashing green—Port activity and PoE power off
●Flashing yellow—Port activity and PoE power on
Table 4. 1000MBase-T and 10/100MBase-T non-PoE System management Ethernet port LEDs
LED Description
Link LED ●Off—No link
●Solid green—Link operating at a maximum speed,
autonegotiated/forced to 1000MBase-T mode
●Solid yellow—Link operating at a lower speed,
autonegotiated/forced or 10/100MBase-T mode
Activity LED ●Off—No activity
●Flashing green—Port activity
Table 5. 1G, 5G, 10G Base-T PoE port LEDs
LED Description
Link LED All four LEDs:
●Off—No link
●Solid green—Link operating at maximum speed,
autonegotiated/forced to 2.5GBase-T mode
●Solid yellow—Link operating at a lower speed,
autonegotiated/forced to 10/100/1000MBase-T
●Flashing green, ~30ms—Port activity
Activity LED ●Off—No activity and PoE power off
●Solid yellow—No port activity and PoE power on
16 N3200-ON Series switch

Table 5. 1G, 5G, 10G Base-T PoE port LEDs (continued)
LED Description
●Flashing green—port activity and PoE power off
●Flashing yellow—port activity and PoE power on
Table 6. 1G or 10G Base-T non-PoE port LEDs
LED Description
Link LED All four LEDs:
●Off—No link
●Solid green—Link operating at maximum speed,
autonegotiated/forced to 2.5GBase-T mode
●Solid yellow—Link operating at a lower speed,
autonegotiated/forced to 10/100/1000MBase-T
Activity LED ●Off—No activity
●Flashing green, ~30ms—Port activity
Table 7. SFP+ port LEDs
LED Description
Link LED All four LEDs:
●Off—No link
●Solid green—Link operating at maximum speed, 10G
●Solid yellow—Link operating at a speed less than 10G
●Flashing green, ~30ms—Port activity
Activity LED ●Off—No activity
●Flashing green—port activity at maximum speed
●Flashing yellow—port activity at lower speed
Table 8. SFP28 port LEDs
LED Description
Link LED All four LEDs:
●Off—No link
●Solid green—Link operating at maximum speed, 25G
●Solid yellow—Link operating at a speed less than 25G
●Flashing green, ~30ms—Port activity
Activity LED ●Off—No activity
●Flashing green—port activity at maximum speed
●Flashing yellow—port activity at lower speed
Table 9. QSFP28 port LEDs
LED Description
Link LED All four LEDs:
●Off—No link
●Solid green—Link operating at maximum speed, 100G
●Solid yellow—Link operating at a speed less than 100G
●Flashing green, ~30ms—Port activity
Activity LED ●Off—No activity
N3200-ON Series switch 17

Table 9. QSFP28 port LEDs (continued)
LED Description
●Flashing green, ~30ms—port activity at maximum speed,
100G
●Flashing yellow, ~30ms—port activity at speed less than
100G
●Flashing yellow, 1 second on/off—port beacon
Prerequisites
The following is a list of components that are required for successful switch installation:
NOTE: For detailed installation instructions, see Site preparations and N3200-ON Series switch installation.
●N3200-ON Series switch or multiple switches, if stacking
●AC or DC country- and regional-specific cables to connect the AC or DC power source to the AC or DC PSU
●Hot-swappable AC or DC power supply units; minimum one AC or DC PSU—excluding N3208PX-ON
●Hot-swappable fan modules—excluding N3208PX-ON
●All N3200-ON DC versions—excluding N3208PX-ON; order DC PSUs separately
●All N3200-ON AC platforms—no ground lug ships with the accessories
●L-bracket and screws for two-post rack mount, or rubber feet for table or shelf placement, or bracket and screws for wall or
ceiling mount—excluding N3208PX-ON
●N3208PX-ON only—Wire clip for PSU cable
●Copper and fiber cables
●N3248PXE-ON DC only—Ground lug and screws ship with the accessories
●N3248PXE-ON AC only—No-OS SKU: Ground lug and screws ship with the accessories.
●N3248P-ON DC only—Ground lug and screws ship with the accessories
●#1 and #2 Phillips screwdrivers, not included
●Torx screwdriver, not included
Other optional components are:
●Extra mounting brackets and screws
●Second AC PSU or DC PSUs—except N3208PX-ON
●MPS-1S shelf with AC or DC PSU
●MPS-3S shelf with AC or DC PSUs
●N3208PX-ON only—External power adapter
N3200-ON Series switch configurations
You can order the N3200-ON Series switch in several different configurations.
●N3200-ON Series AC switch (optional DC PSU available)
○N3208PX-ON—Compact, four ports 1G BASE-T RJ45 with 802.3bt Type-4 90W PoE, four ports 5G BASE-T RJ45 with
802.3bt Type-4 90W PoE, two ports 10G SFP+, one fixed AC PSU, two external power adapters, and one fan
○N3224T-ON—1U, 24 ports 1G BASE-T RJ45, four ports 10G SFP+, two 100G QSFP28 ports for stacking, two pluggable
AC or (optional) DC PSUs, three pluggable fan modules, and normal and reverse airflow options
○N3224F-ON—1U, 24 ports 1G SFP ports, four ports 10G SFP+, two 100G QSFP28 ports for stacking, two pluggable AC
or (optional) DC PSUs, and three pluggable fan modules
○N3224P-ON—1U, 24 ports 1G BASE-T RJ45 with 802.3at Type-2 30W PoE, four ports 10G SFP+, two 100G QSFP28
ports for stacking, two pluggable AC or (optional) DC PSUs, and three pluggable fan modules
○N3224PX-ON—1U, 24 ports 10G BASE-T RJ45 with 802.3bt Type-4 90W PoE, four ports 25G SFP28, two 100G
QSFP28 ports for stacking, two pluggable AC or (optional) DC PSUs, three pluggable fan modules, and (optional) EPS
○N3248TE-ON—1U, 48 ports 1G BASE-T RJ45, four ports 10G SFP28, two 100G QSFP28 ports for stacking, two
pluggable AC or (optional) DC PSUs, three pluggable fan modules, and normal and reverse airflow options
○N3248P-ON—1U, 48 ports 1G BASE-T RJ45 with 802.3at Type-2 30W PoE, four ports 10G SFP+, two 100G QSFP28
ports for stacking, two pluggable AC or (optional) DC PSUs, three pluggable fan modules, and (optional) EPS
18 N3200-ON Series switch

○N3248X-ON—1U, 48 ports 10G BASE-T RJ45, four ports 25G SFP28, two 100G QSFP28 ports for stacking, two
pluggable AC or (optional) DC PSUs, three pluggable fan modules, and normal and reverse airflow options
○N3248PXE—1U, 48 ports 10G BASE-T RJ45 with 802.3bt Type-4 90W PoE, four ports 25G SFP28, two 100G QSFP28
ports for stacking, two pluggable AC or (optional) DC PSUs, three pluggable fan modules, and (optional) EPS
●Normal airflow:
○All N3200-ON Series switches—Fan with airflow from the I/O side to the PSU side—normal airflow
●Reverse airflow:
○N3224T-ON, N3248TE-ON, N3248X-ON only—Fan with airflow from the PSU side to the I/O side—reverse airflow
Luggage tag
The switch has a pull-out tag, which is known as a luggage tag, on the I/O-side of the switch. The front of the luggage tag
includes switch ID information. The back of the luggage tag includes a QRL that takes you to a How-To site where you can
watch videos about racking the switch, replacing components, configuring port channels, and so on.
N3208PX-ON, N3224F-ON, N3224P-ON, N3224PX-ON, and N3224T-ON luggage tag
1. Product ID QRL 2. Product information QRL
3. SVC tag 4. MAC address
5. Exp Svc code
N3248P-ON, N3248PXE-ON, N3248TE-ON, N3248X-ON luggage tag
N3200-ON Series switch 19

1. Product ID QRL 2. Product information QRL
3. SVC tag 4. MAC address
5. Exp Svc code
20 N3200-ON Series switch
