AVYCON CAT5 User manual

2MP/5MP/8MP IP Cameras
QUICK START GUIDE
FIXED VANDAL DOME CAMERA
CAT5 / 6 / 7
Introduction
Safety Instructions
Package Contents
Installation
2
3
4
5
Network Cable Setup6
1
CONTENTS
Resources8
Network Connection7
INTRODUCTION 2
Thank you for purchasing our product. We make every effort to
update and ensure accuracy of the information contained in this
manual, which may be subject to change from time to time
without prior notice. For any questions or needs, please feel free
to contact us at any time.
SAFETY INSTRUCTIONS 3
1)
2)
3)
4)
5)
6)
7)
8)
Please comply with the power supply specifications as required
for this equipment and select the correct power supply.
In the case that equipment fails to operate properly, immediately
contact the manufacturer or the nearest service center. Please
do not attempt to disassemble the product or attempt to modify
the product in any manner, which may void warranty.
For replacement of any parts, contact the distributor. Changing
any parts in the device without authorization is not permitted
and may void warranty.
Prevent water or any other liquid from flowing into the
equipment.
Avoid use of the equipment in any environment other than as
suggested in this manual.
Do not put the camera toward any strong light source (including
lighting lamp or sun) which may cause over-exposure or light
leakage (not due to defect of the product) and impair useful life
of the camera.
Do not drop any object onto the device or knock heavy objects
onto the equipment.
For cleaning of the lens, be sure to use compressed air or a
dedicated lens cleaner. For cleaning of the plastic shield, use a
soft and dry microfiber cloth to wipe it. Do not use any
detergents containing alcohol or benzene.
Vandal Dome Camera Mounting Template
Drywall Anchor x 3
Mounting Screw x 3 L-Wrench
DC Plug Terminal Block
PACKAGE CONTENTS 4
INSTALLATION 5
1.
Sticker
Place mounting template sticker in area where you will be
mounting camera to surface that can sustain weight of camera.
2.
3.
•If using the included hardware, insert the three drywall
anchors into holes in the mounting surface and align holes in
camera mounting plate with anchors. Adjust the angle to an
optimal viewing position.
Drill into ceiling at marked drill holes deep enough to
accommodate for mounting hardware.
Remove the screws securing the dome cover in place. Then pull
the dome cover off carefully.
OPERATING ENVIRONMENT
Power Supply DC12V±10% / PoE (802.3af)
Temperature -22°F ~ 140°F (-30°C~60°C)
Humidity 10%~95%
Altitude -60m~3000m
Atmosphere 86kpa~106kpa
NETWORK IP CAMERA

⑤After setting up your credentials, you can access the camera by
logging into the system with the password you just created.
PLEASE CONFIRM THAT VOLTAGE OF POWER SUPPLY USED MATCHES POWER
REQUIRED BY CAMERA, OTHERWISE PERMANENT DAMAGE OR RISK OF FIRE
MAY OCCUR
CAUTION
NETWORK CABLE SETUP
6
①
②
③
123
Loosen the nut from the main element.
Run the network cable (without RJ45 connector) through both
elements. Then crimp the cable with the RJ45 connector.
Connect the cable to the female portion of the waterproof connector,
then tighten the nut and the main cover.
Need help?
1) Visit www.avycon.com
2) Search for the model number of your product.
3) Click on your product and find appropriate documents on product page.
RESOURCES
8
[email protected]om
www.avycon.com
1 [phone]
1 [phone]
[M-F, 6am-5pm PST]
Technical Support E-mail :
Technical Support Website :
US Helpdesk Number :
Toll Free Number (Canada) :
Note: DHCP is enabled by default.
The first time you access the camera, you will be prompted to choose
a password that must be between 8 to 15 characters. Once you are
done, click on the ‘OK’ button to confirm your login information. The
camera is now activated.
④
NETWORK CONNECTION 7
① Make sure that the camera and the PC are connected to the local network.
②Install the IP Device Tool from the CD and run it after installation.
MENU
IPC
Network Cable Network Cable
Switch
Router Computer
③Camera Activation: Click on the IP address of the camera you want to
activate, which will open that camera’s system in your web browser.
Alternatively, if you already know the IP address of your camera, you
can manually enter it into the address bar of your web browser to
reach the same screen.
Ceiling Mounting complete.
5.
Dome Cover
Fix the dome cover back onto the mounting base by installing
the three dome cover screws into the camera and tightening it
once the position is secured.
4.
Dome Cover Screws
Bracket Adjustments
•With the dome cover removed, you can make adjustments to
the pan, tilt, and rotation of the camera lens and body to allow
for the best possible view for your application.
6.
Rotate: 360°
Tilt:90°
Pan 360°
Drywall Anchors
•Carefully slide the dome cover back onto the camera, then
secure it by screwing it in place.
