AWA STB 237 User manual

OWNER'S MANUAL
English
Read this manualbefore installation anduse.
CHANNEL
STB 237
STB 237
Set Top Box
Digital receiver

TO REDUCE THERISK OF FIREAND ELECTRIC SHOCK,DO NOT EXPOSETHIS UNIT TO
RAIN OR MOISTURE.
IMPORTANT SAFEGUARDS
Read and Follow Instructions- Allthe safety and operation instructions
should be read beforethe video product is operated. Follow all
operating instructions.
Retain Instructions- The safety andoperating instructions should be
retained for future reference.
Heed all Warnings-Comply with allwarnings on the video product and in
the operating instructions.
Polarization- This video product isequipped with a polarized alternating
-current line plug. This plugwill fit into the poweroutlet, try reversing
the plug. If the plug still fails to fit,contact your electrician to replace
your obsolete outlet. To preventelectric shock, do not usethis polarized
plug with an extension cord,receptacle, or other outlet unlessthe
blades can be fully insertedwithout blade exposure. If youneed an
extension cord, use a polarizedcord.
Power Sources- This video productshould be operated only fromthe
type of power source indicatedon the marking label. Ifyou are not sure
of the type of powersupply to your home, consultyour video dealer or
local power company. For videoproducts intended to operate from
battery power, or other sources,refer to the operating instructions.
Overloading- Do not overloadwall outlets or extensioncords as this can
result in a risk offire or electric shock. OverloadedAC outlets, extension
cords, frayed power cords, damagedor cracked wire insulation, and
broken plugs are dangerous, Theymay result in a shockor fire hazard.
Periodically examine the cord, andif its appearance indicated damageor
deteriorated insulation, have it replacedby your service technician.
Power-Cord Protection- Power-supply cords shouldbe routed so that
they are not likely tobe walked on or pinchedby items placed upon or
against them, paying particularattention to cords at plugs,convenience
receptacles, and the point where they exit fromthe video product.
Ventilation- Slots and openings inthe case are provided forventilation
to ensure reliable operation ofthe video product and toprotect it from
overheating. These openings must notthe blocked or covered. The
openings should never be blockedby placing the video producton a
bed, sofa, rug, or heatregister. This video product shouldnot be placed
in a built-in installation suchas a book case orrack, unless proper
ventilation is provided or thevideo product manufacturer's instructions
have been followed.
Attachments- Do not use attachmentsunless recommended by the video
product manufacturer as they maycause hazards.
:To reduce the
risk of fire andelectric shock, do
not remove the cover(or back) of
the unit. Refer servicingonly to qualified servicepersonnel.
The lightning flash with arrowheadsymbol, within an equilateral
triangle, is intended to alertthe user to the presence of uninsulated
"dangerous voltage" within product's enclosure that may be of
sufficient magnitude to constitute arisk of electric shock.
The exclamation point within anequilateral triangle is intended to
alert the user to thepresence of important operationand servicing
instructions in the literature accompanyingthe appliance.
WARNING: TO REDUCE THE RISKOF FIRE OR ELECTRIC SHOCK,DO
NOT EXPOSE THIS APPLIANCE TORAIN OR MOISTURE.
CAUTION: TO PREVENT ELECTRIC SHOCK,MATCH WIDE BLADE OF
PLUG TO WIDE SLOT ANDFULLY INSERT.
In addition to thecareful attention devoted toquality standards
in the manufacture ofyour video product, safetyis a major factor
in the design ofevery instrument. However, safetyis your
responsibility, too. This sheetlists important information thatwill
help to assure yourenjoyment and proper useof the video
product and accessory equipment.Please read them carefully
before operation and usingyour video product.
Installation
Water and Moisture- do notuse this video product nearwater for example,
near a bath tub, washbowl, kitchen sink or laundry tub, in a wet basement,or
near a swimming pool andthe like. Caution: Maintain electricalsafety.
Powerline operated equipment oraccessories connected to thisunit should
bear safety certification mark onthe accessory itself and shouldnot be
modified so as to defeatthe safety features. Thiswill help avoid any andshould
not be modified so asto defeat the safety features.This will help avoid any
potential hazard from electrical shockor fire. If in doubt,contact qualified
service personnel.
Accessories- Do not place thisvideo product on an unstablecart, stand, tripod,
bracket, or table. The videoproduct may fall, causing seriousinjury to a child or
adult as well as seriousdamage to the video product. Use this video product
only with a cart, stand,tripod, bracket, or table recommendedby the
manufacturer's or sold withthe video product. Any mounting of the product
should follow the manufacturer's instructionsand use of a mountingaccessory
recommended by the manufacturer.
A video product and cartcombination should be moved withcare. Quick stops,
excessive force, and uneven surfacesmay cause the video productand cart
combination to overturn.
Note to CATV system installer
This reminder is provided tocall the CATV system installer'sattention to
Section 820-40 of the NECwhich provides guidelines for propergrounding
and, in particular, specifies thatthe cable ground shall beconnected to the
grounding system of the building,as close to the pointof cable entry as
practical.
Outdoor Antenna Grounding- Ifan outside antenna or cablesystem is
connected to the video product,be sure the antenna orcable system is
grounded so as to providesome protection against voltage surgesand built-up
static charges. Section 810 ofthe National Electrical Code, ANSI/NFPA No.70-
1984 (Section 54 of CanadianElectrical Code, Part1) providesinformation with
respect to proper grounding ofthe mast and supporting structure,grounding
of the lead-in wire toan antenna-discharge unit, connection togrounding
electrodes, and requirements for thegrounding electrode.
Power Lines-An outside antenna systemshould not be located inthe vicinity of
overhead power lines, otherelectric light or powercircuits, or where itcan fall
into such power lines orcircuits. When installing an outsideantenna system,
extreme care should betaken to keep fromtouching or approaching such
power lines or circuits, ascontact with them might befatal. Installing an
outdoor antenna can be hazardousand should be left toa professional
antenna installer.
Use
Cleaning- Unplug this video product from the wall outlet before cleaning.
Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning.
Objects that may touch dangerous voltage points or "short-out" parts could result in
a fire or electric shock. Never spill liquid of any kind on the video product.
Lightning-For added protection for this video product during a lightning storm, or
when it is left unattended and unused for long periods of time, unplug it from the
wall outlet and disconnect the antenna or cable system. This will prevent damage to
the video product due to lightning and power line surges.
Service
Servicing-Do not attempt to service this video product yourself, as opening or
removing covers may expose you to dangerous voltage or other hazards. Refer all
servicing to qualified service personnel.
Conditions Requiring Service-Unplug this video product from the wall outlet and
refer servicing to qualified service personnel under the following conditions:
A. When the power-supply cord or plug is damaged.
B. If liquid has been spilled, or objects have fallen into the video product.
C. If the video product has been exposed to rain or water.
D. If the video does not operate normally by following the operating instructions.
Adjust only those controls that are covered by operating instructions.
Improper adjustment of other controls may result in damage and will often
require extensive work by a qualified technician to restore the video product
to its normal operation.
E. If the video product has been dropped or cabinet has been damaged.
F. When the video product exhibits a distinct change in performance-this
indicates a need for service.
Replacement Parts-When replacement parts are required, have the service
technician verify that the replacements he uses have the same safety characteristics
as the original parts. Use of replacements specified by the video product
manufacturer can prevent fire, electric shock, or other hazards.
Safety Check-Upon completion of any service or repairs to this video product, ask the
service technician to perform safety checks recommended by the manufacturer to
determine that the video product is in safe operating condition.
Wall or Ceiling Mounting- The product should be mounted to a wall or ceiling only
as recommended by the manufacturer.
Heat-The product should be situated away from heat sources such as radiators, heat
registers, stoves, or other products (including amplifiers) that products heat.
10.
11.
11a.
12.
13.
14.
15.
16.
17.
18.
19.
20.
21.
22.
CAUTION
The apparatus shall not beexposed to dripping or splashing,and that no
objects filled with liquids, suchas vases, shall be placeon the apparatus.
SAFETY INSTRUCTIONS
1.
2.
3.
4.
5.
6.
7.
8.
9.

SAFTY IMFORMATION
This STB hasbeen manufactured tosatisfy international safetystandards.
Please read thefollowing recommended safetyprecautions carefully.
MAINS SUPPLY:
OVERLOADING:
LIQUIDS:
CLEANING:
VENTILATION:
ATTACHMENTS:
CONNECTION TO
THE CABLE TV
SIGNAL AND TV:
SERVICING:
LIGHTNING:
GROUNDING:
AC230~240V 50Hz
Do not overloadwall outlets, extensioncords or adapters
as this canresult in fireor electrical shock.
NOTE
Before cleaning, disconnectthe STB fromthe wall socket.
Use a clothlightly dampened withwater(no solvents) to
clean the exterior.
Do not blockthe STB ventilationholes. Ensure thatfree airflow
is maintained aroundthe STB. Neverstore the STBwhere it is
exposed to directsunlight or nearheating euipment e.g.a
radiator.
Never stack otherelectronic equipment ontop of theSTB.
Place the STBat least 30mmfrom the wall.
Keep liquids awayfrom the STB.
Do not useany attachment thatis not recommendedby the
manufacturer; it maycause a hazardor damage theequipment.
Connect all componentsbefore plugging anypower cords intothe wall
outlet. Always turnoff the STB,TV and othercomponents before you
connect or disconnectany cables.
Do not attemptto service thisproduct yourself.
Any attempt todo so willmake the warrantyinvalid.
Refer all servicingto a qualifiedservice agent.
If the STBis installed inan area subjectto intense lightning
activity, protection devicesfor the STBmains connector and
modem telephone lineare essential.
The individual manufacturer'sinstruction for safeguardingother
equipment, such asTV set, Hi-Fi,etc., connected tothe STB must
also be followedduring lightning storms.
CATV cable MUSTBE EARTHED.
The grounding systemmust comply withSABS 061.
Dispose the usedbatteries at designatedplace for environment protection
21
1

SAFETY INFORMATION
INTRODUCTION
About STB
Front panel
Rear panel
Remote control
SYSTEM CONNECTION
General about connections
Connecting to theTV aerial
Connecting to theTV
Connecting a HiFisystem
Connecting a videorecorder
GETTING STARTED
Switching on
System setup
Automatic channel scan
Manual channel scan
OPERATION
Changing channels
Volume control
Auto control
Soundtrack language
Accessing the favoritechannels
Displaying program information
Accessing the ElectronicProgram Guide (EPG)
Pausing the currentpicture
Switching between S-Video,CVBSand Y Cb Cr mode
Switching between tvand radio mode
Channels List
Auto power on/ off
SYSTEM SET-UP
GMT setting
Language setting
A/v setting
Sort channel
Factory settings
FAVORITE LIST
Favorite list
TROUBLESHOOTING
SPECIFICATION
1
1
2-3
4
4
5
6
7
8
8
9
9
10
11
11
11
11
12
12
12
12
12
13
14
15
15
16
17
17
18
19
20
CONTENTS

AC 220-240V
~50/60Hz
STB 237
N294
MADE IN CHINA
CHANNEL
STB 237
Front panel
Rear panel
Coaxial Digital Audio
TV Scart
for connection tothe TV
S-Video
TV aerial
for an externalTV aerial
Loop though
for an externalTV aerial
RF
Remote sensor
Main Power button Channel up
Channel down
Component Video
(Y Cb Cr)
Power indicator
About the STB
INTRODUCTION
21
1
USB port
(for connection toPC)
Down Mix Audio
2 channel L/R
CompositeVideo

CHANNEL
STB 237
2
Remove the batterycompartment cover.
Load two AAA(UM-4 or R03)batteries into the
battery compartment.
Make sure thatthe batteries havebeen inserted
in the correctpolarities matching tothe symbols
+, - markedin the batterycompartment. Close
the battery compartmentcover.
When replacing batteries,replace both batteries.
Do not mixnew and usedbatteries operating
together, otherwise, theoperation lifetime will
be much shorterthan normal.
Remove the batteriesif the unitwill not be used
for a prolongedperiod of time.
Remote control
The remote controltransmits a directional
infrared beam. Besure to aim the remote
control directly atthe infrared sensorof the
unit during operation.
If the sensorhas been covered or there isa
large object betweenthe remote control and
the sensor, thesensor will not respond.
The sensor maynot able to receive the
remote signal whenit is exposed to direct
sunlight or astrong artificial light(fluorescent
or strobe light).In this case, change the
direction of thelight or repositionthe unit to
avoid direct lighting.
2
30
o
30
o
Within approximately
6 meter (20feet)
Remote
sensor
BE ENVIRONMENTALLY FRIENDLY
Do not disposebatteries as normalrubbish. Be environmentallyfriendly,
dispose batteries followingthe Government's regulation.
INTRODUCTION
MENU
MENU
OK
EXIT
CH+
CH+
CH
-
VOL
VOL
-
VOL
+
VOL
+
PAUSE
PAUSE
FAVORITE
FAVORITE
LANG INFO
RECALL
RECALL
MUTE
MUTE
TV/RADIO
TV/RADIO
AUDIO
AUDIO
EPG
EPG
X
TTX
SUBTITLE
SUBTITLE

MENU
OK
EXIT
EXIT
CH+
CH
-
VOL
-
VOL
+
VOL
+
PAUSE FAVORITE
LANG
LANG INFO
RECALL
MUTE
TV/RADIO AUDIO
EPG
X
TTX
SUBTITLE
SUBTITLE
3
INTRODUCTION
1
2
3
4
7
5
6
11
12
13
14
Power On/Standby
(Switch the STBON/STANDBY mode)
Numeric entry
(Enter numeric valuesand to select the
channel firectly byentering it's number)
Menu
(Open up menu)
Red Button
(For teletext function)
Cursor/ Enter
( to selectsub-menu from the
main menu andchannel +/-,
( to selectmenu and sub-menu
from the menu and volume +/-,
( Press to enter.)
Yellow Button
(For teletext function)
Mute
RECALL
(switch to previouschannel)
EPG
(Open up Electronic Program Guide
menu)
TTX
(Open Teletext function)
EXIT
(Exit from menu)
Green Button
(For teletext function)
Blue Button
(For teletext function)
FAVOUITE
(Open up Favouritelist)
PAUSE
INFO
(Press for currentchannel information)
LANG
(Select language)
AUDIO
(Select audio: Left/ Right /Stereo / Mono)
TV/RADIO
(Switch between TVand Radio)
SUBTITLE
(On/Off Subtitle)
8
9
11
10
12
13
15
14
1
2
3
4
5
6
7
10
8
9
15
16
17
18
19
20
16
17
18
19
20

You can connectthe STB to the following typeof aerials:
Standard outdoor aerial
Please note thefollowing:
In some blockof flats, the roof-mounted aerial systemincludes a filterand channel selector. If so,
the aerial maynot work withthe STB. Pleaseconsult the landlord.
Many older roof-mountedaerials may only receive a limitednumber of channels.As a result, digital
channels transmitted onhigher frequencies aredifficult or evenimpossible to receive.The
problem can be solved by replacingthe roof aerial.
Some outdoor aerialsare directed towards an analogue transmitter.
The aerial mustbe directed towards a digital TV transmitter.
It is notalways advisable toposition the aerial as high aspossible. If problems arise, experiment with
different aerial heights.
Indoor and windowmounted aerials
It is notadvisable to useindoor or window mounted aerials, asdigital channels willbe difficult or
even impossible toreceive.
Connecting to the TV aerial
1
2
SYSTEM CONNECTION
4
There are manydifferent types ofTV/VCR and other equipment that you can connect to the STB.
In this manualyou will seesome of themost common ways to connectyour equipment.
General

AC 220-240V
~50/60Hz
STB237
N294
MADE IN CHINA
Connecting to the TV
Scart cable
Antenna
RF cable
NOTE
SYSTEM CONNECTION
5
Red White Yello w
Red
Green
Blue
Yellow
White
Red
Green
Blue
Red
Remove the aeriallead from yourTV and connect this to the TV AERIAL inputsocket on theSTB.
Switch on yourTV, plug inand switch on your STB.
You may need toselect the CVBS orY Cb Cr channelon your TV towatch Digital TV. Insome cases your
TV will automatically selectthis channel when theSTB is switched on.
RF Loop Through connectoris used for asecond DVB-T receiver.
The digital signal fromRF In will belooped through via thisconnection.

AC 220-240V
~50/60Hz
STB 237
N294
MADE IN CHINA
Hi-Fi
Connecting a HiFi system
NOTE
To avoid interference youmust use screened audiocables.
Never connect digital outputto any analogue input.
It is always advisableto consult your HiFiinstruction book.
SYSTEM CONNECTION
6
Coaxial cable
Optical cable
You can connectan RCA/Cinch single cable from theDIGITAL AUDIO socketon the STBto a HiFi
system equipped withdigital audio input. This output isalso used forconnection to an external
Dolby digital decoder.

AC 220-240V
~50/60Hz
STB237
N294
MADE IN CHINA
Remove the aeriallead from yourTV and connect this to the TV AERIAL inputsocket on theSTB.
Connect a CVBScable between thevideo and theSTB.
Connect a YCb Cr cablebetween Y Cb Cr socket onthe TV andthe Y Cb Cr on theSTB.
Switch on yourTV, plug inand switch on your STB.
On your VCRthere should bean A/V select button. This shouldbe selected torecord Digital TV.
You may need toselect the AV channelon your TV betweenS-Video,CVBS and Y CbCr.
Video Cassette Recorder
VCR
TV
Antenna
R cable
F
NOTE
To record a digitalchannel you will needto select the CVBScable on your video.
It is always advisableto consult your videoand TV instruction books.
SYSTEM CONNECTION
Red
Yellow
White
Red
White
Yello w
R cable
F
Green
Blue
Red
Red
Green
Blue
7
Connecting to Video Recorder

System setup
Time Setting
Language Setting
Factory Setting
A/V settings
Sort Channel
Channel Favorite Setting Scan
16:9 <>
Auto <>
Pal <>
CVBS <>
TV Shape
Conversion
Standard
Video Output
Press the "MENU"button to enterthe setup menu of the STB.
Press the "LEFT"or" RIGHT" cursor button to select .
Press the "OK"Button to enterthe sub-menu.
Press "UP" or"Down" cursor button to select "A/Vsettings" and press
"OK" Button tocomfirm.
Select the "TVShape" and press "LEFT" or "RIGHT"cursor button
to select desiredShape.
Press "UP" or"DOWN" cursor button to select the
"Conversion" and pressthe "LEFT" or "RIGHT" cursor button
to select desiredconversion.
Press "EXIT" button to quit.
Setting
1
Switching on
Turn on yourTV set and select the corresponding AV input (withthe AV key, or simular, onthe
television remote control).
Turn on themain power supply to the STB,the indicator onthe front of the unit willturn red andthen
green. In standbymode, the indicatorlight will be red. In workingmode, the indicatorlight will be
green.
2
3
4
5
6
7
GETTING STARTED
8
5
6
8

Scan Type
Channel No
Auto Scan <>
Start Scan
Press the "MENU"button to enterthe setup menu of the STB.
Press the "LEFT"or "RIGHT" cursor button to select .
Press the "OK"Button to enter the sub-menu.
Select the "ScanType" and press "LEFT" or "RIGHT"cursor button
to select "Autoscan".
Press "UP" or"DOWN" cursor button to select the
"Start Scan" andpress the "OK"button to startsearching.
Press "EXIT"button toquit.
1
2
3
4
5
6
Scan
Automatic channel scan
Manual channel scan
Press the "MENU"button to enterthe setup menu of the STB.
Press the "LEFT"or "RIGHT" cursor button to select .
Press the "OK"Button to enter the sub-menu.
Highlight the "ScanType" and press "LEFT" or "RIGHT"cursor button
to select "Manualscan".
Press "DOWN" cursorbutton to "Channel No." section and
enter Channel Number
Press "UP" or"DOWN" cursor button to select the
"Start Scan" andpress the "OK"button to startsearching.
Press "EXIT"button toquit.
1
2
3
4
5
6
Scan
7
NOTE
When the searchis finished, the first channel ofthe channel listand the information banner is
displayed you cannow watch digital terrestrial televison.
9
GETTING STARTED
Channel Favorite Setting Scan
Scan Type
Channel No
Manual Scan <>
21
Start Scan
Channel Favorite Setting Scan

EPG
Changing Channels
There are fourways of channelselection - stepping through the channellist,
selection by number,from the on-screen channel list, andusing the electronicprogramme guide(EPG).
Stepping through thechannel list:
To move throughthe channel list, press the upwardarrow or downwardarrow key on the
remote control.
Selection by number:
Enter the channellist number directly by remote controlto select desiredchannel.
auto scan willclean the channelsthat stored first.
mannal scan don'tclean the channels,butit will not add the repeatedchannels that
have stored.
Selection by on-screenchannels list:
You can alsoselect the required channel directly fromon-screen channel list.This is
displayed using theSTB's main menu.
1. BBC1
2. BBC2
3. ITV1
4. ITV1
5. CHANNEL4
TV
Preview
BBC1
0 - Lock/ Unlock
1-Delete
2-Move up
3-Move down
Press the "MENU"button to enter the setup menu
of the STB.
Press the "LEFT"or "RIGHT" cursor button
to select .
Press the "OK"button to enter the sub-menu.
Press "UP" or"DOWN" cursor button to preview
channel.
Press "OK" button to switch tothe desired channel.
1
2
3
4
Channel
Selection by EPG:
You can alsoselect the requiredchannel directly from electronic program guide(EPG).
This is displayedusing the STB'smain menu.
Preview
BBC1
SERVICE NAME
BBC1
Program Event
Like the channellist, the EPG screen displays alist of thestored channels along with
information on whatprogrammes are being broadcast.
Press the "EPG"button to enterthe EPG menu .
Press the "UP"or "DOWN" cursor button to highlight
channel.
Press "LEFT or"RIGHT cursor button to check
program information within30 minutes.
Press "OK" button to switch tothe desired channel
and preview channel.
10
OPERATION
Channel Favorite Setting Scan
NOTE:
Press numeric button" 0-3"to Lock/
Unlock ,Delete,Move up ,Movedown
channels .
09:30 10:00
BBC1
BBC1
Information of the channels
10:30 11:00
Information of the channels
Information of the channels
Information of the channels
Channel Play
OK
Subtitle
Press Subtitle button to switch subtitleOn/Off.
SUBTITLE

The volume levelof the STBcan be altered with the "Left"or "Right" cursor button on the
remote control.
Volume Control
Audio control
Soundtrack language
NOTE
The volume levelselected will remain set, even whenthe receiver isturned off and on again,
until it's altered.
You can silencethe sound from the receiver bypressing the "MUTE"button . Thesound remain
muted until the"MUTE" button ispressed again, the"LEFT" or "Right"cursor button is
pressed, or untilthe receiver is turned off andon again.
You can pressthe "AUDIO" button to select different audio modes amongSTEREO, LEFT, RIGHT,
MONO.
Some Programmes arebroadcast in two or more languagesimultaneously. The soundtrack
language can be selected or bypressing the "LANG"button on the remote control.
11
Accessing the favorite channels
Press the "FAVOURITE"button to openup the "FAVOURITE LIST".
Press "UP" or"DOWN" cursor button to select thedesired favourite group.
Press the "OK"button to enterthe "favourite" group.
Select the favouritechannels and press "OK" button
Press numeric button"1-5" to Add,Delete,Sort,Move favourite
channels .
Press "EXIT" button 3 times to quit.
1
2
3
4
5
OPERATION
6
1.Movie
2.Sports
5.Finance
3.News
4.MTV
1.BBCNEWS 24
4.CBBC Channel
2.BBC ONE
3.BBCI
Favorite channel
1-Add 2-Delete
1-Add 2-Delete 3-Sort
4-Move up 5-Move down
Teletext
Press TTX button to Open/Close teletext.
TTX

Displaying program information
Accessing the Electronic Program
Guide (EPG)
Pausing the current picture
You can readthe current programinformation by pressing "INFO" button onthe remote
control. Press thebutton again tohide the program information table.
You can pausethe current pictureby pressing "PAUSE" button on theremote control.
Press the keyagain to keep switching the program.
Accessing the EPGof all channels:
1
2
3
4
Press the "EPG"button to enter EPG menu .
Press "UP" or"Down" cursor button to preview channel.
Press "Left "or"Right" cursor button to check program
information within 30minutes.
Press "OK" button to switch toview the guides.
NOTE
The broadcast betweentwo pauses willbe skipped.
OPERATION
8
5
6
12
EPG
You can switchbetween S-Video,CVBS andY Cb Cr mode by pressing"S-Video" button .
Switching between S-Video,CVBS
and Y Cb Cr mode
Switching between TV
and Radio mode
You can switchbetween Digital TVmode and Radio mode by pressing"TV/RADIO" button .
S-VIDEO
NOTE
Radio function isnot available in Germany.
From the technicalpoint of view it is possibleto receive radiovia DVB-T.
The german governmentdeceided to keep the standard DABSignal.

Channels List
Some channels broadcastmaterial which youdo not want younger members ofthe family to watch.
Any channel canbe locked sothat it cannot be selected forviewing without enteringPIN code.
1
2
3
4
5
6
Locking/Unlocking a channel:
7
Delete a channel:
Press the "MENU"button to enter the setup menu
of the STB.
Press the "LEFT"or "RIGHT" cursor button
to select .
Press the "OK"button to enter the sub-menu.
Press "UP" or"DOWN" cursor button to preview
channel.
Press "0" button pop out thePIN CODE box
Enter the pincode and press"OK" button toconfirm
(default pin codeis 888888)
Press "EXIT" button 2 times toquit.
Channel
1
2
3
4
5
6
7
Press the "MENU"button to enter the setup menu
of the STB.
Press the "LEFT"or "RIGHT" cursor button
to select .
Press the "OK"Button to enter the sub-menu.
Press "UP" or"DOWN" cursor button to preview channel.
Press "1" button .
Press "OK" button to confirm.
Press "EXIT" button 2 times toquit.
Channel
1
14
OPERATION
13
Move a channel:
1
2
3
4
5
6
7
Press the "MENU"button to enter the setup menu
of the STB.
Press the "LEFT"or "RIGHT" cursor button
.
to select
Press the "OK"Button to enter the sub-menu.
Press "UP" or"DOWN" cursor button to preview channel.
Press "2" button move up highlightchannel
Press "3" button move down highlightchannel
Press "EXIT" button 2 times toquit.
Channel
2
3
1. BBC1
2. BBC2
3. ITV1
4. ITV1
5. CHANNEL4
TV
Preview
BBC1
0 - Lock/ Unlock
1-Delete
2-Move up
3-Move down
Channel Favorite Setting Scan

Time Setting
Language Setting
Factory Setting
A/V settings
Sort Channel
GMT +1
00:00
:
:
Disable <>
Disable <>
Time Zone
Current Time
Auto Power off
Time:
Time:
Auto Power on
You can setthe STB topower on and power off automatically.
Auto power on:
Press the "MENU"button to enter the setup menuof the STB.
Press the "LEFT"or "RIGHT" cursorbutton arrows key to select .
Press the "OK"button to enterthe sub-menu.
Press "UP" or"DOWN" cursor button to select "Time
Setting" and press"OK" button .
Select the "Auto Power On" andpress "LEFT" or"RIGHT" cursor
button to select"Enable".
Press "UP" or'DOWN" cursor button to select "Time".
Enter the hoursof the autopower on time by pressing "NUMERIC"buttons.
Press "RIGHT" cursorbutton "RIGHT" tomove the cursorto the minute box.
Enter the minutesof the autopower on time by pressing "NUMERIC"buttons.
Press "OK" button to confirm.
Press "EXIT" button 3 times to quit.
Press the "MENU"button to enter the setup menuof the STB.
Press the "LEFT"or "RIGHT" cursorbutton arrows key to select .
Press the "OK"button to enterthe sub-menu.
Press "UP" or"DOWN" cursor button to select "Time
Setting" and press"OK" button .
Select the "Auto Power Off" andpress "LEFT" or"RIGHT" cursor
button to select"Enable".
Press "UP" or'DOWN" cursor button to select "Time".
Enter the hoursof the autopower off time by pressing "NUMERIC"buttons.
Press "RIGHT" cursorbutton "RIGHT " to move thecursor to theminute box.
Enter the minutesof the autopower off time by pressing "NUMERIC"buttons.
Press "OK" button to confirm.
Press "EXIT" button 3 times to quit.
Setting
1
1
2
2
3
3
4
4
5
5
6
6
7
7
8
8
Auto power off:
9
9
10
10
11
11
Auto Power On/Off
14
OPERATION
Channel Favorite Setting
Setting
Scan

Many aspects ofyour STB canbe set to reflect your circumstancesand preference. The SETTINGS menu
screen is accessedfrom main menu.
Time Setting
Language Setting
Factory Setting
A/V settings
Sort Channel
GMT +2
00:00
:
:
Disable <>
Disable <>
Time Zone
Current Time
Auto Power off
Time:
Time:
Auto Power on
Press the "MENU"button to enter the setup menuof the STB.
Press the "LEFT"or "RIGHT" cursor button key toselect .
Press the "OK"button to enterthe sub-menu.
Press "UP" or"DOWN" cursor button to select "TimeSetting"
and press "OK"button .
select the desireditem and press "LEFT" or "RIGHT" cursor button
to select desiredsetting.
Press "OK" button to confirm.
Press "EXIT" button2 times toquit.
Setting
1
2
3
4
5
6
GMT setting
Language setting
Various time zonecan be set, such as currentlocal time, switchon/off time. The exact local present
time can beadjusted by using the GMT.
The Language Settingoption allows the user to selectthe desired languageof the OSD or Audio.
Time Setting
Language Setting
Factory Setting
A/V settings
Sort Channel
English
Menu Language
English
Audio Language
NOTE
GMT is referredto the standard time of Greenwich.
Press the "MENU"button to enterthe setup menuof the STB.
Press the "LEFT"or" RIGHT" cursor button to select .
Press the "OK"button to enterthe sub-menu.
Press "UP" or"DOWN" cursor button to select "Languagesettings" and press
"OK" Button toconfirm.
Select the "Audiolanguage" and press"LEFT" or "RIGHT" cursor
button to selectdesired language.
Select the "Subtitlelanguage" and press"LEFT" or "RIGHT" cursor
button to selectdesired language.
Press "EXIT" button3 times toquit.
Setting
1
2
3
4
5
6
NOTE
Digital terrestrial televisionchannels can broadcastsimultaneous soundtracks inmore than one
language. This functionselects which language soundtrack you willhear when switchingto a
channel broadcasting withmulti soundtracks.
15
SYSTEM SET-UP
Channel Favorite Setting Scan
Channel Favorite Setting Scan
English
Subtitle Language
7
7

A/V setting
Time Setting
Language Setting
Factory Setting
A/V settings
Sort Channel
16:9 <>
Auto <>
Pal <>
CVBS <>
TV Shape
Conversion
Standard
Video Output
Press the "MENU"button to enterthe setup menuof the STB.
Press the "LEFT"or "RIGHT" cursor button to select .
Press the "OK"button to enter the sub-menu.
Press "UP" or"DOWN" cursor button to select "A/Vsettings"
and press OKbutton .
Select the desireditems and press "LEFT" or "RIGHT"cursor button toselect
desired settings.
Press "EXIT" button3 times toquit.
Setting
1
2
3
4
5
6
Various A/V modescan be setin this menu, such as TVshape,
conversion, TV standardand Video output.
TV shape
16:9 Auto
FullFrame
VerticalCut
PillarBox
Auto
FullFrame
Pan&Scan
LetterBox
4:3
TV shape
Conversion Conversion
TV Sharp/ Conversion:
SYSTEM SET-UP
PAL
NTSC
AUTO
: Set tooutput PAL signal
: Set tooutput NTSC signal
: Set toauto-switching the outputsignal
Standard:
CVBS
Y Cb Cr
: Set tooutput CVBS videosignal
: Set tocomponent video signal
Video output:
16
Channel Favorite Setting Scan
