AXEM Technology MBA4 User manual

File : MBA4_User_Guide_v1.0.docxMBA4
Version : V1.0
AXEM Technology
11 rue Auguste Perret, 94042 Créteil, FRANCE –[email protected] –[phone] –www.axemtec.com
Siret : 45071140300045 - APE : 4652Z - RCS : CRETEIL 450711403 - N° TVA intracom : FR05450711403 - Capital : 500 000,00 €
MBA4
User guide

File : MBA4_User_Guide_v1.0.docxMBA4
Version : V1.0
AXEM Technology
11 rue Auguste Perret, 94042 Créteil, FRANCE –[email protected] –[phone] –www.axemtec.com
Siret : 45071140300045 - APE : 4652Z - RCS : CRETEIL 450711403 - N° TVA intracom : FR05450711403 - Capital : 500 000,00 €
1
Table of content
1Revision ....................................................................................................................2
2Product introduction ..................................................................................................3
2.1 Precautions before using the battery..................................................................3
2.2 Charger..............................................................................................................3
2.3 Notes .................................................................................................................4
3Installation instructions..............................................................................................5
3.1 Appearance........................................................................................................5
3.2 Install Micro SD and SIM cards ..........................................................................6
3.3 Battery charge.................................................................................................... 6
3.4 Buttons and function area display ......................................................................7
4Call function ..............................................................................................................8
4.1 Calling numbers ................................................................................................. 8
4.2 Contacts.............................................................................................................8
4.3 SMS and MMS................................................................................................... 8
5Barcode reader .........................................................................................................9
5.1. SE4850 (Long range)....................................................................................... 10
5.1 SE4710 (Normal range) ................................................................................... 10
6NFC reader ............................................................................................................. 11
7Other functions........................................................................................................ 12
7.1 PING tool ......................................................................................................... 12
7.2 Bluetooth.......................................................................................................... 13
7.3 GPS ................................................................................................................. 14
7.4 Volume setup................................................................................................... 15
7.5 Sensor ............................................................................................................. 15
7.6 Keyboard ......................................................................................................... 16
7.7 Network............................................................................................................ 17
7.8 Keyboard emulator........................................................................................... 18
8Device features ....................................................................................................... 19

File : MBA4_User_Guide_v1.0.docxMBA4
Version : V1.0
AXEM Technology
11 rue Auguste Perret, 94042 Créteil, FRANCE –[email protected] –[phone] –www.axemtec.com
Siret : 45071140300045 - APE : 4652Z - RCS : CRETEIL 450711403 - N° TVA intracom : FR05450711403 - Capital : 500 000,00 €
2
1Revision
Description
Date
Version
Author
Check
First release
2021/03/04
1.0
CLO
ACA

File : MBA4_User_Guide_v1.0.docxMBA4
Version : V1.0
AXEM Technology
11 rue Auguste Perret, 94042 Créteil, FRANCE –[email protected] –[phone] –www.axemtec.com
Siret : 45071140300045 - APE : 4652Z - RCS : CRETEIL 450711403 - N° TVA intracom : FR05450711403 - Capital : 500 000,00 €
3
2Product introduction
2.1 Precautions before using the battery
•Do not leave battery unused for long time, no matter it is in device or inventory. If
battery has been used for 6 months already, it should be check for charging function
or it should be disposed correctly.
•The lifespan of Li-ion battery is around 2 to 3 years, it can be circularly charged for
300 to 500 times. (One full battery charge period means completely charged and
completely discharged.)
•When Li-ion battery is not in used, it will continue discharge slowly. Therefore,
battery charging status should be checked frequently and take reference of the
related battery charging information on the manuals.
•Observe and record the information of a new unused and non-fully charged battery.
Based on operating time of new battery and compare with a battery that has been
used for long time. According to product configuration and application program, the
operating time of battery would be different.
•Check battery charging status at regular intervals.
•When battery operating time drops below about 80%, charging time will be
increased remarkably.
•If a battery is stored or otherwise unused for an extended period, be sure to follow
the storage instructions in this document. If you do not follow the instructions, and
the battery has no charge remaining when you check it, consider it to be damaged.
Do not attempt to recharge it or to use it. Replace it with a new battery.
•Store the battery at temperatures between 5 °C and 20 °C (41 °F and 68 °F).
2.2 Charger
The charger type is GME10D-050200FGu, output voltage/current is 5V DC/2A. The plug
considered as disconnect device of adapter.

File : MBA4_User_Guide_v1.0.docxMBA4
Version : V1.0
AXEM Technology
11 rue Auguste Perret, 94042 Créteil, FRANCE –[email protected] –[phone] –www.axemtec.com
Siret : 45071140300045 - APE : 4652Z - RCS : CRETEIL 450711403 - N° TVA intracom : FR05450711403 - Capital : 500 000,00 €
4
2.3 Notes
Note 1:
Using the incorrect type battery has danger of explosion.
Please dispose the used battery according to instructions
Note 2:
Due to the used enclosure material, the product shall only be connected to a USB Interface
of version 2.0 or higher. The connection to so called power USB is prohibited.
Note 3:
The adapter shall be installed near the equipment and shall be easily accessible.
Note 4:
The suitable temperature for the product and accessories is 0-10 to 50°C.
Note 5:
CAUTION RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT
TYPE. DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS.

File : MBA4_User_Guide_v1.0.docxMBA4
Version : V1.0
AXEM Technology
11 rue Auguste Perret, 94042 Créteil, FRANCE –[email protected] –[phone] –www.axemtec.com
Siret : 45071140300045 - APE : 4652Z - RCS : CRETEIL 450711403 - N° TVA intracom : FR05450711403 - Capital : 500 000,00 €
5
3Installation instructions
3.1 Appearance
MBA4 back and front appearances are showing as follows:
Buttons instruction

File : MBA4_User_Guide_v1.0.docxMBA4
Version : V1.0
AXEM Technology
11 rue Auguste Perret, 94042 Créteil, FRANCE –[email protected] –[phone] –www.axemtec.com
Siret : 45071140300045 - APE : 4652Z - RCS : CRETEIL 450711403 - N° TVA intracom : FR05450711403 - Capital : 500 000,00 €
6
3.2 Install Micro SD and SIM cards
The cards sockets are showing as follows:
3.3 Battery charge
By using USB Type-C contact, the original adaptor should be used for charging the device.
Make sure not to use other adaptors to charge the device.

File : MBA4_User_Guide_v1.0.docxMBA4
Version : V1.0
AXEM Technology
11 rue Auguste Perret, 94042 Créteil, FRANCE –[email protected] –[phone] –www.axemtec.com
Siret : 45071140300045 - APE : 4652Z - RCS : CRETEIL 450711403 - N° TVA intracom : FR05450711403 - Capital : 500 000,00 €
7
3.4 Buttons and function area display
MBA4 has main keyboard that contains:
10 numeric keys+2 symbolic keys, 4 direction keys, 2 Android function keys,
ENTER/ESC/TAB/ALT/CTRL/BACK/DELETE, 10 user defined function keys (reuse with
letter keys), 1 POWER key, 1 SCA N key, 1 Alt key, 38 keys in total.
Side keys: 2 SCAN keys+2 volume keys+1 user-defined key, 2D scanning module locates
on the top. HD camera and flashlight locate at rear. NFC identification surrounds the
camera.

File : MBA4_User_Guide_v1.0.docxMBA4
Version : V1.0
AXEM Technology
11 rue Auguste Perret, 94042 Créteil, FRANCE –[email protected] –[phone] –www.axemtec.com
Siret : 45071140300045 - APE : 4652Z - RCS : CRETEIL 450711403 - N° TVA intracom : FR05450711403 - Capital : 500 000,00 €
8
4Call function
4.1 Calling numbers
1. Click icon .
2. Click number key to input phone numbers.
3. Click icon to call.
4. Click icon to end call.
4.2 Contacts
1. Click contacts to open contacts list.
2. Click icon to add new contacts.
3. Click icon to import/export contacts.
4.3 SMS and MMS
1. Click to open message window.
2. Click to input message receiver and contents.
3. Click to send out messages.
4. Click to add attachment pictures and videos.

File : MBA4_User_Guide_v1.0.docxMBA4
Version : V1.0
AXEM Technology
11 rue Auguste Perret, 94042 Créteil, FRANCE –[email protected] –[phone] –www.axemtec.com
Siret : 45071140300045 - APE : 4652Z - RCS : CRETEIL 450711403 - N° TVA intracom : FR05450711403 - Capital : 500 000,00 €
9
5Barcode reader
1. In App Center open 2D barcode scan test.
2. Press “SCAN” button or click scan key to start scanning, the parameter “Auto
interval” can be adjusted.
Caution: Please scan codes in correct way otherwise the scanning will fail.
2D code:
Max. radiant power: 0.6mW
Wavelength: 655nM
IEC 60825-1 (Ed.2.0).
21CFR 1040.10 and 1040.11
standard.

File : MBA4_User_Guide_v1.0.docxMBA4
Version : V1.0
AXEM Technology
11 rue Auguste Perret, 94042 Créteil, FRANCE –[email protected] –[phone] –www.axemtec.com
Siret : 45071140300045 - APE : 4652Z - RCS : CRETEIL 450711403 - N° TVA intracom : FR05450711403 - Capital : 500 000,00 €
10
5.1. SE4850 (Long range)
MBA4 provides short and long range 1D and 2D barcode capture thanks to its SE4850
extended range Imager.
This imager enables to read very fast 1D and 2D barcodes of all shapes and sizes.
5.1 SE4710 (Normal range)
SE4710 enables to read 1D and 2D barcodes at a few centimeters.

File : MBA4_User_Guide_v1.0.docxMBA4
Version : V1.0
AXEM Technology
11 rue Auguste Perret, 94042 Créteil, FRANCE –[email protected] –[phone] –www.axemtec.com
Siret : 45071140300045 - APE : 4652Z - RCS : CRETEIL 450711403 - N° TVA intracom : FR05450711403 - Capital : 500 000,00 €
11
6NFC reader
In App Center open “NFC” to read and write tag information.

File : MBA4_User_Guide_v1.0.docxMBA4
Version : V1.0
AXEM Technology
11 rue Auguste Perret, 94042 Créteil, FRANCE –[email protected] –[phone] –www.axemtec.com
Siret : 45071140300045 - APE : 4652Z - RCS : CRETEIL 450711403 - N° TVA intracom : FR05450711403 - Capital : 500 000,00 €
12
7Other functions
7.1 PING tool
1. Open “PING” in App Center.
2. Setup PING parameter and select external/internal address.

File : MBA4_User_Guide_v1.0.docxMBA4
Version : V1.0
AXEM Technology
11 rue Auguste Perret, 94042 Créteil, FRANCE –[email protected] –[phone] –www.axemtec.com
Siret : 45071140300045 - APE : 4652Z - RCS : CRETEIL 450711403 - N° TVA intracom : FR05450711403 - Capital : 500 000,00 €
13
7.2 Bluetooth
1. Open “BT Printer” in App Center.
2. In the list of detected devices, click the device that you want to pair.
3. Select printer and click “Print” to start printing contents.

File : MBA4_User_Guide_v1.0.docxMBA4
Version : V1.0
AXEM Technology
11 rue Auguste Perret, 94042 Créteil, FRANCE –[email protected] –[phone] –www.axemtec.com
Siret : 45071140300045 - APE : 4652Z - RCS : CRETEIL 450711403 - N° TVA intracom : FR05450711403 - Capital : 500 000,00 €
14
7.3 GPS
1. Click “GPS” in App Center to open GPS test.
2. Setup GPS parameters to access GPS information.

File : MBA4_User_Guide_v1.0.docxMBA4
Version : V1.0
AXEM Technology
11 rue Auguste Perret, 94042 Créteil, FRANCE –[email protected] –[phone] –www.axemtec.com
Siret : 45071140300045 - APE : 4652Z - RCS : CRETEIL 450711403 - N° TVA intracom : FR05450711403 - Capital : 500 000,00 €
15
7.4 Volume setup
1. Click “Volume” in App Center.
2. Setup volume.
7.5 Sensor
1. Click “Sensor” in App Center.
2. Setup the sensor.

File : MBA4_User_Guide_v1.0.docxMBA4
Version : V1.0
AXEM Technology
11 rue Auguste Perret, 94042 Créteil, FRANCE –[email protected] –[phone] –www.axemtec.com
Siret : 45071140300045 - APE : 4652Z - RCS : CRETEIL 450711403 - N° TVA intracom : FR05450711403 - Capital : 500 000,00 €
16
7.6 Keyboard
1. Click “Keyboard” in App Center.
2. Setup and test the main value of the device.

File : MBA4_User_Guide_v1.0.docxMBA4
Version : V1.0
AXEM Technology
11 rue Auguste Perret, 94042 Créteil, FRANCE –[email protected] –[phone] –www.axemtec.com
Siret : 45071140300045 - APE : 4652Z - RCS : CRETEIL 450711403 - N° TVA intracom : FR05450711403 - Capital : 500 000,00 €
17
7.7 Network
1. Click “Network” in App Center.
2. Test WIFI/Mobile signal by requirements.

File : MBA4_User_Guide_v1.0.docxMBA4
Version : V1.0
AXEM Technology
11 rue Auguste Perret, 94042 Créteil, FRANCE –[email protected] –[phone] –www.axemtec.com
Siret : 45071140300045 - APE : 4652Z - RCS : CRETEIL 450711403 - N° TVA intracom : FR05450711403 - Capital : 500 000,00 €
18
7.8 Keyboard emulator
The keyboard emulator can be used in multiple operating background and output formats
directly. It includes Prefix/Suffix/Enter/TAB.
Please check Keyboard emulator manual for more details.

File : MBA4_User_Guide_v1.0.docxMBA4
Version : V1.0
AXEM Technology
11 rue Auguste Perret, 94042 Créteil, FRANCE –[email protected] –[phone] –www.axemtec.com
Siret : 45071140300045 - APE : 4652Z - RCS : CRETEIL 450711403 - N° TVA intracom : FR05450711403 - Capital : 500 000,00 €
19
8Device features
Physical characteristics
Size
202.0 x 72.5 x 32.0 mm / 7.95 x 2.85 x 1.26 in.
Weight
390 g / 13.76 oz.
Display
4-inch display, LTPS LCD screen
Main Keyboard
37 keys in total Side keys: 2 SCAN keys + 2 volume keys + 1
user-defined key
Battery
5200 mAh removable main battery, 5200 mAh optional pistol
battery, support QC3.0 and RTC
Standby: over 300 hours (only main battery) Continuous use:
over 12 hours (depending on user environment)
Charging time: 2.5hours (charge device by standard adaptor
and USB cable)
Expansion
Supports up to 128 GB Micro SD card
Expansion Slot
1 slot for SIM card, 1 slot for TF card
Audio
1 Microphones, 1 Speaker
Camera
13MP autofocus camera with flashlight
Performance
CPU
Qualcomm 1.8 GHz Octa-core
OS
Android 9
RAM
3GB
Communication
Interface
USB3.0,Type-C
ROM
32GB
Max. expansion
Supports up to 128 GB Micro SD card
