axiome eBARman User manual

Before getting started
EBARman
Stylus pen
Power adaptor
Battery
CF open cover
Hand strip holder (option)
Ear/Microphone set
Sync cable
Turn on the Backup battery
Open the package and check every accessory:
Replace the battery
pack cover.
Connect power
adaptor to charge
the device.
Turn on battery.
Remove battery cover
and battery. Move upwards
the battery switch (see picture above)
to turn on battery.
If device wont be used for
a long time, turn off the
switch to save battery.
Page 2
Document Version 1.1

10
1. Scanner Window
2. Scanner LED Indicator
( : Read Successful; : Read Error)
3. LCD Screen
4. Navigation Keys
5. Home Application button
6. USB Host
7. Sync Port
8. DC Power Jack
9. Keypad
10. Power and Backlight Button
( Press button to turn device on/off, when on hold button
for 1 second to turn backlight on)
11. Power LED Indicator
( : Charging Complete; : Charging)
12. SD Slot
13. Left Barcode Scan Button
Green
Green
Red
Red
eBARman overview
front
123
4
5
6
7
8
9
11
12 13
Page 3
Document Version 1.1

1. Compact Flash Type I/II Slot
2. Screw Hole
3. CF Type Slot Cover Lock Switch
4. IR Port
5. Hand Strap holder
6. Battery Pack Cover
7. Battery Pack Cover Lock Switch
8. Reset Key
9. Internal Speaker
10. Right Barcode Scan Button
11. Ear/Microphone Jack
12. Stylus Pen
eBARman overview
back
12
3
4
5
6
7
8
9
10
11
12
Page 4
Document Version 1.1

Device can read barcode from 40 to 300mm distance.
WRONG barcode scanner position!
RIGHT barcode scanner position!
Barcode reading
1. Execute barcode application
2. Aim the scan window at the barcode
3. Press “R” or “L” scan key
4. Aim the laser beam at the center of the barcode
5. Check the barcode reading result
Page 5
Document Version 1.1

Using peripherals
CF Type Peheripherals
1. Open CF slot cover
2. Insert correctly oriented a CF card
3. Close the CF slot cover
SD/MMC type card
1. Open SD/MMC slot cover
2. Insert correctly
oriented a SD/MMC card
3. Close the SD/MMC slot cover
USB/Serial Connection
Generally its used for
synchronised data transmission
with desktop.
Connect the data sync cable.
If you use data sync cable, you need
to install Microsoft active sync 3.7 or above
Page 6
Document Version 1.1

Software Tips
battery
To configure your eBARman
use Control Panel
Chose Power Properties and
check battery status.
Adjust Power Schemes
for better power saving.
Page 7
Document Version 1.1

Software Tips
sync software
To activate data synchronisation software:
Start - Programs - Communication
and run required application.
Page 8
Document Version 1.1

Software Tips
Point at icon in right bottom corner of screen
to switch between applications.
Use Date/Time Properties to adjust
time and date settings.
Use Input Panel to enter text with stylus pen.
Run My Computer to access your data.
Page 9
Document Version 1.1

Using Keypad
Press [KBD] + [number] to get special symbols
Press [KBD] + [TAB] to switch to alphabetic keyborad
then press again [KBD] + [TAB] to switch to Uppercase letters
and press [KBD] + [TAB] to return to numbers. See diagramm:
Press [Fn] + [number] to access special function keys:
[Fn] + [1] - Activate wireless network
[Fn] + [2] - Turn sound on/off
[Fn] + [3] - Backspace
[Fn] + [4] or [5] or [6] - Run programmed application
[Fn] + [7] - Copy
[Fn] + [8] - Paste
[Fn] + [9] - Rotate screen
[Fn] + [0] - Delete
[Fn] + [ . ] - Run Task Manager
[Fn] + [ENTER] - Screen calibration
[Fn] + [ESC] - Run Media Player
All functional keys are programmable.
[Keys]
on screen = ‘1234’
[KBD] + [TAB]
[Keys]
on screen = ‘abcd’
[Keys]
on screen = ‘ABCD’
[KBD] + [TAB]
[KBD] + [TAB]
Page 10
Document Version 1.1

Warning
1.
2.
3.
O
4.
5.
6.
Never stare directly into the laser beam or shine the laser
light into the eyes.
Never apply strong pressure to the screen to avoid
cracking the screen or LCD panel glass, which can
cause the danger of personal injury.
If the LCD panel glass breaks, never touch the liquid
inside, which can cause skin inflammation.
Be sure to use only the AC adaptor we provide.
ther AC adaptor models might create electric
problems or the danger of fire and electric shock.
This device has passed the rating IP54 for water and
dust proof standard, but it is better not to use it under
rain / water too long.
If the environment conditions are over the standard IP54,
water may enter the product and cause damage.
Do not disassemble or reassemble the device except those
who have been trained for that.
Be sure to make backup copies of all important data.
For instance, using the separately soId Cradle to transfer
data to a computer. Note that seller shall not be held liable to
anyone for any damages or loss caused by deletion or
corruption of data due to use of this device or due
to the batteries going dead.
Vers. 1.1
Page 11
