AXIOMTEK p6101 User manual

P6101
10.4” XGA TFT Monitor
User’s Manual

ii
Disclaimers
This manual has been carefully checked and believed to contain accurate information.
Axiomtek Co., Ltd. assumes no responsibility for any infringements of patents or any third
party’s rights, and any liability arising from such use.
Axiomtek does not warrant or assume any legal liability or responsibility for the accuracy,
completeness or usefulness of any information in this document. Axiomtek does not make any
commitment to update the information in this manual.
Axiomtek reserves the right to change or revise this document and/or product at any time
without notice.
No part of this document may be reproduced, stored in a retrieval system, or transmitted, in
any form or by any means, electronic, mechanical, photocopying, recording, or otherwise,
without the prior written permission of Axiomtek Co., Ltd.
CAUTION
If you replace wrong batteries, it causes the danger of explosion. It is recommended by the
manufacturer that you follow the manufacturer’s instructions to only replace the same or
equivalent type of battery, and dispose of used ones.
Copyright 2017 Axiomtek Co., Ltd.
All Rights Reserved
Apr 2017, Version A1
Printed in Taiwan

iii
Safety Precautions
Before getting started, read the following important cautions.
1. Be sure to ground yourself to prevent static charge when installing the internal
components. Use a grounding wrist strap and place all electronic components in any
static-shielded devices. Most electronic components are sensitive to static electrical
charge.
2. Disconnect the power cords from the P6101 Series before making any installation. Be
sure both the system and the external devices are turned OFF. Sudden surge of power
could ruin sensitive components. Make sure the P6101 Series is properly grounded.
3. Do not open the system’s top cover. If opening the cover for maintenance is a must, only
a trained technician is allowed to do so. Integrated circuits on computer boards are
sensitive to static electricity. To avoid damaging chips from electrostatic discharge,
observe the following precautions:
Before handling a board or integrated circuit, touch an unpainted portion of the
system unit chassis for a few seconds. This will help to discharge any static
electricity on your body.
When handling boards and components, wear a wrist-grounding strap, available
from most electronic component stores.
Trademarks Acknowledgments
Axiomtek is a trademark of Axiomtek Co., Ltd.
Windows®is a trademark of Microsoft Corporation.
IBM, PC/AT, PS/2, VGA are trademarks of International Business Machines Corporation.
Intel®and Pentium®are trademarks of Intel Corporation.
AMI is trademark of American Megatrend Inc.
Other brand names and trademarks are the properties and registered brands of their
respective owners.

iv
Table of Contents
Disclaimers.....................................................................................................ii
Safety Precautions........................................................................................iii
Chapter 1 Introduction............................................. 1
1.1 General Description............................................................................1
1.2 Features...............................................................................................2
1.3 Specifications......................................................................................2
1.4 Dimensions and Outlines ...................................................................3
1.5 I/O Outlets............................................................................................4
1.6 Packing List.........................................................................................5
Chapter 2 System Setup .......................................... 7
2.1 System Configuration.........................................................................7
2.2 Panel Mounting ...................................................................................8
2.3 Wall Mounting......................................................................................8
2.4 VESA Mounting ...................................................................................9
2.5 System Jumper Setting ....................................................................10
Appendix A Supported Input Timing Modes ............. 11
Appendix B OSD Operation........................................ 13
Function Description of OSD Menu............................................................13

P6101 User’s Manual
Introduction 1
Chapter 1
Introduction
This chapter contains general information and detailed specifications of the P6101. Chapter 1
includes the following sections:
General Description
Features
Specifications
Dimensions and Outlines
I/O Outlets
Package List
1.1 General Description
The P6101, an industrial 10.4 inches view area LCD Monitor comes with slim, light and reliable
features to replace traditional bulky CRT for Industrial application. Its unique flat design is fit for
panel mounting, VESA mounts and Wall mounting. The display interface offers DVI-D, HDMI
and VGA for different input source from PC system or multimedia system that let you upgrade
the display don’t change anything from your system. Besides, for varied HMI field, you can
choose one of resistive touch or glass interface to meet your application. In addition, this
monitor has more comfort, safety, and environmental protection for humanized & health
consideration those would be the benefit that users can get.
This LCD monitor builds in color active matrix thin-film-transistor (TFT) liquid crystal display to
provide superior display performance. A maximum resolution of 1024x768 is ideal for
displaying complex graphics and high definition images. Other outstanding designs that
enhance this LCD monitor’s performance are Plug & Play compatibility, and OSD (On Screen
Display) controls, especially OSD, it made you ease adjustment on screen image.

P6101 User’s Manual
2 Introduction
1.2 Features
High contrast color 10.4”XGA TFT LCD display support resolution up to 1024x768
Flat design with NEMA4/IP65-compliant
Suits with resistive touch or glass
High Brightness and Ultra-wide viewing angle with anti-glare features.
Power management system conforms to VESA DPMS standard
Advanced OSD control for picture quality adjustment
Supports VESA ARMs, Desktop Stand Rear, Panel and Wall mounting
1.3 Specifications
10.4” XGA(1024x768) LCD with LED backlight
Resistive Touch or glass
Front bezel design with NEMA4/IP65
Control: OSD (On Screen Display) control pad on the side
Mounting: Support Panel mount, VESA arm mount and Wall mount (optional)
Net Weight
P6101O: 1.59KG
P6101P:1.94KG
Dimension (Main Body Size)
P6101O: 246.3x 192.3x 51 mm
P6101P: 277.5x 223.55x 48 mm
Operation Temperature
-20℃to 55℃
Relative Humidity
20% to 90% @ 40℃, Non-Condensing
Power input
Screw-type external AC or 12V/24VDC-in
Max power consumption: 8W
NOTE: 1. All specifications and images are subject to change without notice.
2. If vibration is over 1GHz, LCD will have twinkle that is a normal phenomenon.
When the vibration of system goes back 1GHz, the twinkle would disappear.
3.Maximum for Line in: 1V

P6101 User’s Manual
Introduction 3
1.4 Dimensions and Outlines
The following diagrams show the dimensions and outlines of P6101
P6101P:
P6101O:

P6101 User’s Manual
4 Introduction
1.5 I/O Outlets
Please refer to the following illustration for I/O locations of the P6101.
No
Function
No
Function
1
Menu (Enter function)
7
Screw type or
Phoenix type power input
2
SEL+
8
HDMI
3
SEL-
9
DVI-D
4
Exit/Auto Adjust
10
VGA
5
Power LED
11
Audio
6
Power Switch
12
RS-232 or USB for Touch
12 11 10 9 8 7
1
2
3
4
5
6

P6101 User’s Manual
Introduction 5
1.6 Packing List
When you receive the P6101, the bundled package should contain the following items:
P6101 unit x 1
VGA cable x1
USB cable or RS-232 cable x1 (for resisitve touch version only )
Adaptor x1 (for AC version only)
Panel mount kit x 4 (optional)
HDMI cable x1 (optional)
DVI cable x1 (optional)
Wall mount bracket x1 (optional)
If you can not find the package or any items are missing, please contactAxiomtek distributors
immediately.

P6101 User’s Manual
6 Introduction
This page is intentionally left blank.

P6101 User’s Manual
System Setup
7
Chapter 2
System Setup
This chapter details the system parts and components with figures. Sections include:
System Configuration
Panel Mounting
Wall Mounting
VESA Mounting
2.1 System Configuration
The figure below shows the side views of P6101 series.
1. Menu:
Press this button to turn on/off the OSD (On Screen Display) main menu.
Press this button to activate selected items.
2. SEL+:
To scroll up the menu.
To increase the value of selected item.
3. SEL-:
To scroll down the menu.
To decrease the value of selected item.
4. Exit:
Jump out the selection icon.
Auto adjusts.
5. Power LED:
When the light is green, the power is on, red light when stand by.
6. Power switch:
Press this button to turn on/off the monitor.
1
2
3
4
5
6

P6101 User’s Manual
8 System Setup
2.2 Panel Mounting
The P6101 is designed for panel mount application. To mount the P6101, the standard set of
mounting kit (included in the system packaging) is needed.
▲P6101 Panel Mount kits
2.3 Wall Mounting
The P6101 provides VESA mount and wall mount. Screw four screws to fix the kit in the back
chassis.

P6101 User’s Manual
System Setup
9
2.4 VESA Mounting
The P6101 provides VESA mount at the back of system. Screw four screws to fix the kit in the
back chassis.

P6101 User’s Manual
10 System Setup
2.5 System Jumper Setting
12V DC IN
12V in only: JP3(1-3)(2-4), JP4(1-3)(2-4)
24V DC IN
24V in only: JP3(3-5)(4-6), JP4(3-5)(4-6)
Jumper
★Default Setting
Jumper Setting
JP3
12V DC in (VINO-12V) (Default)
24V DC in (VINO-12V)
Short 1-3, Short 2-4
Short 3-5, Short 4-6
JP4
12V DC in (Default)
24V DC to 12V DC
Short 1-3, Short 2-4
Short 3-5, Short 4-6

P6101 User’s Manual
Supported Input Timing Modes
11
Appendix A
Supported Input Timing Modes
Supported Input Timing Modes
Pixel Format
Refresh
Rate
Horizontal
Frequency
vertical
Frequency
Pixel
Frequency
Standard
Type
NOTE
640*480
60 Hz
31.5 kHz
59.94 Hz
25.175 MHz
Industry Standard
72 Hz
37.9 kHz
72.80 Hz
31.500 MHz
VESA Standard
75 Hz
37.5 kHz
75 Hz
31.500 MHz
VESA Standard
800*600
56 Hz
35.2 kHz
56.25 Hz
36.000 MHz
VESA Guidelines
60 Hz
37.9 kHz
60.317 Hz
40.000 MHz
VESA Guidelines
75 Hz
46.9 kHz
75 Hz
49.500 MHz
VESA Standard
1024*768
60 Hz
48.4 kHz
60 Hz
65.000 MHz
VESA Guidelines
70 Hz
56.5 kHz
70 Hz
75.000 MHz
VESA Standard
75 Hz
60.0 kHz
75 Hz
78.750 MHz
VESA Standard
1280*1024
60 Hz
64.0 kHz
60.020 Hz
108.000 MHz
VESA Standard
75 Hz
80.0 kHz
75.025 Hz
135.000 MHz
VESA Standard
1360*768
60 Hz
47.7 kHz
60.015 Hz
85.500 MHz
VESA Standard
//VGA Only
1366*768
60 Hz
47.7 kHz
59.79 Hz
85.500 MHz
VESA Standard
//DVI, HDMI
Only
1680*1050
60 Hz
65.3 kHz
59.954 Hz
146.250 MHz
CVT
1920*1080
60 Hz
67.5 kHz
60 Hz
148.500 MHz
CEA Standard
NOTE: Timing depends on LCD Panel’s requirement.

P6101 User’s Manual
12 Supported Input Timing Modes
This page is intentionally left blank.

P6101 User’s Manual
OSD Operation 13
Appendix B
OSD Operation
Function Description of OSD Menu
※The layout and format of OSD depends on customer’s request.
OSD MENU
Description
Luminance
Luminance：
Brightness
Contrast
Sharpness
Phase
Clock
H position
V position
Color
Color:
Color Temperature (6500,7500,9300,user define)
Red
Green
Blue.
OSD
OSD Settings：
Horizontal
Vertical
Transparency
OSD Time out .
Setup
Setup:
Language
Volume
Mute
Input
Reset

P6101 User’s Manual
14 OSD Operation
This page is intentionally left blank.
