Philips
LCD monitor
81 cm (32")
multimedia
HD Ready
BDL3215E
The best all round public signage display
for indoor applications
Control your costs with this network-controllable 81 cm (32") LCD monitor. Whether
used in a network or as a single public display, this model offers a variety of features to
meet the most demanding public and corporate viewing applications.
Operational flexibility
• VGA Loop through
• Portrait mode operability
• Designed for 24/7 operation
• Remote Management and Configuration via RS232
Optimised for public viewing
• Wide format WXGA 1366 x 768 resolution for sharper display
• Enhanced zoom feature supports tiled matrix applications
• HDMI input for full digital HD connection in one cable
Lower total cost of ownership
• SmartPower for energy saving
• Advanced anti-image sticking function
Sustainable and safe
• Complies with RoHS standards of care for the environment

BDL3215E/00
Highlights
LCD monitor
81 cm (32") multimedia, HD Ready
WXGA 1366 x 768 resolution
The wide format of XGA resolution LCD
panel is capable of displaying 1366 x 768 pixels;
WXGA allows monitors to be non-interlaced
to ensure a better display performance and
accurate colour display effect.
Zoom function for tiled matrix
The internal zoom function enables easy
implementation of a video wall matrix, without
the need for expensive external equipment.
Capable of a vidiwall of 25 displays by dividing
up to 5 displays each horizontally and
vertically.
HDMI input
HDMI makes an uncompressed digital RGB
connection from the source to the screen. By
eliminating conversion to an analogue signal, it
delivers an unblemished image. The non-
degraded signal reduces flicker and leads to a
clearer picture. HDMI intelligently
communicates the highest output resolution
with the source device. The HDMI input is fully
backwards-compatible with DVI sources but
includes digital audio. HDMI uses HDCP copy
protection.
SmartPower
The backlight intensity can be controlled and
pre-set by the system to reduce the power
consumption by up to 50%, which saves
substantially on energy costs.
Advanced anti-image sticking
Static images left on-screen for extended
periods of time may leave a "ghost image" or
image sticking effect on LCD displays.
Although image sticking on LCD displays is not
permanent, you want to prevent this
happening, especially in locations where
content is shown 24/7.
Compliant with RoHS standards
Philips designs and produces display products
in compliance with strict Restriction of
Hazardous Substances (RoHS) standards that
restrict lead and other toxic substances that
can harm the environment.
Designed for 24/7 operation
Because business never sleeps, our signage
displays are designed for 24/7 use. Taking
advantage of superior components to ensure a
higher level of quality, you can count on this
range of models for complete around-the-
clock reliability.
Remote Management: RS232
Remote Management allows the user to
control and adjust the displays remotely via the
RS232 protocol. Using CEC commands, you
are able to have full control over all the
displays in your signage network at any time.

Issue date 2017-08-08
Version: 5.4.3
12 NC: 8670 000 58235
EAN: 87 12581 51555 3
© 2017 Koninklijke Philips N.V.
All Rights reserved.
Specifications are subject to change without notice.
Trademarks are the property of Koninklijke Philips N.V.
or their respective owners.
www.philips.com
BDL3215E/00
Specifications
LCD monitor
81 cm (32") multimedia, HD Ready
Picture/Display
• Diagonal screen size: 32 inch / 81 cm
• Panel resolution: 1366 x 768p
• Optimum resolution: 1360 x 768 @ 60 Hz
• Brightness: 450 cd/m²
• Contrast ratio (typical): 3000:1
• Response time (typical): 8 ms
• Aspect ratio: 16:9
• Viewing Angle (H / V): 178 / 178 degree
• Pixel pitch: 0.511 x 0.511
• Display colours: 16.7 million colours
• Picture enhancement: 3/2 - 2/2 motion pull down,
3D Combfilter, Motion compens. deinterlacing,
Progressive scan, 3D MA deinterlacing, Dynamic
contrast enhancement
Supported Display Resolution
•Computer formats
Resolution Refresh rate
640 x 480 60, 67, 72, 75 Hz
800 x 600 56, 60, 72, 75 Hz
1024 x 768 60 Hz
1280 x 768 60 Hz
1280 x 800 60 Hz
1280 x 1024 60 Hz
1360 x 768 60 Hz
1366 x 768 60 Hz
1440 x 900 60 Hz
1600 x 1200 60 Hz
1920 x 1080 60 Hz
1920 x 1200 60 Hz
•Video formats
Resolution Refresh rate
480i 60 Hz
480p 60 Hz
576p 50 Hz
576i 50 Hz
720p 50, 60 Hz
1080i 50, 60 Hz
1080p 50, 60 Hz
Connectivity
• PC: VGA-in D-Sub 15HD, VGA-out D-Sub 15HD,
DVI-D x 1, RS232 D-Sub9, RS232 D-sub9 output,
3.5 mm PC audio input x 1
• AV input: HDMI x 1, Component (BNC) x 1,
Composite (RCA) x 1, Composite (BNC) x 1, S-
video x 1, Audio (L/R) x 2
• AV output: Composite (BNC) x 1, Audio (L/R) x 1
Convenience
• Placement: Portrait, Landscape
• Tiled Matrix: 5 x 5
• Picture in picture: PBP, PIP, POP
• Screen-saving functions: Pixel shift, Low bright
• Signal Loop Through: RS232, VGA
• Keyboard control: Hidden, Lockable
• Remote control signal:: Lockable
•Ease of installation: Carrying Handles
• Energy-saving functions: Smart Power
• Picture performance: Advanced colour control
• Network controllable: RS232
Dimensions
• Bezel thickness: 4.6 cm/1.81 inch
• Set dimensions (W x H x D): 792 x 487 x 115 mm
• Set dimensions in inch (W x H x D):
31.2 x 19.2 x 4.5 inch
• Set dimensions with stand (H x D): 531 x 205 mm
•Setdimensionswithstand in inch (H x D):
20.9 x 8.1 inch
• Product weight: 11.95 kg
• Product weight (lb): 26.35
• VESA Mount: 200 x 200 mm, 400 x 200 mm
Operating conditions
• Temperature range (operation): 0 - 40 °C
• Relative humidity: 5 - 90 %
• MTBF: 50,000 hour(s)
Power
• Mains power: 90-264 VAC, 50/60 Hz
• Consumption (On mode): Typ. 67 W
• Standby power consumption: <1 W
Sound
• Built-in speakers: 2 x 7 W (8 ohm)
Accessories
• Included accessories: Remote Control, Batteries
for remote control, AC Power Cord, VGA cable,
User manual on CD-ROM, Quick start guide,
Tabletop stand
• Optional accessories: Fixed wall mount, Flexible
wall mount, Ceiling mount
Miscellaneous
• Bezel: metallic anthracite
• Warranty: Europe/North America: 3 years
•On-Screen Display Languages: English, French,
German, Italian, Polish, Turkish, Russian, Simplified
Chinese
• Regulatory approvals: CE, FCC, Class B, UL/cUL,
CCC, RoHS
•
