Philips BDL3245E User manual

Philips
LCD monitor
81 cm (32")
Digital Signage
Full HD
BDL3245E
Draw in your audience in style
with this multi-functional Display
Deliver vital information or marketing messages to your audience in startling clarity with
this 32" display. With a host of connection options, it is ideal for projects where economy
is key.
Optimized for public viewing
• Full HD LCD display, 1920x1080p
• HDMI input for full digital HD connection in one cable
Operational flexibility
• Network Controllability: RJ45
• VESA mounting pattern for easy wall mounting of display
• Remote Management and Configuration via RS232
• Portrait mode operability
Lower total cost of ownership
• SmartPower for energy saving
• Advanced anti image sticking function
Sustainable and safe
• Complies with RoHS standards to care for the environment

BDL3245E/00
Highlights
LCD monitor
81 cm (32") Digital Signage, Full HD
Full HD LCD display 1920x1080p
This display has a resolution that is referred to
as Full HD. The state-of-the-art LCD screen
technology has the full high-definition
widescreen resolution of 1080 progressive
lines, each with 1920 pixels. This allows the
best possible picture quality for HD input
signals with up to 1080 lines. It produces
brilliant flicker-free progressive scan pictures
with optimum brightness and superb colors.
This vibrant and sharp image will provide you
with an enhanced viewing experience.
RJ45
Simple management of your display is available
thanks to the introduction of a LAN (RJ45)
port. You can configure each display or find
out the status of each device quickly and
conveniently via an RJ45 connection.
HDMI input
HDMI makes an uncompressed digital RGB
connection from the source to the screen. By
eliminating conversion to an analog signal, it
delivers an unblemished image. The non-
degraded signal reduces flicker and leads to a
clearer picture. HDMI intelligently
communicates the highest output resolution
with the source device. The HDMI input is fully
backward compatible with DVI sources but
includes digital audio. HDMI uses HDCP copy
protection.
SmartPower
The backlight intensity can be controlled and
pre-set by the system to reduce the power
consumption by up to 50%, which saves
substantially on energy costs.
Remote Management:: RS232
Remote Management allows the user to
control and adjust the displays remotely via the
RS232 protocol. Using CEC commands, you
are able to have full control over all the
displays in your signage network at any time.
Advanced anti image sticking
Static images left on-screen for extended
periods of time may leave a "ghost image" or
image sticking effect on LCD displays.
Although image sticking in LCD displays is not
permanent, you want to prevent this to
happen, especially in locations where content
is shown 24/7.
Compliant with RoHS standards
Philips designs and produces display products
in compliance with strict Restriction of
Hazardous Substances (RoHS) standards that
restrict lead and other toxic substances that
can harm the environment.

Issue date 2014-03-17
Version: 8.3.2
12 NC: 8670 000 81175
EAN: 87 12581 61823 0
© 2014 Koninklijke Philips N.V.
All Rights reserved.
Specifications are subject to change without notice.
Trademarks are the property of Koninklijke Philips N.V.
or their respective owners.
www.philips.com
BDL3245E/00
Specifications
LCD monitor
81 cm (32") Digital Signage, Full HD
Picture/Display
• Diagonal screen size: 31.55 inch / 80.1 cm
• Panel resolution: 1920x1080p
• Optimum resolution: 1920 x 1080 @ 60Hz
• Brightness: 500 cd/m²
• Contrast ratio (typical): 1450:1
• Response time (typical): 5 ms
• Aspect ratio: 16:9
• Viewing angle (H / V): 178 / 178 degree
• Pixel pitch: 0.364 x 0.364
• Display colors: 1.06 Billion Colors
• Picture enhancement: 3/2 - 2/2 motion pull down,
3D Combfilter, Motion compens. deinterlacing,
Progressive scan, 3D MA deinterlacing, Dynamic
contrast enhancement
Supported Display Resolution
•Computer formats
Resolution Refresh rate
640 x 480 60, 67, 72, 75Hz
800 x 600 56, 60, 72, 75Hz
1024 x 768 60Hz
1280 x 768 60Hz
1280 x 800 60Hz
1280 x 1024 60Hz
1360 x 768 60Hz
1366 x 768 60Hz
1440 x 900 60Hz
1600 x 1200 60Hz
1920 x 1080 60Hz
1920 x 1200 60Hz
•Video formats
Resolution Refresh rate
480i 60Hz
480p 60Hz
576p 50Hz
576i 50Hz
720p 50, 60Hz
1080i 50, 60Hz
1080p 50, 60Hz
Connectivity
• PC: VGA-in D-Sub 15HD, VGA-out D-Sub 15HD,
DVI-D x1, RS232 D-Sub9, RS232 D-sub9 output,
3.5 mm PC audio input x1, RJ45
• AV input: HDMI x1, Component (BNC) x1, S-
video x1, Audio (L/R) x2, Composite (BNC) x1
• AV output: Composite (BNC) x1, Audio (L/R) x1
Convenience
• Placement: Portrait, Landscape
• Tiled Matrix: 5 x 5
• Picture in picture: PBP, PIP, POP
• Screen saving functions: Pixel shift, Low bright
• Signal Loop Through: RS232, VGA
• Keyboard control: Hidden, Lockable
• Remote control signal:: Lockable
• Ease of installation: Carrying Handles
• Energy saving functions: Smart Power
• Picture performance: Advanced color control
• Network controllable: RS232, RJ45
• Packaging: Reusable box
Dimensions
• Bezel thickness: 36mm/1.4"
• VESA Mount: 200 x 200mm, 400 x 200mm
• Product weight: 12.8 kg
• Product weight (lb): 28.2 lb
• Set dimensions (W x H x D): 774 x 468 x 116 mm
• Set dimensions in inch (W x H x D):
30.5 x 18.4 x 4.6 inch
Operating conditions
• Temperature range (operation): 0 - 40 °C
• Relative humidity: 5 - 90 %
• MTBF: 50.000 hour(s)
Power
• Consumption (On mode): Typ. 88W
• Standby power consumption: <0.5W
Sound
• Built-in speakers: 2 x 10W
Accessories
• Included accessories: Remote Control, Batteries
for remote control, AC Power Cord, VGA cable,
User manual on CD-ROM, Quick start guide
• Stand: BM03211 (optional)
Miscellaneous
• Warranty: Europe/North America: 3 years
• On-Screen Display Languages: English, French,
German, Italian, Polish, Turkish, Russian, Simplified
Chinese
• Regulatory approvals: CE, FCC, Class B, UL/cUL,
CCC, RoHS, C-Tick
•
