Marshall Electronics
V-R841DP-AFHD
Portable High Definition LCD Monitor
Operating Instructions
Ver. 2010-0216

2 19
Warranty
Marshall Electronics warranties to the first consumer that this V-R841DP-AFHD LCD monitor will, under normal use, be
free from defects in workmanship and materials, when received in its original container, for a period of one year from the
purchase date. This warranty is extended to the first consumer only, and proof of purchase is necessary to honor the
warranty. If there is no proof of purchase provided with a warranty claim, Marshall Electronics reserves the right not to
honor the warranty set forth above. Therefore, labor and parts may be charged to the consumer. This warranty does not
apply to the product exterior or cosmetics. Misuse, abnormal handling, alterations or modifications in design or
construction void this warranty. It is considered normal for a minimal amount of pixels, not to exceed three, to fail on the
periphery of the display active viewing area. Marshall Electronics reserves the option to refuse service for display pixel
failure if deemed unobtrusive to effective use of the monitor by our technicians. No sales personnel of the seller or any
other person is authorized to make any warranties other than those described above, or to extend the duration of any
warranties on behalf of Marshall Electronics, beyond the time period described above. Due to constant effort to improve
products and product features, specifications may change without notice.
07/17/07

18
Optional Accessories
■Batteries
• IDX-E7S 71Wh/4.8Ah Lithium Ion V-Mount Battery Pack
• IDX-E7 71Wh/4.8Ah Lithium Ion V-Mount Battery Pack with PowerLink
• IDX-E10S 98Wh/6.6Ah Lithium Ion V-Mount Battery Pack
• IDX-E10 98Wh/6.6Ah Lithium Ion V-Mount Battery Pack with PowerLink
■Battery Chargers
• IDX-VL-2 Plus 2-Channel Sequential Multi-Format V-Mount Quick Charger/Power Supply
• IDX-VL-4S 4-Channel Simultaneous V-Mount Quick Charger
■Battery Adapters
• V-ABA-01 Anton Bauer to IDX Battery Adapter Plate
■Power Adapter Cables
• V-PAC-D-XLR 4-Pin XLR Male to Anton Bauer PowerTap Cable (3 ft.)
• V-PAC-XLR-1 4-Pin XLR Male to 4-Pin XLR Female Cable (3 ft.)
■Stands, Adapters, and Mounts
• VP-0113-DS-A Fixed Desktop Stand
• VP-0113-PM-B 19” Rack Adapter for up to 2 Monitors (4RU)
• V-LCD70TMB-02 Set of 3 ¼”-20 Tripod Mounting Brackets
• V-DG1105 Noga 8.3” Articulating Arm (¼”-20 to ¼”-20). Holds up to 4.5 lbs.
• V-MG11043 Noga 9.7” Articulating Arm (3/8” to ¼”-20). Holds up to 7.5 lbs.
• V-LP-SLDSHOE1/4 Slide-Shoe Adapter with Nut, for Noga Articulating Arm
• V-LP-SLDSHOEBLOCK Slide-Shoe Block (Required with V-LP-SLDSHOE1/4)
• V-LP-SLDSHOENUT Extra Slide-Shoe Nut for V-MG11043 in Slide-Shoe Configuration
• V-VP-TBRKT Expansion T-Bracket (¼”-20 and 3/8” holes)
■Sun Hoods
• V-H900 Sun Hood for 8.4” Monitors
■Cleaning Accessories
• V-HWP-K Package of 10 Cleaning Wipes for LCD Displays
Visit www.LCDRacks.com for more information and additional accessories
3
Contents
Product Overview.....................................................................................................................................................4
Features ....................................................................................................................................................................4
Installation and Initial Setup ...................................................................................................................................5
Unpacking .............................................................................................................................................................. 5
Installation.............................................................................................................................................................. 5
Connections and Power-On................................................................................................................................... 5
Front Panel Features ...............................................................................................................................................6
Power Button ........................................................................................................................................................ 6
Input Select Buttons............................................................................................................................................... 6
On-Screen Menu Navigation Buttons ....................................................................................................................6
User-Definable Function Buttons...........................................................................................................................6
Image Adjustment Knobs....................................................................................................................................... 6
Tally Lights............................................................................................................................................................. 6
Rear Panel Features.................................................................................................................................................7
Power Input............................................................................................................................................................ 7
Signal Input/Output ................................................................................................................................................ 7
Tally Interface ........................................................................................................................................................ 7
Mounting Holes ...................................................................................................................................................... 7
Compatible Input Formats.......................................................................................................................................8
On-Screen Menu.......................................................................................................................................................9
STRUCTURE OVERVIEW .................................................................................................................................... 9
MAIN MENU AND NAVIGATION .......................................................................................................................... 9
MARKER SETUP SUBMENU ............................................................................................................................. 10
16:9 Markers.................................................................................................................................................... 10
4:3 Markers...................................................................................................................................................... 11
Marker Background ......................................................................................................................................... 11
Center Marker.................................................................................................................................................. 11
VIDEO CONFIGURATION SUBMENU ............................................................................................................... 12
Color Temperature Presets ............................................................................................................................. 12
Adjusting Color Bias ........................................................................................................................................ 12
Adjusting Color Gain........................................................................................................................................ 12
Monochrome Mode.......................................................................................................................................... 13
Blue Only Mode ............................................................................................................................................... 13
Pixel-to-Pixel™Mode ...................................................................................................................................... 13
Aspect Ratio Setting ........................................................................................................................................ 14
Scanning Modes.............................................................................................................................................. 14
Delay Modes.................................................................................................................................................... 14
SYSTEM CONFIGURATION SUBMENU............................................................................................................ 15
Internal SMPTE Color Bars ............................................................................................................................. 15
User-Definable Function Buttons .................................................................................................................... 15
Status Display.................................................................................................................................................. 15
Saving and Loading User Configuration Presets ............................................................................................15
Specifications.........................................................................................................................................................16
Maintenance............................................................................................................................................................17
Optional Accessories ...........................................................................................................................................18
Warranty..................................................................................................................................................................19

4
Product Overview
The V-R841DP-AFHD is a 8.4” high definition LCD monitor featuring our completely digital TFT-MegaPixel™active matrix
LCD platform. Weighing only 3.4 lbs, this monitor is ideal as a light-weight high resolution viewfinder or focus-assist
monitor. The V-R841DP-AFHD can also be rack-mounted with an optional 4RU adapter, or used in a desktop
configuration with optional desktop stand . Emulation of SMPTE-C/EBU color and adjustable color temperature enable the
most precise color representation possible. Our proprietary digital signal processing features 10-bit A/D conversion of all
analog signals, with 4X over-sampling and 5-line super-adaptive 2D comb filtering of composite signals. De-interlacing is
performed using our HyperProcess™algorithm with motion adaptive interpolation. Multi-format compatibility
accommodates virtually all video formats including NTSC/PAL, 480i/p, 720p, and 1080i/p standards. VGA and DVI inputs
accept VESA standards allowing the display to be used as a computer monitor. Advanced features include aspect ratio
settings, a variety of screen markers, underscan mode, blue-only mode, monochrome mode, H/V delay, and Pixel-to-
Pixel™mode.
Features
■High-Resolution 8.4” Panel
The V-R841DP-AFHD features an all-digital TFT-MegaPixel™active matrix LCD system with 2.4 million pixels. The
LCD panel features a brightness of 400 cd/m2, 400:1 contrast ratio, and a 170° all-around viewing angle making the
display ideal in a variety of environments and lighting conditions.
■Multi-Format Compatibility
With a variety of analog and digital inputs, the V-R841DP-AFHD accommodates virtually all video formats. Input types
include Composite Video,S-Video,YPbPr,SDI,VGA, and DVI with HDCP. Accepted formats include NTSC/PAL,
480i/p, 576i/p, 720p, 1035i, and 1080i/p standards, as well as VESA PC formats through SXGA (1280 x 1024).
■End-to-End Digital Signal Processing
Analog signals are digitized using an advanced 10-bit process with 4x over-sampling, 5-line super-adaptive 2D comb
filtering, and exacting color space conversion. Video is scaled to fit on the screen in the highest possible resolution
using a state-of-the-art LSI that incorporates precision gamma correction and our HyperProcess™motion adaptive
interpolation for interlaced images.
■ColorMatch™Conversion with Color Temperature Adjustment
Emulation of SMPTE-C/EBU color space allows the V-R841DP-AFHD to replace any broadcast CRT monitor. Settings
include D55, D65 and D95. Bias and Gain adjustment for each color enables precise color matching and white
balance.
■Advanced Features
Aspect ratio settings, underscan mode, blue-only mode, monochrome mode, and H/V delay are a few of the advanced
features making the V-R841DP-AFHD at home in any broadcast environment. Pixel-to-Pixel™mode also allows native
display of any incoming image format.
■Flexible Screen Markers
A variety of screen markers in both 4:3 and 16:9 modes allow accurate monitoring of the different aspect ratios used in
broadcast environments.
■User-Definable Function Buttons
Two user-assignable function buttons on the front-panel allow quick access to numerous settings and features
including aspect ratio, screen markers, monochrome mode, color temperature, delay mode, and more.
17
Specifications (continued)
Maintenance
■Screen Cleaning
Periodically clean the screen surface using ammonia-free cleaning wipes (Marshall Part No. V-HWP-K). A clean micro-
fiber cloth can also be used using only non-abrasive and ammonia-free cleaning agents. Do not use paper towels.
Paper towel fibers are coarse and may scratch the surface of the polycarbonate faceplate or leave streaks on the
surface. Antistatic and fingerprint resistant cleaning agents are recommended. Do not apply excessive pressure to the
screen to avoid damaging the LCD.
■Faceplate Dusting
Dust the unit with a soft, damp cloth or chamois. Dry or abrasive cloths may cause electrostatic charge on the surface,
attracting dust particles. Neutralize static electricity effects by using the recommended cleaning and polishing practice.

16
Specifications
■PANEL
Screen Size 8.4” Diagonal
Display Area (h x v) 170.469 x 127.872 mm
Aspect Ratio 4:3 Native (4:3/16:9 Modes)
Pixels 1024 x RGB x 768
Color Depth 24-bit (16,777,216 Colors)
Viewing Angle (h x v) 170° x 170°
Brightness 400 cd/m2
Contrast Ratio 400:1
Dot Pitch (h x v) 0.0555 x 0.1665 mm
Pixel Pitch (h x v) 0.1665 x 0.1665 mm
Pixel Response 25 ms (rise + fall)
■VIDEO INPUT/OUTPUT
Video Input / Output
Supports SMPTE 170M, NTSC/PAL
S-Video (Y/C) Input / Output
Supports SMPTE 170M, NTSC/PAL
YPBPRInput / Output
Supports SMPTE 260M, 274M, 296M
HD-SDI Input / Output
Supports ITU-R BT.656, SMPTE 259M, 292M
VGA Input
Supports RGBHV, RsGsBs, RGsB, RGB CS,
DVI Input
Supports Digital Signals Only (DVI-D)
HDMI, HDCP Supported
■CONNECTORS
Video Input
Video 1 x BNC Female (75 Ω)
S-Video (Y/C) 1 x 4-Pin Mini-DIN
YPBPR3 x BNC Female (75 Ω)
HD-SDI 1 x BNC Female (75 Ω)
VGA 1 x HD-15 Female
DVI 1 x DVI-I 29-Pin Female
Video Output (Active Loop-Through)
Video 1 x BNC Female (75 Ω)
S-Video (Y/C) 1 x 4-Pin Mini-DIN
YPBPR3 x BNC Female (75 Ω)
SDI 1 x BNC Female (75 Ω)
Power Input
4-Pin XLR Male
Tally Interface
HD-15 Female
■TALLY
3 LEDs (Green, Red, Yellow). Activation requires contact
closure of pin to ground on the HD-15 connector:
Pin No. Signal
1 Green
2 Red
3 Yellow
4 Ground
5 Ground
6 N/C
7 N/C
8 N/C
9 N/C
10 N/C
11 N/C
12 N/C
13 N/C
N/C
14
15 N/C
■ELECTRICAL
Power Consumption 2A @ 12VDC (24 W)
Voltage Requirement 12 VDC
V-PS12-5V-XLR Power Supply:
Input 100V-240V, 1.5A, 50-60Hz
Output 12VDC, 5A, 60W Max
V-Mount Battery Adapter
(Accepts standard 12V / 14.4V V-Mount Batteries)
■MECHANICAL
Dimensions (w x h x d): 9.00” x 7.00” x 1.87”
Additional Mounting: Desktop Stand and Rack Adapter
Available
Weight (Monitor Only): 3.4 lbs
Operating Temperature 32°F to 120°F (0°C to 50°C)
Storage Temperature -4°F to120°F (-20°C to 50°C)
Compliance ₠, FCC-Class A, ANSI-63.4
(Certificates on file)
RoHs Do not dispose. Return to
Manufacturer or Authorized
Recycle Facility.
5
Installation and Initial Setup
■Unpacking
Carefully unpack the V-R841DP-AFHD monitor and verify that the following items are included:
• V-R841DP-AFHD Monitor
• V-PS12-5V-XLR Power Supply with 4-Pin XLR Connector
• Operating Instructions
Inspect the unit for any physical damage that may have occurred during shipping. Should there be any damage,
immediately contact Marshall Electronics at [phone]. If you are not located within the continental United States,
call [phone].
■Installation
The V-R841DP-AFHD monitor is shipped with a ¼”-20 mounting bracket on the bottom side, allowing the monitor to be
flexibly mounted to a camera or other device using a variety of mounts. This ¼”-20 mounting bracket can also be
attached to any side of the monitor.
Alternately, the V-R841DP-AFHD can be used in a desktop configuration with optional stand (Marshall part number
VP-0113-DS-A), or mounted in 19” inch rack with optional adapter (Marshall part number VP-0113-PM-B).
■Connections and Power-On
Plug the V-PS12-5V-XLR power supply into an AC power source (100-240 V @ 50/60 Hz). Attach the 4-pin XLR
connector to the back of the monitor. Please note that 12VDC can be also supplied directly to the monitor from a
variety of sources. The monitor will draw approximately 2 Amps at 12 Volts in operation.
Connect the required cables for video signal input and output. (Power must be applied to the V-R841DP-AFHD for the
active loop-though outputs to be activated.) All BNC connectors are rated at 75Ω.
Turn on the unit by pressing the power button located on the front panel. Select a video input by pressing the
corresponding input select button.
V-R841DP-AFHD with optional desktop stand
¼”-20 Mounting Bracket
can also be attached to
any side of the monitor

6
Front Panel Features
Power Button
Turn the monitor on by pressing the power button.
In the OFF state, the LED will shine red. The LED
will shine green when the monitor is turned on.
Input Select Buttons
Use the input select buttons to select the input to be
displayed:
• Video
• S-Video
• YPbPr (SD/HD)
• VGA
• DVI
• SDI (SD/HD)
Each input automatically detects the applicable
formats (See Compatible Input Formats – Page 8).
On-Screen Menu Navigation Buttons
Use the Menu,↑,↓, and Select buttons to display
and navigate the on-screen menu (See Main Menu
and Navigation – Page 9).
User-Definable Function Buttons
Two user-definable function buttons can be used for
direct access to various settings. Functions are
assigned using the on-screen menu (See User-
Definable Function Buttons – Page 15).
Image Adjustment Knobs
Use the image adjustment knobs to adjust the
following settings. Pressing each knob will display
the current status of the corresponding control:
• Brightness (0-64)
• Color (0-64)
• Tint (0-64) [NTSC Only]
• Contrast (0-64)
Tally Lights
Three tally LEDs (green, red, and yellow) are
provided as general purpose indicators. Each LED
can be individually controlled, providing multiple
indications. Tally LEDs are controlled via the HD-15
connector on the rear panel (See Tally Interface –
Page 7)
1
2
3
4
5
6
12345
Top Front Panel
6
Lower Front Panel
15
On-Screen Menu (continued)
SYSTEM CONFIGURATION SUBMENU
■Internal SMPTE Color Bars
Use to display internally generated SMPTE split-field color bars.
■User-Definable Function Buttons
Use the FUNCTION 1 and FUNCTION 2 menu items to define each function button on the front panel of the monitor.
The following options are available for each button:
• DELAY Enable and rotate amongst delay modes.
• RATIO Toggle between 4:3 and 16:9 aspect ratios.
• BACK Rotate amongst marker backgrounds.
• CENTER Enable/disable center marker.
• MARKER Enable and rotate amongst marker settings (choices depend on aspect ratio setting).
• MONO Enable/disable monochrome mode.
• CTEMP Rotate amongst color temperature settings.
• PTP Enable/disable Pixel-to-Pixel™mode.
FUNCTION 1 is set to RATIO by default.
FUNCTION 2 is set to PTP by default.
■Status Display
Use to enable on-screen display of input/format status in the upper-left corner of the screen.
■Saving and Loading User Configuration Presets
Use the SAVE CONFIG and LOAD CONFIG menus to save current settings to one of 6 presets, or load a preset. All
monitor settings on the monitor are saved, including the image adjustment knob settings.
• Use the LOAD CONFIG menu to load one of presets USR1 – USR6. Factory default settings can also be loaded
by selecting MFG. (Factory defaults cannot be overwritten.)
• Use the SAVE CONFIG menu to save the current settings to a preset from USR1- USR6.
Video Configuration Submenu

14
On-Screen Menu (continued)
VIDEO CONFIGURATION SUBMENU (continued)
■Aspect Ratio Settings
Use to switch between 4:3 and 16:9 aspect ratios.
As the V-R841DP-AFHD monitor has a native resolution of 1024 x 768 RGB pixels, incoming images are automatically
scaled to fit the screen:
• In 4:3 mode, images are scaled up or down to fill the entire 4:3 screen (1024 x 768).
• In 16:9 mode, images are scaled to fill the maximum 16:9 portion of the screen (1024 x 576), with black bars filling
the remainder of the screen.
Note: The aspect ratio setting is ignored when Pixel-to-Pixel™mode is enabled.
■Scanning Modes
Use this setting to switch between normal and underscan modes:
• In normal scan mode, the active portion of the video signal is displayed on the screen, with 0% overscan.
• In underscan mode, area around the active video area is displayed on the screen, resulting in blanking intervals
being shown around the perimeter of the active image. Use this mode to clearly view the edges of the active video
area.
■Delay Modes
Use this setting to enable one of three delay modes (H/V, H, V):
• In H/V delay mode, both horizontal sync and vertical sync are delayed, resulting in both horizontal and vertical
blanking periods being shown on the screen.
• In V delay mode, vertical sync is delayed so that the vertical blanking period is displayed on screen.
• In H delay mode, horizontal sync is delayed so that the horizontal blanking period is displayed on the screen.
Note: Delay modes are only available in normal scan mode.
4:3 Mode 16:9 Mode
7
Rear Panel Features
Power Input
Connect the 12VDC input to the 4-Pin XLR power input
connector. Power can be supplied from the included
power supply, or from a variety of DC sources supplying
at least 2 Amps at 12 Volts.
IMPORTANT: If using a power source other than the
included power supply, be sure that the polarity of the
DC input is correct:
Pin 1: GND
Pin 2: N/C
Pin 3: N/C
Pin 4: +12VDC
Signal Input/Output
Connections:
• Composite Video Input/Output (BNC)
• S-Video Input/Output (4-Pin Mini-DIN)
• YPBPRInput/Output (BNC x 3)
• SDI Input/Output (BNC)
• VGA (HD-15)
• DVI (29-Pin connector, DVI-D signals only)
All outputs are active and require the monitor to be
powered.
Tally Interface
Each tally light is activated via the HD-15 connector by
connecting the corresponding pin to ground. A variety of
external devices can be used to perform the contact
closure. No additional power should be supplied to the
HD-15 port.
Tally Interface: HD-15 Pinout
Pin No. Signal
1 Green
2 Red
3 Yellow
4 Ground
5 Ground
6 N/C
7 N/C
8 N/C
9 N/C
10 N/C
11 N/C
12 N/C
13 N/C
14 N/C
15 N/C
V-Mount Battery Adapter
Accepts standard V-Mount 12V / 14.4V batteries
1
2
3
4
Rear Panel
1
2
3
4

8
Compatible Input Formats
Format Composite S-Video YPbPr SDI VGA DVI-D
NTSC ● ●
PAL ● ●
525i ● ● ●
625i ● ● ●
486p / 59.94 ● ●
576p / 50 ● ●
1035i / 60 ● ●
1035i / 59.94 ● ●
1080i / 60 ● ● ● ●
1080i / 59.95 ● ● ● ●
1080i / 50 ● ● ● ●
1080psF / 24 ● ● ● ●
1080psF / 23.98 ● ● ●
1080p / 30 ● ●
1080p / 29.97
1080p / 25
720p / 60 ● ● ● ●
720p / 59.94 ● ● ● ●
720p / 50 ● ● ● ●
720p / 30 ● ●
720p / 29.97
720p / 25
640 x 480 @ 60Hz ● ●
640 x 480 @ 75Hz ● ●
640 x 480 @ 85Hz ● ●
800 x 600 @ 60Hz ● ●
800 x 600 @ 75Hz ● ●
800 x 600 @ 85Hz ●
1024 x 768 @ 60Hz ● ●
1024 x 768 @ 75Hz ● ●
1024 x 768 @ 85Hz ● ●
1280 x 1024 @ 60Hz ● ●
13
On-Screen Menu (continued)
VIDEO CONFIGURATION SUBMENU (continued)
■Monochrome Mode
Use this setting to enable monochrome mode. Only the luminance of the image will be displayed as a grayscale
picture.
■Blue-Only Mode
Use this setting to enable Blue-Only mode. This mode displays only the blue color component of the image, switching
off the red and green components. Use this mode when calibrating the monitor to SMPTE color bars with the following
procedure:
1. Allow the monitor to warm up for at least 5-10 minutes.
2. Display SMPTE split-field color bars on the monitor using the internal generator or an external source.
3. Enable Monochrome mode.
4. Locate the pluge pattern (super black, black, and gray bars) at the lower-right corner of the screen. Adjust the Brightness knob until there is
no visible difference between the super black and black bars, but the gray bar is still visible.
5. Adjust the Contrast knob until an even grayscale appears along the top bars.
6. Disable Monochrome mode.
7. Enable Blue-Only mode and adjust the Color knob so that the outermost bars (white and blue) appear to match in brightness.
8. Composite/S-Video NTSC only: Adjust the Tint knob until the third bar from the left (cyan) and the third bar from the right (magenta) appear to
match in brightness.
9. Disable Blue-Only mode.
■Pixel-to-Pixel™Mode
Use this setting to enable Pixel-to-Pixel™mode.
This mode bypasses the monitor’s internal scaling function and displays incoming images in their native resolution and
aspect ratio, with a one-to-one mapping:
• For incoming formats smaller than the native resolution of the LCD panel (1024 x 768), the image will be
displayed in the center of the screen using only the necessary LCD pixels. For example, NTSC or PAL images will
occupy exactly 720 x 486 or 720 x 576 pixels respectively. The surrounding pixels will be black.
• For incoming formats exceeding 1024 x 768 pixels, only the center 1024 x 768 of the incoming image will
displayed occupying the whole screen, with the remainder of the picture cropped. For example, 1080i/p formats
will both be cropped to 1024 x 768 and displayed full-screen.
Note: Pixel-to-Pixel™mode will utilize the entire screen (1024 x 768) regardless of the aspect ratio setting. Pixel-to-
Pixel™mode is not available when using the VGA or DVI inputs.

12
On-Screen Menu (continued)
VIDEO CONFIGURATION SUBMENU
■Color Temperature Presets
Use this setting to choose one of three color temperature presets:
• D55 (5500K)
• D65 (6500K)
• D93 (9300K)
• USER (Adjustable Color Bias and Gain)
■Adjusting Color Bias
Use this submenu to adjust bias of the color response. Adjust the bias for each color to alter the white balance of the
image. The Color Temperature preset will automatically switch to USER when Color Bias settings are adjusted. It is
normal for color bias adjustments to be very subtle.
■Adjusting Color Gain
Use this submenu to adjust gain of the color response. The Color Temperature preset will automatically switch to
USER when Color Gain settings are adjusted.
Video Configuration Submenu
Color Bias Menu
Color Gain Menu
9
On-Screen Menu
STRUCTURE OVERVIEW
MAIN MENU AND NAVIGATION
Access the main menu by pushing and holding the MENU button on the front panel of the monitor.
• Step through menu items using the ↑and ↓ buttons.
• Choose a menu item by pressing SELECT.
• Rotate through options using the ↑and ↓ buttons.
• Choose a setting by pressing SELECT.
• Return to the previous menu by pressing MENU.
• Exit the main menu by pressing MENU. The menu will automatically
time out after 8 seconds. After exiting the menu, wait 1-2 seconds
before displaying the menu again.
MARKER 16:9 OFF, 13:9, 14:9, 4:3, 2.35:1,
1.85:1, 95%, 93%, 90%,
88%, 80%
MARKER 4:3 OFF, 95%, 93%, 90%, 88%,
80%
MARKER BACKGROUND OFF, HALF, BLACK
MARKER SETUP
CENTER MARKER OFF, ON
COLOR TEMP D55, D65, D93, USER
RED (0-100)
GREEN (0-100)
ADJ COLOR BIAS
BLUE (0-100)
RED (0-100)
GREEN (0-100)
ADJ COLOR GAIN
BLUE (0-100)
MONO OFF, ON
BLUE ONLY OFF, ON
PIXEL TO PIXEL OFF, ON
ASPECT RATIO 4:3, 16:9
SCAN NORMAL, UNDER
VIDEO CONFIG
DELAY OFF, H/V, V, H
SMPTE BAR OFF, ON
FUNCTION 1 DELAY, RATIO, BACK,
CENTER, MARKER, MONO,
CTEMP, PTP
FUNCTION 2 DELAY, RATIO, BACK,
CENTER, MARKER, MONO,
CTEMP, PTP
STATUS DISPLAY OFF, ON
LOAD CONFIG USR1, USR2, USR3, USR4,
USR5, USR6, MFG
MAIN
SYSTEM CONFIG
SAVE CONFIG USR1, USR2, USR3, USR4,
USR5, USR6
Main Menu

10
On-Screen Menu (continued)
MARKER SETUP SUBMENU
■16:9 Markers
Use this setting to superimpose one of 10 markers on the screen when in 16:9 mode. This setting is disabled when the
aspect ratio is set to 4:3, or when Pixel-to-Pixel™, Underscan, or H/V Delay is enabled.
• OFF (No Marker)
• 13:9 Aspect Ratio
• 14:9 Aspect Ratio
• 4:3 Aspect Ratio
• 2.35:1 Aspect Ratio
• 1.85:1 Aspect Ratio
• 95% Safe Area
• 93% Safe Area
• 90% Safe Area
• 88% Safe Area
• 80% Safe Area
16:9 Marker Examples:
OFF (No Marker)
4:3 Aspect Ratio Marker2.35:1 Aspect Ratio
90% Safe Area
Marker Setup Submenu
11
On-Screen Menu (continued)
MARKER SETUP SUBMENU (continued)
■4:3 Markers
Use this setting to superimpose one of 5 markers on the screen when in 4:3 mode. This setting is disabled when the
aspect ratio is set to 16:9, or when Pixel-to-Pixel™, Underscan, or H/V Delay is enabled.
• OFF (No Marker)
• 95% Safe Area
• 93% Safe Area
• 90% Safe Area
• 88% Safe Area
• 80% Safe Area
4:3 Marker Examples:
■Marker Background
Use this setting to choose how selected markers are displayed on the screen:
• OFF The marker is superimposed on the complete image.
• Half-tone Image area beyond the marker is shown at 50% intensity.
• Black Image area beyond the marker is shown at 0% intensity (black).
Example (80% Marker in 4:3 Mode):
■Center Marker
Use this setting to display a center marker on the screen. This feature is not available when H/V delay is on.
Center Marker
Background OFF Half-tone Background Black Background
OFF (No Marker) 90% Safe Area
