Axis AX1570 User manual

1
TECHNICAL SPECIFICATIONS
- TFT Panel: New ‘A’ Grade LCD - LED Backlight
- LCD Size: 178mm (7-inch) Diagonal
- Display Format: 16:9
- Resolution: 800 (H) x 480 (V)
- Video System: Auto PAL/NTSC Select
- Video Input: AV1 and AV2 - Video/Audio Input
(AV2 includes Auto Switching For Reverse Camera)
- Main Menu: Brightness/Contrast/Colour/Volume/Language/IR Control/Reset
- Video Connections: 4-Pin (Female) x 2
- IR Frequency: Ch A 2.3MHz ~ 2.8MHz
Ch B 3.2MHz ~ 3.8MHz
- Audio: On Board Speaker
- Remote Control: Full Function
- Power Input: 12/24V DC (Negative Ground)
- Dimensions: 183W x 123H x 35D mm (excl brackets)
INCLUDED
- Mounting Brackets: Headrest Mount/Stand Mount/U-Shape Bracket
- Accessories: Sunshade/Remote Control/Power Cable Assembly
AX1570
7-INCH LCD ENTERTAINMENT
& SAFETY MONITOR
• Slimline Design
• 2 AV Inputs & Built-In Speakers
• Headrest, In-Dash or Stand Alone Mounting
12 24
(for optional wireless headphones)

2
P.P
MENU
AV
R E M - 010
Thank you for choosing this versatile AXIS monitor!
Please take time to read through the simple instructions below.
CAUTIONS:
• Securely install the monitor in a location that will not hinder driver vision
or control.
• Keep the monitor away from moisture and heat sources
• Clean the display with a soft dry cloth. Do not use chemical cleaners.
MONITOR FUNCTIONS:
1. Remote Control Receiver
2. Decrease Button
3. Increase Button
4. Menu Button
5. Video Selection (to change between cameras)
6. Power On/Off
7. IR Transmitter (2Ch) - for optional wireless headphones
REMOTE CONTROL:
• Aim directly at the reception window
• Replace battery (CR2025) if the range reduces or will not operate.
(1) Mute
(2) Decrease Button
(3) Up/Down/Left/Right
(4) Time Switch
(5) Power Switch
(6) AV Switch
(7) Increase Button
(8) Menu
(9) Display Selection
(to adjust settings in Menu)
}
123456
Built-In
Speaker
77

3
WIRELESS IR HEADPHONE FUNCTION:
1. From Main Menu, select channel A or B.
(Using 2 IR headphones at the same time on the same channel may cause signal interference.
Set different channels to avoid distortion).
2. Turn on headphone power
3. Set volume level for comfortable listening.
CONNECTIONS:
ACCESSORIES:
13 Pin Male 4 Pin Female Video V1
4 Pin Female Video V2
Green - Reverse Connection
Black - Ground
Orange - Dimmer Control Input
Red - 12 - 24V
Note: Cam 2 has reverse trigger control.
Denition: Connector Front View
U-shape Mount Remote control
Sunshade
(XGIQKZ
Headrest Bracket

4
AX1570
