Axis AX 1102BT User manual
'1:*9449-:8'8)22(51&>*7
+2&29:3*7
• Xtreme Tuner • USB / SD Memory Card Ports
• Deckless • Front Panel Aux-In • Mini Chassis
&='9
DESIGNED FOR AUSTRALASIAN CONDITIONS
TUNER
- PLL Synthesized AM/FM Stereo
- Xtreme Long Range Tuner
- FM 87.5~108 MHz; AM 522~1710 KHz
- Interference Absorption Circuit
- 30 Station Presets - 18FM/12AM Memory
- Station Seek / Preset Scan / Auto Store
- Local / Distant Control
- Automatic or Manual Tuning
- Mono / Stereo
- Digital Clock
A
UDIO CONTROL
- Rotary Encoder
- Electronic Volume / Balance / Bass / Treble
- Loud / Mute
- Front panel AUX-IN
- 4 Ch RCA Line Out - 4 Volt
- 4-Band DSP Settings
- Speaker Impedance 4-8 Ohm
- Max Power 40 Watts x 4 Ch
MULTIMEDIA
- USB Input: Front Panel
- SD / MMC Card Port: Behind Front Panel
- AUX-IN Socket: Front Panel
- iPod / MP3 Playback Through USB
- MP3 / WMA Player
- Intro / Repeat / Random Play
- Select Folder / Track, File or Character Search
- Compatible with audio output of most
iPod and MP3 players
BLUETOOTH
- Bluetooth in Phone Mode
- External Microphone
- Phone Contacts / History
- Audio Streaming
SPECIFICATIONS
GENERAL
- Flip Down Detachable Face Panel
- LCD Display
- Illuminated Controls (Blue)
- ISO DIN Mounting
- ISO Wiring harness
- Mini DIN Chassis: 178W x 50H x 90Dmm
- 12 Volt DC (11-15V) Negative Ground
EN - 1
Safety Precautions
Neverthis unit,
peakers to moisture or water
Please off this unit and
(a). Water or other obstacle enters the unit;
(b). Smoking;
(c). smell.
Only connect the unit to a 12-volt power
supply with negative grounding.
Never install this unit
Thank you for purchasing this product.
Please read through these
so you will know how to operate
eep this manual ina safe place for
Tgraphic illustration
future reference.
EN - 2
WMA and MP3 Compatibility
!
About WMA
The unit can playback WMA data.
Windows Media and the Windows logo are
trade marks or registered trademarks of
Microsoft Corporation in the United States
and/or other countries.
About MP3
Supply of this product only conveys a license
for private, non-commercial use and does not
convey a license nor imply any right to use
this product in any commercial
Features Contents
Safety Precautions
Features
Panel Controls
General Operation
Tuner Operation
USB/SD/MMC/MP3 Playback
Playing MP3/WMA Files
Bluetooth Operation
Menu Function
Device Connections
Installation Guide
Anti-Theft System
Troubleshooting
EN - 3
Panel Controls
Power ON: Press to turn on the unit.
Press
1. - Power on
- Mute
- Power off (press")
2. - Rotate the knob to adjust volume level.
- Press to select audio setting, and rotate
the knob to adjust level.
- Press more than 2 seconds to access
menu.
3. - Search the previous/next station manually,
and each press to seek step by step (press
- Search the previous/next station
automatically (press more than 2 seconds,
in Radio mode).
- Press to search the previous/next track or
- Fast backward/forward (press more than 2
4. - Band switch (in Radio mode)
- Terminate call (in BT mode)
- Auto preset (press more than 2 seconds,
in Radio mode)
- Make a call (in BT mode)
6. - Press to select playing mode:
devices can be connected with the unit.)
7. - Display switch
- Set time (ress")
8. - MP3/WMA playback
Button 1: - Play/Pause
- Top play (")
Button 2: - Intro play (10 sec)
Button 3: - Track repeat play
Button 4: - Track random play
Button 5: - MP3 folder down
- MP3 track -10 down (")
Button 6: - MP3 folder up
- MP3 track +10 up (")
- Radio preset
Press to listen to a preset station.
Press and hold to store station.
9. - FM Stero/Mono (in Radio mode)
- Loudness (", in Radio mode)
10. - Radio local/distant (in Radio mode)
11. - Aux-in jack
12. - USB port
13. - Panel open
14. - SD card slot
ST/LOU LOC
EN - 4
Power On/Off Button
Press the / button to the unit
when the vehicle ignition is on. Press
and hold the button to turn the unit off.
Adjust Volume level
Rotate the knob to adjust volume level.
#it clockwise to increase and anticlockwise
decrease the volume.
Audio Mute
Press the / button to mute the volume
from the system. “MUTE” will appear on the
display panel and the volume will mute.
Press the / button again, or rotate or
press the knob to return the volume level to
the setting
Audio Controls
To adjust the bass, treble, balance and fader,
press the knob until the appropriate audio
appears on the display panel. Within
five seconds, rotate the knob to adjust the
audio settings for the selected function.
Mode Button (SRC)
Press the SRC button to change
ollowing mode: Radio, USB (when USB is
), Card(when SD/MMC card is in),
Auxiliary Input
To access an auxiliary device:
1. Connect the portable audio player to the
Display Selector (DISP)
This unit can display the clock time, radio
frequencor PTY type. Ordinarily, the radio
frequency or MP3/WMA track indication is
!he unit will display the time
the DISP button is pressed. The time
display for approximately 5 seconds then
return to previous mode.
Setting the Clock
The correct time of day can be set by pressing
and holding the DISP button.
To set the clock, perform the following steps:
1. Press the DISP button to view the clock.
2. With the clock visible on the display, press
and hold the DISP button until the time
3. Within 5 seconds, rotate the knob counter
clockwise to adjust the minutes to the
desired setting. To change the hour, rotate
the knob clockwise to adjust the hour to the
desired time.
General Operation
EN - 5
Tuner Operation USB/SD/MMC/MP3 Playback
1. Load SD/MMC Card
Press $
the SD/MMC card into the slot, with the front
side right%lose the panel.
The unit will play the music automatically and
the LCD will show CARD.
2. Take out SD/MMC Card
Press SRC button and switch to non CARD
mode&ress '
press SD/MMC card# the card when
it pops out. Close the panel.
3. Load USB Equipment
Open the USB cap to the right$nsert the
USB into the connector and the unit will
.
4. Take out USB Equipment
Press SRC button and switch to non USB
mode!hen the USB stick
%ap.
USB/SD/MMC Notes
play
1. SD/MMC card support
3. FAT 12/FAT 16, FAT 32 is possible
4. Tag (id3 tag ver 2.0)
- Title/artist/album: 32 byte support
5. Multi card reader not support
6. USB 1.1 support
USB 2.0 support
(It ca support USB 2.0 speed.
*the same speed with USB 1.1)
Note:
+
6'"'+%
Band
During radio play, press the BAND button to
choose between three FM and two < bands.
Up Tuning
Press the seek up >>| button to tune stations
step-by-step. The current frequency
shown in digital format on the display
Press and hold the seek >>| button to the next
available station.
Down Tuning
Press the seek down |<< button to tune
stations downward.
Press and hold the seek down |<< button
the previous available station.
Auto Store
Press the AMS button to scan preset stations
1-6. Hold it to automatically select six strong
stations and store them in the current band.
The new stations replace stations already
stored in that band.
devices are compatible with the unit.
EN - 6
Playing MP3/WMA Files
Display Information
During playback, ID3 tag information display
scrolling on the screen: FOLDER, FILE,
ALBUM, TITLE, ARTIST and Track Number/
Elapsed Time.
Folder Up/Down
Press the 5/DN button to go to the previous
folder. Press the 6/UP button to go to the next
folder.
Direct Song/File Access
1. Press the AMS button once&ress the
knob to enable direct track searching.
2. Rotate the knob to select a digit.
3. Press the knob to confirm entry and the
==
4. Rotate the knob to select digit.
5. Repeat above steps to enter the =hundred=
and =thousand=digit, if necessary.
NOTE: The unit will only allow the selection
of digits that correspond with the number of
6. Once the track number appears on the
screen, the knob to play the
Searching Folders/Files
1. Press the AMS button twice press the
2. Rotate the knob to select the desired
directory/song.
3. Press the knob to view the files inside the
selected directory.
>
the knob to play the selected song/
Searching by Name (CHAR-SCH)
1. Press the AMS button three times and press
the knob to access the character search
option.
2. Rotate the knob to select the characters A-Z,
3. Press the knob to confirm entry of the
character and move to the next position.
4. Repeat for up to eight characters.
5. Press and hold the knob for 2 seconds to
begin the search.
6. If a directory is found, rotate the knob to
7. Press and hold the knob for 2 seconds to
play the selected song/file. “NOT FIND”
search string entered.
MP3 Overview
MP3 is short for MPEG Audio Layer 3 and
refers to an audio compression technology
standard.
This product allows playback of MP3 files
on USB or SD/MMC card.
The unit can read MP3 files written in the
format compliant with ISO 9660. However
it not support the MP3 data written by
the packet write.
extension, you may hear noise.
In this manual, we refer to ?<&@?
?!?
and “Album”, respectively.
The unit may not play tracks in the order of
track numbers.
The unit plays only the audio tracks if
EN - 7
Note:
For your safety, phone conversations
much as possible while driving.
Bluetooth is a wireless transmission
short distance.The built-in Bluetooth
can connect with mobile phones having
Bluetooth function.
After connecti, your mobile
through the unit.
Pairing
Use this function to establish a connection
between the unit and your mobile phone.
1. Turn on the unit and press SRC button to
select BT MUSIC mode.
2. Turn on Bluetooth function of your mobile
phoneeep phone within 3 metrs o
the unit and search for Bluetooth
3. After the name of the Bluetooth module
appears on the pairing list of your
phone, select it. At this time, a
code is required. Enter the pairing
“1234”, and the Bluetooth pairing
will process automatically. Some mobile
phones may instruct you to select connect
or disconnect&lease select connect.
Exit Pairing
After pair successfully,
button to
$J
'#%
Make a call
1. Switch to BT MUSIC mode.
2. Press button.
3. Rotate the VOL knob to select from the
following list:
DIAL NUM: dial number directly
DIALLED: dialed number
MISSED: missed call
RECEIVED: received call
ME PBK: Phone directory
SIM PBK: SIM directory
To dial a number directly, select DIAL NUM.
1. Rotate the VOL knob to select phone
- Press |<< button to delete a digit ed.
- Press button to reset entered number.
2. Press to dial out.
To use a number in call log or directory, select
the option other than DIAL NUM.
Receive
1. After pair successfully,
! mode
2. Press button to receive.
3. Press button to hang up.
Call Transfer
During talk, press button to
audio the unit to your mobile phone.
Note:
Some mobile phones will audio
t once the incoming call
is answered.
BT Audio
To listen to audio from a bluetooth device and
control playback the unit.
1. Press SRC button to select BT
MUSIC mode.
2. To play or pause, press 1 >|| TOP.
Music Mode
A2DP
A2DP is short for Advanced Audio Distribution
Profile. The mobile phones supporting this
function can transmit stereo audio, whereas
t not supporting this function can
transmit mono only.
AVRCP
AVRCP is short for Audio/Video Remote
this function can control the playback of a
Bluetooth audio player.
Bluetooth Operation
EN - 8
General Notes for Bluetooth
1. For some types of mobile phones,
after the
unit still appearto be
Q
module name on the
mobile phone and select
submenu!hen the unit %YZZ[%!
!\+&
find the unit name in the phone menu and,
reconnect (check if your mobile phone has the
A2DP & AVRCP functions).
2. When pairing, some types of mobile phone
e
3. Depending on the mobile phone, if private
mode is selected,
'
disconnect
4. For mobile phone, the Bluetooth device
name must be primary symbols or numbers.
5. After CONNECT, if no sound produced,
please check the Bluetooth stereo
on the phone switched ON.
Bluetooth Operation Menu Function
Press the knob more than 2 seconds to enter
menu!hen each press changes the
mode as follows:
————————————————————
DSP mode
Rotate the knob to choose DSP sound effect:
POP -> ROCK -> CLASSIC -> FLAT ->OFF
————————————————————
BEEP ON/OFF mode
Rotate the knob to beep sound
on or off.
————————————————————
SEEK 1/2 mode (in Radio mode)
Rotate the knob to choose radio seek mode 1
or 2.
SEEK 1: Station will stop when the
next station is received.
SEEK 2: Station will stop when |<<
or >>| button is released and next station is
received.
————————————————————
VOL mode
Rotate the knob to choose volume last/adjust
mode.
V-LAST: The turn-on volume level is the
volume of latest power off.
V-ADJ: Press the knob to enter Volume Adjust
mode#otate to set the turn-on volume level.
————————————————————
12/24 HOURS mode
Rotate the knob to choose time format: 12 or
24 HOUR.
EN - 9
Device Connections
Wiring Diagram
Microphone Black
Fuse 15A Antenna
e
ee
EN - 10
Installation Guide
Preparation
1. Disconnect battery
Before you begin, isconnect the
battery negative terminal.
Note:
If the unit is to be installed in a car equipped
with an on-board drive or navigation computer,
do not disconnect the battery cable. If the
cable is disconnected, the computer memory
may be lost. Under these conditions, use extra
caution during installation to avoid causing a
short circuit.
2. Remove unit from sleeve
Lift latches on both sides of sleeve to remove
from the unit.
Mounting Sleeve Installation
1. Slide the mounting sleeve off the chassis.
If it is locked into position, use the removal
tools (supplied) to disengage it.
2. Check the dashboard opening size by
sliding the mounting sleeve into it.
If the opening is too small, carefully cut or
file as necessary until the sleeve easily
slides into the opening. Do not force the
sleeve into the opening or cause it to bend
or bow. Check for sufficient space behind
the dashboard for the unit chassis.
This unit can be installed in any dashboard
with a suitable 183 mm (W) x 52 mm (H)
opening as shown above. The dashboard
should be 4.75 mm - 5.56 mm thick in order
to be able to support the unit.
3. Locate the series of bend tabs along the
top, bottom, and sides of the mounting
sleeve. With the sleeve fully inserted into
the dashboard opening, bend as many of
the tabs outward as necessary to firmly
secure the sleeve to the dashboard.
Device Connections
Notes of connection
system, the negative battery
cable before installation.
damagto this unit, secure all
or adhesive tape.
the wiring
parts
ZJ$
installed and electrical problems still
please contact a professional
the speakers are wellinsulated. !
damage short circuit.
ACC lead the power supply
!J
s
impedance.
EN - 11
4. Place the unit in front of the dashboard
opening so the wiring can be brought
through the mounting sleeve. Follow the
wiring diagram carefully and make certain
all connections are secure and insulated
After
the ]
ignition ^$
operate J
is corrected.
5. %
6. Secure the rear of the unit to the car body
using the mounting bolt and rubber cushion.
7. Test the unit using the “Operation”
instructions that follow.
Kit Installation
If your vehicle requires the use of an
installation kit to mount this unit, follow the
instructions included with the installation kit to
attach the unit to the mounting plate supplied
1. Wire and test the unit as outlined in the
Mounting Sleeve Installation instructions.
2. Install the radio/mounting plate assembly
Installation Guide
to the sub-dashboard according to the
instructions in the installation kit.
3.
Replace the dashboard trim panel.
ISO Installation
This unit has threaded holes in the chassis
side panels which may be used with the
original factory mounting brackets of some
vehicles to mount the radio to the dashboard.
Please consult with your local car stereo shop
for assistance on this type of installation.
1.
Remove the existing factory radio from the
dashboard or centrconsole mounting.
Save all hardware and brackets as they will
be used to mount the new radio.
2.
Carefully unsnap the plastic frame from the
front of the new unit chassis. Remove and
discard the frame.
3.
Remove the factory mounting brackets
and hardware from the existing unit and
attach them to the new unit. Do not exceed
M5 x 9mm maximum screw size. Longer
screws may damage components inside the
chassis.
4.
Wire the new unit as outlined in the
Mounting Sleeve Installation instructions.
5.
Mount the new unit assembly to the
dashboard or cent console using the
reverse procedure of step 1.
EN - 12
Reset
The RESET button is located behind the front
panel and can only be accessed with the front
panel opened. Resetting the unit will erase
the time and preset memories. It should only
be activated upon initial installation after all
wiring is complete, or if there is a malfunction
of any of the switches on the unit. In these
circumstances, pressing the RESET button
will clear the system and return the unit to
default operation.
Fuse
When replacing a fuse, make sure the new
fuse is the correct type and amperage. Using
an incorrect fuse could damage the radio.
Reconnect Battery
When wiring is complete, reconnect the
battery negative terminal.
Installation Guide
This unit is equipped with a detachable panel
can be and taken with you,
deter theft.
Removing the Panel
1. Switch off the power of the unit.
2. Press
3. At an angle hold the panel to pull it out.
4. Place the panel into the case and take it
with you when you leave the car.
Installing the Panel
1. Hold the panel and ensure the panel faces
toward you, and set the right side of the
panel in the panel bracket.
2. Press the left side of the panel until it locks.
2
1
Removing the Unit
1. Remove the panel and the trim plate.
side and pulling.
3. Insert the removal keys straight back until
they lock, then the radio out. If the
removal keys are inserted at an angle, they
will not lock properly and will not release the
unit.
Anti-Theft System
EN - 13
Troubleshooting
If you suspect something is wrong, immediately switch powerand
you purchase.
Problem Possible cause Solution
General
The unit will not switch
on.
Car ignition is not on.
Cable is not properly
connected.
Fuse is burnt.
Turn your car key in the ignition.
Check cable connection.
Replace fuse with a new fuse of the
same capacity.
No sound Volume is set at minimum or
the mute function is on.
Check the volume or switch the mute
function off.
The unit or screen does
not function normally. The unit system is unstable. Press the RESET button.
TUNER mode
Unable to receive
stations.
The antenna is not connected
properly. Connect the antenna properly.
Poor quality reception of
radio station.
The antenna is not fully
extended or it is broken.
Fully extend the antenna and if
broken, replace it with a new one.
Preset stations are lost. The battery cable is not
properly connected.
Connect the permanent on
unit to the permanent
vehicle.
USB/SD/MMC mode
Unable to insert USB
device or SD/MMC card.
The memory card or USB
device has been inserted the
wrong way round.
Insert it the other way around.
The USB device or SD/
MMC card cannot be
read.
_ormat is not supported.
Check that the USB/SD/MMC file
system is in FAT or FAT32 format.
Due to different formats, some models
of USB storage devices or MP3
players may not be read.
EN - 14
General
Power supply: 12VDC (11V-16V), Test voltage 14.4V, negative ground
Maximum power output: 45W x 4 channels
Continuous power output: 20W x 4 channels (4 10% T.H.D.)
Suitable speaker impedance: 4-8ohm
Pre-Amp output voltage: 4.0V (Play mode: 1KHz, 0dB, 10K load)
Fuse: 15A
Dimensions (WxHxD): 178 x 50 x 166mm
Weight: 1.7kg
Aux-in level: 500mV
FM Stereo Radio
Frequency range: 87.5-108.0MHz
Usable sensitivity: 8dB µ
Frequency response: 30Hz-15KHz
Stereo separation: 30dB(1KHz)
Image response ratio: 50dB
IF response ratio: 70dB
Signal/noise ratio: >55dB
AM(MW) Radio
Frequency range 522-1620KHz
Usable sensitivity (S/N=20dB) 30dBµ
Components
Mounting sleeve 1
Machine screws M5x6 mm 4
Mounting bolt (50 mm) 1
Wire connector 1
Removable face plate case 1
Trim plate 1
Removal key 2
Operating Instructions 1
Rubber cushion 1
External microphone 1
Note:
WARRANTY
Congratulations on your purchase of a quality Mobile Audio System! You’re joining
thousands of satisfied customers who enjoy & experience the benefits of the products we
distribute. In the unlikely event that some technical difficulty arises with your purchase, be
assured that we are most anxious to see that the problem is quickly rectified to your
satisfaction. Please familiarise yourself with the following simple conditions of our warranty.
This warranty covers faults through component failure or failure of the product to operate in
accordance with published specifications. Product failure as a result of unreasonable
environmental conditions, accident, misuse, improper installation, unauthorised repair, vehicle
electrical or wiring faults or neglect etc, will not be covered by this warranty. Removal and
installation costs, if any, would be paid by the owner as well as any freight or postage costs of
transporting the product to AudioXtra. AudioXtra shall not be liable or responsible for any loss
of use of this product or any form of consequential loss.
CONSUMER WARRANTY
This product is warranted by AudioXtra International Pty Ltd to be free from defects in
materials and workmanship under NORMAL USE for a period of TWENTY FOUR MONTHS
from the date of purchase.
WITHIN 30 DAYS OF PURCHASE DATE: Please return the unit for replacement to our
National Service Centre or the Retailer from where you made the purchase. All accessories
must be included. Proof of purchase date must accompany the product.
AFTER 30 DAYS OF PURCHASE DATE: Warranty repair and service is carried out by our
National Service Centre. Repair and service will be carried out at no cost to the owner if proof
of ownership and the date of purchase can be verified to the satisfaction of the authorised
centre concerned with this repair. This proof should take the form of either:
a) The warranty card accompanying this product, stamped and dated by the dealer.
b) A Tax Invoice or Receipt showing full details of original vendor, purchaser, model
number and serial number.
COMMERCIAL WARRANTY: A product used in or associated with a commercial
application will carry a limited SIX MONTH warranty. An abnormal commercial application is
one where usage, dust, vibration, heat/cold and other environmental conditions exist at an
extreme level.
Model Number: AX 1102BT Serial Number:
Dealer Name: Date of Purchase: / /
Dealer Address:
www.audioxtra.com.au
Purchaser’s Name:
Invoice/Sales Docket no:
Purchaser’s Address:
National Service Centre:
10 STODDART ROAD, PROSPECT, SYDNEY NSW 2148 Australia
Please complete details below in the event of warranty service being required.
General Hints:
To expedite service and prompt return of the equipment, please:
a) Clearly describe the fault in detail
b) Safety and security pack the unit for transport
c) Include your return address
d) Provide proof of purchase date as outlined above
Other manuals for AX 1102BT
1
Table of contents
Other Axis Car Receiver manuals
Popular Car Receiver manuals by other brands
Pioneer
Pioneer KEH-P7900R EW Operation manual
Clarion
Clarion AX523R owner's manual
Jensen
Jensen VM9324 operating instructions
Pioneer
Pioneer DEH-P7700MP - In-Dash CD/MP3/WMA/WAV/iTunes AAC Car Stereo... Operation manual
BullTronics
BullTronics MIB IV user manual
Celsus
Celsus Medialab Installation and operation
