Axxera AXM230 Operating instructions

INSTALLATION/OWNER'S
MANUAL
Front and Rear Inputs
AXM230

2
AXM230
REMOVAL
KEYS
HEAD UNIT
MOUNTING SLEEVE
OPTIONAL REAR
MOUNTING SUPPORT
Please read entire manual before installation.
Before You Start
•Disconnectnegativebatteryterminal.Consultaqualifiedtechnicianforinstructions.
•Avoidinstallingtheunitwhereitwouldbesubjecttohightemperatures,suchasfrom
directsunlight,orwhereitwouldbesubjecttodust,dirtorexcessivevibration.
Getting Started
•Removetrimringfromunit.
•Insertthesuppliedkeysintotheslotsasshown,andslidetheunitoutofthemounting
sleeve.
•Installmountingsleeveintoopening,bendingtabstosecure.
•Connectwiringharnessandantenna.Consultaqualifiedtechnicianifyouareunsure.
•Certainvehiclesmayrequireaninstallationkitand/orwiringharnessadapter(sold
separately).
•Testforcorrectoperationandslideintomountingsleevetosecure.
•Snaptrimringintoplace.
Preparation
TYPICAL DIN FRONT-LOAD MOUNTING METHOD

3
AXM230
BLUE
BLACK
RED
YELLOW
Remote Turn-On
Connect to amplifier or power
antenna. Insulate wire if not used.
Ground
Connect to the vehicle
chassis ground.
Accessory
Connect to an existing ignition
circuit or switched 12 volt source.
Memory
Connect to the battery
circuit or constant 12 volt source.
Right Front
Gray/Black (-)
Gray (+)
Left Front
White/Black (-)
White (+)
Left Rear
Green/Black (-)
Green (+)
Right Rear
Violet/Black (-)
Violet (+)
Antenna
Connector
Steering Wheel Interface Input
PAC SWI-PS connection (sold separately)
AUXR/SUBFRONT
L-CH
R-CH
Rear/Subwoofer Output
RCA Preamp Connections
Front Output
Rear Auxiliary Input
FUSE
Whenreplacingthefuse,
makesurenewfuseisthe
correcttypeandamperage.
Usinganincorrectfusecould
damagetheradio.
TheAXM230usesone
10ampAGCfuselocated
in-line.
Wiring Diagram

4
AXM230
AuxiliaryInput
Tune/TrackDown
PresetDown/ThumbsDown
Display
Mute
Band/GoBack
Power
Menu
Open
Source
Loudness
Play/Pause
VolumeKnob/Select(push)
PresetUp/ThumbsUp
Tune/TrackUp
Function
USBPort
1 2 3 4 9
110
211
312
413
514
615
716
8
9
14
10
11
65
1213
17 1516
Control Locations - Receiver
17
7 8

5
AXM230
PresetUp/ThumbsUp
Menu
PresetDown/ThumbsDown
Key5/FolderDown
Key4/Play/Pause
Key1/Repeat
Key2/Random
Band/GoBack
Tune/TrackDown
Source
VolumeUp
Power
Select
Tune/TrackUp
VolumeDown
Mute
Key3/Intro
Key6/FolderUp
110
211
312
413
514
615
716
817
918
12
3
5
6
8
9
10
4
12
13
14
15
16
11
17
Control Locations - Remote
7
18

6
AXM230
Press OPEN toopenthefaceplate,thenpullawayfrom
therightsidetoremove.Tore-install,insertrightsideof
faceplatefirstthenpushleftsidetosecure.
Press oranyotherbuttontoturntheuniton.Press to
turntheunitoff.
Press SOURCEtoentertheSourceMenu,thenpress
SOURCEorrotatethevolume knobtoselectbetween
Tuner,AuxFront,AuxRear,USB,iPodandPandoramodes.
Modesofoperationareshowninthedisplay.
TheAXM230offersbothfrontandrearauxiliaryinput
portsforconnectinganaudiodevice,MP3player,etc.Press
SOURCEtoselecteitherthefrontorrearauxiliaryinput
mode.
Adjustvolumeusingvolumeknob(00-46).
Press DISPtotogglebetweenID3tagandfile/foldername
forMP3/WMAfilesbeingplayedfromUSBdevices.
Press RESETuponinitialinstallationorifabnormaloperation
occurs.Resetbuttonislocatedbehindthefrontpanel.
TheunitwilldisplaythetimeontheLCDdisplay.Clock
settingsareadjustedintheGeneralsetupmenu(referto
page8).
Theclockwilldisplay12-hourAM/PMtimeor24-hourtime
(22:00).FrequencyspacingisadjustedintheGeneralsetup
menu(refertopage8).
Faceplate Removal
Power On/Off
Source
Auxiliary Input
Volume
Display
Reset
Set the Clock
12/24-hour Clock
General Operation

7
AXM230
General Operation
Audio Setup Menu
Menu Function Options
Equalization
Curves
Rotatethevolume knobtocyclethroughthefollowingequalizationcurves:Flat,
Pop,Jazz,Classic,Beat,RockandUser.AnymanualadjustmenttotheBassor
TreblesettingsareautomaticallysavedasUser.
Bass Level Rotatethevolume knobtoadjustthebasslevelsetting
(-6minimum/+6maximum).
Bass Frequency Rotatethevolume knobtoselectoneofthefollowingbassfrequencysettings:
60Hz,80Hz,100Hzor200Hz.
Middle Level Rotatethevolume knobtoadjustthemiddlelevelsetting
(-6minimum/+6maximum).
Middle
Frequency Rotatethevolume knobtoselectoneofthefollowingmiddlefrequencysettings: 500Hz,1kHz,1.5kHzor2.5kHz.
Treble Level Rotatethevolume knobtoadjustthetreblelevelsetting
(-6minimum/+6maximum).
Treble
Frequency Rotatethevolume knobtoselectoneofthefollowingtreblefrequencysettings: 10KHz,12.5KHz,15KHzor17.5KHz.
Balance Rotatethevolume knobtoadjustthebalancesetting.
(12-Lto12-R;0representsequalbalance).
Fader Rotatethevolume knobtoadjustthefadersetting.
(12-Fto12-R;0representsequalbalance)
Subwoofer Rotatethevolume knobtoturnsubwooferoutputONorOFF.
Subwoofer Level Rotatethevolume knobtoadjustsubwooferlevelbetween0and12.
Subwoofer
Frequency
Rotatethevolume knobtoselectoneofthefollowingsubwoofercenter
frequencysettings:Off,80Hz,120Hzand160Hz."Off"representsafullrange
subwooferoutput.
Press MENUtotogglethroughandselectoneofthe
followingsetupmenus:Audio,General,GainandScreen.
1. Oncethedesiredmenuisdisplayed,rotatethevolume
knobtoscrollthroughthelistofmenufeatures.
2. Press SELECTtoselectaspecificfeaturetoadjust,then
 rotatethevolume knobleft/righttoadjustoractivate
 thedesiredfeature.
3. Press SELECTtoconfirmandsavethechanges.
Setup Menu

8
AXM230
General Operation
Menu Function Options Action
Tuner
Frequency
Spacing
USA ProgramstheunittoUSAtunerspacing.
(200kHzforFMand10kHzforAM).
S-America ProgramstheunittoSouthAmericantunerspacing.
(100kHzforFMand10kHzforAM).
Europe ProgramstheunittoEuropeantunerspacing.
(50kHzforFMand9kHzforAM).
Auto Station
Store AUTOSTORE Press SELECTtoseekandsave6strongstationsinthe
currentband.
Local/Distance
Tuning
Off Activatesdistancetuning.
On Activateslocaltuningforstrongstationreceptiononly.
Set the Clock Clock Rotatethevolume knobtoadjustthehours,thenpress SELECTtoconfirm.Repeattoadjusttheminutes,andrepeat
againtoadjustAM/PMsetting.
Clock Mode 12Hour Programstheunittodisplay12-hourAM/PMtime(example:
10:00PM)
24Hour Programstheunittodisplay24-hourtime(example:22:00)
Scrolling
Option
Off Programstheunittonotscrollanyinformationonthedisplay.
Once Programstheunittoonlyscrollinformationonce.
15Sec Programsunittoscrollinformationonceevery15seconds
(default).
On Programsunittoscrollinformationcontinuously.
iPod Control
Full ProgramstheheadunittoadvancedcontroloftheiPod/
iPhonedevice.
Manual ProgramstheheadunittomanualcontroloftheiPod/iPhone deviceandallowsmusictobecontrolledfromtheiPod/
iPhonedevice.
Beep
Confirmation
Off Disablestheconfirmationbeep.
On Enablestheconfirmationbeep.
Programmable
Turn On Volume
Variable
Value Programsunittoalwaysturnonataspecificvolume
(defaultisOff).Avolumelevelof1-30canbeselected.
General Setup Menu

9
AXM230
General Operation
Gain Setup Menu
Menu Function Options
Tuner Gain Rotatethevolume knobtoadjustthetunergain.
(-6minimum/+6maximum)
Aux Front Gain Rotatethevolume knobtoadjustthegainforthefrontauxiliaryinput.
(-6minimum/+6maximum)
Aux Rear Gain Rotatethevolume knobtoadjustthegainfortherearauxiliaryinput.
(-6minimum/+6maximum)
USB Gain Rotatethevolume knobtoadjustthegainforUSBplayback.
(-6minimum/+6maximum)
iPod Gain Rotatethevolume knobtoadjustthegainforiPodplayback.
(-6minimum/+6maximum)
Pandora Gain Rotatethevolume knobtoadjustthegainforPandoraplayback.
(-6minimum/+6maximum)
Screen Setup Menu
Menu Function Options
Color Rotatethevolume knobtoadjustthecolorsettingsofthedisplayscreenfrom
0to50.
Contrast Rotatethevolume knobtoadjustthecontrastsettingsofthedisplayscreen
from0to50.
Brightness Rotatethevolume knobtoadjustthebrightnesssettingsofthedisplayscreen
from0to50.
Demo Rotatethevolume knobtotoenable(ON)ordisable(OFF)thedemonstration
mode.

10
AXM230
Manual Tuning
Seek Tuning
Band
Storing Station Presets
Recalling Station
Presets
Press TUNE
nn
or TUNE
ll
momentarilytochange
radiofrequencyupordownonestepatatime.Pressand
holdtoadvancequickly.
Press TUNE
nn
or TUNE
ll
formorethantwo
seconds(thenrelease)toautomaticallyseekandtunetothe
nextstrongstation.
Press BANDtoselectbetweenFM1,FM2,FM3,AM1and
AM2bands.
Selectthedesiredbandandstation.Pressthe
(F)unctionbutton,turnthevolumeknobuntilthedesired
presetnumberishighlighted,thenpressSELECT to store
thepreset.
PresstheP+ or P-buttonstocyclethroughthe1-6presets
inthecurrentband.
AM/FM Tuner Operation

11
AXM230
Playing MP3/WMA
Files
Displaying Information
Repeat
Random
Intro
ToplayMP3/WMAfiles,insertaUSBdevicecontaining
MP3/WMAfiles.“Loading"willflashinthedisplay.
Dependingonthenumberoffilesandfolders,thismaytake
severalseconds.
Press DISPtocyclebetweentrackinformationandfile/
folder information.
*Songtitle,artistnameandalbumnamewillonlybe
displayedifincludedwiththeMP3/WMAfile.
WhenreferringtoMP3/WMAplayback,thefollowing
termsaresynonymous:
•Filenameandtrackname
•Foldernameanddirectoryname
Press (F)unctiontoentertheFunctionMenu,thenrotate
thevolume knobuntilRepeatishighlighted.PressSELECT,
thenrotatethevolume knobtoselectoneofthefollowing
repeatoptions.
•All-Playsallsongsondevice.
•Track-Continuouslyrepeatsselectedsong.
•Folder-Continuouslyrepeatsallsongsinselectedfolder.
Press (F)unctiontoentertheFunctionMenu,thenrotate
thevolume knobuntilRandomishighlighted.Press
SELECT,thenrotatethevolume knobtoselectoneofthe
followingoptionsforrandomplayback.
•Off-CancelstheRandomfunction.
•All-Playsallsongsinrandomorder.
•Folder-Playsallsongsinfolderinrandomorder.
Press (F)unctiontoentertheFunctionMenu,thenrotate
thevolume knobuntilIntroishighlighted.PressSELECT,
thenrotatethevolume knobtoselectoneofthefollowing
optionsforintroplayback.
•Off-CancelstheIntrofunction.
•All-Playsfirst10secondsofeachsong.
•Folder-Playsfirst10secondsofeachsonginfolder.
Note:Folderrepeat,randomandintrooptionsonlyfunction
onMP3/WMAdevicesrecordedwithmorethanonefolder.
MP3/WMA Operation

12
AXM230
MP3/WMA Operation
File/Folder Search
Press
SELECT
Press
BACK
SELECT
Turn the
volume knob
Folder 1 Folder 2 Folder 3 Folder 4 Folder 5 Folder 6 Folder 7
FilesFiles Files Files FilesFilesFiles
Press SELECT
to begin
Press SELECT toenterthefile/foldersearchmode.Alistof
allthefoldersfromthedevicewillbedisplayed.
Note: Anyfileslocatedintherootdirectorywillbelocatedin
thefoldernamed"ROOT".
Turnthevolume knobtocyclethroughallthefoldersonthe
device,andpressSELECTtochoosethedesiredfolder.The
listoffilesintheselectedfolderwillbedisplayed.Turnthe
volume knobtocyclethroughthelistoffiles.
PressingGO BACKwhenviewingthecontentsofafolderwill
returntothelistoffoldersonthedevice.PressGO BACK
againtoexitthesearchmenu.
Oncethedesiredsongisdisplayed,pressSELECTtobegin
playbackofthedesiredsong.
Begin Searching
Choose a Song
Menu Navigation
Playing a Song

13
AXM230
MP3/WMA Operation
Type Specification
Compatible File
Types
•MP3data(.mp3)
•WMAdata(.wma)
Incompatible File
Types
•DRMprotectedfiles
•WMAlossless
•Applelossless
•WMAPro
•MP3Pro
•MP3playlists
•M4A/AACdata
•WAVlossless
Sampling Frequency
Rate Compatibility
•MP3:8kHz-48kHz
•WMA:32kHz-48kHz
Transfer Bit Rate
Compatibility
•MP3:32kbps-320kbps
•WMA:32kbps-192kbps
Character Support
•SongTitle:32characters
•ArtistName:32characters
•AlbumName:32characters
•FileName:32characters
•FolderName:32characters
ID3 Tag Support •MP3Tags:Version1.0-2.4
•WMATags
File/Folder Limit
•Maximumnumberoffiles:50000
•Maximumnumberoffolders:500(plustherootfolder)
•Maximumnumberoffilesineachfolder:50000
Note:Fordeviceswithmorethanthemaximumnumberof
files/folders,somefileswillbeingnoredandmaynotfunction
properly.
USB File System •FAT/FAT32filesystemsupported.
•HFS/NTFS/EXT2/EXT3notsupported.
File/Folder Compatibility and Support

14
AXM230
iPod Operation
TheAXM230featuresadirectUSBcontrolsystemforiPod.
ToplaymusicfromaniPoddevice,connecttheUSBcable
(includedwithyouriPoddevice)totheUSBportonthefront
panel.
Onceconnected,"Loading"willflashinthedisplay,then
playbackwillbeginautomatically.Ifasongisplayingonthe
iPoddevicebeforeitisconnected,itwillcontinuetoplay.
Connect an iPod Device
(Not Included)
SearchItem MenuNavigation
Playlist Menu Playlists Songs
Songs Menu Songs
Artists Menu Artists Albums Songs
Albums Menu Albums Songs
Podcase Menu Podcasts
Seethebelowtableforalistofthesearchmenunavigationoptions.
Search Menu Functions
(step 1)
(step 2)
(step 3)
Press SELECToncetoenterthesearchmode.
Rotatethevolume knobtochoosebetweenplaylist,songs,
artists,albums and podcasts. Press SELECTtoselectthe
desiredsearchtype.
NavigatetothedesiredsongandpressSELECTtobegin
playbackofthatsong.Usethetablebelowforreference
whennavigatingthroughthemenuoptions.
Note: Press GO BACKtoaccessthepreviouslevel(upone
level).PressingGO BACK fromthesearchmainmenuwill
exitthesearch.
Search Mode
Full/Manual Control
TheAXM230featuresbothfullandmanualcontrolmodesforiPod/iPhonedevices.See
page8fordetailstotogglethecontrolbetweenfullandmanualmodes.
Important:TosupportmanualcontrolforiPod/iPhone,theiPoddevicemustbeupdatedto
thenewestfirmware.
Note:NotalliPod/iPhonedevicesarecompatiblewithmanualcontrolmode.

15
AXM230
iPod Operation
Press
ll
toskiptothebeginningofnextsong.Press
nn
toreturntothebeginningofcurrentsong.Pressing
nn
againskipstothebeginningofprevioussong.
Pressandhold
ll
or
nn
tofastforwardorreversea
song.
Press
l
/ II totemporarilystopplayback.
Press
l
/ II againtoresumeplayback.
Press (F)unctiontoentertheRepeatmenu,thenturnthe
volume knobtoselectoneofthefollowingoptions:
•Off-Repeatsalltracks.
•CurrentSong-Repeatsselectedtrack.
Press (F)unctiontoentertheRandommenu,thenturnthe
volume knobtoselectoneofthefollowingoptions:
•Off-CancelstheRDMfunction.
•AllSongs-Playsalltracksinrandomorder.
•CurrentAlbum-Playsalltracksintheselectedalbumin
random order.
Press (F)unctiontoentertheIntromenu,thenturnthe
volume knobtoselectoneofthefollowingoptions:
•Off-CancelstheINTfunction.
•On-Playsfirst10secondsofeachtrack.
Onlyalphanumericcharacterscanbedisplayed(ASCII
type)."NOSUPPORT"willbedisplayedifthefilecontains
charactersthatcannotbedisplayed."NOFILE"willbe
displayediftherearenosongsintheselectedplaylist.
Maximumcharacterdisplayinformation
•*Songtitle–32charactermaximum
•*Artistname–32charactermaximum
•*Albumname–32charactermaximum
*SongTitle,ArtistNameandAlbumnamewillonlybe
displayedifincludedwiththefile.
Song Select
Fast Forward and
Reverse
Pause
Repeat
Random
Intro
Character Support

16
AXM230
Pandora Operation
Requirements
USB Connection
Changing Stations
Shuffle
Skipping Tracks
Play/Pause
Thumbs Up
Thumbs Down
Device Compatibility
Troubleshooting
ControlforPandorarequires:
•AniPhonedevicewithareliabledataconnection,oran
iPodtouchthatisconnectedtowirelessinternet.
•ThePandoraAppinstalledontheiPhone/iPoddevice.
•AnactiveaccountwithPandora.Signupatwww.pandora.
com.
•TheUSBsynccablethatcamewithyouriPod/iPhone
device.
ConnectaniPodtouchoriPhonedevice(required,soldsepa-
rately)totheUSBport,usingtheUSBsynccableincluded
withyouriPhonedevice.
1. Press SELECTtodisplaytheStationsMenu.
2. Rotatethevolume knob tochoosetosortchannelsby
 dateoralphabetically.
3. Press SELECTtoconfirm,thenturnthevolume knob
 tocyclethroughthelistofstations.
4. Press SELECTwhenthedesiredstationishighlighted,
 andplaybackwillbegin.
Note:Stationsmustbecreatedonyouraccountpriorto
connectingyouriPod/iPhonedevicetotheheadunit.
Press SELECTtodisplaytheStationsMenu.Choose
“Shuffle”fromthestationsmenutoshufflesongsfromallof
yourstations.
Press
ll
toskipthecurrentsong.
Press
l
/ II totemporarilystopplayback.
Press
l
/ II againtoresumeplayback.
Press totellPandorayoulikethecurrenttrack.Pandora
willplaymoretrackswithsimilarqualities.
Press totellPandorayoudonotlikethecurrenttrack.
Pandorawillnotplaythecurrenttrackagain,andwillavoid
playingtrackswithsimilarqualities.
Refertowww.pandora.com/everywhere/mobilefordevices
compatiblewiththePandoramobileapplication.
Note:Pandoraisaninternetservice,carrieranddata
chargesmayapply.

17
AXM230
Thiswarrantygivesyouspecificlegalrights.
Youmayalsohaveotherrightswhichvary
from state to state.
DualElectronicsCorp.warrantsthis
producttotheoriginalpurchasertobefree
fromdefectsinmaterialandworkmanship
foraperiodofoneyearfromthedateof
theoriginalpurchase.
DualElectronicsCorp.agrees,atour
option,duringthewarrantyperiod,torepair
anydefectinmaterialorworkmanship
ortofurnishanequalnew,renewed
orcomparableproduct(whicheveris
deemednecessary)inexchangewithout
charges,subjecttoverificationofthe
defectormalfunctionandproofofthedate
ofpurchase.Subsequentreplacement
productsarewarrantedforthebalanceof
theoriginalwarrantyperiod.
Who is covered?Thiswarrantyis
extendedtotheoriginalretailpurchaser
forproductspurchasedfromanauthorized
DualdealerandusedintheU.S.A.
What is covered?Thiswarrantycovers
alldefectsinmaterialandworkmanshipin
thisproduct.Thefollowingarenotcovered:
software,installation/removalcosts,
damageresultingfromaccident,misuse,
abuse,neglect,productmodification,
improperinstallation,incorrectlinevoltage,
unauthorizedrepairorfailuretofollow
instructionssuppliedwiththeproduct,or
damageoccurringduringreturnshipment
oftheproduct.Specificlicenseconditions
andcopyrightnoticesforthesoftwarecan
befoundviawww.dualav.com.
What to do?
1.Beforeyoucallforservice,checkthe
troubleshootingguideinyourowner’s
manual.Aslightadjustmentofany
customcontrolsmaysaveyouaservice
call.
2.Ifyourequireserviceduringthe
warrantyperiod,youmustcarefully
packtheproduct(preferablyinthe
originalpackage)andshipitbyprepaid
transportationwithacopyoftheoriginal
receiptfromtheretailertoan
authorizedservicecenter.
3.Pleasedescribeyourproblemin
writingandincludeyourname,areturn
UPSshippingaddress(P.O.Boxnot
acceptable),andadaytimephone
numberwithyourshipment.
4.Formoreinformationandforthe
locationofthenearestauthorized
servicecenterpleasecontactusbyone
ofthefollowingmethods:
•Callustoll-freeat1-866-382-5476
•E-mailusat[e-mail]
ExclusionofCertainDamages:This
warrantyisexclusiveandinlieuofany
andallotherwarranties,expressedor
implied,includingwithoutlimitationthe
impliedwarrantiesofmerchantabilityand
fitnessforaparticularpurposeandany
obligation,liability,right,claimorremedy
incontractortort,whetherornotarising
fromthecompany’snegligence,actualor
imputed.Nopersonorrepresentativeis
authorizedtoassumeforthecompany
anyotherliabilityinconnectionwiththe
saleofthisproduct.Innoeventshallthe
companybeliableforindirect,incidentalor
consequentialdamages.
Limited One-Year Warranty

18
AXM230
Tuningrange: 87.5MHz-107.9MHz
Usablesensitivity: 8.5dBf
50dBquietingsensitivity: 10dBf
Stereoseparation@1kHz: >30dB
Frequencyresponse: 30Hz-13kHz
Tuningrange:530kHz-1710kHz
Usablesensitivity: 22uV
Frequencyresponse: 30Hz-2.2kHz
Speakeroutputimpedance: 4-8 ohms
Lineoutputvoltage:4 Volts RMS
Dimensions: 7" x 7" x 2" (178 x 178 x 50 mm)
Designandspecificationssubjecttochangewithoutnotice.
FM Tuner
AM Tuner
General
Specifications
CEA-2006PowerStandardSpecifications
(reference:14.4VDC+/-0.2V,20Hz-20kHz)
PowerOutput:18WattsRMSx4channelsat4ohmsand<1%THD+N
SignaltoNoiseRatio:70dBA(reference:1wattinto4ohms)

19
AXM230
Problem Cause Action
Unit will not turn on
(no power)
Yellowwirenotconnectedorincorrect
voltageRedwirenotconnectedor
incorrectvoltage
Checkconnectionsforproper
voltage(11-16VDC)
Blackwirenotconnected Checkconnectiontoground
Fuseblown Replacefuse
Unit has power
(but no sound)
Speakerwiresnotconnected Checkconnectionsatspeakers
Oneormorespeakerwirestouching
eachotherortouchingchassisground
Insulateallbarespeakerwires
fromeachotherandchassis
ground
Unit blows fuses
Yelloworredwiretouchingchassis
ground Checkforpinchedwire
Speakerwirestouchingchassisground Checkforpinchedwire
Incorrectfuserating Usefusewithcorrectrating
NO FILE appears
on display
WMAfileisprotectedbyDRM(Digital
RightsManagement) UseWMAfilesthatarenot protected
NoplayableMP3/WMAfilesfoundon
thedevice Checkthedeviceforvalid MP3/WMAfiles
Communicationerror Removeandreconnectthe
device
NO SUPPORT
appears on display AninvalidID3tagversionispresent Version1.0to2.4ID3tagsare supported.
Troubleshooting
ThisdevicecomplieswithPart15oftheFCCRules.Operationissubjecttothefollowingtwo
conditions:
(1)thisdevicemaynotcauseharmfulinterference,and
(2)thisdevicemustacceptanyinterferencereceived,includinginterferencethatmaycause
undesiredoperation.
Warning:Changesormodificationstothisunitnotexpresslyapprovedbythepartyresponsiblefor
compliancecouldvoidtheuser’sauthoritytooperatetheequipment.
Note:ThisequipmenthasbeentestedandfoundtocomplywiththelimitsforaClassBdigitaldevice,
pursuanttoPart15oftheFCCRules.Theselimitsaredesignedtoprovidereasonableprotection
againstharmfulinterferenceinaresidentialinstallation.Thisequipmentgenerates,usesandcan
radiateradiofrequencyenergyand,ifnotinstalledandusedinaccordancewiththeinstructions,
maycauseharmfulinterferencetoradiocommunications.However,thereisnoguaranteethat
interferencewillnotoccurinaparticularinstallation.Ifthisequipmentdoescauseharmful
interferencetoradioortelevisionreception,whichcanbedeterminedbyturningtheequipmentoff
andon,theuserisencouragedtotrytocorrecttheinterferencebyoneormoreofthefollowing
measures:
• Reorientorrelocatethereceivingantenna.
• Increasetheseparationbetweentheequipmentandreceiver.
• Connecttheequipmentintoanoutletonacircuitdifferentfromthattowhichthereceiveris
connected.
• Consultthedealeroranexperiencedradio/TVtechnicianforhelp.
FCC Compliance

DualElectronicsCorp.
TollFree:1-866-382-5476
Monday-Friday,9AM-5PM,EST
www.axxeraaudio.com
©2013DualElectronicsCorp.Allrightsreserved.
iPhone,iPod,iPodclassic,iPodnano,andiPodtoucharetrademarksofAppleInc.,registeredintheU.S.andothercountries.
“MadeforiPod”and“MadeforiPhone”meanthatanelectronicaccessoryhasbeendesignedtoconnectspecificallytoiPodoriPhone,
respectively,andhasbeencertifiedbythedevelopertomeetAppleperformancestandards.Appleisnotresponsiblefortheoperation
ofthisdeviceoritscompliancewithsafetyandregulatorystandards.PleasenotethattheuseofthisaccessorywithiPodoriPhone
mayaffectwirelessperformance.
Pandora,thePandoralogo,andthePandoratradedressaretrademarksofPandoraMedia,Inc.,usedwithpermission.
Othertrademarksandtradenamesarethoseoftheirrespectiveowners.
NSA0513-V01
