FREESTANDING COMBINE SERVICE MANUAL
CHANGING SIDE PANELS
Before changing the side panel ;
Take off all components possible to move/fall or defect:
Grids and pan supports, knobs, burner caps & heads, trays, warmer drawers etc
1-Lay down the oven
Pay attention to put sytrofoam on the ground

FREESTANDING COMBINE SERVICE MANUAL
2-Unscrew the inner panel and side panel connections.
( apply this procedure for one panel. Do not try to remove both side panels at once. )
3-Unscrew all surrounding screws on the side panel
4-Unscrew the front and rear plinth.

FREESTANDING COMBINE SERVICE MANUAL
5-Unscrew the rear panel

FREESTANDING COMBINE SERVICE MANUAL
6-The side panel sets free - you may remove and change it.
Repeat the same procedure backwards when assemblying the new side panel

FREESTANDING COMBINE SERVICE MANUAL
CHANGING REAR PANELS
You have to remove bottom panel first.
Detach all screws on bottom rear panel to remove
1-Remove exhaust protection cover to take off rear top panel

FREESTANDING COMBINE SERVICE MANUAL
CHANGING GAS COOKTOPS
( Table-Top Hobs & Double Ovens )
1) Table-top hobs :
1-Remove knobs, and screws around burner body.
2-Then you may change cooktop
2) Freestanding Models with or without Metal Lid
1-Unscrew the back angle irons at the bottom of the
plate.
(THESE SCREWS ARE NOT AVAILABLE FOR MODELS WITH LID )

FREESTANDING COMBINE SERVICE MANUAL
Changing Cooktops ( with Lid ) : Pull off the plastic cooktop hinge counterparts.
1-Unscrew the burner body, then cooktop comes free.
2-Hold up from the back side of the cooktop.

FREESTANDING COMBINE SERVICE MANUAL
3-Then slightly push forward ; to release the cooktop from the hooks.
Cooktop
hooks
4-Follow the above steps backwards- to remount the cooktop.
Please note that :
a) Cooktop must be put on the hooks completely

FREESTANDING COMBINE SERVICE MANUAL
b) Do not forget to put the washer ; when screwing the hinge counterparts.
washer
3) Freestanding Models with Glass Lid
1-Remove glass lid.
Fixate the nuts at bottom ( by a nipper ) and then unscrew

FREESTANDING COMBINE SERVICE MANUAL
2-Unscrew the burner body- then the cooktop comes free.

FREESTANDING COMBINE SERVICE MANUAL
CHANGING GLASS LIDS
1-Take off the hinge cover plastics on the left / right side of glass lid
2-Turn the hinge screws to fix the glass lid.

FREESTANDING COMBINE SERVICE MANUAL
3- If not solved, change the lid with a new one.

FREESTANDING COMBINE SERVICE MANUAL
Placing Cooktop Lids ( Glass )
1-Put on the hinge cover plastics on the left / right side of glass lid
2-Place the cooktop hinges into the glass lid profile.

FREESTANDING COMBINE SERVICE MANUAL
3-Set the glass lid, it is completed! Turn the hinge screws to adjust the glass lid if necessary

FREESTANDING COMBINE SERVICE MANUAL
CHANGING SPARK PLUG WITH CABLE
For Oven & Grill Burner
1-Remove spark plug manually ( of oven/grill burner )
spark plug for oven burner
spark plug for grill burner
2-Pull back and remove the spark module manually

FREESTANDING COMBINE SERVICE MANUAL
3-Pull back and remove "spark plug with cable"out of the rear panel.
4-The other end of spark plug is connected to the ignitor box.
Pull off the terminal of oven/grill burner wiring.

FREESTANDING COMBINE SERVICE MANUAL

FREESTANDING COMBINE SERVICE MANUAL
CHANGING OVEN BURNER AND INJECTOR
1-Unscrew the two screws and remove the burner cover.

FREESTANDING COMBINE SERVICE MANUAL
2-Pull back and remove the spark module manually.
3-To remove the thermocouple ( ffd ) pull backwards manually.

FREESTANDING COMBINE SERVICE MANUAL
4-Open drawer.
Unscrew the connection screw under the burner box.
Use a short , appropriate handhold screwdriver.
