AzureWave Technologies, Inc.
AW-GR520
User's Manual
IEEE 802.11 b/g Wireless Router
with 4 Port Switch

COPYRIGHT
AzureWave Technologies, Inc. All rights reserved. No part of this document may be
reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any
language in any form or by any means without the written permission of AzureWave
Technologies, Inc.
DISCLAIMER
AzureWave provides this document “as is”, without warranty of any kind, neither
expressed nor implied, including, but not limited to, the particular purpose. AzureWave
may make improvements and/or changes in this document or in the product described in
this document at any time. This document could include technical inaccuracies or
typographical errors.
TRADEMARKS
AzureWave is a trademark of AzureWave Technologies, Inc. Other names mentioned in
this document are trademarks/registered trademarks of their respective owners.
USING THIS DOCUMENT
This document provides detailed user guidelines to provide AzureWave 802.11 g/b
Wireless Router with 4 Port Switch operation and setting-up. Though every effort has
been made to assure that this document is current and accurate, more information may
have become available subsequent to the production of this guide. In that event, please
contact your AzureWave representative for additional information that may help in the
development process.
2

LINE OUT 4 3 2 1
LAN
INTERNET RESET
DC
Model: AW-GR520
User’s Manual
English
1st Edition, April 2007
3

Contents of Package
System Requirements
Introduction
Product overview
Key Features
LED Indicator & Hardware overview
LED Indicator
Antenna Location
The Hardware Installation
System Requirements
Hardware Installation
Range of Operation
How to Access the Web-based Utility
Status-Main Page
Log
DHCP Client List
Wireless Station List
Network
Connection type
DHCP-Automatically Set
Static IP
PPPOE
PPTP
LAN
Mac Clone
Dynamic DNS
UPnP
Wireless
Basic
Encryption type
64bit/128bit
WPA-PSK
WPA2-PSK
WPA-PSK/WPA2-PSK Mixed
WPA Enterprise
WPA2 Enterprise
WPA/WPA2 Mixed
5
5
6
6
6
7
8
8
8
8
8
8
10
10
11
11
11
12
12
12
12
12
13
14
14
14
15
15
15
16
16
16
17
17
17
18
19
Advanced
Broadcast SSID
Channel With
Beacon Period
RTS Threshold
Fragmentation Threshold
DTIM Interval
WMM
Short GI
Firewall
Internet Access
MAC Filter
Domain Filter
URL Filter
Port Forwarding
Triggering
DMZ
Security
Ping Access on WAN
IDENT Pass Through
Stateful Protect
SYN FLOOD Protect
PING FLOOD Protect
VPN Pass Through
IPSec Pass Through
PPTP Pass Through
L2TP Pass Through
System
Admin
Time
Config
Firmware
Regulatory Information
19
19
19
19
19
19
19
19
20
20
20
21
22
23
23
24
25
26
26
26
26
26
26
26
26
26
26
27
27
28
28
29
30
Table of Contents
4

Contents of Package:
Azurewave AW-GR520
1
2
3
802.11 b/g Wireless
Router
Quick Installation
Gui de
User Manual on
CD-ROM
Power Adapter
5V/2.0A
Ethernet
Cable
※ If any of the above items are missing, please contact your retailer.
System Requirements:
1. Browser-Internet Explorer 5.5 above or Firefox 1.0
2. Wired or Wireless Network Adapter
3. CD-ROM Drive
5

Introduction
Product overview
Compliant with the IEEE 802.11b/g standard and the AW-GR520 use Direct Sequence
Spread Spectrum (DSSS), Orthogonal Frequency Division Multiplexing (OFDM), DBPSK,
DQPSK, CCK and QAM baseband modulation.
AW-GR520 is a Wireless Access Point and Broadband Router which allow user access
Internet via LAN/WLAN. AW-GR520 supports advanced security features including WEP,
WPA,WPA2, and Firewall, DoS (Denial of Service) protection, and internet access control.
Key Features
Standard
Wireless: IEEE 802.11b, IEEE 802.11g standard
Ethernet: IEEE802.3, IEEE802.3u
Data Rate: Up to 54Mbps data rate.
Security: Wi-Fi Protected Access (WPA), WPA2, 128-bit WEP encryption and MAC filtering
UPnP IGD enabled.
Web-based browser configuration for simplified management.
DHCP Client and Server allow true plug-and play installations.
Network Address /Port Translation (NAT/PAT) and Virtual Server Mapping allow LANs to be
served with one of few IP addresses
Firewall support for access-list control, DoS Attack prevention, stateful inspection (SPI).
Supporting Internet protocols include Cable modem (DHCP Client), ADSL modem (PPPoE),
PPTP, and Static IP.
Support VPN Pass Through for IPSec, PPTP, and L2TP.
All LAN ports support Auto-Crossover(MDI/MDI-X)
6

Environmental factors may adversely affect range
READ Y WL AN LAN1 LAN2 LAN3 LAN4 INTERNET
LED Indicator & Hardware overview
The Front Panel
The Back Panel
Ready LED: A blinking light indicates
that the AW-GR520 is ready.
Local Network LEDs: A solid light
indicates a connection to an Ethernet-
enabled computer on ports 1-4. This
LED blinks during data transmission.
Internet LED: A solid light indicates
connection on the Internet port.
This LED blinks during data
transmission.
LAN Ports (1-4): Connect Ethernet
devices such as computers,
switches, and hubs.
Power Receptor: Receptor for the
supplied power adapter.
Non-Detachable Antenna
Internet Port: The auto MDI/MDIX
Internet port is the connection for
the Ethernet cable to the cable or
DSL modem.
Reset: Pressing the Reset button
restores the router to its original
factory default settings
Reserving for advance
functions
WLAN LED: A solid light indicates
that the wireless segment is ready.
This LED blinks during wireless data
transmission.
7

The Hardware Installation
System Requirements
Before installing the AW-GR520, make sure your system satisfies the following requirements.
Desktop or Laptop with an Ethernet port
Browser-Internet Explorer 5.5 or Firefox 1.0 above
Wired or Wireless Network Adapter
CD-ROM Drive
Hardware Installation
The AW-GR520 package comes together with a Non-detachable type-antenna to maximize
its network operating range.
1. Make sure that all of your hardware is powered off, including the broadband modem and
PCs.
2. Connect your broadband modem’s Ethernet cable to the Router’s Internet port.
3. Connect one end of an Ethernet network cable to one of the numbered ports on the back
of the Router. Connect the other end to an Ethernet port on a network device, e.g., a PC,
print server, or switch. Repeat this step to connect more PCs or other network devices to the
Router.
4. Power on the broadband modem.
5. Connect the included power adapter to the Router’s Power port, and then plug the power
adapter into an electrical outlet. 6. Power on your PC(s).
7. Locate an optimum location for the Router. The best place for the Router is usually at the
center of your wireless network, with line of sight to all of your wireless devices.
Operating Range
The signal range of AW-GR520 varies from the operating environment. Obstacles such as
walls and metal barriers could reflex and absorb radio signals. Devices like microwave
ovens can create problems to the wireless network greatly. 802.11b/g: Indoor 130ft (40m),
outdoor (LOS, Light-of-Sight) 1000f t (310m) Set by default, the AW-GR520 should
automatically adjust the data rate. The closer the wireless stations are the better the signal
and transmission speed they will receive. To improve your wireless transmission, try moving
your wireless stations closer to the AW-GR520
8

AW-GR520 Configuration
The Router Status menu provides status and usage information. This page displays the
current information for the AW-GR520. It will display the System (Firmware version) WAN
(Internet), LAN, and Wireless.
If your Internet connection is set up for a Dynamic IP address then a Release button and a
Renew button will be displayed. Use Release to disconnect from your ISP and use Renew to
connect to your ISP. If your Internet connection is set up for PPPoE or PPTP, a Connect
button and a Disconnect button will be displayed. Use Disconnect to drop the PPPoE or
PPTP connection and use Connect to establish the PPPoE or PPTP connection.
How to Access the Web-based Utility
To access the configuration utility, open a web-browser such as Internet Explorer and enter
the IP address of the AW-GR520 router (192.168.0.1).
Status-Main page
9

Status-Log
The AW-GR520 router automatically logs (records) events of possible interest in its internal
memory. If there isn’t enough internal memory for all events, logs of older events are
deleted but logs of the latest events are retained.
Refresh: Click this button to refresh the log screen.
Clear: Click this button to clear the log entries.
System: This field displays the AW-GR520 firmware was built time, firmware version, Host
Name and Domain Name assigned to the router.
WAN (Internet): Displays the MAC address and IP address assigned by ISP.
LAN: Displays the MAC address and the private (local) IP settings and DHCP IP address
range from the AW-GR520 router.
Wireless: Displays the wireless MAC address and wireless settings such as SSID, Channel,
Wireless mode and Encryption mode.
Status-DHCP Client List
Displays computers and devices that are connected to the AW-GR520 router via Ethernet or
Wireless and that are receiving an IP address assigned by the AW-GR520 router
Status-Wireless Station List
The wireless Station List displays a list of current connected wireless Station. This List also
displays the MAC address and Wireless Mode of the connected wireless Stations.
10

Network-WAN (Internet) DHCP -- Automatically Set
Connection Type: Select DHCP-Automatically Set to obtain IP Address information
automatically from your ISP. Select this option if your ISP does not give you any IP numbers
to use. This option is commonly used for Cable modem services.
Host Name: The Host Name is optional but may be required by some ISPs. Domain Name:
The Domain Name is optional but may be required by some ISPs
Network-WAN - Static IP
Connection Type: Select Static IP Address if all the Internet port’s IP information is provided
to you by your ISP. You will need to enter in the IP address, subnet mask, gateway address,
and DNS address provided to you by your ISP. Each IP address entered in the fields must be
in the appropriate IP form, which are four octets separated by a dot (x.x.x.x). The AW-GR520
router will not accept the IP address if it is not in this format
IP: Enter the IP address assigned by your ISP.
Subnet Mask: Enter the Subnet Mask assigned by your ISP.
Gateway: Enter the Gateway assigned by your ISP.
DNS: The DNS server information will be supplied by your ISP (Internet Service Provider.)
11

Network-WAN -- PPPoE
Connection Type: Choose PPPoE (Point to Point Protocol over Ethernet) if your ISP uses a
PPPoE connection. Your ISP will provide you with a username and password. This option is
typically used for DSL services. Make sure to remove your PPPoE software from your
computer. The software is no longer needed and will not work through a router. Select
PPPoE (Username/Password) from the drop-down menu.
User Name: Enter your PPPoE user name.
Password: Enter your PPPoE password and then retype the password in the next box.
Select either “Always connect” or “Auto connect.”
Enter a maximum idle time during which the Internet connection is maintained during
inactivity. To disable this feature, enable "Always connect."
Network-WAN - PPTP
Connection Type: Choose PPTP (Point-to-Point-Tunneling Protocol) if your ISP uses a PPTP
connection. Your ISP will provide you with a username and password. This option is typically
used for DSL services.
IP: Enter the IP address assigned by your ISP.
Subnet Mask: Enter the Subnet Mask assigned by your ISP
Server IP: Enter the Server IP provided by your ISP (optional).
User Name: Enter your PPTP username assigned by your ISP.
Password: Enter your PPTP password assigned by your ISP.
Select either “Always connect” or "Auto connect."
Enter a maximum idle time during which the Internet connection is maintained during
inactivity. To disable this feature, enable “Always connect.”
12

Network-LAN
This section will allow you to change the local network settings of the router and to
configure the DHCP settings.
IP: Enter the IP address of the AW-GR520 router. The default IP address is 192.168.0.1.
If you change the IP address, once you click Apply, you will need to enter the new IP address
in your browser to get back into the configuration utility.
Subnet mask: The default subnet mask is 255.255.255.0.
DHCP Server: DHCP stands for Dynamic Host Control Protocol. The AW-GR520 Router has a
built-in DHCP server. The DHCP Server will automatically assign an IP address to the
computers on the LAN/private network. Be sure to set your computers to be DHCP clients by
setting their TCP/IP settings to “Obtain an IP Address Automatically.” When you turn your
computers on, they will automatically load the proper TCP/IP settings provided by the
Router. The DHCP Server will automatically allocate an unused IP address from the IP
address pool to the requesting computer. You must specify the starting and ending address
of the IP address pool.
DHCP Server: Choose the “Enable” button to enable the DHCP server or choose the
“Disabled” button to disable DHCP server function on your router
Address Range: Enter the starting and ending IP addresses for the IP assignment from
DHCP server.
WINS: Enter the Domain name (Optional).
Network-MAC Clone
The default MAC Address is set to the Internet port’s physical interface MAC address on the
Broadband Router. It is not recommended that you change the default MAC address unless
required by your ISP. You can use the Clone MAC of this PC button to replace the Internet
port’s MAC address with the MAC address of your Ethernet card.
13

Network-Dynamic DNS
The DDNS feature allows you to host a server (Web, FTP, Game Server, etc…) using a domain
name that you have purchased (www.dyndns.com) with your dynamically assigned IP
address. Most broadband Internet Service Providers assign dynamic (changing) IP
addresses. Using a DDNS service provider, your friends can enter in your domain name to
connect to your server no matter what your IP address is.
Dynamic DNS: Enabled/Disabled DDNS function.
User Name: Enter the Username for your DDNS account.
Password: Enter the Password for your DDNS account.
Host Name: Enter the Host Name that you registered with your DDNS service provider.
Network-UPnP
To use the Universal Plug and Play (UPnP™) feature click on Enabled. UPNP provides
compatibility with networking equipment, software and peripherals.
UPnP: Enabled/Disabled UPnP function.
Wireless-Basic
SSID: Service Set Identifier (SSID) is the name of your wireless network. Create a name
using up to 32 characters. The SSID is case-sensitive.
Channel: Indicates the channel setting for the AW-GR520. By default the channel is set to 6.
The Channel can be changed to fit the channel setting for an existing wireless network or to
customize the wireless network.
Mode: Mixed 802.11b/g- using a mix of 802.11b/g wireless clients.
14

Wireless-Basic Encryption Type – WEP 64/128bit
It is recommended to enable encryption on your wireless router before your wireless
network adapters. Please establish wireless connectivity before enabling encryption.
1. Select Encryption Type to WEP 64/128bit.
2. Next to WEP Key Length, select the level of encryption (64 or 128-bit) and either Hex or
ASCII. Hex - (recommended) Letters A-F and numbers 0-9 are valid. ASCII - All numbers and
letters are valid. 3. Next to WEP Key 1, enter a WEP key that you create. Make sure you enter
this key exactly on all your wireless devices. You may enter up to 4 different keys.
4. Click Apply to save your settings. If you are configuring the router with a wireless adapter,
you will lose connectivity until you enable WEP on your adapter and enter the same WEP key
as you did on the router.
Wireless-Basic Encryption Type – WPA-PSK
It is recommended to enable encryption on your wireless router before your wireless
network adapters. Please establish wireless connectivity before enabling encryption.
1. Select WPA-PSK mode.
2. Next to Cipher Suite, select TKIP or CCMP (AES).
3. Next to WPA Pass Phrase (Pre-Shared Key), enter a key (pass phrase). The key is entered as
a pass-phrase in ASCII format at both ends of the wireless connection. The pass-phrase
must be between 8-63 characters. 4. Click Apply to save your settings. If you are configuring
the router with a wireless adapter, you will lose connectivity until you enable WPA-PSK on
your adapter and enter the same pass phrase as you did on the router.
15

Wireless-Basic Encryption Type – WPA2-PSK
It is recommended to enable encryption on your wireless router before your wireless
network adapters. Please establish wireless connectivity before enabling encryption.
1. Select WPA2-PSK mode.
2. Next to Cipher Suite, select TKIP or CCMP (AES).
3. Next to WPA Pass Phrase (Pre-Shared Key), enter a key (pass phrase). The key is entered as
a pass-phrase in ASCII format at both ends of the wireless connection. The pass-phrase
must be between 8-63 characters.
4. Click Apply to save your settings. If you are configuring the router with a wireless adapter,
you will lose connectivity until you enable WPA2-PSK on your adapter and enter the same
pass phrase as you did on the router.
Wireless-Basic Encryption Type – WPA-PSK/WPA2-PSK Mixed
It is recommended to enable encryption on your wireless router before your wireless
network adapters. Please establish wireless connectivity before enabling encryption.
1. Select WPA-PSK/WPA2-PSK Mixed mode.
2. Next to Cipher Suite, select TKIP or CCMP (AES).
3. Next to WPA Pass Phrase (Pre-Shared Key), enter a key (pass phrase). The key is entered as
a pass-phrase in ASCII format at both ends of the wireless connection. The pass-phrase
must be between 8-63 characters.
4. Click Apply to save your settings. If you are configuring the router with a wireless adapter,
you will lose connectivity until you enable WPA-PSK/WPA2-PSK Mixed on your adapter and
enter the same pass phrase as you did on the router.
16

Wireless-Basic Encryption Type – WPA Enterprise
It is recommended to enable encryption on your wireless router before your wireless
network adapters. Please establish wireless connectivity before enabling encryption.
1. Select WPA Enterprise mode.
2. Next to Cipher Suite, select TKIP or CCMP (AES).
3. Next to RADIUS Server IP Address enter the IP Address of your RADIUS server.
4. Next to RADIUS Server Port, enter the port you are using with your RADIUS server. 1812 is
the default port.
5. Next to RADIUS Server Shared Secret, enter the security key.
6. Click Apply to save your settings. If you are configuring the router with a wireless adapter,
you will lose connectivity until you enable WPA Enterprise on your adapter.
Wireless-Basic Encryption Type – WPA2 Enterprise
It is recommended to enable encryption on your wireless router before your wireless
network adapters. Please establish wireless connectivity before enabling encryption.
1. Select WPA2 Enterprise mode.
2. Next to Cipher Suite, select TKIP or CCMP (AES).
3. Next to RADIUS Server IP Address enter the IP Address of your RADIUS server.
4. Next to RADIUS Server Port, enter the port you are using with your RADIUS server. 1812 is
the default port.
5. Next to RADIUS Server Shared Secret, enter the security key.
6. Click Apply to save your settings. If you are configuring the router with a wireless adapter,
you will lose connectivity until you enable WPA2 Enterprise on your adapter.
17

Wireless-Basic Encryption Type – WPA/WPA2 Mixed
It is recommended to enable encryption on your wireless router before your wireless
network adapters. Please establish wireless connectivity before enabling encryption.
1. Select WPA/WPA2 Mixed mode.
2. Next to Cipher Suite, select TKIP or AES.
3. Next to RADIUS Server IP Address enter the IP Address of your RADIUS server.
4. Next to RADIUS Server Port, enter the port you are using with your RADIUS server. 1812 is
the default port.
5. Next to RADIUS Server Shared Secret, enter the security key.
6. Click Apply to save your settings. If you are configuring the router with a wireless adapter,
you will lose connectivity until you enable WPA/WPA2 Mixed on your adapter.
Wireless-Advanced
Broadcast SSID: Select disabled if you do not want the SSID of your wireless network to be
broadcasted by the AW-GR520. If Disabled is selected, the SSID of the AW-GR520 will not be
seen by Site Survey utilities so your wireless clients will have to know the SSID of your AW-
GR520 in order to connect to it. Beacon Period: Beacons are packets sent by an Access Point
to synchronize a wireless network. Specify a value. 100 is the default setting and is
recommended. RTS Threshold: This value should remain at its default setting of 2346. If
inconsistent data flow is a problem, only a minor modification should be made.
Fragmentation Threshold: The fragmentation threshold, which is specified in bytes,
determines whether packets will be fragmented. Packets exceeding the 2346 byte setting
will be fragmented before transmission. 2346 is the default setting. DTIM Interval: (Delivery
Traffic Indication Message) is the default setting. A DTIM is a countdown informing clients
of the next window for listening to broadcast and multicast messages.
18

Firewall-Internet Access
The AW-GR520 router allows you to block the use of certain Internet services by computers
on
your network. This is called Internet Access blocking or port filtering. Enter a name for the
rule and select a Service (HTTP, FTP….) from the drop-down menu. Select the Protocol TCP or
UDP port that you want to block. You can enter a single port or a range of ports. When you
have finished making changes to this screen, click the Apply button to save the changes.
Disabled: Select this option if you do not want to block Internet services.
Allow to access services listed below, others are blocked: Select this option to allow
using Internet services listed below. Users will be block to all other Internet services.
Block services listed below, others are allowed: Select this option to block Internet
services listed below. Users will be allowed access to all other Internet services.
To delete the rules, click "delete Button."
19

Firewall-MAC Filter
Use MAC (Media Access Control) Filters to allow or deny LAN (Local Area Network) and
wireless station computers by their MAC addresses from accessing the Network. You can
either manually add a MAC address or select the MAC address from the list of clients that
are currently connected to the Broadband Router.
Select Turn MAC Filtering Off, allow MAC addresses listed below, or deny MAC addresses
listed.
Disabled: Select this option if you do not want to use MAC Filter.
Allow PC listed below to access this device, others are denied: Select this option to only
allow PCs that are in the list to access the network and Internet. All other PCs will be denied
access to the network and Internet.
Deny PCs listed below to access this device, others are allowed: Select this option to only
deny PCs that are in the list to access the network and Internet. All other PCs will be allowed
access to the network and Internet.
20
