B-Tech DMR-6X2 User manual

A2.221017
baofengtech.com

DMR
DIGITAL MOBILE RADIO ASSOCIATION
DMR-6X2 PRO
Operating Manual
Digital DMR and Analog
UHF/VHF Two Way Radio

THANK YOU!
Thank you very much for choosing our Dual Band Digital DMR and
Analog two way radio.
This radio adopts the latest advances in technology, providing reliable
communication in today’s demanding communication environment.
This radio offers both DMR digital and analog communication, introduces
innovative DMR digital processing system to achieve SMS, high-audio
quality and digital encryption. It offers great stability, and reliability, together
with long distance communication as well as fashionable design and
compact exterior lines. DMR-6X2 PRO has Text Messaging, Recording,
Voice Message, Digital Encryption, Emergency Alarm, Man Down Alarm,
Work Alone GPS, APRS Location Reporting, Roaming, Vibration, Analog
DTMF, 2TONE, 5TONE, CTCSS/DCS encode/decode functions.
»When programming the radio, start by reading the factory
software data, and then rewrite this data with your frequency etc.,
to a new saved code plug, otherwise errors may occur.
»You can use the programming cable with a Windows PC
to program the frequency, channel type, power etc. your
programming must comply with your FCC (or other country)
license certication.

CONTENTS
1.UNPACKING AND CHECKING THE EQUIPMENT........................ 1
1.1 Supplied Accessories................................................................. 1
1.2 Standard Accessories ................................................................ 2
1.3 Optional Accessories ................................................................. 2
2.BATTERY INFORMATION.............................................................. 3
2.1 Charging the Battery Pack ......................................................... 3
2.2 Charger Supplied ....................................................................... 3
2.3 Use Caution with the Li-ion Battery............................................ 3
2.4 How to Charge ........................................................................... 4
2.5 Normal Charging Tips ................................................................ 5
2.6 How to Store the Battery............................................................ 6
3. PREPARATION.............................................................................. 7
3.1 Installing / Removing the Battery ............................................... 7
3.2 Installing / Removing the Antenna ............................................. 7
3.3 Installing / Removing the Belt Clip ............................................. 8
3.4 Installing the Additional Speaker/Microphone (Optional) ........... 8
4. Radio Overview............................................................................. 9
4.1 Status Indications..................................................................... 10
4.2 Programmed Key ..................................................................... 10
4.3 Hot Key Setting for PF1, PF2, PF3, P1, P2 ............................. 13
4.4 Combination key function......................................................... 13
5.BASIC OPERATIONS................................................................... 14
5.1 Power on the Radio ................................................................. 14
5.2 Adjust Volume .......................................................................... 14
5.3 Main band/Sub Band Switch.................................................... 14
5.4 VFO/Channel Switch................................................................ 14
5.5 Set up VFO Frequency ............................................................ 14
5.6 Select a Channel...................................................................... 14
5.7 Adding a New Channel ............................................................ 15
5.8 To Delete a Channel ................................................................ 15
5.9 Receiving and Responding to a Radio Call ............................. 16

5.10 Making a Call ......................................................................... 16
5.11 Monitor ................................................................................... 16
5.12 Man Down Alarm.................................................................... 17
5.13 Battery Voltage Test ............................................................... 17
6. ADVANCED FEATURES ............................................................. 18
6.1 Access Advanced Features for Private Call............................. 18
6.2 Set up Advanced Features for Private Call .............................. 18
7.MAIN MENU FUNCTIONS............................................................ 20
7.1 Talk Group................................................................................ 20
7.2 SMS ......................................................................................... 20
7.3 Call Log.................................................................................... 20
7.4 Zone......................................................................................... 20
7.5 Scan......................................................................................... 21
7.6 Roaming................................................................................... 22
7.7 Settings .................................................................................... 22
7.8 Record ..................................................................................... 34
7.9 GPS Positioning Function(Optional with installed GPS) .......... 35
7.10 APRS Location Reporting(Supported by GPS)...................... 36
7.11 Digital Monitor ........................................................................ 38
8.RESET........................................................................................... 39
9.TROUBLE SHOOTING GUIDE..................................................... 40
10.PROGRAMMING GUIDE............................................................ 41
11.ON-LINE SERVICE AND SUPPORT .......................................... 43
SAFETY ........................................................................................... 44
12.TECHNICAL SPECIFICATIONS................................................. 46

1Digital DMR and Analog UHF/VHF Two Way Radio
1. UNPACKING AND CHECKING THE EQUIPMENT
Unpack the radio carefully. We recommend that you identify the items listed
in the following table before discarding the packing materials. If any items
are missing or have been damaged during shipment, please contact the
carrier or the dealers immediately.
1.1 Supplied Accessories
Item Quantity
Antenna 1
Li-ion Battery Pack 1
Battery Charger 1
AC Adaptor 1
Belt Clip 1
Hand Strap 1
Instruction Manual 1
Programming Cable 1

2
Digital DMR and Analog UHF/VHF Two Way Radio
1. UNPACKING AND CHECKING THE EQUIPMENT
1.2 Standard Accessories
Antenna
Li-ion Battery Pack
(2100mAh)
(included in 2 battery kit)
Charger
AC Adaptor Belt Clip
(2 pcs included in 2 battery kit)
Instruction Manual
Li-ion Battery Pack
(3100mAh)
1.3 Optional Accessories
USB Programming cable
Programming Software
Software is available
online for Download:
QHM22
Microphone
Earphone
Car Charger

3Digital DMR and Analog UHF/VHF Two Way Radio
2.2 Use Caution with the Li-ion Battery
The Li-ion battery pack is not charged at the factory; please charge it
before use.
Charging the battery pack for the first time after purchase or extended
storage (more than 2 months) may not bring the battery pack to its normal
maximum operating capacity. Best operation will require fully charging/
discharging the battery two or three times before the operating capacity will
reach its best performance. The battery pack life may be depleted when
its operating time decreases even though it has been fully and correctly
charged. If this is the case, replace the battery pack.
Please use the specied charger provided by . Other models may
cause explosion and personal injury. After installing the battery pack, and
if the radio displays low battery with a red ashing lamp or voice prompt,
please charge the battery.
a. Do not short the battery terminals or throw the battery into a re. Never
attempt to remove the casing from the battery pack, as cannot be
held responsible for any accident caused by modifying the battery.
b.The ambient temperature should be between 5℃-40℃ (40˚F - 105˚F)
while charging the battery. Charging outside this range may not fully
charge the battery.
c. Please turn off the radio before inserting it into the charger. It may
otherwise interfere with correct charging.
d.To avoid interfering with the charging cycle, please do not cut off the
power or remove the battery during charging until the green light is on.
e. Do not recharge the battery pack if it is fully charged. This may shorten
the life of the battery pack or damage the battery pack.
f. Do not charge the battery or the radio if it is damp. Dry it before charging
to avoid damage.
2.1 Charging the Battery Pack
2. BATTERY INFORMATION
WARNING:
»When keys, key chains or other metals contact the battery terminal,
the battery may become damaged or injure a human. If the battery
terminals are short circuited it will generate a lot of heat. Take care

4
Digital DMR and Analog UHF/VHF Two Way Radio
2.3 How to Charge
a. Plug the AC adaptor into the AC outlet, and then plug the cable of the
AC adaptor into the DC jack located on the back of the charger. The
indicator light blinks orange and is then ready to charge a battery.
b.Plug the battery or the radio into the charger. Make sure the battery
terminals are good in contact with charging terminals. When the indicator
light turns to red--- charging begins.
c. It takes approximately 2-5 hours to fully charge the battery. When the
lamp switches to green, the charging is completed. Remove the battery
or the radio unit with its battery from socket
»When charging a radio (with the battery) the indicating lamp
will not turn green to show the fully charged status if the radio
is powered on. Only when the radio is switched off will the lamp
indicate normal operation and obtain a proper read on the status
of the battery. The radio consumes energy when it is powered on,
and the charger cannot detect the correct battery voltage while it
is in use. So, the charger will charge the battery in constant voltage
mode and fail to indicate correctly when the battery has been fully
charged.
2. BATTERY INFORMATION
when carrying and using the battery. Remember to put the battery or
radio into an insulated container for storage when not in use. Do not
put it into a metal container.

5Digital DMR and Analog UHF/VHF Two Way Radio
STATUS LED
Standby(No Battery) None
Precharge Red light Flashing
Charging Red Light
Fully Charged Green Light
»Trouble means battery is too warm, battery short-circuited or
charger short-circuited.
2.4 Normal Charging Tips
a. Self-Test: When powering on the charger, the red light turns on and then
turns off and stays off, which means the charger has passed the self test
and it is ready to charge the battery. If the light remains orange or the
red light blinks, it means the charger cannot pass it self-test and cannot
charge the battery.
b.Trickle Pre-Charging: If red light blinks when the battery is inserted
into the charger, it means that the battery voltage is low and the charger
is trickle-charging the battery (Pre-Charging Mode). The charger will
automatically turn into normal charging when the battery reaches a
certain electric charge, and if the red light stops blinking, it means the
battery voltage has reached a certain level, and the charger will charge
the battery in normal mode.
e. LED Indicator:
2. BATTERY INFORMATION
»Trickle charging (Pre-Charging Mode) time should not last beyond
30 minutes. If the indicating lamp still blinks red after 30 minutes
of trickle-charging, it means that the charger cannot charge the
battery correctly. Please check whether the battery or charger is
damaged.

6
Digital DMR and Analog UHF/VHF Two Way Radio
»Do not short circuit the battery terminals.
»Never attempt to remove the casing from the battery pack.
»Never store the battery in unsafe surroundings, as a short may
cause an explosion.
»Do not put the battery in a hot environment or throw it into a re,
as it may cause an explosion.
2.5 How to Store the Battery
a. If the battery needs to be stored, keep the level at approximately 80% of
full charge.
b.It should be kept in low temperature and dry environment.
c. Keep it away from hot places and direct sunlight.
2. BATTERY INFORMATION

7Digital DMR and Analog UHF/VHF Two Way Radio
3.2 Installing / Removing the Antenna
a. Installing the Antenna: Screw the antenna into the connector on the
top of the transceiver by holding the antenna at its base and turning it
clockwise until secure.
b.Removing the Antenna: Turn the antenna counter-clockwise to remove
it.
3.1 Installing / Removing the Battery
a. Match the two bottom grooves of the battery pack with the corresponding
guides on the back of the radio and then push it until you hear a click.
b.To remove the battery pack, slide the release latch at the top away from
the battery and remove the pack away from the transceiver.
3. PREPARATION

8
Digital DMR and Analog UHF/VHF Two Way Radio
3.4 Installing the Additional Speaker/Microphone (Optional)
Pry open the rubber MIC-Headset jack cover and then insert the Speaker
/ Microphone plug into the double jack. Push the plug straight in, do not
have at an angle, as damage may occur.
3.3 Installing / Removing the Belt Clip
a. Installing the Belt Clip: Place the belt clip above the corresponding holes
on the back of the radio, and screw it into place clockwise with the two
supplied screws.
b.Removing the Belt Clip: Unscrew counter-clockwise to remove the belt
clip.
3. PREPARATION

9Digital DMR and Analog UHF/VHF Two Way Radio
Speaker/Mic Jacks
PTT Button
[PF1] top Key
[PF2] bottom Key
4. RADIO OVERVIEW
PTT
PF3
Antenna
Menu key
P1 key/ P2 key
MIC Input
Channel Switch
POWER/VOL
LED Status Indicator
LCD
Exit Key
Speaker

10
Digital DMR and Analog UHF/VHF Two Way Radio
4. RADIO OVERVIEW
The top LED will help you to identify the current radio status.
4.1 Status Indications
LED Indication Status
Flashes Red Low battery voltage
Constant Red Transmitting
Constant Green Analog Receiving
Constant Cyan Digital Receiving
Flashes Green Scan
4.2 Programmed Key
It is possible to set different functions for [PF1], [PF2], [PF3], , keys.
Method 1: In radio Menu - Settings - Radio Set - Key - PF1, PF2, PF3, P1,P2.
Method 2: In PC software - Public - Optional Setting - Key function.
OFF No Function
Volt Check the current battery capacity voltage
Tx Power Switch the power between super high, high, middle and low power.
TalkAround Switch between Talk Around and Repeater mode
Reverse Turn on/off the frequency reverse function.
Encrypt Choose the digital encryption group for digital channel
Call In Analog mode, send the DTMF/5TONE/2TONE encode. This
function is only valid for analog channel.
VOX Set up the VOX level
VFO / MR Switch between VFO mode and memory channel mode.
Sub PTT Sub channel PTT, press to start the call on sub channel (NOTE: On
PF1 - PF2 - PF3 Keys Only)
Scan Press the key to start or stop scanning the channels in scan list.
FM Radio FM radio on/off
Alarm Long press the key to start alarm, short press again to exit the alarm.
Record Switch Enable/disable the recording function

11 Digital DMR and Analog UHF/VHF Two Way Radio
4. RADIO OVERVIEW
Record Start/stop recording. When stop recording, the radio will remind repeat
or send the record.
Messages In digital mode, press to enter into SMS messages
Dial Start the manually dial
GPS Info Check the GPS position information
Monitor Monitor the weak signal or the signal with unmatched ID.
Main Choose Choose channel A or channel B as the main channel
Hot Key 1~6 Selects Hot Keys 1-6 Note: Hot key setup details on next page
Work Alone Turn on/off the work alone function.
Nuisance Delete
During scanning, press the key to skip the unwanted channel
Digi Monitor In DMR mode, press the key to turn on/off digital monitor
Sub Ch Switch Turn on/ off the sub channel
Prior Zone Switch to Priority Zone
Program Scan
Press the key to start or stop the VFO scan.
The VFO scan start and end frequency should be set in CPS -Optional
Setting - VFO Scan.
Mic Feature In digital channel, switch the microphone tone to normal or enhanced mode.
LastCall Reply In digital channel, press the key to access the last call and press PTT
to call back.
Switch ChType Switch the channel type(Analog, Digital, Ana+Dgi, Dgi+Ana)
Simp
Repeater Enable / disable the simplex repeater function.
Ranging
When the radio receives a call and the suspension time is on, press
the key programmed as "Ranging" to obtain the caller's position and
distance. (Both party need GPS positioned, or will receive only GPS
information.)
CH Ranging
In standby, if the call contact type for a channel is "Private call" , press
the key programmed as "Channel Ranging" to turn on this function. The
radio will automatically start ranging function when turn to this channel.

12
Digital DMR and Analog UHF/VHF Two Way Radio
4. RADIO OVERVIEW
Max VOL Set In standby, press the key programmed as "Max Volume", will enable
users to set the maximum RX volume.
Slot Set Choose Slot for current channel, this function is only valid in repeater mode.
Ana SQ Set Set the squelch level in analog mode.
Roaming
In standby, press the key programmed as "Roaming" to search and lock
on the repeater with strongest signal. (Note: After lock on a repeater,
the radio will return to last frequency only after channel or frequency is
changed. The repeater frequency list must preprogrammed in CPS.)
Zone Select
In standby, press the programmed "Zone Select" key, it will allow you
input the zone number and then press conrm key will switch to the
zone.
Roaming Set Sets Roaming Function.
FixTime Mute Press the key to mute the radio in set time. The mute timing should be
set in CPS -Optional Setting - Other -Mute Timing.
CTC/DCS Set Set the CTCSS/DCS for analog channel.
Aprs Type Choose Aprs Type for current channel.
APRS Set Sets APRS Function.
TBST Send Send the TBST Tone.
BHT On/Off Enable / disable the bluetooth function.
Gps On/Off Enable / disable the GPS function.
Ch.Name Switch between channel name display and frequency display for the
current channel.
Aprs Send Manually transmit the APRS at the current channel.
Ana Aprs Info Fast access the analog aprs info menu.
GPS Roaming
Enable / disable the GPS roaming function. GPS roaming function
allows the radio switches to a zone when GPS positioning is within the
preset radiation of coordinates.

13 Digital DMR and Analog UHF/VHF Two Way Radio
The Switch operations listed are factory default functions. They can be
modied in CPS or by the front panel menus for other functions. If you do
not get the operations shown, check to see if function has been changed in
CPS by reading the radio and reviewing options.
4. RADIO OVERVIEW
4.4 Combination Key Function
+ number key operation:
Press key and hold until the LCD display “Next Please Press Dial Key”,
press the number key, it will perform the programmed function.
Combination key function shall be setup in PC software-Public-Hot key.
4.3 Hot Key Setting for PF1, PF2, PF3, P1, P2
Call
Analog
Should edit the analog quick call rst, then choose analog in
the hot key set. Press the key to transmit 2Tone/5Tone/DTMF
to start the analog quick call.
Digital
It allows to select a contact from the digital contact list, press
the key to switch the channel to the contact temporary. It will
switch back to the original contact after the group/personal
call hold time.
Menu
SMS Quick access to Messages in the menu
New Msg Quick access to New Msg in the Menu - Messages
Hot Text Quick access to Quick Text in the Menu - Messages
Received SMS Quick access to Inbox in the Menu - Messages
Send SMS Quick access to Out box in the Menu - Messages
Contact list Quick access to Contact list in the Menu - Contacts
Manual dial Quick access to Manual Dial in the Menu - Contacts
Call Log Quick access to Call Log in the Menu
Dialed Calls Quick access to Dialed Calls in the Menu - Call Log
Received Calls Quick access to Answered Calls in the Menu - Call Log
Missed Calls Quick access to Missed Calls in the Menu - Call Log
Zone Quick access to Zone in the Menu
Radio set Quick access to Radio Set in the Menu - Settings
Enter radio Menu-Settings-Radio Set-PF1, PF2,PF3,P1,P2,sub menu.
Users can choose settings for Hot Keys 1-6.
Hot Key function details must be setup in PC software – Public - Hot key.

14
Digital DMR and Analog UHF/VHF Two Way Radio
5.1 Power on the Radio
5.2 Adjust Volume
5.3 Main Band/Sub Band Switch
5.4 VFO/Channel Switch
5.5 Set Up VFO Frequency
Turn on the radio by turning the [Power/Volume] switch clockwise till a click
is heard, and the LCD displays will show a start-up message, and you will
hear a beep after 7 seconds.
Rotate the [Power/Volume] knob to adjust the volume. Turn clockwise to
increase the volume and counterclockwise to decrease the volume. The
LCD display will show the volume status during an adjustment.
Press the key to switch the main channel to the other channel
if there is 2 channels shown on the display. The channel with bold
characters is the main channel.
Press the key to switch between VFO and channel display.
Turn the radio to VFO mode , then press the key to switch to the
main band, the VFO frequency can only be set up when the channel is in
the main "bold text" channel.
Operation 1: Input the VFO frequency directly by the keyboard.
Operation 2: Turn the channel selector to adjust the VFO frequency steps.
5. BASIC OPERATIONS
5.6 Select a Channel
Press key to switch the radio between VFO and Channel mode, select
Channel mode.
Operation 1: Turn the channel switch to select a channel.
Operation 2: Input the channel numbers by the keyboard. For example, if
you want switch to channel 99, input 0+0+9+9 a total of 4 digits, and it will
switch to channel 99.
A channel can either be Analog or Digital.
For the analog channels the Push-To-Talk button is always available, and
on the Digital Channels the parameters can be set up by the users / system
operators by individual channel to allow talk permit.
