Baby Lock Elageo Configuration guide

The Ellageo Sewing & Embroidery Machine
The Ellageo is an innovative machine from Baby Lock that will
add luxury to all of your sewing and embroidery projects. With
advanced features found on a Baby Lock, you can edit designs
on your machine and transfer them back into your computer,
download upgrades and more. This technology will expand your
creative options, but you’ll also have a head start with a built-
in design library that includes a multitude of exclusive designs
as well as a built-in collection of 358 stitches. Plus, the Ellageo
is packed with all of the convenient Baby Lock features that
enhance your love of sewing. Change the way you feel about
sewing and embroidery with the Baby Lock Ellageo.
For the love of sewing.
FOR THE LOVE OF SEWING
FOR THE LOVE OF SEWING
FOR THE LOVE OF SEWING
• 358 Built-in stitches including
• 107 Utility with 14 one-step
buttonhole styles
• 58 Combinable Utility stitches
• 142 Decorative
• 23 Wide satin
• 14 Satin
• 14 Cross
• 3 Built-in alphabets
• Stitch length 0.0mm - 5.0mm
• Maximum Utility stitch width: 7mm
• Utility stitch editing capabilities
• Store personal stitch settings for each
Utility stitch
• Decorative stitch editing capabilities
• Edit and combine Character/
Decorative Stitches
• 16 Memory pockets for Character/
Decorative stitches equaling 256KB
• Mirror-imaging
• Lock key for Utility and Decorative
stitches
• Lateral and diagonal feeding
• Variable needle positions
• Fully automatic built-in darning
• Twin needle settings
Advanced Sewing Features
Embroidery Capabilities
• Combine embroidery designs on screen
• Character/Text array function
• Character spacing
• 1°, 10°, and 90° Pattern rotation
• Design enlargement (up to 20%)
• Design reduction (up to 10%)
• Mirror imaging
• Design color selections
Embroidery Editing Capabilities
• Language conversion capabilities
(3 languages)
• Warranty (25 years limited, 10 years
parts, 5 years computer circuit,
5 years electrical, 1 year labor)
• Optional Gold Standard service and
support for your peace of mind
• Optional embroidery hoops
• Small 1” x 2-1/2” (20mm x 60mm)
• Optional 512MB flash drive
• Optional thread stand
Additional Information
• Convenient One-Touch Buttons
• Start/Stop
• Reverse sewing
• Needle up/down
• Thread cutter
• Automatic presser foot lift
• Ergonomic knee lift with extra high
presser foot
• 10mm automatic and 13mm manual
• Programmable needle up/down
• Needle plate with scale in inches
and centimeters
• Electronic foot control with separate
power cord
• Free arm with drop feed lever
• Two accessory storage compartments
• Large sewing surface 12-5/8" x 8-3/16"
(320mm x 212mm)
Convenient Sewing Features
• Built-in embroidery design library
• 197 Built-in embroidery designs including 115 Baby Lock exclusive designs
• 120 Frame combinations
• 11 Font styles including one exclusive script
• Embroiders up to 6-1/4” x 10-1/4” (160mm x 260mm) embroidery field
• 12 Memory pockets for Embroidery and Embroidery Edit equaling 767KB
• Reads embroidery designs with a stitch capacity of up to 200,000 stitches per design
• LCD color touch screen (240 x 320 dot matrix) shows
• Estimated embroidery time display and stitch count
• Needle position placement (1, 10, or 100 stitch increments)
• Measurements displayed in inches or millimeters (mm)
• Thread color indicator
• On-screen hoop size indicator
• Low bobbin thread indicator
• 300 Color names
• Embroidery speed up to 800 spm
• 8-point trial check points
• Alternate bobbin case for prewound bobbins
• Resume feature
• On-screen grid
• Program thread cutter ON or OFF
• Knee lifter
• Touch pen (stylus)
• USB cable
• 14 Snap-on feet
• Buttonhole
• Embroidery
• Overcasting
• Monogramming
• Zipper
• Zigzag
• Blind stitch
• Button fitting
• Cording (with 3 cord guides)
• Walking
• Blind stitch (with guide)
• Narrow hemmer
• Free-motion quilting
• Straight stitch
• Hard case for machine
• Carrying case for embroidery unit
• Straight stitch needle plate
• Alternate bobbin case for use with
pre-wound bobbins
• Bobbin center pin
• Embroidery bobbin thread
• Bobbins
• Seam ripper
• Twin needle
• Embroidery hoops and grids included
• Extra large 6-1/4” x 10-1/4”
(160mm x 260mm)
• Large 5” x 7” (130mm x 180mm)
• Medium 4” x 4” (100mm x 100mm)
• Plus more
Included Accessories
• USB direct connect (type A & B)
• LCD touch screen (240 x 320 dot matrix) with touch pen
• Embroidery card slot
• Advanced needle threader
• Automatic thread cutter
• Quick-Set, top-loading bobbin with sensor
• Quick-Set, bobbin winder
• Independent bobbin winding system
• Automatic sensors
• Thread tension control makes adjustments to feed thread properly
• Upper and lower thread sensors to alert when threads are broken
• On-screen hoop sensor to recommend size of hoop to use
• 5 LED lights that illuminate the needle and work area
• Access designs stored in folders using USB (type A)
• Sewing speed up to 1,000 spm
Technology Features
Downloadable Software from
www.babylock.com
Your Ellageo will stay current with
future upgrades via USB connection
• Built-in Operational Guide
• Built-in Sewing Application Guide
• Built-in Help Messages
Instructional and Help Resources
Sewing & Embroidery machine

Sewing & Embroidery machine
FOR THE LOVE OF SEWING
FOR THE LOVE OF SEWING
FOR THE LOVE OF SEWING
ellageo
Key Embroidery and Sewing Features
Embroidery Design Library
Built-in (197 total designs)
The built-in library gives you an
amazing selection of 197 built-in
designs that will make all of
your projects unique, including
115 designs created exclusively
for Baby Lock.
Embroidery Lettering
The Ellageo gives you the ability to
arrange your text and combine it
with your designs on-screen. Give
your projects a personalized touch
with 11 font styles to choose from,
including one exclusive script.
358 Built-in Stitches
Add a personal touch and
versatility to all of your projects!
Choose from 358 built-in stitches,
including 107 utility stitches (with
14 styles of one-step buttonholes),
58 combinable utility stitches,
142 decorative, 23 wide satin,
14 satin, and 14 cross stitches.
Embroidery Editing On-Screen
Edit your designs effortlessly with the
Ellageo. Use the color LCD screen
to rotate, resize, and combine your
designs, or use the character/text
array function to give designs the
exact look you’re going for.
Quick-Set, Top-Loading
Bobbin
Bobbins are a breeze with the
Quick-Set, top-loading bobbin,
which comes with a clear cover so
you’ll never run out in the middle
of stitching.
Two-Way USB Connectivity
Easily transfer designs to and from
your PC. Build your design library
with edited designs, save and
access designs on your computer,
download machine upgrades and
more!
Advanced Needle Threader
The advanced needle threader
allows you to change thread colors
quickly without straining your eyes.
LCD Color Touch Screen
(240 x 320 size) with touch pen
This easy-to-read touch screen makes
changing your machine’s settings
simple, and the color LCD screen
allows you to edit your designs while
distinguishing between thread colors.
LBSP-BLL
800-422-2952
www.babylock.com
