Fyrite®UserSoftware
Instruction Manual 0024-9465
Rev. 3 - June 2011
Fyrite®User Software Installation Guide
Instruction Manual 0024-9465
1. Introduction
This instruction manual describes how to install Fyrite®User Software onto computers that run under the Windows XP,
Windows Vista, and Windows 7 operating systems. (Note that the Fyrite User Software is not compatible with Windows
operating systems prior to Windows XP.) Select the appropriate installation section based on your operating system.
2. Installation: Windows XP
After the CD is loaded, the Setup window will be displayed. Click on OK. If applicable, wait for the Net 3.5 Framework set
up to complete. Then follow the instructions listed below.
1. Click on OK. 2. Wait for Net 3.5 Framework set up completion (optional)
3. Click on Next. 4. Click on Finish.
5. Click on Next. 6. Click on Next.

Fyrite®User Software Installation Instructions
2 0024-9465 Rev 3
7. Click on Next. 8. Click on Close.
9. Click on OK.
10. After installation:
Open Fyrite® User Software via the desktop icon.
Connect the instrument to the PC with a USB cable.
Power up the unit.
When first connected, a “Found New Hardware
Wizard” screen will be displayed.

Fyrite®User Software Installation Instructions
0024-9465 Rev 3 3
11. Select “No, not this time”. Click on Next. 12. Click on “Continue Anyway”.
13. Click on Finish.
14. For further information about the use of this product,
refer to the Fyrite user manual.
3. Installation: Windows Vista
After loading the CD, the Security window will be displayed. Click on OK. If applicable, wait for the Net 3.5 Framework set
up to complete. Then follow the instructions listed below.
1. Click on OK. 2. Wait for Net 3.5 Framework set up completion (optional)

Fyrite®User Software Installation Instructions
4 0024-9465 Rev 3
3. Click on Continue. 4. Click on Next.
5. Click on Install. 6. Click on “Install this driver software anyway”.
7. Click on Finish. 8. Click on Next.

Fyrite®User Software Installation Instructions
0024-9465 Rev 3 5
9. Click on Next. 10. Click on Next.
11. The installation will progress. Click Continue. 12. The installation will progress. Click on Close.
13. Click on OK.
14. After installation
Open Fyrite® User Software via the desktop icon.
Connect the instrument to the PC with a USB cable.
Power up the unit.
When first connected, a “Found New Hardware
Wizard” screen will be displayed.

Fyrite®User Software Installation Instructions
6 0024-9465 Rev 3
15. Select “No, not this time”. Click on Next. 16. Select “Install software automatically”. Click on Next.
17. Click on “Continue Anyway”. 18. Click on Finish.
19. For further information about the use of this product, refer to the Fyrite® user manual.

Fyrite®User Software Installation Instructions
0024-9465 Rev 3 7
4. Installation: Windows 7
After loading the CD, the AutoPlay window will be displayed. Click on Run Setup.EXE. If applicable, wait for the Net 3.5
Framework set up to complete. Then follow the instructions listed below.
1. Click on Run Setup.exe.
2. Wait for Net 3.5 Framework set up completion (optional).
3. Click on OK.
4. Click on Next. 5. Click on Finish.

Fyrite®User Software Installation Instructions
8 0024-9465 Rev 3
6. Click on Next. 7. Click on Next.
8. Click on Next. 9. Wait for software to be installed.
10. Click on Close. 11. Click OK.

Fyrite®User Software Installation Instructions
0024-9465 Rev 3 9
12. After installation
Open Fyrite® User Software via the Start menu.
Connect the instrument to the PC with a USB
cable.
Power up the unit.
When first connected, a “Found New Hardware
Wizard” screen will be displayed.
13. For further information about the use of this product,
refer to the Fyrite® user manual.
5. Fyrite®User Software Overview
This section shows sample menu screens of the Fyrite®User Software. Note that your screens may vary depending on
the instrument that is connected.
Main Screen Set Instrument Time
Calibration Password Time Meters
B-Smart Logged Data

Fyrite®User Software Installation Instructions
10 0024-9465 Rev 3
Saved Measurements Test IDs
User/Customer ID Settings
Customer Logo Setup Custom Fuel
Update Instrument Software Language


Fyrite®User Software Installation Instructions
0024-9465 Rev 3 11
