Badeloft AT-03 User manual

Badeloft
AT-03
Installation Instructions

1

2

Name QTY.
spout
hand shower
hose
S2.5mm hex wrench
S4mm hex wrench
connecting pipe
water inlet pipe
M5x15 hex. bolt
M5 washer
water test base
rubber ring
rubber water stop
dustproof cover
fixing nut
rosette
expansion anchor bolts
plastic box
manual
water pipe
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
1
1
1
1
1
1
2
8
8
1
1
2
1
1
1
4
1
1
1
specifications:
water pipe thread: G1/2
working pressure: 0.1Mpa~0.5Mpa
working temp.: 3°C ~ 85°C
working material: normal water
producing standard: GB 18148-2003
Checking List
19
7
6
9
18
5
4
10
17
16
8
15
14
13
12
11
8
3
2
1
SE 4009 29.
3

disassemble and take out put the dustproof cover on
90°±2°
cold water
hot water
fix the position of the tap
underground parts installation
4

cold
hot connect water pipes
fix the screw position
!
fasten the bolts after adjusted the level
highest underground level
lowest underground level
underground parts installation
150mm
150mm
50mm
40mm
Ø10 depth 40
5

hot
adjust again the level after
fasten the bolts.
take off the cover
install water test spareparts
hot
hot
cold
cold
!
underground parts installation
6

Mpa ON
ON
turn the water on under pressure 0.8Mpa,
keep for 30min to be sure no water leak.
turn off the water,
take off the testing spare parts.
off
off
off
off
Caution:
please decompress the water
before unfasten the screw.
!
install pipe cleaning spare parts.
underground parts installation
7

turn on the valve to let water flush to
clean the water pipes
on on
off
off
turn off the valve, take out the
pipe cleaning spare parts.
put on the cover
hot
cold
underground parts installation
8

paving tiles, use silicon
to close the gaps.
after everything dried,
cut off the upper ground parts.
take off the cover
underground parts installation
9

taps installation
10

taps installation
①
③
fasten the spout onto the
connection pipe.
②put on the rosette be careful to
avoid scratches.
Fasten the brass nut onto the
body, use thread glue if necessary.
,
①
②
insert the 2 water pipes in the
tap into the holes in the plastic box
underground.
fasten the brass nut by 4 screws.
①
②
③
①
②
11

push the rosette smoothly
down to the ground
install the hand shower sets
taps installation
12

taps installation
OFF
OFF
ON
ON
C
C
H/C
H/C
H
H
Turn the handle according to arrow
showed direction, water comes out from
spout. Temperature from cold to hot by
turning.
Turn the handle according to arrow
showed direction, water comes out from
hand shower. Temperature from cold to
hot by turning.
13
