BAIC D50 Series User manual

1
D50
Foreword
Thank you for choosing this car.
This instruction manual applies to all the models of D50 series. Before using the vehicle for the first time, please be sure to read this manual carefully and get
familiar with the vehicle structure, various functions, operation methods and relevant regulations of BAIC as soon as possible. The user will lose the right to
claim because of failed following the instruction of the user manual, or the modification without the approval of BAIC. The contents contained in the
instruction manual will help you learn the correct method of driving and maintenance, so that you can fully enjoy the fun of driving.
This manual aims to provide users with instructions on the use and maintenance of vehicles. Please check the purchase contract for the specific configuration
of the vehicles you purchased. If you have any questions about this car and this manual, please contact BAIC distributor in your country.
The pictures, data and instructions contained in this manual conform to the current product definition. In view of BAIC will continue to modify and improve
the vehicle, the pictures, data and instructions in the operation manual are only for the introduction of the use method, not as a basis for order acceptance.
We will continue to improve all models. Therefore, we reserve the right to change the vehicle, equipment or part of the technical specifications at any time.
Please understand. Data relating to delivery scope, appearance, performance, size, weight, fuel consumption, specifications and vehicle functions are correct
as of the time of delivered. Some of the equipment/functions described in this article may not be installed on your vehicle (unclearly issues please can ask the
local distributor). All information, drawings or descriptions in this manual shall not be deemed as a legal commitment.
BAIC solemnly declares that it is solely responsible for the revision of this manual, and reserves all rights and interests stipulated in the copyright law and the
right to modify.
Without the prior written consent of BAIC, it is not allowed to reproduce, copy or translate any part of this user manual, copy or store this publication in the
public retrieval system, or transmit it by electronic, mechanical record or any other form.

2
D50
Foreword
The equipment/functions marked with "*" are only applicable to some models or only used as optional parts or optional functions for some models. Please
refer to the real car configuration.
"Warning", "attention", "prompt" and some special symbols will appear frequently in this instruction manual. Special attention should be paid to these contents,
ignoring these warning instructions may lead to personal injury or damage to your vehicle.
"Warning" means that failure to follow instructions is likely to result in serious bodily injury or even death;
"Caution" means that dangerous or unsafe operation will result in personal injury or vehicle damage;
Tips give helpful information.
Indicate, which means "do not do this" or "do not let this happen."
Indicate, which means "please do this" or "this operation is feasible".
A similar sign that in order to indicate an item in the diagram.
A similar sign indicates the direction of movement or action.
BAIC International Development Co., Ltd

3
D50
Notes to users
1. Before you use the vehicle, please be sure to
carefully read this instruction manual, in the
process of using the vehicle comply with the
operation method suggested in the instruction
manual, to ensure that familiar with the operation
and maintenance of the vehicle and safe driving
vehicles. We are not responsible for any loss
caused by improper use of the vehicle.
2. Please be sure to carry out regular vehicle
maintenance and maintenance in accordance with
the provisions of the maintenance information
form.
3. In order to adapt to drivers of different sizes,
the driving position should be adjusted as follows:
●Seat front and rear adjustment, height adjustment
*, backrest inclination adjustment, headrest
adjustment;
●Steering wheel position adjustment;
●Internal and external rearview mirror position
adjustment.
4. Wearing safety belt is a necessary guarantee for
the safety of drivers and passengers. Adults should
wear seat belts correctly and children should
correctly select and use child restraints and seat
belts in accordance with the relevant requirements
in this instruction manual.
5. Checking before driving:
●Whether the vehicle lamps and lanterns work
normally;
●Cleanliness of windscreen and rearview mirror,
working condition of wiper;
●Rearview mirror Angle position;
●Tire pressure and tire wear. The condition of the tire
has a direct impact on the vehicle's power, economy
and comfort, more related to traffic safety, please
correctly use and maintain the wheels (including
spare wheels) according to the regulations. Check the
tire pressure when the tire is cold.
●Engine oil, coolant, brake fluid and other liquid
level height;
●Battery status.
6. Put the start/stop button in "RUN" mode to check
the alarm lights.
7. Engine operation:
●Do not run the engine in the closed warehouse for a
long time to prevent exhaust poisoning;
●When the battery power failure, the engine
electronic control unit and starter will not work
properly, the engine cannot start
8. braking
●When the engine is shut off, the vacuum
booster device will not work, and the brake
pedal trample force will be significantly
increased, and the braking efficiency will be
greatly reduced. Therefore, it is strictly
prohibited for vehicles to slide when the engine
is shut down
●For vehicles equipped with automatic
transmission, stop the vehicle before leaving
the vehicle, put the shift handle in the position
of "N", apply parking brake and then put the
shift handle in the position of "P". For vehicles
equipped with manual transmission, stop the
vehicle before leaving the vehicle, and then put
the shift handle in neutral position and apply
parking brake

4
D50
●When braking in emergency or on wet road,
ABS can prevent the wheels from locking, which
is conducive to the stability of driving direction.
However, careful and safe driving is still
necessary
9. About the combined instrument alarm lamp:
●If, while driving on combination instrument have
red alarm lamp (such as brake, engine oil, coolant
temperature, etc.) to light, should be safe parked
car as soon as possible, according to this
instruction manual instructions to check the
vehicle, if necessary please contact BAIC shop of
distribute of engage by special arrangement.
●If there is yellow alarm light on the combination
instrument on the way, please check the vehicle
according to the instructions in this operation
manual. If necessary, please contact BAIC special
dealership for maintenance
10. Electrical accessories
●Any electrical accessories must be connected in
accordance with the specified wiring location and
wiring methods, please go to BAIC dealership
11. The car is equipped with a catalytic converter. It
is strictly prohibited to use leaded gasoline, otherwise
the catalytic converter will be damaged soon
12. Safety tips
Follow the following important driving rules to help
ensure the safety of drivers and passengers
throughout the journey!
●Strictly abide by traffic rules and drive safely
●Do not drive after drinking or taking drugs;
●Observe the speed limit sign and do not exceed the
speed limit
13. When the front windshield is coated
internally, pay special attention not to let water
into the instrument panel; Daily use vehicles
don't take wet umbrellas, aside the water glass
with the liquid on the dashboard, otherwise the
water into the dashboard may lead to electrical
components damage is installed on the
dashboard
14. Please go to BAIC dealership for vehicle
repair and modification. BAIC shop of
distribute of engage by special arrangement
with the necessary tools, diagnostic equipment,
maintenance information and have the
qualification of the staff.

5
D50
General Catalogue Safety operation instruction 1
Operating system and equipment 2
Driving Guide 3
Maintenance 4
Emergency treatment 5
Technical Data 6
Maintenance Information 7
