Baird TI4603BC User manual

User Guide
Model:
TI4603BC
 $ #
A3./=-<//8
Please Read this Manual carefully before using your Television
and retain for future reference.

2

3
CONTENTS
Important Safety Instructions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-5
What is included in the box. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Attaching/Detaching the stand and wall mounting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Getting Started - Initial Set Up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
TV Buttons and Input Source Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Remote Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11-12
TV Menu Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13-18
Channel Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Picture Menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Sound Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Time Menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Lock Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Setup Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
PC Operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19-20
8 Day TV Guide. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
USB Record . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
USB Mode / Media Player . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
General Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24-26
Frequently Asked Questions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Technical Specications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

4
IMPORTANT SAFETY INSTRUCTIONS
Please read these instructions. All the safety and operating instructions should be read before the appliance is
operated.
Warnings
• To reduce the risk of re, electric shock or damage to the television, do not expose it to dust, rain or moisture, or place any
objects lled with liquids on or near the television.
• Do not place the television in a conned space, ensure that nothing can obstruct the ventilation openings at the rear of
the television.
Dispose of this television and any components including batteries in an environmentally friendly manner. If in doubt,
please contact your local authority for details of recycling.
Safety
• For your safety, this appliance is tted with a fused moulded 3 pin mains plug. Should the fuse need to be replaced,
ensure that any replacement is of the same amperage and approved with the BSI mark.
• The television must be connected to a mains socket outlet with a protective earthing connection.
• Never try and replace the mains plug unless you have adequate qualications and are legally authorised to do so. In the
event that a replacement Mains cable is required, contact the manufacturer for a suitable replacement.
• Never use the television if it is damaged in any way.
• Always place the television on a at level surface avoiding anywhere which may be subject to strong vibration.
• Ensure the television is not placed on top of the power cable as the weight of the television may damage the cable and
cause a safety hazard.
• Never place mobile phones, speakers or any other device which may cause magnetic or radio interference in close
proximity to the television. If interference is apparent, move the device causing the interference away from the television.
• To disconnect the apparatus from the mains, disconnect the plug from the wall socket. Always ensure the switch on the
wall socket is readily accessible.
• Batteries (battery pack or batteries installed) shall not be exposed to excessive heat such as sunshine, re or the like.
• Install the product at least 5cm from the wall for ventilation.
Maintenance
• To clean this unit, wipe with a soft, dry cloth. If the surfaces are extremely dirty, use a soft cloth dipped in a soap and
water solution or a weak detergent solution.
• Use eyeglass cleaner to remove stubborn dirt from the LCD/LED Screen.
• Never use alcohol, paint thinner or benzene to clean this unit.
• Before using a chemically treated cloth, read the instructions that came with the cloth carefully.
CAUTION: If water or other liquid enters the television through the display panel surface,
a malfunction may occur.
Packaging
• The safest way to transport your television is in the original box/packaging - please save your packaging for this purpose.
• You will need the original box/packaging in the event of warranty/service repair or support. We are unable to carry out
warranty/service if you are unable to package it correctly.
To prevent the risk of re, keep candles or other open ames
away from this product at all times

5
IMPORTANT SAFETY INSTRUCTIONS
Please read these instructions. All the safety and operating instructions should be read before the appliance is
operated.
Important Information Regarding Use of Video Games, Computers, Captions or Other
Fixed Image Displays
The extended use of xed image programme material can cause a permanent “shadow image”on the LCD
panel.
This background image is viewable on normal programmes in the form of a stationary xed image. This type of
irreversible LCD/LED panel deterioration can be limited by observing the following steps:
1. Reduce the brightness/contrast setting to a minimum acceptable viewing level.
2. Do not display a xed image for extended periods of time.
3. Turn the power o when not in actual use.
Examples of images that you need to watch out for are as follows (this is not an exhaustive list):
• TV Channel Logos: e.g. Shopping channel logos and pricing displays-especially if they are bright and stationary. Moving or
low-contrast graphics are less likely to cause ageing of the screen.
• Time Displays
• Teletext: Do not view a stationary page for a long period of time
• TV/DVD Menus: e.g. Listings of DVD disk content
• Pause Mode: Do not leave the TV in pause mode for long periods of time, e.g. When watching DVDs or videos.
Important: Once a‘shadow image/screen burn’occurs, it will never disappear and is not repairable under
warranty.
How do I dispose of this product?
UK: Waste electrical products should not be disposed of with household waste. Separate
disposal facilities exist. For your nearest facilities, please see www.recycle-more.co.uk or in store
for details.
ROI: Waste electrical products should not be disposed of with household waste. Separate
disposal facilities exist. Check with your Local Authority or retailer for recycling advice.
Batteries
• Observe the correct polarity when inserting batteries.
• Do not use dierent types of batteries together or mix old and new batteries.
• Dispose of batteries in an environmentally friendly way.
• Certain regions may regulate the disposal of batteries.
• If you are not using your TV for an extended period of time then remove the batteries to prevent
possible damage due to leakage.
• Please consult your local authority regarding disposal.
Cd

6
Please save your packaging as you will need this in the event of warranty/service repair or support. We are
unable to carry out warranty/service if you are unable to package it correctly. The safest way to package your
item in the event of warranty/service repair is in it’s original box/packaging.
WHAT IS INCLUDED IN THE BOX
Accessories
Included with this TV are the following accessories:
1 x User Guide
1 x Quick Start Guide
2 x AAA Batteries
1 x TV
1 x Remote Control
User Guide
Model:
TI4603BC
 $ #
A3./=-<//8
1
4
2
5
3
6
Insertthe stand into the bottom of the LED TV body and tigten the
screws.
Inserttwo UM-4 (AAA) batteries into the remote control. Takecare to
observecorrect polarity.
Insertthe aerial cable into the RF socket.
Switchon the TV by pressing the power button on the top of the TV
oron the remote control. (The LED will change from red to green)
Connectthe power cord to the AC IN socket,then
plugthe other end of the power cord into a suit-
ablewall socket. Switch on the power to the TV.
Pressthe LED TV menu button on the remote control to bring up the
ONSCREEN DISPLAY.Select AUTO TUNING using the arrow DOWN
button.Use the arrow RIGHT button to go to the submenu and check
thatthe COUNTRY setting is UK. If not, use the arrow DOWN button
andthan press ENTER to start AUTO TUNE, this will take several
minutes.On completion the TV will store all ANALOGUE and DIGITAL
PROGRAMMESavailable in your area and will then display the rst
channelfound. This may not be BBC1.
Forall other Setup Information please refer to your User Manual.
32”, 37” 42”,47”
32”, 37” 42”,47”
Switchon the
WallSocket and
theMaster Power
Switchon the
rearof the TV.
QUICK START GUIDE
Easy 6 step installation
Pleaseread the section on SAFET Y before proceeding with your installation.
Thankyou for purchasing this Baird T V. Remove the TV from the packaging and proceed with the followingsteps for best results.
Tofully understand the features and safety advice of your LED TV, we strongly recommend that you read the manual enclosed with the LED TV.
1 x Bottom Stand
What is included in the box
1 x Stand Cover
1 x Stand Components and
xing screws

7
Important installation instructions
NOTE: For safety, you are advised to seek the assistance of a second person when installing or removing the
stand. Laying the TV at on a table withe bottom of the TV level with the edge makes tment and removal
much easier.
Detaching the Stand
1) Remove the screws highlighted
IMPORTANT - Before drilling any holes in the wall ensure you are not
drilling where there could be any electric wires, water or gas pipes.
Wall mounting the TV
This television requires a VESA STANDARD wall mount, or equivalent (The size of
the mount will vary depending upon the screen size of your TV).
1) Your TV is provided with four hexagonal spacers to attach your wall mount.
2) The wall mount can now be easily attached to the spacers using the screws provided. The positions of the
spacers is indicated in the diagram below.
Important – If wall mounting this TV, only use the spacers already provided in the wall mounting holes. Using
other screws which are longer could cause irreparable damage to internal parts.
For optimum viewing, if wall mounting the TV higher than eye level, the TV should be tilted downwards so
that the TV’s screen is ‘face on’. See g 1 and 2
Vi
g 2 TV
ewing angle
TV
Viewing angle
g 1
ATTACHING / DETACHING THE STAND
Attaching the Stand
Insert the stand into the bottom of the LED TV body and tighten the screws.

8
GETTING STARTED - INITIAL SET UP
Getting Started - Initial Set Up
1) Connect the TV to the TV Aerial wall socket
(Fig A)
2) Connect the power cable to the wall socket,
ensuring the wall socket is OFF.
3) Insert the batteries into the Remote control. Take
care to observe correct polarity.
4) Switch on the wall socket and then the
television using the red (power) button on the
remote control: or on the bottom of your TV.
Fig A Fig B
5. You will now be welcomed with the initial set-up
screen. Press OK twice to conrm OSD LANGUAGE
and COUNTRY. Then press OK again and the auto
tuning will start.
6) After tuning the following screen will appear.
Press OK to conrm Country Code, again to
conrm Primary region and twice more to conrm
Secondary and Territory Regions. Your rst
Programme should now appear.
Tip: If the TV nds some, but not all, of the Digital channels, the TV is functioning correctly but the signal being
received is not strong enough. (The signal strength needs to be above 85% - you can see the signal strength
the TV is receiving when you change channels/ programmes) you will need to increase the signal reception
in order to receive all of the channels available. The most economical way to do this is by purchasing and
connecting a ‘signal booster’ in between the TV and the TV aerial socket. If this does not solve the problem,
you will need to upgrade the TV aerial to a digital hi-gain compatible aerial
Signal Booster
Connect between TV
and TV aerial socket

9
TV BUTTONS & SOURCE MENU
Choosing Mode Input/Source
To switch between the dierent input/connections.
A) Using the buttons on the remote control:
1) Press [SOURCE/ AV] - The source menu will appear
2) Press [\/] or [/\] to select the input you require.
3) Press [OK]
B) Using the buttons on the Television:
1) Press [SOURCE]
2) Scroll up / down using CH+/ CH- buttons to the input/
source you require
3) Press Vol+ to change input/source to the one selected.
Volume up and down
Menu up and down
Displays Menu/OSD | Displays the input source menu
Standby Power On/O
Red is standby mode, green when your TV is switched on.
Infrared sensor for the remote control.
Turn on/o the LED TV power
1
2
3
4
5
6
7
TV Buttons and Source Menu
DTV
ATV
Input Source
AV
COMPONENT
HDMI 1
HDMI 2
HDMI 3
PC
SCART
Media
OK
VOL+ VOL- CH+ CH- MENU SOURCE STANDB Y
5

10
Remote Control
REMOTE CONTROL
STANDBY Switch on the TV when in standby or vice versa
MUTE Mute the sound or vice versa
NUMBER BUTTONS
0 – 9 to select a TV channel directly.
REC LIST Opens the list of Programmes you have
previously recorded
To return to the previous channel viewed
EPG Opens the 8 Day TV Guide (Digital TV mode)
SUBTITLE To switch the dialogue at the bottom of the
screen (on/o)
AUDIO Switches audio output from L - R and Mono -
Stereo
DISPLAY To switch o the screen when listening to radio
TV/RADIO Switch to Digital TV and switch between TV
and radio in Digital TV mode
Allows you to navigate the on-screen menus
and adjust the system settings to your
preference
MENU To display OSD menu
EXIT To exit all menus
VOL To increase / decrease the sound level
FAV Displays Favourites list.
To Record what is currently on television
MEDIA No function
CH To increase or decrease the number of the
channel being watched
SOURCE To display the input/source menu
P.MODE Scrolls through picture mode options
S.MODE Scrolls through sound mode options
SLEEP Press repeatedly to cycle through the sleep
options
TEXT To enter Teletext mode
HOLD Teletext mode - Hold current page which is
displayed
REVEAL Teletext mode - To reveal or hide the hidden
words
SUBPAGE Sub coded page access.
TIMESHIFT In DTV mode, press to execute the time shift
function.
INDEX To display the index page
SIZE Changes text size in Analogue TV mode
To play/pause
To stop the playback
To play in fast rewind mode
To play in fast forward mode
To restart the current chapter
To advance forward to the next chapter
COLOURED BUTTONS
For navigating as prompted on screen
1
2
3
4
5
Only operates
when a
compatible
USB device is
connected
1
4
5
2
3

11
Connecting a DVD Player/Recorder, Video Recorder or Cable/Satellite Box
TVs Input/Source should be set to SCART
CONNECTIONS
RF I N
SCART
TV Aerial
Wall Socket SCART
OUT RF
IN
RF
OUT
DVD or VCR
Connections
2
3Y Pb Pr
CVBS R L Earphone
Out
W RY
R
GB
A COAX Audio Out Coax Audio Output
B USB USB-input
C1 HDMI HDMI-input
C2 HDMI HDMI-input
C3 HDMI HDMI-input
D CI CARD IN CI CARD input
E CVBS CVBS Input
F VIDEO Audio In /
YPbPr Audio In
Video Audio input/YPbPr Audio input
G YPbPr Component-input
H SCART SCART-input
I VGA (PC) Audio In VGA-PC-Audio-input
J VGA (PC) VGA-PC-input
K RF IN RF-input (tv-antenna)
L Earphone Out Earphone Output
A G L
C2 C3 H I K
D E FC1B
J

12
Connections
CONNECTIONS
Connecting a Camcorder, Camera or Games Console
Source should be set to Video
Connecting a High Denition (HD) Device
Option 1 - via HDMI to HDMI cable
A HDMI cable can output both video and audio and enables you to enjoy digital-quality video and audio with
minimal loss of quality.
TVs Input/Source should be set to HDMI 1, 2 or 3.
Option 2 - via Component cable
If you are supplied with a cable from the device which has RED, GREEN, BLUE, RED & WHITE connectors you
must connect via Component (for picture) and by phono cable (for sound). These cables are not supplied with
your TV.
TV Source should be set to Component.
Component (HD)
Component
Green
Blue
Red
A u di o L/ R
White
Red
Audio
In L/R
Ca mer a or
Camcorder
Yellow
White
Red Audio
In L/R
Video
HDMI OUT
HDMI
Connecting a hi- system / sound amplier
3,5mm jack to 2xRCA reduction which is not included in the box enables
you to enjoy better audio with minimal loss of quality.
L
R
3.5mm jack
headphones
output

13
CHANNEL MENU
Auto Tuning - Allows you to retune the television for all digital channels, digital radio stations and analogue
channels.
DTV Manual Tuning- Allows you to manually tune your digital signal
Programme Edit - Allows you to delete, skip, move, rename and add favourite channels.
Signal Information - Allows you to display signal details, including Channel, Quality and Strength.
CI Information - Pay per view services require a“smartcard” to be inserted into the TV.
If you subscribe to a pay per view service the provider will issue you with a‘CAM’ and a “smartcard”. The CAM
can then be inserted into the COMMON INTERFACE PORT (CI Card In).
To access this menu, press [MENU] button on the remote control. To enter a menu press [OK]
If you wish to make changes to any of the default settings, use the scroll buttons. To conrm any
settings press [OK] button.
To exit this menu at anytime, press [EXIT] button.
TV Menu Operation

14
PICTURE MENU
TV Menu Operation
To access this menu, press [MENU] button on the remote control. To enter a menu press [OK]
If you wish to make changes to any of the default settings, use the scroll buttons.
To conrm any settings press [OK] button.
To exit this menu at anytime, press [EXIT] button.
Picture Mode - Choose from the following presets
Standard Default settings
Dynamic Recommended settings for viewing in high ambient light
Mild Set to be lighter in colour and less bright
Personal Lets you manually alter all the settings
Contrast - Switch the balance between black and white
Brightness - Increase or decrease the brightness of the picture
Colour - Increases the colour level
Tint - Lets you increase or decrease the level of tint within the picture. (only in NTSC playback mode)
Sharpness - Increase or decrease the sharpness of the picture
Colour Temperature - Choose from the following presets
Normal Default settings
Warm Increases red within the picture
Cool Increases blue within the picture
Noise Reduction - Choose from the following presets
O Turns noise reduction o
Low Minor system adjustment
Middle Medium system adjustments
High Maximum system adjustments
Default Default settings
Tip: If you do not press any buttons for 10 seconds, the menu will automatically exit. You can change the
length of time before the menu exits automatically - see ‘OSD Timer’in the TIME Menu.
Tip: Only the “Personal”mode allows you to adjust Contrast, Brightness and Colour.

15
SOUND MENU
TV Menu Operation
Treble - To adjust the amount of high frequency within the sound
Bass - To adjust the amount of low frequency within the sound
Balance - To switch the sound between the left and right speakers
Auto Volume - When ‘on’is selected, the volume will stay at a constant level regardless of input/source
AD Switch - Increase or decrease the volume level of the Audio Descriptor when this feature is activated.
Sound Mode - Choose from the following presets
Standard Default settings
Music Emphasises music over voices
Movie Provides live and full sound for movies
Personal Selects your personal sound settings
Sports Emphasises sound for sports
SPDIF Mode - This is the digital COAX Audio output. Choose from the following options:
O O
Auto Selects the best settings automatically
PCM Select this option if you are connecting to a Stereo Hi- via coax cable
(Pulse-code modulation (PCM) is a digital representation of an analogue signal)
To access this menu, press [MENU] button on the remote control. To enter a menu press [OK]
If you wish to make changes to any of the default settings, use the scroll buttons. To conrm any
settings press [OK] button.
To exit this menu at anytime, press [EXIT] button.
Tip: Treble and bass levels can only be adjusted when the sound mode‘Personal’is selected.

16
TIME MENU
TV Menu Operation
To access this menu, press [MENU] button on the remote control. To enter a menu press [OK]
If you wish to make changes to any of the default settings, use the scroll buttons. To conrm any
settings press [OK] button.
To exit this menu at anytime, press [EXIT] button.
Clock - Set the date and time
Time Zone - Change your current time zone
Sleep Timer - Lets you set the sleep timer so the television automatically switches o after a set amount of time.
O -> 10min -> 20min -> 30min -> 60min -> 90min -> 120min -> 180min -> 240min
Auto standby - Toggle the Function between OFF, 3, 4 or 5 hours
OSD Timer - Toggle the Function between 5s, 10s, 15s, 20s, 25s, 30s.
Tip: If you are receiving a Digital TV signal your date and time will be set automatically and this function will
be greyed out.

17 TV Menu Operation
LOCK MENU
To access this menu, press [MENU] button on the remote control. To enter a menu press [OK]
If you wish to make changes to any of the default settings, use the scroll buttons. To conrm any
settings press [OK] button.
To exit this menu at anytime, press [EXIT] button.
Lock System - Allows you to Lock System (Default Password is ‘0000‘.)
Set Password - Allows you to change Password
Block Program - Allows you to sellect the program you want to lock. Then press green button on your remote
control. (To unlock program, input the password you set.))
Parental Guidance - Allows you to change O, 4-18
Key Lock - Allows you to change On, O

18
TV Menu Operation
SETUP MENU
OSD language - Allows you to change the language of the menu
TT language –switches between dierent Teletext font formats
Audio language –Allows you to change Audio language
Subtitle language –Allows you to change Subtitle language
Hearing Impaired – When this option is turned on the TV will select HoH subtitles automatically
PVR File System - Allows you to change PVR File System
Aspect Ratio - Within the UK the picture format varies depending on the channel/broadcast. There are a number
of dierent options to best meet your needs
Blue Screen - Changes the background when there is no input between clear and a blue background (Only
available on some sources)
First Time Installation - Allows you to choose First Time Installation
Reset Reset Menu System - This resets the menus to factory settings.
Reset TV Channels - This clears all the TV channels from the television and the Menu settings.
Software Update (USB) - From time to time we may release new rmware to improve the operation of the
television (available to download). This menu lets you install the new software/rmware onto the television.
Further details of how to do this will be issued with the rmware. Contact the helpline or refer to the‘product
support’ section of the website.
To access this menu, press [MENU] button on the remote control. To enter a menu press [OK]
If you wish to make changes to any of the default settings, use the scroll buttons. To conrm any
settings press [OK] button.
To exit this menu at anytime, press [EXIT] button.
Auto
Automatically displays the best picture format. So the
picture is in the correct position. May have black lines
At the top/bottom and/or sides.
Zoom
Original
16:9
The picture is the
correct proportion
but zoomed in to ll
the screen
Will display the picture from the broadcaster without
any change
4:3 Displays the 4:3 picture
in its original size. Side
bars are shown to ll the
16:9 screen
Top and bottom bars
are shown to ll the 16:9
screen. 4:3 pictures will
be stretched

19
USING THE TELEVISION AS A COMPUTER MONITOR
IMPORTANT – Before connecting the computer to the television you must ensure the computer settings are
correct for the television. You MUST do this using your old monitor.
How to set up for Windows XP, Windows
Vista & Windows 7 (connecting via a VGA
cable to the TV)
1) Switch on your computer
2) When it has nished booting up right click
your mouse anywhere on the screen
3) Left click your mouse on Properties/
Personalise
4) Left click your mouse on Setting/Display
Settings. Ensure the screen resolution
is set to what is shown in the technical
specications section toward the
rear of this user guide. To correct the
resolution to that of the television move the
slider.
5) Left click your mouse on Advance/
Advanced Settings and left click on Monitor
6) Left click on the drop down for Screen
refresh rate and select 60 Hertz, if you
experience picture noise or ‘ickering’, select
50 hertz or 70 hertz.
7) Click on Apply, then click Yes and the
settings will be saved.
8) Now switch o your computer and
connect the
television (as shown)
9) Switch on the TV, select the input/source
to VGA/PC and re-start your PC.
Connecting a Laptop
In addition to the above if you are connecting a laptop to the television you will also need to activate the VGA
connection on the laptop. This can vary based on the brand of laptop you have, on many brands/models, it is as
per below.
1) Connect the laptop to the television
2) On the Laptop push buttons
The screen will now switch to the television.
Windows XP Windows Vista Windows 7
PC Operation

20
PC Operation
PC SETTINGS
To access this menu, press [MENU] button on the remote control. To enter a menu press [OK]
If you wish to make changes to any of the default settings, use the scroll buttons. To conrm any
settings press [OK] button.
To exit this menu at anytime, press [EXIT] button.
Auto Adjust - Lets you automatically congure the television to be used as a computer monitor. It is
recommended that you use this feature rst as in most cases it will correctly align the picture.
H Oset - Changes the horizontal position of the picture
V Oset - Changes the vertical position of the picture
Size - Increases the picture size
Phase - To adjust the phase delay time to reduce the noise present in the display
Position Reset - Changes back to the original settings
Tip: If the computer is left in-active for a period of time, the television will switch into a ‘sleep’ state (the
screen will power o to save power). To switch back on press the standby button.
